display Peugeot 406 2002.5 Owner's Guide

RDS
Using the RDS (Radio Data System) function on FMRadio Data System allows you to continue listening to the sa me station, whatever frequency it is using for
the region you are going through.
Briefly press the " RDS" button to switch the function on or off; the display wil l show:
"RDS" if the function is selected.
"(RDS)" if the function is selected but not available.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best
reception and which is transmitting the same programme.
Traffic information programme
Press the "TA"button to switch the function on or off.
The display will show: "TA" if the function is selected,
" (TA) " if the function is selected but not available.
Any traffic information flash will be given priority, whatever source you are listening to (radio, CD or CD changer).
If you wish to interrupt a message, press the "TA"button; this switches the function off.
Note: the volume of traffic information announcements is inde pendent of the volume of normal radio listening. You
can adjust it using the volume button. The setting will be stored and will be used when the next messages are broad
cast.
Regional following mode
When they are part of a network, certain stations broadcast regi onal programmes in the various areas they
serve.
With regional following mode you can keep listening to th e same programme.
Press the " RDS" button for more than two seconds to switch the function on or off.
YOUR 406 IN DETAIL
90
29-07-2002

PTY functionThis allows you to listen to stations broadcasting a specific t ype of programme (news, culture, sport, rock etc.)
With FM selected, press the "TA"button for two seconds to switch this function on or off.
To search for a PTYprogramme:
select the PTYfunction,
briefly press button Kor Lto scroll down the list of the various types of pro
grammes offered.
when the programme of your choice is displayed, keep button Kor Lpressed for two seconds to carry out an automatic
search (after an automatic search the PTYfunction is switched off).
In PTY mode the different types of programmes can be stored in the
memory. To do this, press the preselection buttons " 1" to " 6" for more
than two seconds. To recall the type of programme stored in the
memory, briefly press the corresponding button.
EON system
This connects stations which are part of the same network. It en ables the broadcast of traffic information by a station, which
is part of the same network as the station to which you are li stening.
This service is available when you have selected the TA traffic i nformation programme or the PTYfunction.
YOUR 406 IN DETAIL 91
29-07-2002

29-07-2002
THE SATELLITE NAVIGATION
SYSTEM
Introduction
The satellite navigation system guides
you to the destination of your choice
by means of vocal and visual instruc
tions.
The heart of the system lies in the use
of a map database and GPS (Global
Positioning System). This enables
your position to be located by means
of several satellites.
The satellite navigation system con
sists of the following components:
the remote control,
the display,
the control unit,
the last voice message recall control,
the CD ROM.
Some functions or services
described in this guide may vary depending on the CD ROM version or the country.The remote control
There is a storage compartment for the remote control in front of the ashtray.
Pointing the remote control at the screen enables the informat ion contained in
the various menus to be selected.
Direction arrows:
These enable you to move around the screen and
thus select a function.
On the welcome screen only, the Up and Down
buttons enable the brightness of the screen to be
adjusted.
menu : this button allows access to the main menu. It can
be used at any time.
esc : escape button
"Short press": cancels the current operation and
returns to the previous screen.
"Press for more than 2 seconds": returns to the
welcome screen.
This button can be used in any menu. It is inactive
during guidance.
mod : mode button
"Short press": changes between date, navigation
and radio.
val : Confirmation button
Confirms the function selected.
YOUR 406 IN DETAIL 95

29-07-2002
The display
When the menus are used, the functions which appear at
the bottom of the screen are presented in various ways:
1.Function selected.
2. Function inaccessible in this situation.
3. Function accessible.
Note: The "List" function can hold a maximum of
80 addresses. During guidance the screen displays different information
depending on the manoeuvres to be carried out:
1.
Distance to next manoeuvre.
2. Next manoeuvre to be carried out.
3. Next road to take.
4. Time.
5. Exterior temperature.
6. Current road.
7. Distance to final destination.
8. Manoeuvre to be carried out.
YOUR 406 IN DETAIL
96
12
875
3
12364

29-07-2002
Main menu
Switch on the ignition.
Press the "Menu"button to access the main menu.
Select a function using the direction arrows, then confirm ( "VAL" button). The
"Navigation/guidance" menu offers various options
for selecting guidance:
By entering the address of a new destination.
By selecting a service (Hotel, station, airport...) available in a town.
By selecting an address stored in one of the two directo ries.
By resuming previously interrupted guidance or by stop ping current guidance. Two messages may be displayed
depending on the previous actions: "Resume guid
ance" or "Stop guidance" .
Radio functions are suspended when the system is in guidance mode.
YOUR 406 IN DETAIL
98
Navigation / Guidance
Following selection of the "Navigation/guidance"menu,
a screen warns you about the use of the navigation sys
tem. Follow the regulations in force and do not use the
remote control while driving.
Press the "VAL"button to access the next screen.

