Peugeot 308 SW BL 2012.5 Owner's Manual - RHD (UK, Australia)

This personal space offers advice and other useful information for
the care and maintenance of your vehicle.

You can find your user guide on the PEUGEOT website, under theheading "Personal space".

Referring to the user guide on-line also gives you access to thelatest information available, easily identified by the bookmarks, associated with this pictogram:
If the heading "Personal space" is not available on the public websitefor your country, you can find your user guide at the following address:http://public.servicebox.peugeot.com

the link in "Private customer access",
the language,
the model,
the edition date appropriate for the date of registration of your vehicle.
Please note the following point:
The fitting of electrical equipment or accessories which are not recommended by PEUGEOT may result in a failure of your vehicle's electronic system. Please note this specific warning.It is advisable to contact a PEUGEOT dealer to be shown the recommended equipment and accessories.
Select:
You will find your user guide, presented in the same way as the paper version.

!
i
1
Thank you for choosing a 308, symbol
of confi dence, passion and inspiration.

Page reference:
this symbol invites you to refer to
the pages which provide details of
the function.


Key


Protection of the environment:
this symbol accompanies advice
relating to protection of the envi-
ronment.
Information:
this symbol draws your attention
to additional information for better
use of your vehicle.
Warning:
this symbol marks warnings which
it is essential to observe for your
own safety, for the safety of others
or to avoid any risk of damaging
your vehicle. Your vehicle is fi tted with only some of the
equipment described in this document,
depending on its trim level, version and
the specifi cation for the country in which
it was sold.
WELCOME

This handbook has been designed to
enable you to make the most of your
308 saloon or 308 SW.
On the fi rst few pages, you will fi nd a
detailed summary, followed by a quick
reference guide intended to make it
easier for you to become familiar with
your vehicle.
All of the details specifi c to your 308,
comfort, safety, driving, are then pre-
sented in this handbook, to increase
your appreciation of the vehicle and
make the most of it. 308 saloon
308 SW with bench rear
seat
308 SW with individual rear
seats At the end of the handbook, a visual
search enables you to identify the spe-
cial features in relation to the outline
illustration of your vehicle, saloon or SW.


Key

This key will enable you to distinguish
the special features of your vehicle:

2
CONTENTS
Instrument panels 25
Warning and indicator lamps 29
Indicators 39
Instrument panel buttons 43Ventilation 61
Heating 63
Manual air conditioning 63
Rear screen demist - defrost 65
Dual-zone digital air conditioning 66
Front seats 68
Rear seats 72
Seat modularity 78
Mirrors 80
Steering wheel adjustment 82
COMFORT 61 Î 82
Remote control key 83
Alarm 87
Electric windows 89
Doors 91
Boot 94
Panoramic sunroof 95
Fuel tank 96
Misfuel prevention (Diesel) 97
ACCESS 83 Î 98
Lighting controls 99
LED lamps 101
Daytime running lamps 101
Headlamp adjustment 103
Directional lighting 104
Wiper controls 105
Automatic rain sensitive wipers 107
Courtesy lamps 108
Interior mood lighting 109
Boot lamp 109
VISIBILITY 99 Î 109
Child seats 125
ISOFIX child seats 131
Child lock 136
CHILD
SAFETY 125 Î 136 FAMILIARISATION 4 Î 22
INSTRUMENTS and
CONTROLS 25 Î 44
Screens without audio equipment 45
Screens with audio equipment 47
Retractable colour screen (Peugeot
Connect Navigation (RT6)) 52
Retractable colour screen (Peugeot
Connect Media Navigation
(NG4 3D)) 54
Trip computer 57
MULTIFUNCTION
SCREENS 45 Î 60
Interior fi ttings 110
Front armrest 113
Boot fi ttings 116
FITTINGS 110 Î 124
7
5
4
3
26
ECO-DRIVING 23 Î 24

