PORSCHE 911 CARRERA 2011 6.G Information Manual

4445
DFI delivers fuel directly into the combustion
chamber with millisecond precision. The
spray and cone angles of the multi­hole
injectors have been optimised for torque,
power output, fuel consumption, emissions
and ef ficient combustion.
With direct injection, the engine manage ­
ment system regulates injection timing
individually for each cylinder as well as
the injection rate for each cylinder bank.
This improves the combustion process
and fuel economy. operation to the prevailing conditions.
This results in instant acceleration,
extremely smooth running and an
extraordinary level of tractive power,

but with a comparatively low level of
fuel consumption.
For faster heating of the catalytic converters
after a cold start and optimum torque in
the upper load range, up to three injection
pulses take place per combustion cycle.
DFI improves the internal cooling of

the combustion chamber by having the
mixture prepared directly in the cylinder.
This allows for a higher compression
ratio, which helps to deliver more output
at the same time as enhanced engine
efficiency. Injection is regulated by the
electronic engine management system
and emissions are monitored by the
Lambda sensors.
Temperament | Engines
VarioCam Plus System.
VarioCam Plus is a two ­in ­one engine
concept for adjusting the intake
camshafts and switching the lift of the
intake valves.
The system first dif ferentiates bet ween
driver inputs that typify normal,
everyday driving and those inputs
that demand maximum performance.
The electronic engine management
system then seamlessly adapts valve
What lies between your home and Le Mans?
Advanced engineering as standard.

Direct fuel injection (DFI).
For fuel consumption and CO2 emissions, please refer to pages 139/141.

4647
Temperament
|
Engines
Integrated dry-sump lubrication.
Integrated dr y ­sump lubrication ensures
a reliable supply of oil even when a
sport y driving st yle is adopted. It also
has additional cooling functions.
The oil tank is located in the engine,
thereby eliminating the need for an
external oil tank, which saves both space
and weight. To reduce power loss and
increase efficiency, an electronically
controlled oil pump supplies the lubricat ­
ing points inside the engine as and
when required. When demand is low, the
oil pump is operated at reduced power,
thereby saving fuel.
Air intake system.
The resonance intake system increases
the intake volume by exploiting the fact
that air oscillates as it passes through
the intake manifold. The system can
adjust to engine speed. Benefits of this
include higher torque at low engine
speeds and a flat ter torque curve.
The
9 11 Carrera S models operate a t wo ­
stage
system.
The entire intake system is made from
light weight plastic. In the 9 11 Carrera
model range, the resonator volume of
the air filter housing varies with engine
speed to bring added character to the
engine sound, which becomes much
more powerful at higher rpm.
Exhaust system.
The exhaust system of the 911 Carrera
models has been redesigned, acoustics
included.
The stainless ­steel exhaust system com ­
prises t wo distinctive and independent
exhaust tracts. The cataly tic converters
heat up rapidly for effective emissions
reduction.
A selectable t win ­tube sports exhaust
system featuring distinctive polished
stainless ­steel tailpipes is available as an
option. Activated by a but ton, it produces
an even more intensive sports car sound.
Engine management system.
The EMS SDI 9.1 engine management
system ensures optimum engine perfor ­
mance at all times. It controls, for
example, the position of the electronic
throt tle valve (ETC) – a prerequisite for
compati bility with the Porsche Stability
Management (PSM), which comes as
standard. It also regulates all engine ­
related functions to achieve optimum
fuel consumption, emissions and power
output whatever the driving st yle.
Another function is the cylinder ­specific
knock control. Since the cylinders never
all work under exactly the same condi ­
tions, the knock control function monitors
each one separately. The ignition point
is shifted individually, as and when
necessary, to protect the cylinders and
pistons at high engine speeds.
For compliance with EU standards, the
on ­board diagnostics detect any faults
and defects that may occur in the exhaust
and fuel systems and then notify the
driver immediately. This also prevents
increased pollutant emissions and
unnecessary fuel consumption.
Twin tailpipe of the sports exhaust system Single
­tube tailpipe on the 911 Carrera
Twin ­tube tailpipe on the 911 Carrera S
For fuel consumption and CO2 emissions, please refer to pages 139/141.

4849
Temperament
|
Transmission
The long and winding road is where you’d like to be.
Sometimes, it pays to take the direct route.

