Interior.
Efficient ergonomics is the guid-
ing theme for the interior. The
steering wheel of fers 40 mm of
adjustment for both height and
reach. A multifunction steering
wheel – with or without steering
wheel heating – is available on
request. The distinctively designed gear lever (for the six-
speed manual gearbox) and PDK
gear selector are easy to operate.
Porsche Communication Manage
-
ment (PCM) with a touchscreen is
fit ted as standard, as is the inte -
gral GPS navigation module with
hard drive navigation (page 86).
The new 911 Turbo S models come equipped with an integrated
six- disc CD/ DVD autochanger
and cruise control as standard.
The air- conditioning system with
an active carbon filter is fully
automatic. The leather finish on the seats,
dashboard, doors and rear
side panels is pleasing to the
touch. Available exclusively for
911 Turbo S models as standard
is the choice of t wo -tone leather
interior in either Black and Cream
or Black and Titanium Blue.
The centre console and door
storage compartments provide
storage space for personal items.
Below the passenger airbag are
t wo cup holders and below these
is the glove compartment with
CD storage.
Two 12-volt sockets (including the
cigaret te lighter) provide power
for a range of electrical devices.
Instruments.
The classic Porsche grouping of
five round instruments offers a
clear overview of all key informa -
tion.
The digital display in the centre-
left dial (speedometer) provides
main and trip odometer readings.
The central rev counter, featuring
the ‘turbo’ ‘or turbo S’ logo,
includes the standard on-board
computer display. This multi -
pur
pose field contains a perma -
nent digital speedometer as well
as the upshif t display on manual
models. The following optional information can also be displayed:
boost pressure, average speed,
average fuel consumption, t yre
pressure, current radio station,
navigation instructions and
remaining range till empt y. When
‘Sport ’ mode is selected on
the Sport Chrono Package Turbo
in a 911 Turbo model equipped
with dynamic engine mount
system, the temporary increase
in maximum torque is clearly
indicated by an arrow symbol in
the boost pressure display.
The third display, in the centre-
right dial, shows the time and
outside temperature.
Why do you need huge gestures
when the signs are clear?
Comfort.
An expressive design.
Well conceived technology.
A consistently sporty style.
No gimmicks. Why should the
rules for performance be
any different for the interior?
Personality | Comfort
Instruments in the 911 Turbo with PDK
Interior of the 911 Turbo in natural leather Carrera Red
· 80 ·· 81 ·
Page 42 of 59
Comfort seats.
The comfort seats fit ted as
standard in the 911 Turbo and
911 Turbo Cabriolet models fea -
ture full electric adjustment of
fore/af t position, height, backrest
angle, squab angle and lumbar
support (also available at no extra
cost for 911 Turbo S models).
The high side bolsters provide
excellent lateral support, without
restricting occupant comfort.
The generous range of adjustment
options on the standard seats
means that virtually every driver
can find the ideal position, regard -less of physical build. A memory
function stores personal prefer
-ences for seat position, lumbar
support and exterior mirrors.
Sports seats.
Available as a no -cost option,
these mechanical sports seats
of fer firmer upholstery as well as
higher side bolsters on the back -
rest and squab for added lateral
support. The fore/af t position and
height are manually adjustable,
while the backrest is electrically
controlled.
Adaptive sports seats.
Adaptive sports seats are
fit ted as standard in the new
911 Turbo S models (optional for
911 Turbo models). They of fer
individual electric adjustment of
fore/af t position, height, backrest
angle, lumbar support, squab
side bolsters and backrest side
bolsters for maximum comfort
on long- distance journeys or
lateral support on the racetrack.
The additional memory function
covers both exterior mirrors
and all seating positions on the
driver’s side, except side bolster
set tings.
Sports bucket seats.*
For the ultimate sports experi -
ence, choose the new sports
bucket seats featuring a folding
backrest, integral thorax airbag
and manual fore/af t adjustment
(available as a no -cost option
for 911 Turbo S models). The
backrest shell is made from
glass/carbon -fibre reinforced
plastic and has a st ylish carbon-
weave finish.
Unusually, the pivot points of the
seat backrest are positioned high
in the side bolsters, guaranteeing
lateral support – characteristic of
racing bucket seats – in the pelvis
area too. Unlike conventional
bucket seats, the folding backrest
enables easy access to the rear
luggage area.
Seat ventilation.
As an option, seat ventilation is
available for the comfort seats
when fit ted in combination with
seat heating. Active ventilation of the perforated seat centre pad
and backrest, along with passive
ventilation on the side bolsters,
generates a flow of air.
