Parking Brake and Automatic
Transmission Park (P) Mechanism Check
{CAUTION:
When you are doing this check, your vehicle
could begin to move. You or others could be
injured and property could be damaged. Make
sure there is room in front of your vehicle in
case it begins to roll. Be ready to apply the
regular brake at once should the vehicle begin
to move.Park on a fairly steep hill, with the vehicle facing
downhill. Keeping your foot on the regular brake, set the
parking brake.
·To check the parking brake's holding ability: With
the engine running and transaxle in NEUTRAL (N),
slowly remove foot pressure from the regular
brake pedal. Do this until the vehicle is held by the
parking brake only.
·To check the PARK (P) mechanism's holding ability:
With the engine running, shift to PARK (P). Then
release the parking brake followed by the regular
brake.
Contact your GM Goodwrench
ždealer if service is
required.
Underbody Flushing Service
At least every spring, use plain water to ¯ush any
corrosive materials from the underbody. Take care to
clean thoroughly any areas where mud and other debris
can collect.
6-11
2006 - Pontiac GTO Owner Manual

Recommended Fluids and
Lubricants
Fluids and lubricants identi®ed below by name, part
number, or speci®cation may be obtained from
your dealer.
Usage Fluid/Lubricant
Engine OilThe engine requires a special
engine oil meeting GM Standard
GM4718M. Oils meeting this
standard may be identi®ed as
synthetic, and should also be
identi®ed with the American
Petroleum Institute Certi®ed for
Gasoline Engines starburst symbol.
However, not all synthetic API oils
with the starburst symbol will meet
this GM standard. You should look
for and use only an oil that meets
GM Standard GM4718M. GM
Goodwrench
žoil meets all the
requirements for your vehicle. For
the proper viscosity, see
Engine Oil
on page 5-13.
Usage Fluid/Lubricant
Engine Coolant50/50 mixture of clean, drinkable
water and use only DEX-COOL
ž
Coolant. SeeEngine Coolant on
page 5-23.
Hydraulic Brake
SystemHydraulic Brake Fluid. Use only
GM Part No. U.S. 88958860, in
Canada 88901244, Super DOT-4
brake ¯uid.
Windshield
WasherGM Optikleen
žWasher Solvent.
Hydraulic
Clutch SystemHydraulic Clutch Fluid. Use only
GM Part No. U.S. 88958860, in
Canada 88901244, Super DOT-4
brake ¯uid.
Parking Brake
Cable GuidesChassis Lubricant
(GM Part No. U.S. 12377985, in
Canada 88901242) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Power Steering
SystemDEXRON
ž-III Automatic
Transmission Fluid. Look for
ªApproved for the H-Speci®cationº
on the label.
6-12
2006 - Pontiac GTO Owner Manual

Usage Fluid/Lubricant
Manual
TransmissionDEXRONž-III Automatic
Transmission Fluid. Look for
ªApproved for the H-Speci®cationº
on the label.
Automatic
TransmissionDEXRON
ž-VI Automatic
Transmission Fluid.
Key Lock
CylindersMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474).
Rear AxleSAE 75W-140 GL-5 Synthetic Gear
Oil (GM Part No. 89021809). With a
complete drain and re®ll add 1 oz.
(25 ml) of Limited-Slip Differential
Friction Modi®er 7098
(GM Part No. 89021958).
Usage Fluid/Lubricant
Hood Latch
Assembly,
Secondary
Latch, Pivots,
Spring Anchor,
and Release
PawlLubriplate Lubricant Aerosol
(GM Part No. U.S. 12346293, in
Canada 992723) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Hood and Door
HingesMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241, in
Canada 10953474).
Weatherstrip
ConditioningDielectric Silicone Grease
(GM Part No. U.S. 12345579, in
Canada 992887).
6-13
2006 - Pontiac GTO Owner Manual

A
Accessories and Modi®cations............................ 5-3
Accessory Power Outlet(s)...............................3-17
Adding Equipment to Your Airbag-Equipped
Vehicle.......................................................1-52
Additives, Fuel................................................. 5-6
Add-On Electrical Equipment............................5-85
Air Cleaner/Filter, Engine.................................5-18
Air Conditioning..............................................3-19
Airbag
Readiness Light..........................................3-25
Airbag Sensing and Diagnostic Module (SDM)...... 7-9
Airbag System................................................1-46
Adding Equipment to Your Airbag-Equipped
Vehicle...................................................1-52
How Does an Airbag Restrain?......................1-50
Servicing Your Airbag-Equipped Vehicle..........1-52
What Makes an Airbag In¯ate?......................1-50
What Will You See After an Airbag In¯ates?....1-50
When Should an Airbag In¯ate?....................1-49
Where Are the Airbags?...............................1-48
Antenna, Backglass.........................................3-58
Anti-Lock Brake System (ABS)........................... 4-7
Anti-Lock Brake, System Warning Light..............3-27
Appearance Care
Aluminum Wheels........................................5-81
Care of Safety Belts....................................5-79
Chemical Paint Spotting...............................5-83
Cleaning Exterior Lamps/Lenses....................5-80Appearance Care (cont.)
Cleaning the Inside of Your Vehicle................5-76
Fabric/Carpet..............................................5-78
Finish Care.................................................5-80
Finish Damage............................................5-82
Instrument Panel, Vinyl, and Other Plastic
Surfaces.................................................5-79
Leather......................................................5-78
Sheet Metal Damage...................................5-82
Tires..........................................................5-82
Underbody Maintenance...............................5-83
Vehicle Care/Appearance Materials................5-84
Washing Your Vehicle...................................5-80
Weatherstrips..............................................5-80
Windshield and Wiper Blades........................5-81
Ashtray(s)......................................................3-18
Audio System(s).............................................3-44
Audio Steering Wheel Controls......................3-56
Backglass Antenna......................................3-58
Care of Your CD Player...............................3-57
Care of Your CDs........................................3-57
Radio with Six-Disc CD................................3-46
Setting the Time..........................................3-45
Theft-Deterrent Feature................................3-55
Understanding Radio Reception.....................3-57
Automatic Headlamp System............................3-14
Automatic Transmission
Fluid..........................................................5-19
Operation...................................................2-19
1
2006 - Pontiac GTO Owner Manual

