Peugeot 607 Dag 2002 Owner's Manual

YOUR AT A GLANCE2

3YOUR AT A GLANCE
1Lights and direction indica
tors stalk.
2 Steering wheel adjustment.
3 Driver's front air bag.
Horn.
4 Instrument dials.
5 Windscreen wash/wipe
stalk.
Trip computer stalk.
6 Audio remote control stalk.
7 Hazard warning lights
switch.
8 Central adjustable
heating/ventilation vents and
air flow regulation.
9 Sunshine / brightness
sensor.
10 Windscreen demisting
vents.
11 Passenger air bag.
12 Glove compartment.
13 Side adjustable heating/ven
tilation vents and air flow
regulation. 14
Door window demisting
vent.
15 Passenger air bag disarming
switch.
16 Front seats heating switch.
17 Rear ashtray.
Rear lighter.
Rear seats heating switch.
18 Rear footwell heating vent.
19 Twoposition armrest with
compartments.
20 Handbrake.
21 Electronically controlled sus
pension switch.
Doors and boot locking
switch.
Sunroof switch.
Rear blind switch.
22 Front ashtray.
Front lighter.
23 Gear lever.
24 RM2 audio system or RT2
audio/telephone system with
PEUGEOT call button. 25
Heating/ventilation controls.
26 Multifunction display.
27 Steering lock and ignition.
28 Fuse box.
29 Speakers location.
30 Electric mirror controls.
Window controls.
Rear window locking control.
31 Headlamp height adjust
ment.
32 ESP disarming switch.
33 Alarm button.
34 Cruise control.
35 Memory buttons for:
Front seat settings
Electric mirror settings

YOUR AT A GLANCE4
THE REMOTE CONTROL
KEY
From the driver's door, the key
allows you to lock or unlock the
doors, the boot and the fuel filler
flap, as well as to fold back or
open out the exterior mirrors.
The remote control in the key
provides the same function at a
distance.
Locking with the remote
control  Press button A.
This is confirmed by fixed lighting
of the direction indicators for
approximately two seconds.
Unlocking with the remote
control key  Press button B.
This is confirmed by rapid flash
ing of the direction indicators. With the vehicle unlocked, the
boot is opened using the push
button located on the right rear
side, in the '
zero' of the 607
badge.
Opening the boot with the
remote control key  Keep button Cpressed.
Key in ignition
If you leave the key in the
ignition, this is indicated by a
buzzer upon opening the
driver's door.
Locating the vehicle
To locate your vehicle in a car
park, press button A; the cour
tesy lights come on and the
direction indicators flash for
approximately twenty seconds.
Driving position memorised
by the remote control key
When locking the doors, the
remote control key memorises
the position of the driver's seat
and the driving mirrors.
Each remote control key mem
orises a specific setting.
When unlocking the doors, the
driver's seat and the driving mir
rors assume the position memo
rised by the remote control key, if
this position has been changed in
the meantime. Note:
do not press the buttons of
your remote control key out of
range of your vehicle as there is
a risk that you could render it
inoperative. It would then be nec
essary to reprogramme it.
Deadlocking
This renders the internal and
external door locking controls
inoperative and permits the auto
matic closing of the windows and
the sunroof.
With the key: lock the vehicle and keep the
key in the locked position for
approximately one second.
With the remote control:  press button Ato lock the
vehicle (the direction indicator
lights remain on for approxi
mately two seconds),
 within five seconds, press but
ton Aagain to deadlock the
vehicle (the direction indicator
lights remain on for approxi
mately two seconds).
101

