RDS Using the RDS (Radio Data System) function on FMRadio Data System allows you to continue listening to the same station, whatever frequency it is using for the region you are going through. Briefly press the " RDS" button to switch the function on or off.
The display will show: - "RDS" if the function is selected.
- "(RDS)" if the function is selected but not available.
RDS station following
The display indicates the name of the station selected. The radio is continually searching for the station which has the best reception and which is transmitting the same programme.
Traffic information programme Press the "TA" button to switch the function on or off.
The display will show: -" TA " if the function is selected,
-" (TA) " if the function is selected but not available.
Any traffic information flash will be given priority, whatever source is in use (radio, cassette or CD changer). If you wish to interrupt a message, press the " TA" button; this switches the function off.
Note: the volume of traffic information announcements is independent of the volume of normal radio listening. You can adjust it using the volume button. The setting will be stored and will be used when the next messages are broad-cast.
YOUR 406 COUPE IN DETAIL
58
01-07-2002

Regional following modeWhen they are part of a network, certain stations broadcast regional programmes in the various areas they serve. With regional following mode you can keep listening to the same programme. Press the "RDS" button for more than two seconds to switch the function on or off.
PTY function This allows you to listen to stations broadcasting a specific type of programme (news, culture, sport, rock etc.). With FM selected, press the " TA" button for two seconds to switch this function on or off.
To search for a PTYprogramme:
- select the PTYfunction,
- briefly press button Kor Mto scroll down the list of the various types of pro-
grammes offered.
- when the programme of your choice is displayed, keep one of the buttons Kor Mpressed for two seconds to carry out an
automatic search (after an automatic search the PTYfunction is switched off).
In PTY mode, the different types of programmes can be stored in the
memory. To do this, press the preselection buttons 1to 6for more
than two seconds. To recall the type of programme stored in the
memory, briefly press the corresponding button.
EON system
This connects stations which are part of the same network. It allows the broadcast of traffic information, by a station that is part of the same network as the station to which you are listening.
This service is available when you have selected the TA traffic information programme or the PTYfunction.
YOUR 406 COUPE IN DETAIL 59
01-07-2002

CASSETTE Selecting cassette modeWhen a cassette is inserted, the cassette player will start automatically. If a cassette is already inserted, press button C.
Ejecting the cassette Press button Eto eject the cassette from the player.
Direction of play
The player will play sides 1 and 2 of the cassette alternately, by automatically reversing the direction of play at the end of a
side. To manually reverse the direction of play, press button C.
Selecting a track on a cassette (blank search) Press button Kto select the following track.
Press button Mto return to the start of the current track or to select the previous
track.
Fast forward/rewindPress and hold button Kor Mto fast forward or rewind the cassette. At the end of the fast forward/rewind, the set plays the
current side. Noise reduction (Dolby B NR system) Press button Cfor more than two seconds to switch the function on or off.
Dolby noise reduction manufactured under licence from Dolby Laboratories Licensing Corporation "Dolby" and the double D symbol are trade marks of Dolby Laboratories Licensing Corporation. Recommendations for the use of cassettes
- Use good quality cassettes.
- Avoid using cassettes of a duration of more than 90 minutes.
- Never expose the cassettes to heat or direct sunlight.
- If necessary, tighten the tape before inserting the cassette into the player.
- Clean the play heads regularly using a damp-type cleaning cassette.
YOUR 406 COUPE IN DETAIL
60
01-07-2002

CD CHANGER Selecting CD changer modePress button D.
Selecting a disc Press one of the buttons 1to 6to select the corresponding disc.
Selecting a track Press button Kto select the following track.
Press button Mto return to the start of the current track or to select the previous
track.
Accelerated playPress and hold button Kor Mfor forwards or backwards accelerated play.
Accelerated play stops as soon as the button is released. Shuffle
When the CD changer is selected, keep button Dpressed for two seconds. The tracks will be played in ran-
dom sequence. Pressing button D again for two seconds returns you to normal play.
YOUR 406 COUPE IN DETAIL 61
01-07-2002

YOUR 406 COUPE IN DETAIL
62
This is located inside the boot on the left hand side. It holds up to 6 discs.
To insert a disc into the changer:
- open sliding panel A,
- press button Bto eject the cartridge C,
- open one of the six compartments of the cartridge by pulling tab D,
- insert the disc with the printed face upwards and close the compartment,
- insert the cartridge into the changer,
- close the sliding panel A.
RM2 CD CHANGER
The use of copied compact discs can cause malfunctions.
01-07-2002