Rear seats.
The rear seats are surprisingly
comfortable for a sportscar. The
seat backrests fold down, giving
you a generous rear luggage
area of 190 litres (155 litres in the
911 Turbo Cabriolet models).
Child seats.*
Child seats with and without
ISOFIX mountings can be fit ted
in any vehicle of the 911 Turbo
model range. The Porsche
Tequipment accessory range
includes the necessary fittings
and a deactivation function
for the passenger airbag. The
complete range of child seats
is available from Porsche
Tequipment. Please ask your
Porsche Centre for details.
Comfort seat with seat ventilation Adaptive sports seatSports bucket seat *
Child seats must not be used with the
sports bucket seats.
Rear compartment space
Personality
| Comfort
· 82 ·· 83 ·
Page 43 of 59
HomeLink®.
The optional freely programmable
garage door opener is incorpo-
rated into the roof console and
of fers remote control of up to
three garage door, gate, home
lighting and/or alarm systems.
Luggage compartment.
In addition to the rear luggage
area, the luggage compartment
at the front has a capacit y of
105 litres. The entire luggage compartment is lined with high-
qualit y scratch - resistant materials.
Roof transport system.
The optional roof carrier system
for the 911 Turbo (Coupé versions
only) is aerodynamically efficient,
extremely light weight and easy
to fit. The system can be com -
bined with a range of at tachments,
such as a roof box and carriers
for bikes, skis and snowboards.
Maximum roof load is 75 kg.
Anti-theft protection.
An engine immobiliser with in -key
transponder as well as a powerful
alarm system featuring contact-
sensitive exterior protection and
radar-based interior surveillance
are standard on all models.
Vehicle Tracking System.
An optional factory-fit ted prepa -
ration enabling future installation
of a vehicle tracking system is ob -
tainable from Porsche Tequipment.
This system allows a stolen
vehicle
to be traced throughout most of
Europe. The package includes
a special wiring loom and a high
capacit y bat tery. A tilt sensor
for the alarm system is
also part
of the preliminary fit tings.
Automatically dimming mirrors.
An auto -dimming function is
included as standard for the
interior and exterior mirrors. Also
included is an integrated rain
sensor for the front wiper system.
ParkAssist.
This standard feature is
automatically enabled whenever
you select reverse gear. Move
too close to a stationary object
and a warning signal is emit ted.
Continue to reverse and the
tone increases in frequency. The ultrasonic sensors are neatly
concealed in the rear bumper.
Cruise control.
Standard on 911 Turbo S models
(optional for 911 Turbo models),
cruise control has an ef fective
speed range of 30 –240 km/ h
(19–149 mph). The system is
operated using a separate control
stalk on the steering column and
can even be used in first gear.
Luggage compartment with t wo PTS ‘Ultralight edition’ trolley cases, size M
Roof transport system
Personality | Comfort
· 84 ·· 85 ·
Page 44 of 59
Porsche Communication
Management (PCM).
Fit ted as standard, PCM is the
central information and commu -
nications system. It is both
multifunctional and very easy to
operate.
The main feature is the 6.5-inch
touchscreen for intuitive control.
For radio listeners, there is an
FM t win tuner with RDS, which
constantly scans for the best signal for the selected station,
and up to four radio aerials for
optimum reception.
The integrated single CD/ DVD
drive of the 911 Turbo models
can, in combination with the
standard BOSE
® Surround Sound
System, replay music from audio
and video DVDs in 5.1 Discrete
Surround Format. As an option,
a six-disc CD/ DVD autochanger
can also be integrated in PCM
(standard on 911 Turbo S
models). The standard GPS navigation
module has a hard drive with
map data for most European
countries. When viewing a map,
it is possible to select either a
3D perspective or a 2D display.
Electronic logbook.
The optional electronic logbook
enables automatic recording
of mileage, route distance, date
and time, starting point and
destination for each journey.
TV tuner.
A T V tuner, available as an option,
receives unencoded analogue
and digital television broadcasts
(DVB-T) to provide entertainment
bet ween journeys. For your
safet y, the T V picture cannot be
displayed while the vehicle is in
motion.
Voice control system.
Almost all of the functions of PCM
can be controlled via the optional
voice control system. The main
menu item is read aloud exactly
as it is displayed on the screen
and the voice control system
recognises commands or number
sequences, irrespective of the
speaker. It gives audible feedback
and guides you through the
functions. There is no need to
‘train’
the system. Phone book
entries can be retrieved, a radio
station selected or the navigation
destination entered directly by
speaking whole words.