YOUR AT A GLANCE5
STARTING
STOP position:
The ignition is switched off.
1st notch, Accessories position:The ignition is switched off but
the accessories still function.
2nd notch, Running position:
The ignition is on.
Starting position:
Operates the starter.
Starting a diesel engineIf the temperature is highenough, the preheat
indicator light does not
come on and you can
start immediately.
If the indicator light comes on,
wait for it to go out before operat
ing the starter.
If the engine stalls, it is neces
sary to return the key to the
'Stop' position before restarting. CHECK
(vehicle autotest)
Automatic check
With the ignition on (2nd notch)
If no malfunction has been
detected: In the absence of
vehicle function status indi
cator lights, the OK light is
displayed after two seconds
on the instrument panel screen.
Otherwise, it will be displayed after
these indicator lights come on.
If a 'minor' malfunction has been
detected: the warning light for the
faulty function is displayed on the
instrument panel screen. Certain
indicator lights showing the status of
vehicle functions may also come on,
followed by the OKindicator light.
If a 'major' malfunction has been
detected: the corresponding warn
ing light is displayed on the instru
ment panel screen. Certain indicator
lights showing the status of vehicle
functions may also come on. The
OK indicator light does not come
on. Do not start your vehicle.
Contact a PEUGEOT dealer.
Afterwards, if the passenger air
bag is disarmed, the correspond
ing warning light will come on.
With the engine running or if the
vehicle is moving, the instrument
panel screen temporarily displays:
– lights indicating warnings, when
these occur,
– vehicle function sta tus indicator lights,
when a change
occurs.
The display of certain indicator
lights is accompanied by an audi
ble signal and a message on the
multifunction display.
MANUAL CHECK  Press the "CHECK" button on the
instrument panel.
With the ignition key in the accessories
position, with the ignition switched on,
with the engine running or the vehicle
moving, this function informs you at all
times of the following:
– any current warnings,
– the status of functions which it is possible to switch on or switch off
(windscreen wipers, automatic
switching on of lights, cruise con
trol, disarming of passenger air
bag, etc.).
The corresponding warning lights are
displayed in succession on the instru
ment panel screen.
If a warning or a change of status
occurs during the CHECKmode, the
corresponding indicator light(s) will be
displayed at the end of this mode.
Never run the engine in
a confined space.
Do not make any modi fications to the steering
lock.
31

YOUR AT A GLANCE6
STEERING WHEEL
STALKS
LIGHTS
Front and rear lights (ring A)Lights off.
Side lights.Dipped / main
beam headlamps. Front and rear fog lamps
(ring B)
Front fog lamps.Neutral position of the
ring.
Rear fog lamps.
Parking lights
To switch on the parking lights on
the traffic side, with the engine
off, place the direction indicator
lights stalk on the traffic side.
Automatic switching on of lights
This occurs if the light is poor, as well as in cases of contin uous operation
of the windscreen wipers, and stops as soon as the light has b ecome
bright enough or the windscreen wipers have stopped.
 To activate or disarm the function, place the key in the accessori es
position (1st notch), place the lights stalk in position 0and press the
end of the stalk for more than two seconds.
Do not cover the sunshine / brightness sensor located i n
the centre of the fascia. It helps to regulate the air condi
tioning, the automatic switching on of the lights and the
automatic adjustment of the instrument panel bright
ness. WINDSCREEN WIPERS
3
Rapid wipe
2 Normal wipe
1 Automatic wipe
0 Off
Automatic wipe
In position 1, the wipers operate
automatically and adjust their
speed to the intensity of the rain
fall.
When the ignition has been
switched off for more than one
minute with the control in a
wipe position, it is necessary
to reactivate this function.
To do this, move the control to
any position, then return to the
required position.
10811 0

YOUR AT A GLANCE8
THE SEATS
Manual front seats
1 Forwardsbackwards adjustment.
2 Seat angle adjustment*.
3 Seat height adjustment*.
4 Seat back angle adjustment.
5 Lumbar adjustment*.
6 Head restraint height and tilt adjust
ment (press the tab to slide it down).
* Driver's seat only.
Electric front seats
A Forwardsbackwards adjust
ment.
B Seat angle adjustment.
C Seat height adjustment
D Seat back angle adjustment.
E Lumbar adjustment.
F Head restraint height adjust
ment.
M Memorises settings.
 Switch on the ignition and
adjust the seat and the mirrors.
 Press button 'M'then within 4
seconds either button '1'for
the first position, or button '2'
for the second position.
1 Recalls the first position.
2 Recalls the
second position.
94
93

CRUISE CONTROL
Cruise control enables the vehi
cle to maintain a steady speed
programmed by the driver, with
out the accelerator being
pressed.
In order for it to be memorised,
the speed of the vehicle must be
greater than 25mph (40km/h) or
40mph (60km/h) depending on
engine.
OperationPlace the ring of stalk
A in the ONposition. The
indicator light comes on,
accompanied by an audi
ble signal. FRONT AIR BAGS
Disarming the passenger air
bag*
with the ignition off, insert the
key into slot
1and turn it:
–to the 'ON'position, the pas
senger air bag is armed,
–to the 'OFF'position, the pas
senger air bag is disarmed.
Operating check When the passenger air
bag is disarmed, the
warning light comes on
when the ignition is
switched on (2nd notch),
accompanied by an audible sig
nal and the message 'Passenger
air bag disarmed' . Front air bag faulty
If this warning light
comes on, accompanied
by an audible signal and
the message 'Air bag
faulty' , contact a PEUGEOT
dealer to have the system
checked.
Passenger air bag
precautions
 Disarm the
air bag if you
install a rear
facing child
seat.  Arm the air
bag for an
adult passen
ger.
Never place your feet or any
object on the fascia.
* According to country
YOUR AT A GLANCE11
127129