3
CONTENTS
Direction indicators 137
Hazard warning lamps 137
Horn 137
Tyre under-infl ation detection 138
Emergency or assistance call 139
Braking assistance systems 139
Trajectory control systems 140
Front seat belts 141
Airbags 146
SAFETY 137 Î 149
Parking brake 150
Manual gearbox 150
Gear shift indicator 151
Hill start assist 152
6-speed electronic gear control
gearbox 153
Automatic gearbox 157
Stop & Start 160
Speed limiter 163
Cruise control 165
Parking sensors 167
DRIVING 150 Î 168
Bonnet 170
Running out of fuel (Diesel) 171
Petrol engines 172
Diesel engines 173
Checking levels 174
Checks 176
CHECKS 169 Î 177
Temporary puncture repair kit 178
Changing a wheel 187
Changing a bulb 194
Changing a fuse 201
Battery 207
Energy economy mode 210
Changing a wiper blade 211
Towing the vehicle 211
Towing a trailer 214
Very cold climate screen 215
Fitting roof bars 216
Accessories 217
PRACTICAL
INFORMATION 178 Î 218
Petrol engines 219
Petrol weights 222
Diesel engines 228
Diesel weights 231
Dimensions 240
Identifi cation markings 241
TECHNICAL
DATA 219 Î 242
AUDIO EQUIPMENT
and TELEMATICS 243 Î 364
VISUAL SEARCH 365 Î 371
ALPHABETICAL
INDEX 372 Î 376
Emergency or assistance 243
Peugeot Connect Media
Navigation (NG4 3D) 247
Peugeot Connect Navigation (RT6) 291
Peugeot Connect Sound (RD5) 345
8
9
10
11
12

4
FAMILIARISATION
EXTERIOR


Stop & Start system
This system puts the engine temporarily into
standby during stops in the traffi c (red lights,
traffi c jams, etc....). The engine restarts
automatically as soon as you want to move
off. The Stop & Start system reduces fuel
consumption, exhaust emissions and the
noise level when stationary.



160


Directional lighting
This lighting automatically provides
additional visibility when cornering.



104

Panoramic sunroof
This roof provides incomparable
visibility and light in the passenger
compartment.



95


Temporary puncture repair kit
This kit is a complete system,
consisting of a compressor and a
sealant cartridge, for the temporary
repair of a tyre.



178

5
FAMILIARISATION
EXTERIOR


Panoramic sunroof
This roof provides incomparable
visibility and light in the passenger
compartment.



216

Roof bars
Transverse bars fi tted on the longitudinal
bars, these permit the loading of long
and bulky objects on the roof.



95


Seat modularity
The 2nd and 3rd row individual rear
seats can be arranged in various ways
to provide different layout and loading
confi gurations.



78

6
FAMILIARISATION
ACCESS

Remote control key


A.
Unfolding / Folding the key
(press this button fi rst).
Normal locking
(press once; fi xed lighting of
the direction indicators).

Fuel tank



1.
Opening the fuel fi ller fl ap.

2.
Opening and hooking the fuel fi ller
cap. Unlocking the vehicle
(rapid fl ashing of the direction
indicators).
In the same way, the passenger
compartment lighting, such as the
courtesy lamps, the front door sill lamps
and the footwell lamps, comes on. or
Deadlocking the vehicle
(press twice in succession;
fi xed lighting of the direction
indicators).



83


109



96
Capacity of the tank: approximately
60 litres.


103 When a sensor detects a low level of
light, remote switching on of the dipped
beam headlamps and sidelamps makes
your approach to the vehicle easier.

7
FAMILIARISATION
ACCESS

Panoramic sunroof
Boot




95


1.
Opening the blind.

2.
Closing the blind.

1.
Unlocking the vehicle.

2.
Opening the boot.



94

8
FAMILIARISATION
INTERIOR


Interior mood lighting
This dimmed lighting of the passenger
compartment improves visibility inside
the vehicle when the light is poor.



109


6-speed electronic gear control
gearbox
This system provides a fully automatic
driving mode and a manual mode.



153

Audio and communication systems
This equipment benefi ts from the latest
technology: MP3 compatible Peugeot
Connect Sound (RD5), Bluetooth,
Peugeot Connect Navigation (RT6) or
Peugeot Connect Media Navigation
(NG4 3D) with 16/9 retractable colour
screen, auxiliary sockets.

Peugeot Connect Sound (RD5)




345

Peugeot Connect Navigation (RT6)




291

Peugeot Connect Media Navigation
(NG4 3D)




247
