Page 24 of 400
22
Monitoring
308_EN_CHAP01_CONTROLE DE MARCHE_ED02-2013
Engine autodiagnosis system
flashing. The engine management system has a fault. Risk of destruction of the catalytic converter. Have it checked by a PEUGEOT dealer or a qualified workshop.
fixed. The emission control system has a fault. The warning lamp should go off when the engine is started. If it does not go off, contact a PEUGEOT dealer or qualified workshop without delay.
Emergency Collision Braking System
flashing. The Emergency Collision Braking System is active. The system brakes briefly so as to reduce the speed of collision with the vehicle ahead.
fixed, accompanied by a mesage and an audible signal
The Emergency Collision Braking System has a fault. Have it checked by a PEUGEOT dealer or a qualified workshop.
fixed. The Emergency Collision Braking System has been deactivated (via the menu).
Warning / indicator lampStateCauseAction / Observations
Low fuel level fixed, with the needle in the red zone. When it first comes on there remains less than 10 litres of less than 10 litres of less than 10 litres offuel in the tank.
You must refuel as soon as possible to avoid running out of fuel. This warning lamp will come on every time the ignition is switched on, until a sufficient addition of fuel is made. Fuel tank capacity: approximately 53 litres or 45 litres depending on version. Never continue to drive until you run out of fuel as this could damage the emission control and injection systems.