YOUR AT A GLANCE7
ELECTRIC WINDOWS
1 Driver's electric window.
2 Passenger's electric window.
3 Rear right electric window.
4 Rear left electric window.
5 Disarming the rear window controls.
Manual mode: Press or pull the switch lightly. The window stops as soon as th e switch
is released.
Automatic mode: Press or pull the switch firmly. One touch completely opens or close s
the window.
Safety autoreverse: when the glass rises and meets an
obstacle, it stops and lowers again.
ELECTRIC REAR VIEW MIRRORS  Turn knob 6to the right or to the left to select the corre
sponding mirror.
 Move the knob in all four directions to adjust.
When parked, the mirrors can be folded back manually, electrically by
means of button 6or automatically on locking the vehicle. STEERING WHEEL
HEIGHT AND DEPTH
ADJUSTMENT
Pull handle Adownwards to
unlock the steering wheel.
 Adjust the height and depth of
the steering wheel.
 Lock by pushing handle Afully
upwards.
11 5
11 611 8

14
FUEL FILLER FLAP
Opening / Closing:
Locking and unlocking of the fuel filler
flap, the doors and boot is simultane
ous (except when selective unlocking
is initialised; in this case press the
unlocking button of the remote control
once).
FILLING WITH FUEL
This must be carried out with the engine and the ignition switched
off.
A hook is provided inside the fuel filler flap to hold the filler cap.
A label affixed to the inside of the fuel filler flap i nforms you which fuels
are authorised or prohibited.
The tank capacity is approximately 80 litres.
When the minimum level of the tank is reached, this light come s
on, accompanied by an audible signal and the message 'Fuel
level low' on the multifunction display.
You have enough fuel to drive approximately
30 miles (50 km).
OPENING THE BONNET
From inside:
pull the handle downwards.
From outside:
lift the catch and raise the
bonnet.
YOUR AT A GLANCE
107107

YOUR AT A GLANCE9
REAR PARKING
ASSISTANCE
This system, installed in the rear
bumper, detects any obstacle (per
son, vehicle, tree, gate, kerb...)
located behind the vehicle.
To activate
With the engine running, the sys
tem is activated as soon as
reverse gear is engaged; a bleep
sounds to inform you that it is
active.
The proximity information is
given by an audible signal, con
sisting of bleeps which become
more and more rapid as the vehi
cle approaches the obstacle.
When the distance between the
rear of the vehicle and the obsta
cle is less than approximately
twentyfive centimetres, the
signal becomes con
tinuous.The system ceas
es to be active
when you change
to neutral. TYRE UNDERINFLATION
DETECTION
Sensors check the tyre pressure
during driving, and trigger a warn
ing if there is a malfunction (speed
greater than 15 mph (25 km/h).
Tyre underinflation
When this warning light
comes on, accompanied
by a bleep and the mes
sage 'Tyre(s) pressure
low', have the tyre pressure
checked as soon as possible.
Puncture
Display of this warning
light, accompanied by an
audible signal and the
message 'Punctured
tyre(s) detected', is followed by
illumination of the STOPwarning
light.
Stop immediately, avoiding all
abrupt manoeuvres with the
steering wheel and the brakes.
Change the damaged (punctured
or very underinflated) wheel and
have the tyre pressure checked
as soon as possible.
Note: if the damaged wheel is
stored temporarily in the boot, it
will again send this message as a
reminder of the necessity of hav
ing it repaired. This will prevent a
similar warning being displayed. Sensor(s) not detected
Display of this warning
light, accompanied by an
audible signal and the
message 'X tyre pres
sure sensor(s) missing', indi
cates that one or more wheels
are not being detected.
Contact a PEUGEOT dealer to
replace the faulty sensor(s).
Warning: this message is dis
played when one of the wheels is
at a distance from the vehicle
(being repaired) or when a wheel
without a sensor is fitted (winter
fitting).
This system does not eliminate
the need to check the tyre
pressure regularly.
128139
