PORSCHE 911 CARRERA 2011 6.G Information Manual

8485
Our identity is found under the bonnet,
in the design and behind the steering wheel.

Comfort.
Driving a 911 is first and foremost about
the feel of the road in the original,
unadulterated and direct sense. Is it
possible, then, to mention the 911 and
comfort in the same breath? To speak
of systems that make driving ‘more
agreeable’, or of materials that feel
‘pleasant ’ to the touch? Good question.
In reality, however, should anyone really
be forced to choose one over the other?
Let ’s introduce ourselves to the concept
of sport y comfort – dynamic performance
that maintains composure even when
pushed to the extreme.
Interior.
Engineering and st yle – and Porsche
identit y on the inside, as demonstrated
by the ascending centre console. In
t ypical Porsche fashion, the use of form
follows a basic principle: focus on the
driver. This is why the distance bet ween
the gear lever or selector and steering
wheel is extremely short and the operat ­
ing logic, such as that of the t wo ­zone
air conditioning system or the suspension
settings, is clear and uncomplicated.
You shouldn’t have to browse one sub ­
menu after another. You should instead
be able to concentrate on what ’s
important: the road.
Our materials are high qualit y with a
sporty character. The steering wheel rim,
door pulls and armrests are in leather, for
instance. Alcantara has proven its worth
in motorsport and is used as standard
for the rooflining of the Coupé models.
In addition to the choice of Black,
Platinum Grey, Luxor Beige and Yachting
Blue for the interior, there is a wide
range of other personalisation options
available, including two ­tone colour
combinations or special colours and
materials such as carbon, aluminium
or high ­qualit y wood.
Composure | Comfor t

8687
Composure
| Comfor t
Engineering that takes you forward:

the standard Porsche Communication
Management (PCM) with navigation
module and a high ­resolution 7 ­inch
colour touchscreen. PCM is your
control centre for audio, navigation
and communication functions.Instruments.
Sporty not kitsch, practical not fanciful.
The five circular instruments have one
purpose above all: to provide information.
They do so efficiently and accurately.
Their st yling is t ypically Porsche with the
rev counter exactly where you would
expect it to be: in the middle.
Another element of the Porsche identit y
is sound. Fit ted as standard, the Sound
Package Plus offers outstanding perfor
­
mance with a totaloutput of 235 wat ts.
Available as an option is the BOSE
®
Surround Sound System with a total out ­
put of 445 wat ts. In short, it delivers
powerful audio playback combined with
an impressive spatial sound. No system promises such high standards
in the 911, and fulfils them, as the
optional High
­End Surround Sound System
from Burmester
®, the bespoke manufac ­
turer based in Berlin and one of the most
respected premium audio manufacturers
worldwide. With a total output of
821 wat ts, it ensures an incredible audio
experience.
Our patented integral subwoofer enhances
the bass performance of both optional
sound systems and also saves weight.
Typically Porsche.
Ergonomics, st yle and sound. Sports car
technology, intelligently combined.The instrument cluster with a high­
resolution 4.6 ­inch TFT colour screen
provides you with a continuous stream
of data from the on ­board computer,
such as trip mileage, journey time or
average fuel consumption. It also dis ­
plays the navigation system map, delivers
various warnings, including alerts from
the Tyre Pressure Monitoring (TPM)
system, and reminds you of your selected
communication and audio set tings. You
can also use it to carry out individual
vehicle settings.
TFT display
Instruments in the 911 Carrera S with silver ­coloured rev counter

8889
Composure
| Comfor t
In the 911, there is a point at which all
forces come together. The steering wheel
is the most important inter face bet ween
the driver and the sports car. This is

why all available steering wheels feature
a high ­grip steering wheel rim in smooth ­
finish leather and offer outstanding
ergonomics. A full ­size airbag is integrated
as st a n d a rd .SportDesign steering wheel.
As with the sports steering wheel, the
optional SportDesign steering wheel
is adjustable for both height and reach
and, thanks to its grip mouldings, it’s
in safe hands – even on the sportiest
of drives.
Sports steering wheel.
The sports steering wheel is fit ted as
standard and adjusts up to 40 mm for
height and up to 60 mm for reach.
The optional multifunction steering
wheel has four function but tons and t wo thumbwheels for convenient operation

of audio, telephone and navigation
functions, TFT display and on ­board
computer. On request, the steering
wheel is available in smooth ­finish leather,
carbon or mahogany. In conjunction with PDK, the steering
wheels are equipped with t wo ergonomic
gearshift switches enabling you to
change gear directly from the steering
wheel. With the optional Sport Chrono
Package, the steering wheel also features
a display above the airbag module