Transmission.
The 7-speed manual gearbox.
Pure, direct, precise. Short shif t move ­
ments and an optimum transition from
one gear to the next. That ’s exactly what
you would expect of a Porsche manual
gearbox.
What you might not have expected is a
7 ­speed manual gearbox that combines
a high level of sport y performance with
an equally high level of efficiency and
offers extra comfort for longer journeys. It’s an exceptional innovation, and not
only in the sports car segment.
The design of this manual gearbox is
based in principle on that of Porsche
Doppelkupplung (PDK). Gears 1 to 6 have
a sports ratio and top speed is reached
in 6th gear. The additional 7th gear,

however, has a long ratio, which reduces
torque and helps to reduce fuel consump ­
tion. Lower engine revs at fast driving
speeds also ensure a high level of com
fort
on long stretches of road. In addition
, a gear indicator in the rev counter reminds
you which gear has been selected. The
upshift indicator in the instrument cluster
helps you actively conserve fuel.
Thanks to the elevated centre console,
the gear lever is within easy reach –

ideal for sport y gear changes.
Whether you select a sporty or comfortable
gear, the way you reach your destination
is in your own hands.
For fuel consumption and CO
2 emissions, please refer to pages 139/141.

462135
7R
5051
Porsche Doppelkupplung (PDK).
Available as an option for all 911 Carrera
models is 7­speed PDK, featuring
manual and automatic modes. It facili ­
tates extremely fast gear changes
with no interruption in the flow of power,
whilst at the same time improving
acceleration and fuel efficiency. In total, PDK has seven gears at its dis
­
posal. Gears 1 to 6 have a sports ratio
and top speed is reached in 6th gear.
7th gear has a long ratio and helps to
reduce fuel consumption by keeping
engine revs low.
PDK is essentially t wo gearboxes in one
and thus requires t wo clutches. This
double ­clutch arrangement provides an
Porsche Doppelkupplung (PDK)
alternating, non ­positive connection
bet ween the t wo half gearboxes and the
engine by means of t wo separate input
shafts.
The flow of power from the engine is
transmit ted through one half gearbox and
one clutch at a time, while the next gear
is preselected in the second half gearbox. During a gear change, therefore, one
clutch simply opens and the other closes
at the same time, enabling gear changes
to take place within milliseconds.The effect is instant. Driving feels even
sportier and more dynamic, and agility

is increased. Depending on the gearshift
programme (SPORT button activated
Temperament | Transmission
or deactivated), the gear change is opti ­
mised for comfort or for sport y driving.
With the optional Sport Chrono Package,
PDK is enhanced by the ‘Launch Control’
and ‘motorsport ­derived gearshif t strategy’
functions (p. 67).
Coasting.
The ‘coasting’ function available with
Porsche Doppelkupplung (PDK) enables
you to save even more fuel where the
situation allows. The engine is decoupled
from the transmission to prevent
deceleration caused by engine braking.
In this way, optimum use is made of the
vehicle’s momentum, allowing it to coast
for longer distances.
For example, you may want to slow down
from 62 to 49 mph in anticipation of the
change of speed limit ahead. As soon as
you release the accelerator pedal, PDK
deselects the current gear auto matically and you begin to coast in neutral until
you have reached your desired speed.
The moment you engage the accelerator
or brake pedal, PDK selects the appropri
­
ate gear smoothly and seamlessly within
a fraction of a second. In short, driving in coasting mode makes
a real impact on fuel consumption without
any need for compromise on comfort or
sporty performance.
Another way to reduce fuel consumption is
to utilise the coasting function on downhill
gradients that are gentle enough for you

to maintain a constant speed. Efficient on
long journeys, such as on the motorway,
PDK remains ready to respond as swiftly
and precisely as you would expect.
For fuel consumption and CO2 emissions, please refer to pages 139/141.

5253
T
emperament
| Transmission
It is possible to have a lot of power and
yet not be able to move any thing. Only
by using your power intelligently will you
truly progress – and with consummate
ease.
Enhanced Porsche Traction Management
(PTM) is standard on all 911 Carrera
all ­wheel ­drive models. It is an active all ­
wheel ­drive system with an electronically
variable map ­controlled multi ­plate clutch,
automatic brake differential (ABD) and
anti ­slip regulation (ASR). Drive power is distributed bet ween the
permanently driven rear axle and the
front axle by means of the electronically
variable multi
­plate clutch.
The status of the vehicle is continuously
monitored so that it is possible to respond
to different driving situations. Sensors
are used to collect a range of data, includ ­
ing the rotational speed of all four wheels,

the lateral and longitudinal acceleration
of the car and the current steering angle. If, for example, the rear wheels begin

to lose traction under acceleration, a
greater proportion of the drive power
is automatically transmit ted to the front
axle by a more positive engagement of
the multi ­plate clutch. In addition, ASR
prevents wheel spin by adapting the
engine’s power output. During cornering,
the optimal level of drive power is dis­
tributed to the front wheels to ensure
excellent lateral stability.