Telephone module for PCM.*
The standard GSM telephone
module offers convenience and
excellent reception. By inserting
a SIM card directly into PCM’s
integral SIM card reader, calls
can be made using the hands-free
facilit y. For even more conven -
ience, the Bluetooth
® capabilit y
of a mobile phone can be used
to make calls via the SIM Access
Profile (SAP). Once automatic
pairing is complete, the mobile
phone’s aerial is switched of f to
conserve bat tery charge and the
phone operates via the car aerial.
Depending on the mobile phone
model, this gives access not only
to the numbers on the SIM card,
but also to the phone’s internal
memory. Depending on the phone,
it can also be controlled using
PCM, the optional multifunction
steering wheel or the optional
voice control system, without it
ever leaving your pocket.
In addition, the telephone module
enables you to establish a
Bluetooth
® link with those mobile
phones that only support the
Handsfree Profile (HFP). In this
case, the GSM connection is
always established through the
aerial of the mobile phone.
PCM acts as a hands-free system
and you can leave the mobile
phone tucked away. On request,
a cordless handset for the tele -
phone module is also available.
However, the handset cannot be
used for Bluetooth
® links estab -
lished using the Handsfree Profile
(HFP).
Porsche Communication Management (PCM) Cordless handset
* Note: see page 104.
Personality | Comfort
· 86 ·· 87 ·
Page 45 of 59
12
3
34
5
6
6
7
7
5
Universal audio interface.
With this standard feature, the
storage compartment in the
centre console will contain three
connections: one for your iPod
®,
one for a USB stick/ MP3-player
and one as an AUX interface for
any chosen compatible audio
source. The iPod
® or USB stick
can be operated conveniently and
safely via PCM, the optional multi -
function steering wheel or the
optional voice control system.
BOSE® Surround Sound System.
The standard BOSE® Surround
Sound System is optimally
matched to the specific interior
acoustics. A total of 13 loud -
speakers (12 in the 911 Turbo
Cabriolet models), including an active subwoofer and central
speaker, and a seven-channel
digital amplifier with a rated
output of 385 wat ts ensure an
impressive sound experience.
When playing music from audio
or video DVDs, the system
now has the impressive sound
spectrum of digital 5.1 recording.
Five dedicated audio channels
(front left, front right, centre,
surround lef t, surround right) and
a power channel for the bass
frequencies deliver a sound that
is as authentic as it is natural.
The 5.1 Discrete Surround Sound
is balanced, lifelike and crystal
clear. A 360 - degree sound
expe rience that is as close to a
live performance as you could
imagine.
Naturally, you can also play
conventional CDs, either in
stereo or in one of the surround
modes generated by the BOSE
®
Centerpoint
® technology. The
algorithm of Centerpoint
® II
extracts a precise and realistic
sound from the stereo signal. To complement these features,
the BOSE
® Surround Sound
System of fers a comprehensive
selection of equaliser presets for
customised sound. The dynamic
loudness function emphasises
the bass notes as the volume
decreases to compensate for the
diminishing sensitivit y of the human hearing at these frequen
-
cies. In addition, the AudioPilot®
Noise Compensation Technology
uses a microphone to continu -
ously measure the ambient noise
inside the vehicle and adapts
music playback automatically,
to give a constant sound qualit y
in all driving conditions.
In short, you are sit ting in a
concert hall – one of the fastest
there is.
Personality | Comfort
1. System electronics
2. 7.0 - cm mid - range center fill speaker
3. 2.5 - cm Neodym high - range speakers
4. AudioPilot
® microphone
5. 8.0 - cm Neodym mid - range speaker
20.0 - cm Nd
® low- range speaker
6. 2.5 - cm Neodym high - range speaker
8.0 - cm Neodym mid - range speaker
7. 911 Turbo Coupé models: t wo 13.0 - cm
low - range speakers in 14 - litre bass
reflex enclosure with TSM switching
amplifier. 911 Turbo Cabriolet models:
one low - range speaker in bass reflex
enclosure with TSM switching amplifier
in front passenger foot well
· 88 ·· 89 ·
Page 46 of 59
Colours.
Choice of colour is always an
expression of personal character.
So it ’s good that our wide
variet y
of colour options does
this prin ciple justice.
t wo -tone combinations for the
leather interior.
