Your vehicle may have an electronic immobilizer
designed to protect your car against theft. If so, only
keys with the correct electronic code can be used to start
the vehicle. SeeImmobilizer Operation on page 2-14
for additional information. If a replacement key or an
additional key is needed, it must be purchased from
your dealer/retailer or certi ed locksmith.
Notice:If you ever lock your keys in the vehicle,
you may have to damage the vehicle to get in.
Be sure you have spare keys.
In an emergency, contact Roadside Assistance.
SeeRoadside Assistance Program on page 7-7
for more information.
Remote Keyless Entry (RKE)
System
If this vehicle has the Remote Keyless Entry (RKE)
system, it operates on a radio frequency subject
to Federal Communications Commission (FCC)
Rules and with Industry Canada.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.This device complies with RSS-210 of Industry Canada.
Operation is subject to the following two conditions:
1. This device may not cause interference.
2. This device must accept any interference received,
including interference that may cause undesired
operation of the device.
Changes or modi cations to this system by other than
an authorized service facility could void authorization to
use this equipment.
If there is a decrease in the RKE operating range,
try this:
Check the distance. The transmitter may be too far
from the vehicle. Stand closer during rainy or snowy
weather.
Check the location. Other vehicles or objects may be
blocking the signal. Take a few steps to the left or
right, hold the transmitter higher, and try again.
Check the transmitter’s battery. See “Battery
Replacement” later in this section.
If the transmitter is still not working correctly, see
your dealer/retailer or a quali ed technician for
service.
2-3
Page 82 of 348
Remote Keyless Entry (RKE)
System Operation
The Remote Keyless Entry (RKE) transmitter functions
work up to 65 feet (20 m) away from the vehicle.
There are other conditions which can affect the
performance of the transmitter. SeeRemote Keyless
Entry (RKE) System on page 2-3.The following functions may be available if the vehicle
has RKE:Q(Lock):Press to lock all of the doors. If all of the
doors and the trunk or liftgate are closed, the hazard
lamps ash once and the horn will sound to indicate that
locking has occurred and the theft-deterrent system is
active.
K(Unlock):Press to unlock all of the doors.
The hazard lamps ash twice to indicate that unlocking
has occurred and that the theft-deterrent system is
deactivated. If the doors are not opened within
30 seconds the doors will lock again.
3(Panic) (Hatchback):Press to sound the panic
alarm. The hazard lamps will ash and the panic alarm
will stay on for about 30 seconds. Press any of the
buttons on the transmitter to turn off the alarm.
V(Remote Trunk Release) (Sedan):Press and hold
for approximately one second to open the trunk.
The LED light (A) on the transmitter ashes when the
buttons on the transmitter are pressed. If the light does
not ash see “Battery Replacement” later in this section.
The buttons do not operate and the theft-deterrent
system does not activate if the key is in the ignition. Hatchback
Sedan
2-4
Page 83 of 348
Programming Transmitters to the
Vehicle
Only RKE transmitters programmed to the vehicle
will work. If a transmitter is lost or stolen, a replacement
can be purchased and programmed through your
dealer/retailer. When the replacement transmitter is
programmed to the vehicle, all remaining transmitters
must also be programmed. Any lost or stolen transmitters
no longer work once the new transmitter is programmed.
Each vehicle can have up to ve transmitters
programmed to it.
Battery Replacement
Replace the battery if the LED on the transmitter does
not ash when you press the buttons.
Notice:When replacing the battery, do not touch
any of the circuitry on the transmitter. Static
from your body could damage the transmitter.To replace the battery:
1. Remove the screw from the back of the cover and
open the cover of the transmitter.
2. Pull the transmitter out of the cover and
carefully turn the circle cover of the transmitter
unit toward open.
3. Remove the battery.
4. Insert the new battery, positive side facing up. Use
one three-volt, CR1620, or equivalent, type battery.
5. Turn the circle cover of the transmitter unit toward
close and put the transmitter unit in the cover.
6. Put the two halves back together and replace the
screw. Make sure the cover is on tightly, so water
will not get in.
7. Test the transmitter operation.
2-5
Page 84 of 348
Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can easily
open the doors and fall out of a moving
vehicle. When a door is locked, the handle
will not open it. The chance of being thrown
out of the vehicle in a crash is increased if
the doors are not locked. So, all passengers
should wear safety belts properly and the
doors should be locked whenever the vehicle
is driven.
Young children who get into unlocked vehicles
may be unable to get out. A child can be
overcome by extreme heat and can suffer
permanent injuries or even death from heat
stroke. Always lock the vehicle whenever
leaving it.
Outsiders can easily enter through an unlocked
door when you slow down or stop your vehicle.
Locking your doors can help prevent this from
happening.There are several ways to lock and unlock the vehicle.
From the outside, use your key or the Remote
Keyless Entry (RKE) transmitter. SeeRemote Keyless
Entry (RKE) System Operation on page 2-4.
To manually unlock the front doors from the outside,
insert the key and turn it toward the front of the vehicle.
To manually lock the doors from the outside, insert
the key and turn it toward the rear of the vehicle.
All doors, except for the driver door, can be locked by
pushing down the manual door lock and then closing
the door. On vehicles with power locks, the driver door
can only by locked from the outside by using the key
or the optional RKE transmitter.
From the inside, all of the doors can be locked and
unlocked by pushing or pulling the manual door
lock located on each door.
Central Door Unlocking System
The vehicle may be equipped with the central door
unlocking system. This system is activated from
the driver door.
From the outside, lock or unlock all the doors by using
either the key or the RKE transmitter, if equipped.
From the inside, lock or unlock all the doors by using
the driver door lock switch.