In conjunction with Porsche Stability

Management (PSM), PTM helps to ensure
the perfect distribution of drive power for
optimum traction in most road scenarios,
whether on long straights, through tight
corners, or on surfaces with different
friction coefficients.
Far better than a power struggle
is power interplay.


Porsche Traction Management (PTM).

5455
Temperament

| Chassis and body
“That can’t be done.”
If ever a sentence gave motivation to sports car designers, this is it.

Chassis and body.
A solid identit y tends to be described
with words like stability, directness or
substance. This might sound a lit tle
serious but, when it comes to the chassis
and body, we think that this is entirely
the right approach.
The best example is the engineered
design. Indeed, dynamic per formance
and ride comfort fundamentally depend
on factors such as vehicle weight, body
rigidity, wheelbase, axle construction
and steering. With the 911, we challenged
our engineers to push the boundaries
of what is possible. Chassis control systems make a key

contribution to the 911 driving experience
and thus to the 9 11 i d e n t i t y. T h e se
include Porsche Stability Management
(PSM), Porsche Active Suspension
Management (PASM), which comes as
standard in the 911 Carrera S models,
Porsche Torque Vectoring Plus (PTV Plus).
Porsche Dynamic Chassis Control (PDCC)
is additionally available as an option for
the
9 11 Carrera S models.
Yet, there is still scope for improvement
as far as sport y performance is
concerned. The optional Sport Chrono
Package triggers an adrenaline rush
at the push of a but ton. Dynamic engine
mounts, until now exclusively reserved
for 911 GT and Turbo models, may not be
capable of breaking the laws of physics
but they do succeed in exploiting them
to their own advantage – and yours.

5657
Temperament

| Chassis and body
Engineered design.
The innovative bodyshell of the 911 fulfils
t wo structural design requirements: first,
excellent driving dynamics due to the
body’s extremely high rigidit y; second,
a vehicle weight saving of up to 65 kg
primarily as a result of the intelligent
lightweight construction. To meet the second requirement, we
employed state
­of­ the ­art techniques for
combining various materials in order
to utilise specific material properties
exactly where they are needed.
For the bodyshell, therefore, we used
very thin, but nevertheless extremely
rigid, sheets of steel. Aluminium and magnesium were used extensively in
areas such as the roof, underbody, front
end, doors, rear wings and engine com
­
partment and luggage compartment lids.
Magnesium, which is a particularly light ­
weight material, was also selected for
the cockpit and centre console support
beam and, in the Cabriolet models,
the hood shell elements. Such material efficiency is key to reducing the overall
weight and, as a result, fuel consumption
of the vehicle.
For the driver, this intelligent blend

of materials reduces the weight of the
vehicle and offers a high level of comfort
thanks to excellent vibration ­damping
characteristics and particularly high com ­
posite rigidit y, an increase in dynamic
torsional stiffness of up to 25 % compared
with that of the previous model, and
even
sportier handling despite a further
improvement in the weight to power ratio.
The longer wheelbase improves comfort
as well as straight ­line accuracy and
driving stabilit y at high speeds and in
fast corners.

Front and rear axles.
The independent suspension at the front
features a light weight spring ­strut axle
with longitudinal and transverse links and
cross members that have been refined
for stiffness. Each front wheel is precisely
located, ensuring excellent directional stability, superior handling and reduced
pitching under braking, and the wide
track optimises turn
­in.
The rear axle is equipped with a
motorsport ­derived multi ­link suspension
and chassis subframe. Refined axle
kinematics for improved longitudinal
damping reduce acceleration squat and increase comfort. Light weight spring
struts further enhance agilit y.
The high proportion of aluminium used in
the construction of the axles reduces the
weight of the vehicle and of the unsprung masses, helping to improve fuel economy,
comfort and agility.
Rear axle of the 911 Carrera S
Front axle of the 911 Carrera S
Aluminium
Deep
­drawn steels
Multiphase steels
Super ­high ­strength micro ­alloyed steels
Boron ­alloyed steels