to inform you whether the SPORT,
SPORT PLUS and Launch Control functions
have been activated.
SportDesign steering wheel
In conjunction with PDK, the steering
wheel features t wo gearshif t paddles.
These are made from a strong alloy and
are ergonomically located behind the
lef t ­ and right ­hand steering wheel
spokes. Pull the right ­hand paddle and
PDK shifts up. Pull the left ­hand paddle and PDK shifts down. When PDK has
been combined with the optional Sport
Chrono Package, the left ­ and right­hand
spokes additionally feature a display
that tells you whether the SPORT,
SPORT PLUS and Launch Control functions
have been activated.
Steering wheel heating.
For increased comfort on cold days,
steering wheel heating is available as
an option for the sports steering wheel
and multifunction steering wheels.
The heating is operated by a but ton
on the rear of the lower steering wheel
spoke.
Multifunction steering wheel in conjunction with PDK Spor tDesign steering wheel with gearshif t paddles
Sports steering wheel

9091
Composure
| Comfor t
Sports seats.
The sports seats in partial leather

are comfortable and provide support
even during performance driving.
They are equipped as standard with
electric seat height and backrest
adjustment and mechanical fore/aft
adjustment.
Sports seats Plus.
Available as an option are sports seats
Plus in leather with electric seat height
and backrest adjustment as well as
mechanical fore/aft adjustment. The side
bolsters on the squab and backrest the steering wheel, lights, wipers, air

conditioning, door locks, PCM, and
instrument cluster.
Adaptive sports seats Plus.
The optional adaptive sports seats Plus
are the ideal combination of sport
and comfort. Finished in leather and
with side bolsters having a firm, sport y
padding, they also feature shoulder
supports for the best possible hold.
Of fering 18 ­way electric adjustment,
the seats can be optimally adapted to
meet your needs in terms of seat height,
squab and backrest angle, squab length,
have a firmer, sportier padding and offer
even bet ter lateral support. The backrest
shell is finished in Silver Grey.
Fully electric sports seats.
If you don’t want to sacrifice sportiness
for comfort, the optional fully electric
sports seats offer fully electric adjustment
of seat height, backrest angle, squab angle,
sq ua b dept h, fore/a f t posi t io n, fou r ­way
lumbar support and even the steering
column.
The integrated memor y package supports
the exterior mirrors and all seat positions
on the driver’s side as well as set tings for
fore/aft adjustment and four ­way lumbar
support. The steering column is also
electrically adjustable.
In addition, the side bolsters on the seat
squab and backrest are independently
adjustable for added comfort on long
journeys and precision lateral support
on winding roads. Also included is the
personal memory for all seat positions
(apart from the side bolsters) and lumbar
support on the driver’s side as well as
the positions of the steering wheel and
exterior mirrors. The memory function
also supports set tings for the steering
wheel, lights, wipers, air conditioning,
door locks, PCM, and instrument cluster.
Sports bucket seats.*
Sports bucket seats featuring a folding
backrest, integral thorax airbag and
manual fore/aft adjustment are available
as optional equipment. The seat shells
are made from glass ­ and carbon­fibre
reinforced plastic (CFRP) with a carbon
surface finish.

Seat heating and ventilation.
Seat heating is available as an option
for all seats (except for sports bucket
seats). Seats are heated in the squab,
the backrest and, for the front seats,
the side bolsters.
The ideal basis for any relationship:
Support as well as freedom.

Seating.In conjunction with seat heating, we can
equip the seats with seat ventilation on
request. A slipstream effect is produced
by active ventilation of the perforated
seat centre and backrest and by passive
aeration at the side bolsters. This evapo ­
rates perspiration moisture and therefore
makes for a dry and pleasant seating
environment, even in hot weather.
Rear seats.
The rear seats are remarkably comforta ­
ble for a sports car and the shelf behind
offers additional storage space. With
the backrests folded down, the luggage
compartment volume in the 911 Carrera
Coupé models increases to 260 litres
and, with a capacit y of 160 litres availa ­
ble, the 911 Carrera Cabriolet models
offer plent y of space for luggage, too.
Child seats.*
ISOFIX child seat preparation including
top tether is available on the rear seats
as standard. On request, we can equip
the front passenger seat with ISOFIX child
seat preparation and integrate an airbag
deactivation feature.
Spor ts bucket seat folded down
Spor ts bucket seat * Child seats must not be used with the spor ts bucket seats.