2-6
Page 85 of 348
Door Ajar Reminder
If one of the doors, trunk,
or liftgate is not closed
properly while the ignition
is on, the door ajar light on
the instrument panel comes
on and stays on until the
doors are closed.
Rear Door Security Locks
The vehicle has rear
door security locks on
each rear door that
prevents passengers
from opening the rear
doors from the inside.
Using the Rear Door Security Lock
1. Move the lever up to lock.
2. Close the door.
3. Repeat Steps 1 and 2 to the other rear door lock.
Notice:Pulling the inside door handle while
the rear door security locks are engaged could
damage your vehicle. Do not pull the inside door
handle while the rear door security locks are
engaged.
The rear doors on the vehicle cannot be opened from
the inside while this feature is in use.
Opening a Rear Door When the
Security Lock is On
1. Unlock the door from the inside.
2. Open the door from the outside.
If you do not cancel the security lock, adults or older
children who ride in the rear will not be able to open the
rear door from the inside.
Canceling the Rear Door Security Lock
1. Unlock the door from the inside and open the
door from the outside.
2. Move the lever down to unlock.
3. Repeat Steps 1 and 2 to the other rear door lock.
The rear door locks can now be locked and unlocked
normally.
2-7
Page 86 of 348
Trunk (Sedan)
{CAUTION:
Exhaust gases can enter the vehicle if it is driven
with the liftgate, trunk/hatch open, or with any
objects that pass through the seal between the
body and the trunk/hatch or liftgate. Engine exhaust
contains Carbon Monoxide (CO) which cannot be
seen or smelled. It can cause unconsciousness
and even death.
If the vehicle must be driven with the liftgate, or
trunk/hatch open:
Close all of the windows.
Fully open the air outlets on or under the
instrument panel.
Adjust the Climate Control system to a setting
that brings in only outside air and set the fan
speed to the highest setting. See Climate
Control System in the Index.
If the vehicle is equipped with a power liftgate,
disable the power liftgate function.
For more information about carbon monoxide, see
Engine Exhaust on page 2-30.To open the trunk on a sedan from outside of the
vehicle, insert the key into the lock cylinder and turn the
key clockwise or use the RKE transmitter, if equipped.
SeeRemote Keyless Entry (RKE) System Operation on
page 2-4.
Remote Trunk Release
If the vehicle has a trunk
release button located on
the driver door, the trunk
can be opened from inside
the vehicle by pressing the
release button.
When closing the trunk, close from the center to ensure
it fully latches.Trunk Release Button
2-8
Page 87 of 348
If the vehicle has a trunk
release lever located on
the outboard side of the
driver seat, the trunk can
be opened from inside the
vehicle by pulling the
release lever.
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk release
handle as a tie-down or anchor point when securing
items in the trunk as it could damage the handle.
The emergency trunk release handle is only
intended to aid a person trapped in a latched trunk,
enabling them to open the trunk from the inside.There is a glow-in-the-dark emergency trunk release
handle located on the underside of the trunk lid.
This handle will glow following exposure to light. Pull the
release handle down to open the trunk from the inside. Trunk Release Lever
2-9
Page 88 of 348
Liftgate (Hatchback)
{CAUTION:
Exhaust gases can enter the vehicle if it is driven
with the liftgate, trunk/hatch open, or with any
objects that pass through the seal between the
body and the trunk/hatch or liftgate. Engine exhaust
contains Carbon Monoxide (CO) which cannot be
seen or smelled. It can cause unconsciousness and
even death.
If the vehicle must be driven with the liftgate, or
trunk/hatch open:
Close all of the windows.
Fully open the air outlets on or under the
instrument panel.
Adjust the Climate Control system to a setting
that brings in only outside air and set the fan
speed to the highest setting. See Climate
Control System in the Index.
If the vehicle is equipped with a power liftgate,
disable the power liftgate function.
For more information about carbon monoxide, see
Engine Exhaust on page 2-30.To open the liftgate on a hatchback from outside of the
vehicle, insert the key into the lock cylinder and turn it
counterclockwise or use the RKE transmitter, if equipped.
Then pull up the handle above the license plate to open
the liftgate.
When closing the liftgate, close from the center to
ensure it fully latches.
To lock the liftgate, insert the key into the lock cylinder
and turn it clockwise or use the RKE transmitter,
if equipped.
The liftgate can also be locked or unlocked by the
central door unlocking system or RKE transmitter,
if equipped. SeeCentral Door Unlocking System on
page 2-6andRemote Keyless Entry (RKE) System
Operation on page 2-4.
2-10
Page 89 of 348
Windows
{CAUTION:
Leaving children, helpless adults, or pets in a
vehicle with the windows closed is dangerous.
They can be overcome by the extreme heat and
suffer permanent injuries or even death from heat
stroke. Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the windows
closed in warm or hot weather.
2-11
Page 90 of 348
Manual Windows
Use the window crank to open and close each window.
The rear windows do not open fully.
Power Windows
{CAUTION:
Leaving children in a vehicle with the keys is
dangerous for many reasons, children or others
could be badly injured or even killed. They could
operate the power windows or other controls or
even make the vehicle move. The windows will
function and they could be seriously injured or
killed if caught in the path of a closing window.
Do not leave keys in a vehicle with children.
When there are children in the rear seat use the
window lockout button to prevent unintentional
operation of the windows.On vehicles with power windows, the switches are
located on the driver door. In addition, each passenger
door has a switch for its own window.
The ignition must be turned to ON/RUN to use the
power windows. To lower the window, press and hold
the switch. To raise the window, lift up on the switch.
Release the switch when the window reaches the
desired level.
2-12
