PONTIAC G5 2010 Owners Manual

Using the Tire Sealant and Compressor
Kit without Sealant to Inate a Tire
(Not Punctured)
To use the air compressor to inflate a tire with air only
and not sealant:
Always do a safety check first. SeeIf a Tire Goes Flat
on page 6-70.
1. Remove the tire sealant and compressor kit from its storage location. See Tire Sealant and Compressor
Kit Storage on page 6-79 .
2. Unlock the air only hose (F) from the sealant canister (B) by pulling up on the lever. 3. Pull the air only hose (F) from the sealant
canister (B).
4. Remove the power plug (C) from the air compressor (A).
5. Place the kit on the ground. Make sure the tire valve stem is positioned close to
the ground so the hose will reach it.
6. Remove the tire valve stem cap by turning it counterclockwise.
7. Attach the air only hose (F) onto the tire valve stem and press the lever down to secure it.
8. Plug the power plug (C) into the accessory power outlet in the vehicle. Unplug all items from other
accessory power outlets. See Accessory Power
Outlet(s) on page 4-13 .
If the vehicle has an accessory power outlet, do not
use the cigarette lighter.
If the vehicle only has a cigarette lighter, use the
cigarette lighter.
Do not pinch the power plug cord in the door or
window.
9. Start the vehicle. The vehicle must be running while using the air compressor.
10. Press the on/off (D) button to turn the compressor on.
The compressor will inflate the tire with air only.
6-77

11. Inflate the tire to the recommended inflationpressure using the pressure gage (E). The
recommended inflation pressure can be found on
the Tire and Loading Information label. See
Ination - Tire Pressure on page 6-55 .
The pressure gage (E) may read higher than the
actual tire pressure while the compressor is on. Turn
the compressor off to get an accurate reading.
The compressor may be turned on/off until
the correct pressure is reached.
12. Press the on/off button (D) to turn the tire sealant and compressor kit off.
Be careful while handling the tire sealant and
compressor kit as it could be warm after usage.
13. Unplug the power plug (C) from the accessory power outlet in the vehicle.
14. Disconnect the air only hose (F) from the tire valve stem, by turning it counterclockwise, and replace
the tire valve stem cap.
15. Replace the air only hose (F) and the power plug (C) back in its original location.
16. Place the equipment in the original storage location in the vehicle.Removal and Installation of the Sealant
Canister
To remove the sealant canister:
1. Unlock the air only hose (F) from the sealant canister (B) by pulling up on the lever.
2. Pull the air only hose (F) from the sealant canister (B).
3. Unwrap the sealant/air hose (F) from the compressor (A).
6-78

4. Turn the sealant canister (B) so the inflator fillinghose is aligned with the slot in the compressor.
5. Lift the sealant canister (B) from the compressor and replace with a new sealant canister. See your
dealer/retailer for more information. To install a new sealant canister:
1. Align the sealant/air hose (F) with the slot in the air compressor.
2. Push the sealant canister (B) down and turn it clockwise.
3. Wrap the sealant/air hose (F) around the air compressor channel to stow it in its original location.
4. Push the air compressor inflator hose (F) onto the sealant canister inlet and push the lever down.
Tire Sealant and Compressor Kit
Storage
The tire sealant and compressor kit is located in the
trunk.
1. Open the trunk. See Trunk on page 3-11.
2. Lift the trunk liner.
6-79

3. Remove the retainer that holds the tire sealant andcompressor kit.
4. Remove the kit from the foam container.
To store the tire sealant and compressor kit, reverse the
steps.
Changing a Flat Tire
If a tire goes flat, avoid further tire and wheel damage
by driving slowly to a level place. Turn on the hazard
warning flashers. See Hazard Warning Flashers
on page 4-3.
{WARNING:
Changing a tire can be dangerous. The vehicle
can slip off the jack and roll over or fall on you or
other people. You and they could be badly injured
or even killed. Find a level place to change your
tire. To help prevent the vehicle from moving:
1. Set the parking brake firmly.
2. Put an automatic transmission shift lever in P (Park), or shift a manual transmission to
1 (First) or R (Reverse).
3. Turn off the engine and do not restart while the vehicle is raised.
4. Do not allow passengers to remain in the vehicle.
To be even more certain the vehicle will not move,
you should put blocks at the front and rear of the
tire farthest away from the one being changed.
That would be the tire on the other side, at the
opposite end of the vehicle.
6-80

When the vehicle has a flat tire (B), use the following
example as a guide to assist you in the placement
of wheel blocks (A).A. Wheel Block
B. Flat Tire
The following information explains how to use the jack
and change a tire.Removing the Spare Tire and Tools
The equipment you will need is located in the trunk.
Base Models
1. Open the trunk. See Trunk on page 3-11.
2. Lift the trunk liner to access the spare tire and tools.
6-81

A. Cover
B. Retainer
C. Spare Tire
D. Wing Nut E. Jack and Wheel Wrench F. Bolt
6-82

3. Remove the retainer (B) that holds down the sparetire. See Compact Spare Tire on page 6-93 for
more information.
4. Remove the spare tire (C) by gently pulling it up and out of the trunk.
5. Remove the wing nut (D) that holds the jack and remove the jack and wheel wrench (E).Uplevel Models
1. Open the trunk. See Trunk on page 3-11.
2. Lift the trunk liner to access the spare tire and tools.
6-83

A. Retainer
B. Jack and Wheel Wrench
C. Spare Tire
D. Foam Support E. Bolt
3. Remove the retainer (A) that holds down the jack, wheel wrench (B) and spare tire (C).
4. Remove the spare tire by gently pulling it up and out of the trunk.
The tools you will be using include the jack (A) and
wheel wrench (B).
6-84

You will need to turn the plastic wheel nut
counterclockwise to loosen the wheel wrench from
the jack.Press the button and then pull on the end of the wheel
wrench to extend the handle.
6-85

Removing the Flat Tire and
Installing the Spare Tire
1. Do a safety check before preceding. SeeChanging
a Flat Tire on page 6-80.
2. If your vehicle has plastic wheel covers, use the wheel wrench to loosen the plastic wheel nut caps.
Once you have loosened the plastic wheel nut caps
with the wheel wrench, you can finish loosening
them with your fingers. The plastic nut caps do not
come off.
3. If necessary, use the flat end of the wheel wrench to pry along the edge of the wheel cover until it
comes off.
Store the wheel cover in the trunk until you have
the flat tire repaired or replaced. 4. Turn the wheel wrench counterclockwise to loosen
all the wheel nuts. Do not remove them yet.
Notice: Make sure that the jack lift head is in the
correct position or you may damage your vehicle.
The repairs would not be covered by your warranty.
6-86