9293
Composure
| Comfor t
Climate control.
The 911 models feature t wo
­zone auto ­
matic climate control as standard with
an enhanced ventilation effect and sepa ­
rate temperature controls for the driver
and front passenger. The available air
conditioning modes are gentle, normal
and strong.
An active carbon filter traps particles,
pollen and odours and an automatic
air ­recirculation function permanently
monitors air quality, reduces humidity
and switches from fresh to recirculated
air when required. A demister function keeps the windows
clear in cold weather. In warmer weather,
a solar sensor helps the climate control

to detect strong sunlight and automatically
compensate for the comfort of both the
driver and front passenger.
HomeLink® (programmable garage
door opener).
As an option, it is possible to have
a programmable garage door opener
integrated into the overhead console.
At the push of a but ton, it controls up
to three different garage doors, lighting
systems or alarm systems.
Many things have practical qualities.
Even more have a sporty function.
And some are just extremely convenient.

Additional comfort and convenience features.
Light design package.
The optional light design package is both
practical and aesthetically appealing.
It comprises dimmable LEDs in the over ­
head console and in the areas of the
door pulls, door storage compartments,
front foot wells and rear seats.
‘Welcome Home’ lighting.
For convenience, particularly at night,
the ‘Welcome Home’ lighting function
automatically switches on the LED day ­
time running lights for a defined period
whenever the vehicle is opened or
closed using the key remote. A customisable delayed switch
­of f timer
keeps the daytime running lights, the
taillights and, where applicable, the
courtesy lights switched on until you
reach your front door.
Cruise control.
This automatic speed control function is
available as an option. For greater driver
comfort on long stretches of road, cruise
control operates in the 18–149 mph
speed range and is activated using a but ­
ton on the steering column control stalk.
Adaptive cruise control with Porsche
Active Safe (PAS).
1)
Available as an option, this cruise control
function regulates your speed according
to the distance bet ween your vehicle and
the vehicle in front. A radar sensor moni ­
tors the road ahead up to a distance of
200 m. If you have set a cruising speed
but have begun to gain on the vehicle in front because it is driving more slowly,
this is detected by the radar sensor.
The system now reduces the speed

of your vehicle at a maximum rate of
3.5 m/sec
2 by restricting the throt tle
or gently applying the brakes, until
the distance that you have preset is
maintained. Your vehicle will now
continue at a reduced speed. If the
other vehicle decelerates further, adaptive
cruise control will continue to reduce
your cruising speed – even down to a halt.
For additional safet y, if the system
detects that the distance from the

vehicle in front is decreasing, it will also
prepare your vehicle for braking by
precharging the braking system so that
the brake pads are already in light contact with the brake discs. However,

drivers still have to perform heavier
braking themselves.
As soon as the road ahead clears again,
your vehicle will accelerate back up to
the cruising speed originally set.
If your vehicle approaches the vehicle
in front too quickly, Porsche Active Safe
(PAS) will issue audible and visual warn ­
ings. In addition, the system briefly jerks
the brakes and if necessary initiates
target braking, with any braking pressure
applied by the driver being increased
within certain system limits.
Adaptive cruise control display
Radar sensor of adaptive cruise control1) Available from November 2012 at the earliest.

9495
Composure
| Comfor t
Slide/tilt sunroof.
The electrically adjustable slide/tilt sun
­
roof is available as optional equipment
for all 911 Carrera models. It opens out ­
wards so that it does not interfere with
headroom. Another advantage of the
novel design is the large aperture for
increased driving pleasure under the
open sky.
The two ­position net ­type wind deflector
protects against draught and further
reduces wind noise.
Glass slide/tilt sunroof.
The electrically adjustable slide/tilt sun ­
roof is also available in tinted single­
glazed safet y glass. An integral electric
sunblind provides shade from unwanted
bright light. It is available in five different
colours. The design, headroom and aper ­
ture of the glass roof are identical to
those of the regular slide/tilt sunroof. The
only difference is that, even when closed,
the glass sunroof still gives you that
open ­to ­the ­sky feeling.
ParkAssist.
Park Assist is fit ted as standard in the
911 Carrera Cabriolet models and is
available as an option for the 911 Carrera
Coupé models. Featuring four inconspicuous
sensors in the rear end, the system
audibly alerts the driver to the presence
of obstacles detected behind the vehicle.
An intermittent warning tone increases in
rapidit y as the obstacle is approached.
An enhanced version of Park Assist, with
four sensors in the front end, is available
as an option. The audible alert is supple ­
mented by a visual warning in the central
display screen, which shows a graphical
representation of the vehicle from over ­
head.
Exterior mirrors and rear-view mirror.
Electrically adjustable exterior mirrors
are fitted as standard. Electrically folding
exterior mirrors with courtesy lighting
on both sides of the
vehicle are available
as an option. By
illuminating the area in front of the doors, they make it easier to
find your way in the dark.
An auto
­dimming function for the rear ­
view mirror and exterior mirrors, with
an integrated rain sensor for the wind ­
screen wipers, is available as an option.
Luggage compartment.
The luggage compartment volume in the
911 models is 135 litres – 125 litres on
the 911 Carrera all ­wheel ­drive models.
The luggage compartment is fully trimmed
in scratch ­resistant materials.
Roof transport system.
Available as an option for the Coupé
models, the roof transport system in
aluminium is aerodynamically efficient,
very light weight and easy to fit. A range
of at tachments is available, such as a
roof box, a bike carrier or a ski/snow ­
board carrier. Maximum roof load is
75 kg.