29-07-2002
Entering a new destination
The last town entered is displayed.
To enter the name of another town, select each letter using
the direction arrows then confirm ("VAL"button) for each
letter.
If an error is made, the "Correct" function enables the last
letter entered to be deleted.
As the name is entered, the "List"function indicates the
number of towns beginning with the same letters. If the li st
contains less than 5 names, these are displayed automat
ically. Select a town then confirm ( "VAL"button).
The "Change" function enables the town entered to be
completely cleared.
When the complete name of the town is displayed, select
the "Validate" function then press the "VAL"button.
Note: following confirmation of a letter, only those letters
which could make up an existing name appear. Enter the name of the street. Select the
"Validate"function
then press the "VAL"button.
Note: the guidance can be activated from the time the
town is entered, without the name of a street or a number.
To do this, select the "Town centre"function.
YOUR 406 IN DETAIL 99
Enter the number in the street. Select the "Validate"func
tion then press the "VAL"button.
Note: the guidance can be activated as soon as the town
and street are entered, without a number. To do this, sele ct
the "Validate" function.

29-07-2002
YOUR 406 IN DETAIL
100
The complete destination is displayed. Select the "Vali
date" function then press the "VAL"button.
Note: you can also change the destination or store it in one
of the two directories (see the section on storing an
address in a directory).
The last guidance criterion used is displayed.
Guidance begins automatically, retaining this criterion if
there is no action within 5 seconds or following confirma
tion of the "NO"function.
Follow the instructions.
If you wish to change the guidance criterion, select the
"YES" function then press the "VAL"button. Select a criterion from the list offered then confirm (
"VAL"
button). When the criterion of your choice is selected,
select the "Validate" function then press the "VAL"button.
Guidance begins, follow the instructions.

29-07-2002
YOUR 406 IN DETAIL101
Selecting a service
The last address entered is displayed.
There are 3 options for defining the location in which you
wish to obtain this service:
repeat the last address entered by means of the "Vali
date" function.
enter the name of a new town then enter the street (or use the "Town centre" function) by means of the
"Change" function.
automatically enter your current location by using the "current location" function.
After confirming the address, select a service by scrolling
through the list using the direction arrows then press the
"VAL" button.
A cursor on the lefthand side of the screen indicates your
position in the list. The address of the required service is displayed.
An indication on the righthand side of the screen (e.g.
1/50) indicates whether there are any other establishments
(50 maximum) which offer the same service within a radius
of approximately 30 miles (50 km), as the crow flies.
Use the
"Next"or "Previous" functions to consult the list
offered.
When the establishment of your choice is displayed, select
the "Validate" function then press the "VAL"button.
Select a guidance criterion. Guidance begins, follow the
instructions.

29-07-2002
Selecting a stored destination
Using the direction arrows, select the directory in which the
address you are looking for is stored, then press the "VAL"
button.
The stored addresses are displayed.
A cursor on the lefthand side of the screen indicates your
position in the list. Select a name by scrolling through the
list using the direction arrows, then press the "Val"button.
The complete address is displayed. Select the "Validate"
function then press the "Val"button. Select a guidance cri
terion. Guidance begins, follow the instructions.
YOUR 406 IN DETAIL
102
Storing an address in a directory
When a new address is entered, you can store it by select
ing the "Store" function.
Enter the name for the address. If the name already exists
for a different address, you can replace the old address
with a new one.
Select the Personal directory or the Professional directory
then press the "VAL"button. The address is then stored in
the directory of your choice.

29-07-2002
YOUR 406 IN DETAIL103
Display configuration
From the general menu, the "Configure display"menu
gives access to the following parameters:
Adjustment of the brightness and the video display.
Adjustment of the date and time.
Selection of the language of the display and voice infor mation (English, German, Spanish, French, Italian).
Adjustment of the mode and units. This allows selection of the display in km/h or mph, in degrees Celsius or
Fahrenheit and selection of the time format (12 or 24
hour mode). Navigation options
From the main menu, the
"Navigation options"menu
gives access to the following parameters:
Management of the directories. It enables an address stored under a name to be renamed or deleted. To do
this, select the directory and the name to be changed.
Voice synthesis volume adjustment.
Deletion of all data stored in the two directories.
