PONTIAC G6 2007 Owners Manual

Programmable Automatic Door
Unlock
If you have a sedan with a manual transaxle, the
doors will automatically unlock when the ignition
is turned off.
If you have a vehicle with an automatic transaxle,
it was programmed at the factory to unlock
when the shift lever is moved to PARK (P).
You can change the settings of the programmable
automatic door unlock feature through the Driver
Information Center (DIC). SeeDIC Vehicle
Personalization on page 216.
Rear Door Security Locks
Your vehicle may have rear door security locks.
These prevent passengers from opening the
rear doors from the inside.
The rear door security
locks are located on the
inside edge of each rear
door. You must open the
rear doors to access
them. The label
depicting lock and
unlock positions is
located near the lock.
To set the locks, do the following:
1. Insert the key into the security lock slot and
turn it so the slot is in the horizontal position.
2. Close the door.
Security Lock Label
shown
111

To open a rear door when the security lock is on,
do the following:
1. Unlock the by lifting the rear door manual
lock, the power door lock switch, or if the
vehicle has one, by using the Remote Keyless
Entry (RKE) transmitter.
2. Open the door from the outside.
To cancel the rear door security lock, do the
following:
1. Unlock the door and open it from the outside.
2. Insert the key into the security lock slot
and turn it so the slot is in the vertical position.Lockout Protection
This feature prevents the driver’s door from being
locked using the power door locks, if the key is
left in the ignition and a door is open.
Pressing the power door lock switch will lock all
the doors and then unlock the driver’s door.
Pressing and holding the power door lock switch
for more than three seconds will override this
feature.
If you remove the key from the ignition, or if you
use the manual door lock or the remote keyless
entry transmitter, you could still lock your key
inside your vehicle. Always remember to take your
key with you.
112

Trunk
To open the trunk from the outside, press and hold
the trunk release button on the Remote Keyless
Entry (RKE) transmitter. You can also use the key
in the trunk lock, except on retractable hardtop
models.
Use the pull cup to aid in closing the trunk.
{CAUTION:
It can be dangerous to drive with the trunk
lid open because carbon monoxide (CO)
gas can come into your vehicle. You
cannot see or smell CO. It can cause
unconsciousness and even death.
CAUTION: (Continued)
CAUTION: (Continued)
If you must drive with the trunk lid open
or if electrical wiring or other cable
connections must pass through the seal
between the body and the trunk lid:
Make sure all other windows are shut.
Turn the fan on your heating or cooling
system to its highest speed and select
the control setting that will force
outside air into your vehicle.
See Climate Control System.
If you have air outlets on or under
the instrument panel, open them
all the way.
SeeEngine Exhaust on page 140.
113

Remote Trunk Release
Press this button
located on the driver’s
door near the map
pocket to open
the trunk.
You can open the trunk when the gear selector is
in PARK (P).
Emergency Trunk Release Handle
Notice:Do not use the emergency trunk
release handle as a tie-down or anchor point
when securing items in the trunk as it could
damage the handle. The emergency trunk
release handle is only intended to aid a person
trapped in a latched trunk, enabling them to
open the trunk from the inside.
114

There is a glow-in-the-dark emergency trunk
release handle located inside the trunk on
the trunk latch. This handle will glow following
exposure to light. Pull the release handle up
to open the trunk from the inside.
Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by the
extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
115

Power Windows
The power window switches for all the windows
are located on the driver’s door armrest. Each
passenger door also has a power window switch for
its own window. Press the front of the switch to the
rst position to lower the window to the desired
level. Pull the switch up to raise the window.
Window Indexing
(Coupe and Retractable Hardtop)
This feature automatically lowers the window a
small amount when the door is opened. Then,
when the door is closed, the window will
automatically raise fully.
Power Window Initialize
(Coupe and Retractable Hardtop)
After a power reconnect, such as battery
replacement, the indexing feature will not function
until the system is initialized. This procedure needs
to be done for each individual window. Once power
is restored, do the following:
1. Close the door.
2. Raise the window by pulling the power
window switch up.
3. Hold the window switch up for two seconds
after the window is closed. Release the
switch. Then hold the switch up again for
two seconds.
4. Lower the window all the way down. Hold the
switch down for two seconds.
Sedan SwitchesCoupe Switches
116