If you can’t find the colour you’d
like, we can probably mix it
for you. For more information,
see the Porsche Exclusive 911
catalogue. To see how your individual
choices would look on your car,
visit w w w.porsche.com
and use the online Porsche Car
C o n f i g u ra t o r.
Why it’s worth
letting your imagination run free.
Personalisation.
The success story of the
911 Turbo is always a very
personal one. Because power
also means providing plenty
of scope for individual inter -
pretation.
In total, you can choose from four
solid and eight metallic colours,
four ‘special’ paint finishes and
four hood colours. Plus for the
interior, there’s a choice of nine
colours, three t wo -tone combi -
nations and, exclusively for
911 Turbo S models, t wo additional
Personality | Personalisation
· 90 ·· 91 ·
Page 47 of 59
Solid exterior colours. 1Metallic exterior colours. 1
BlackCream White
Guards Red GT Silver Metallic
Basalt Black Metallic
Macadamia Metallic Black
Platinum Silver Metallic
2Meteor Grey Metallic Stone Grey
Dark Blue Metallic Aqua Blue Metallic Metropole Blue
Carrara White Amethyst Metallic
2
Ice Blue Metallic 3Porsche Racing Green Metallic Cocoa
Speed Yellow Ruby Red Metallic
1 Solid and metallic colours are all no - cost options.2 Available from 09/2010 at the earliest.3 For 911 Turbo models, available from 09/2010 at the earliest.
Note for 911 Turbo and 911 Turbo S models: up to 07/2010 available as metallic paint: Arctic Silver Metallic
up to 07/2010 available as special colour: Atlas Grey Metallic
Special exterior colours. Hood colours.
· 92 ·· 93 ·
Page 48 of 59
Standard interior colours.Special/two-tone interior colours 4.Natural leather interior.
Black
Stone GreyBlack
Black Terracotta 5TerracottaBlack
Stone Grey Stone Grey Cocoa
5CocoaBlack
Sand Beige Sand Beige Black and Terracotta
4 , 6TerracottaBlack
Sand Beige
Ocean BlueOcean Blue Black and Stone Grey
4 , 7Stone GreyBlack
Ocean Blue
Black and Sand Beige
4 , 7
Dark Grey Natural8
Natural Brown 5
Carrera Red 5
Sand Beige Dark Grey Natural
Natural Brown
Carrera Red
Black Black
Black
BlackSee price list for recommended colour combinations.
1
Sof t-touch paint in interior colour; sun visors and inner door sill guards with film finish in interior colour.2 Rooflining in Alcantara (Coupé) or black fabric (Cabriolet).3 Available for 911 Turbo S models only. Interior in black leather with the following sur faces in the chosen combination colour of Cream
or Titanium Blue: door panels, seat centres front and rear. Decorative stitching in selected interior colour: dashboard upper section, door
panels upper section, seats front and rear.
4 Two -tone interior: black leather finish on dashboard upper section including instrument shroud, dashboard for ward section including front
passenger airbag cover, steering wheel rim and airbag module, door upper panels, rear side panel upper sections, A - pillar/windscreen top
trim, B/C- pillar trim (Coupé). All other sur faces in chosen combination colour.
5 Sof t-touch paint in interior colour; sun visors and inner door sill guards with black film finish.6 Sof t-touch paint in interior colour or black; sun visors and inner door sill guards with black film finish.7 Sof t-touch paint in interior colour or black; sun visors with black film finish, and inner door sill guards with film finish in interior colour.8 Sof t-touch paint in black; sun visors and inner door sill guards with black film finish.
Black and Cream 3Black Black
Black and Titanium Blue
3Black Black
Leather/soft-touch paint 1
Interior colour. Leather/soft-touch paint
Interior colour. Leather/soft-touch paint
Interior colour.
Carpet. Rooflining. 2Carpet. Rooflining. 2Carpet. Rooflining. 2
· 94 · · 95 · · 96 ·
Page 49 of 59
equipment packages. Detailed
information can be found on
the following pages and in the
separate price list.
To make your 911 Turbo or
911 Turbo S model even more of
an individual statement, please
ask about the Porsche Exclusive
factory-fitted modifications.
You can also continue to enhance
your car with Porsche Tequipment.
Numerous examples can be
found in the respective
brochures. For more information,
please consult your Porsche
Centre.
Then comes the moment when
you take delivery of your dream
car. Where bet ter to do it than
at the place where the success
story began, in Zuf fenhausen?
For full details about the factory
collection option, please consult
the price list.