F
Filter
Engine Air Cleaner......................................5-18
Finish Damage...............................................5-82
Flashers, Hazard Warning.................................. 3-6
Flash-to-Pass................................................... 3-9
Flat Tire........................................................5-68
Flat Tire, Changing.........................................5-69
Flat Tire, Storing.............................................5-75
Fluid
Automatic Transmission................................5-19
Manual Transmission....................................5-21
Power Steering...........................................5-33
Windshield Washer......................................5-34
Fog Lamp Light..............................................3-31
Fog Lamps....................................................3-15
Front Reading Lamps......................................3-16
Front Storage Area.........................................2-30
Fuel............................................................... 5-5
Additives...................................................... 5-6
California Fuel.............................................. 5-6
Filling a Portable Fuel Container....................5-10Fuel (cont.)
Filling Your Tank........................................... 5-8
Fuels in Foreign Countries.............................. 5-7
Gage.........................................................3-32
Gasoline Octane........................................... 5-5
Gasoline Speci®cations.................................. 5-5
Fuses
Engine Compartment Fuse Block...................5-88
Fuses and Circuit Breakers...........................5-86
Instrument Panel Fuse Block.........................5-86
G
Gage
Engine Coolant Temperature.........................3-28
Fuel..........................................................3-32
Speedometer..............................................3-24
Tachometer.................................................3-24
Gasoline
Octane........................................................ 5-5
Speci®cations............................................... 5-5
Glove Box.....................................................2-30
GM Mobility Reimbursement Program.................. 7-5
5
2006 - Pontiac GTO Owner Manual

Manual Transmission
Fluid..........................................................5-21
Operation...................................................2-21
Mirrors
Manual Rearview Mirror................................2-29
Outside Convex Mirror.................................2-29
Outside Power Mirrors..................................2-29
MyGMLink.com................................................ 7-3
N
New Vehicle Break-In......................................2-16
Normal Maintenance Replacement Parts............6-14
O
Off-Road Recovery..........................................4-12
Oil
Engine.......................................................5-13
Oil, Engine Oil Life System..............................5-16
Older Children, Restraints................................1-25
One-to-Four Shift Light....................................3-26
Online Owner Center........................................ 7-3
Other Warning Devices...................................... 3-6
Outlet Adjustment............................................3-21
Outlet(s), Accessory Power...............................3-17Outside
Convex Mirror.............................................2-29
Power Mirrors.............................................2-29
Owner Checks and Services.............................. 6-8
P
Paint, Damage...............................................5-82
Park (P)
Shifting Into................................................2-24
Shifting Out of............................................2-26
Parking
Brake........................................................2-24
Over Things That Burn.................................2-27
Passing.........................................................4-13
Power
Accessory Outlet(s)......................................3-17
Door Locks.................................................. 2-8
Retained Accessory (RAP)............................2-17
Seat............................................................ 1-2
Steering Fluid.............................................5-33
Windows....................................................2-13
Pretensioners, Safety Belt................................1-24
Programmable Automatic Door Locks.................. 2-9
Q
Questions and Answers About Safety Belts.........1-11
8
2006 - Pontiac GTO Owner Manual

T
Tachometer....................................................3-24
Taillamps
Turn Signal, Stoplamps and Back-up Lamps....5-48
Theft-Deterrent, Radio.....................................3-55
Theft-Deterrent Systems...................................2-14
Content Theft-Deterrent................................2-15
Immobilizer.................................................2-14
Immobilizer Operation...................................2-14
Tilt Wheel........................................................ 3-6
Tires.............................................................5-51
Aluminum Wheels, Cleaning..........................5-81
Buying New Tires........................................5-63
Chains.......................................................5-67
Changing a Flat Tire....................................5-69
Cleaning....................................................5-82
Compact Spare Tire.....................................5-76
Different Size..............................................5-64
If a Tire Goes Flat.......................................5-68
In¯ation - Tire Pressure................................5-58
Inspection and Rotation................................5-61
Installing the Spare Tire................................5-71
Removing the Flat Tire.................................5-71
Removing the Spare Tire and Tools...............5-70Tires (cont.)
Storing a Flat or Spare Tire and Tools............5-75
Tire Sidewall Labeling..................................5-53
Tire Terminology and De®nitions....................5-55
Uniform Tire Quality Grading.........................5-64
Wheel Alignment and Tire Balance.................5-66
Wheel Replacement.....................................5-66
When It Is Time for New Tires......................5-62
Towing
Recreational Vehicle.....................................4-34
Towing a Trailer..........................................4-34
Your Vehicle...............................................4-34
Traction
Control System (TCS).................................... 4-9
Transmission
Fluid, Automatic...........................................5-19
Fluid, Manual..............................................5-21
One-to-Four Shift Light.................................3-26
Transmission Operation, Automatic....................2-19
Transmission Operation, Manual........................2-21
Trip Computer................................................3-33
Trunk.............................................................. 2-9
Trunk Lamps..................................................3-16
Turn and Lane-Change Signals.......................... 3-8
Turn Signal/Multifunction Lever........................... 3-7
11
2006 - Pontiac GTO Owner Manual