5. Repeat the procedure for each window,
including the rear quarter windows on
retractable hardtop models, until all
windows are initialized.
Express-Down Window
The express-down feature lowers the window all
the way without continuously pressing the
switch. The switch(es) is labeled AUTO.
On sedan and retractable hardtop models, the
driver’s window has the express-down feature.
On coupe models, both the driver’s and front
passenger’s window have the express-down
feature. The front passenger’s express-down is
activated by the driver’s side switch only. Press the
front of the switch all the way down and release it to
express open the window.
To stop the window while it is lowering, pull the
front of the switch up briey.
Window Lockout (Sedan Only)
o
(Window Lockout):This button prevents the
rear passengers from using their window
switches.
The window lockout button is located near the
driver’s power window switches. The driver can still
operate all the windows and the front passenger
can operate their own window with the lockout on.
Press the right side of the switch to turn the lockout
feature on. Press the left side to turn it off. The red
part of the switch is visible when you have returned
to normal window operation.
Sun Visors
Swing down the visors to block glare. The visors
can be removed from the center mount and swung
to the side. The visors also have extenders that
can be pulled out for additional blockage.
Your vehicle may have lighted vanity mirrors on
the driver’s and passenger’s visors. When
you lift the cover, the light will turn on.
117

Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Content Theft-Deterrent
Your vehicle may have
a content theft-deterrent
alarm system.
Arming the System
With the ignition off, you can arm the system
by pressing the Remote Keyless Entry (RKE)
transmitter lock button or the power door lock
switch while the driver’s door is open.The system will arm thirty seconds after all the
doors are closed, or sixty seconds with any
door open.
If you press the lock button on the transmitter a
second time while all the doors are closed, the
system will arm immediately. The system will still
arm in sixty seconds if a door is open. When the
open door is closed, the system will arm.
The security light, located on the instrument panel
cluster, will turn on to indicate that arming has been
initiated. Once the system is armed, the security
light will ash once every three seconds.
If the security light is ashing twice per second,
this means that a door is open.
If you do not want to arm the system, you may
lock the car with the lock levers on the doors.
Disarming the System
Press the RKE transmitter unlock button, or turn
the ignition to ON to disarm the system.
Once the system is disarmed, the security light will
stop ashing.
118

How the System Alarm is Activated
If the system is armed, it can be activated by:
Opening the driver’s door or trunk. This
will cause a ten second pre-alarm chirp
followed by a thirty second full alarm of horn
and lights.
Opening any other door. This will immediately
cause a full alarm of horn and lights for
thirty seconds.
Opening the hood. If the vehicle has the
remote start feature, it will activate the
full alarm.
When an alarm event has nished, the system will
re-arm itself automatically.
How to Turn Off the System Alarm
To turn off the system alarm, do one of the
following:
Press the lock button on the RKE transmitter.
The system will then re-arm itself.
Press the unlock button on the RKE
transmitter. This will also disarm the system.
Insert the key in the ignition and turn it on. This
will also disarm the system.
How to Detect a Tamper Condition
If you hear three chirps when the unlock or lock
button is pressed on the RKE transmitter, it means
that the content theft security system alarm was
previously triggered.
119

PASS-Key®III+
The PASS-Key®III+ system operates on a radio
frequency subject to Federal Communications
Commission (FCC) Rules and with Industry
Canada.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions:
1. This device may not cause harmful
interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation.
This device complies with RSS-210 of Industry
Canada. Operation is subject to the following two
conditions:
1. This device may not cause interference.
2. This device must accept any interference
received, including interference that may
cause undesired operation of the device.
Changes or modications to this system by other
than an authorized service facility could void
authorization to use this equipment.
PASS-Key
®III+ uses a radio frequency
transponder in the key that matches a decoder
in your vehicle.
PASS-Key®III+ Operation
Your vehicle has the PASS-Key®III+
(Personalized Automotive Security System)
theft-deterrent system. PASS-Key
®III+ is a
passive theft-deterrent system. This means you do
not have to do anything special to arm or disarm
the system. It works when you insert or remove the
key from the ignition.
When the PASS-Key
®III+ system senses that
someone is using the wrong key, it prevents the
vehicle from starting. Anyone using a trial-and-error
method to start the vehicle will be discouraged
because of the high number of electrical key codes.
When trying to start the vehicle if the engine does
not start and the SECURITY light comes on, the
key may have a damaged transponder. Turn the
ignition off and try again.
If the engine still does not start, and the key
appears to be undamaged, try another ignition key.
Also, check the fuse. SeeFuses on page 415.Ifthe
engine still does not start with the other key, your
vehicle needs service. If your vehicle does start, the
rst key may be faulty. See your dealer who can
service the PASS-Key
®III+ and have a new key
made. In an emergency, contact Roadside
Assistance.
120