Personalisation options and
factory collection.
Is there any thing bet ter than the
911 Turbo concept? Of course
there is. Your interpretation of
that concept. What bet ter way to
complement this captivating
sportscar than by using the power
of your imagination?
To enhance the individualit y of
your car – both inside and out –
you can choose from a range of
individual items of equipment and
911 Turbo Cabriolet with interior in t wo -tone combination (Black and Stone Grey) 911 Turbo Cabriolet with hardtop 911 Turbo with Aerokit Turbo and 19 - inch RS Spyder wheels
The vehicles pictured in the chapter on personalisation may include additional options not featured in this catalogue.
For information on these options, please consult your Porsche Centre.
For information on the options featured in this catalogue, please refer to the price list. – not available
I number/extra - cost option• standard equipmentw no - cost option
Personality | Personalisation
9 11 T u r b o
911 Turbo Cabriolet
9 11 T u r b o S
911 Turbo S CabrioletI no. Page
Option
Engine, transmission and chassis.
• Porsche Doppelkupplung (PDK)•• ••250 42
•
Porsche Ceramic Composite Brake (PCCB)
•• ••450 68
•
Porsche Torque Vectoring (PTV)
•• ••220 50
•
Sport Chrono Package Turbo with dynamic engine mount system
•• ••640 58
•
Wheel centres with full- colour Porsche Crest
•• w
w446
•
19 -inch RS Spyder wheels with central locking device
•• ••422 54
• 19-inch 911 Turbo II wheels
• •w
w421 54
Personality | Personalisation
Exterior.
•
Special colours••••Code 93
• Individual colours
••••Code
•
Dynamic cornering lights
•• ••603 65
• Deletion of model designation
w www498
•
Park Assist (parking aid at rear)
• •••635 85
•
Aerokit Turbo
• –•–XAF
99
•
Rear wiper
• –•–425
•
Windscreen with grey top tint
• •••567
•
Electric slide/tilt sunroof
• –•–650
•
Hardtop
–• –•550
25, 99
•
Roof transport system
• –•–549
84
· 97 ·· 98 ·· 99 ·
Page 50 of 59
Personality | Personalisation
Interior.
• HomeLink® (programmable garage door opener)••••608 84
•
Cruise control (automatic speed control)
•• ••454 85
•
Comfort seats with driver memory
• •w
wP15 82
•
Sports seats
w wwwP77 82
• Adaptive sports seats with driver memory
•• ••P 01 82
•
Sports bucket seats
•• w
wP03 83
•
Heated seats
••••342
• Seat ventilation
••••5 41 83
• Steering wheel heating
••••345
•
Fire extinguisher
••••509
• Floor mats
••••810
Interior: macassar (dark wood with satin finish).
• Macassar interior package••••8 01 10 2
• Three-spoke multifunction steering wheel in macassar
••••8 47 10 2
Interior: leather and natural leather.
•
Leather interior package
– in standard colour
– in t wo -tone leather
– in special colour
– in t wo -tone combination
– in natural leather
– in individual colour
•
–
•
•
•
• •
–
•
•
•
••
•
•
•
•
••
•
•
•
•
•
Code
Code
Code
970
998
Code
21, 23
10 2
16 , 8 0
• Three-spoke multifunction steering wheel
w www844 10 2
•
Three-spoke sports steering wheel with gearshif t paddles
•• ••840 44
• Sof t ruf fled leather on seats
••••982
Interior: carbon.
• Carbon interior package••••803 10 3
• Three-spoke multifunction steering wheel in carbon
••••845 10 3
• Door sill guards in carbon
••••X69
Interior: Aluminium Look /aluminium /stainless steel.
• Three-spoke multifunction steering wheel in Aluminium Look••••XPU 10 3
• Gear and handbrake levers in aluminium I
•• –
–ECA 10 3
• PDK gear selector and handbrake lever in aluminium
••••ECB
9 11 T u r b o
911 Turbo Cabriolet
9 11 T u r b o S
911 Turbo S CabrioletI no. Page
Option9 11 T u r b o
911 Turbo Cabriolet
9 11 T u r b o S
911 Turbo S CabrioletI no. Page
Option
– not available I number/extra - cost option• standard equipmentw no - cost option
The vehicles pictured in the chapter on personalisation may include additional options not featured in this catalogue.
For information on these options, please consult your Porsche Centre.
For information on the options featured in this catalogue, please refer to the price list.
· 100 ·· 101 ·