5859
T
emperament
| Chassis and body
Hood.
Our engineers have completely redeveloped
the hood for the 911 Carrera Cabriolet
models. The result is a flexible roof
comprising a glass rear screen and three
individual and integral hood elements,
which are manufactured from magnesium
and covered in fabric. This makes the
hood highly robust and, yet, particularly
lightweight.
Another benefit is that the hood is
smooth and firm. The fabric remains taut
keeping the familiar 911 lines elegant.
A trivialit y? Only if you choose to ignore
the impressively low drag coefficient
of just 0.30 for the 911 Carrera Cabriolet
models. A further feat of Porsche
engineering.
The rear screen is made from glass and
is electrically heated and scratch ­resistant to provide excellent rearward
visibilit y. A rain channel on the hood

carries away water to avoid dripping
when the doors are opened.
Electrically powered, the hood is operat ­
ed using a but ton on the centre console
or via the key remote. It opens or closes
in approximately 13 seconds and remains
operable up to a speed of 31 mph.
The concertina action ensures optimum
protection for the interior lining. The interior hood lining is made from

a heat ­insulating and sound ­absorbing
material. Consistent interior temperatures
and an effective suppression of wind
noise are the perceptible results. Thank ­
fully, however, even the hood’s sound ­
proofing properties are no match for
the resonant Porsche sound.
Open, flexible, independent.
The optimum prerequisites for a long-term relationship.

Cabriolet technology.

6061
Electrically powered wind deflector.
Once again, our engineers have explored
new directions, this time in the wind
tunnel. The 911 Carrera Cabriolet models
are equipped as standard with an
electrically powered wind deflector,
which offers practically draught ­free driving and minimal wind noise with the
top down.
With the 911, fit ting and removing the
wind deflector is now a thing of the past
because it is integrated directly into

the body behind the rear seats. As a
result, it doesn’t take up any extra space in the interior or luggage compartment
and it is ready for use at all times.
For unrestricted open
­top driving pleasure,
the wind deflector extends or retracts in
only 2.0 seconds and can be operated at
speeds of up to 74 mph.
T emperament | Chassis and body
Electrically powered wind deflector

6263
Temperament

| Chassis and body
PASM, the electronic damping control
system, is standard in the 911 Carrera S
models and available as an option for
the 911 Carrera models. It actively and
continuously regulates damping forces
according to driving st yle and road
conditions. In addition, the suspension
is lowered by 10 mm.
PASM has t wo modes, which can be
selected using a separate but ton on
the centre console: ‘Normal’, which is a
blend of performance and comfort, and
‘Sport ’ where the setup is much firmer. Sensors record the body movements

that accompany powerful acceleration,
braking or uneven road surfaces. In the
911, the number of sensors has been
increased for improved data acquisition
and even more ef ficient control interven­
tions. The PASM control unit evaluates
the driving conditions and modifies the
damping force on each of the wheels in
accordance with the selected mode.
In ‘Sport ’ mode, the suspension is set to
a harder damper rating. On uneven roads,
PASM immediately switches to a softer rating, thereby improving contact
bet ween the wheels and the road.

When the road surface improves, PASM
automatically reverts to the original,
harder rating. If ‘Normal’ mode is selected
and the driver’s st yle becomes more
assertive, PASM automatically switches
to a harder rating. Damping firms up,
and driving stabilit y and road safet y are
increased.
The results are tangible: increased
driving stability, improved comfort and
enhanced performance.
No need to let the laws of physics
spoil your fun.

Porsche Active Suspension Management (PASM).PASM sports suspension.
The PASM sports suspension is available
as an option for the 911 Carrera Coupé
models in conjunction with 20 ­inch wheels
and Porsche Torque Vectoring (PTV) or
Porsche Torque Vectoring Plus (PTV Plus). The ride height is 20 mm lower than

with the standard suspension or 10 mm
compared with the PASM suspension.
The springs are harder and shorter, and
the anti ­roll bars on the front and rear
axles are stiffer. The front spoiler lip has
a more sport y geometry, the rear spoiler extends even further. These not only

further reduce lift at the front axle, but
also provide downforce at the rear axle
for improved aerodynamics and even
better performance.