AUDIO SYSTEM (RM2) Presentation
Your 406 CoupŽ is fitted with a JBL Audio Hi-Fi system, designed specifically for the vehicle's passenger compartment.
At the heart of the system, a 240 Watt multifunction amplifier (1), located in the boot, independently controls 10 high acoustic definition speakers. These speakers make it possible to obtain optimum reproduction and distribution of the sound in the vehicle, in the
front and in the rear. The speakers are located:
- in the fascia: two Micro Tweeters (3) fitted in two Mediums (4) for clear and head-on reproduction of the sound, favour-
ing listening in the front.
- in the front doors: two Woofers (5)for reproduction of the bass (low frequencies) in the front.
- in the passenger pillars: two Tweeters (2)for reproduction of the treble (high frequencies) in the rear.
- on the rear shelf: two Subwoofers (6)for reproduction of the extreme bass sounds (low and very low frequencies) through-
out the passenger compartment; you will appreciate the impact and depth, noticing that the sound fills the vehicle
perfectly.
Adjustment in CD mode The basic functions remain those of the audio equipment.
No additional adjustment is required. However, to benefit fully from your
JBL audio system, you are advised to adjust the AUDIO functions (BASS,
TREB, FAD, BAL) to position " 0 " (zero) and the Loudness (LOUD)to the
" ON " position.
YOUR 406 COUPE IN DETAIL 63
01-07-2002

YOUR 406 COUPE IN DETAIL
64
Stalk movement Function
1
Ð Press (behind) Increase volume.
2Ð Press (behind) Decrease volume.
1+2 Ð Simultaneous pressCutting off of the sound (mute); restoring of the sound by pressing any button.
3Ð Press Automatic search of upper frequencies (radio) -
Selection of the following track (CD).
4Ð Press utomatic search of lower frequencies (radio) -
Selection of the previous track (CD).
5Ð Press the end Change of source (radio/CD changer).
6Ð Rotation Selection of next memorised station (radio) -
(clockwise) Selection of following CD.
7Ð Rotation Selection of previous memorised station (radio) -
(anti-clockwise) Selection of previous CD.
AUDIO RD3
01-07-2002

ButtonFunction
A ON/VOLRadio On/Off. Volume adjustment.
BRadio selection. Selection of FM1, FM2, FMast and AM wavebands. Press for more than 2 seconds: automatic storing of stations in the memory (autostore).
CCD selection.
Press for more than 2 seconds: shuffle.
DCD changer selection.
Press for more than 2 seconds: shuffle.
EEjection of the CD.
FT ATraffic information priority on/off.
Press for more than 2 seconds: PTY function on/off.
G RDSRDS function on/off.
Press for more than 2 seconds: regional following mode on/off.
HIncrease bass/treble setting.
IDecrease bass/treble setting.
J AUDIOSelection of bass, treble, loudness, sound distribution and automatic volume correction.
K kkkkAutomatic search of higher frequency. Selection of following CD track.
L MANManual/automatic operation of buttons
K and M in radio mode.
M jjjjAutomatic search of lower frequency. Selection of previous CD track.
1 to 6 12 34 56Selection of station stored in the memory.
Press for more than 2 seconds: storing of a station in the memory.
Selection of a disc in the CD changer.
YOUR 406 COUPE IN DETAIL 65
01-07-2002

GENERAL FUNCTIONS On/offWith the ignition key in the ACCESSORIES or IGNITION position, press button Ato switch the set on or
off.The set can operate for 30 minutes without the vehicle ignition being switched on.
ANTI-THEFT SYSTEMThe audio system is coded in such a way that it can operate only on your vehicle. It would not function if fitted to another vehicle. The anti-theft system is automatic and requires no action on your part. ADJUSTING THE VOLUME Turn button Ato increase or decrease the volume of the set.
Note: If you have a telephone fitted with a "mute"signal output connected to the set, the set will automatically
change to "mute"when the telephone is used.
AUDIO SETTINGS Press the "AUDIO" button several times in succession to access the bass (BASS), treble(TREB), loudness
(LOUD), fader(FAD) , balance (BAL)and the automatic volume correction.
Exit from audio mode is automatic after a few seconds without pressing any button, or by pressing the " AUDIO " button after configuration of the automatic volume correction.
Note: the bass and treble settings are specific to each source. It is possible to set them differently for radio,
CD, or CD changer.
YOUR 406 COUPE IN DETAIL
66
01-07-2002

Adjusting the bassWhen "BASS" is displayed, press button Hor Ito vary the setting.
- "BASS Ð9" for a minimum bass setting,
- "BASS 0" for a normal setting,
- "BASS +9" for a maximum bass setting.
Adjusting the treble When " TREB" is displayed, press button H or Ito vary the setting.
- "TREB Ð9" for a minimum treble setting,
- "TREB 0" for a normal setting,
- "TREB +9" for a maximum treble setting.
Adjusting the loudness
This function automatically emphasises bass and treble tones when the volume is low.Press button Hor Ito switch the function on or off.
Adjusting the front/rear sound distribution (Fader)When " FA D" is displayed, press button Hor Ito vary the setting
Button Hincreases the volume in the front.
Button Iincreases the volume in the rear.
Adjusting the right/left sound distribution (Balance)When " BAL" is displayed, press button H or Ito vary the setting.
Button Hincreases the volume on the right-hand side.
Button Iincreases the volume on the left-hand side.
Automatic Volume Correction This function enables the volume to be adjusted automatically according to the level of noise produced by the speed of the vehi cle.
Press buttons H or Ito switch the function on or off.
YOUR 406 COUPE IN DETAIL 67