9697
Composure
| Comfor t
Porsche Entry & Drive.
With the optional Porsche Entry & Drive,
you can leave your car key in your pocket.
As soon as you grab the door handle

or approach the luggage compartment,
the system automatically checks the
encrypted access code on the key. Once
the key is validated, the door or the luggage compartment lid unlocks. The
engine can then be started and switched
off using the electronic ignition switch.
To lock the vehicle, you simply press the
but ton on the outside of the door handle.
Porsche Entry & Drive then locks the
vehicle and activates the engine immobi
­
liser and steering column lock.
Anti-theft protection.
All 911 Carrera models are equipped as
standard with an immobiliser with in ­key
transponder and an alarm system with
radar ­based interior surveillance. The
system secures the doors, luggage com ­
partment, passenger compartment and
ignition lock.
Audio and communication in the 911
Sound Package Plus.
The Sound Package Plus is fit ted as
standard. The system comprises a
separate amplifier with a total output
of 235 wat ts, seven amplifier channels
and nine loudspeakers, all of which
combine to create the perfect interior
sound experience.
Identity is to do with where you come from.
Sometimes, it’s also to do with where you want to be.

Audio and communication.

9899
Composure
| Comfor t
Porsche Communication Management
(PCM) including navigation module.
Porsche Communication Management
(PCM) is standard for all 911 models.

Powerful, multifunctional and easy to

use, PCM is your control centre for audio,
navigation and commu nication functions. The main feature is the intuitive 7
­inch
touchscreen. Alternatively, you can choose
to operate PCM using conventional rotary
pushbut ton controls. With a maximum of
five list items per page, the screen dis ­
play is very clearly presented. A useful
help function is displayed at the foot of
the screen. Radio functions include up to 42 memory
presets and an FM dual tuner frequency diversit y with RDS, which continuously
scans in the background for the best
signal, and a dynamic autostore.
The DVD ­audio drive plays CDs and audio
DVDs and is MP3 ­compatible. Audio
playback of video DVDs is also supported. A six
­disc CD/ DVD autochanger integrated
into PCM is available as an option.
The standard ­fitted universal audio inter ­
face (AUX) in the glove compartment
enables you to connect your iPod
® or
any audio source. Recharging is also
supported. Once connected, your iPod
®
or USB stick is then conveniently and
safely operated via the PCM, the optional
multifunction steering wheel or the
optional voice control system.
You can download the performance dis ­
play data from the Sport Chrono Package
and data from the electronic logbook
via the USB port. You can also transfer
up to 10,000 tracks in MP3 format to
the internal hard drive (or Jukebox)
1) of
the PCM and play them from there. Pod ­
casts and audiobooks are recognised
and played and cover art is displayed.
Further details are available from your
Porsche Centre.
Universal audio interface
The navigation module in PCM features
a high ­speed hard drive and allows you to
choose bet ween a 2D display and a 3D
perspective. In some regions, it is possi ­
ble to display the terrain (with an overlaid
satellite map) and buildings in 3D. Split
screen mode enables you to view
t wo
functions at once, such as the current

navigation map and a list of symbols that
represent the next driving manoeuvre.
The navigation module also has a dynam ­
ic route guidance function which takes
into account official traffic messages
(TMC) and additional traffic flow sensors
(TMC Pro).
2)
1) Available from November 2012 at the earliest.2) TMC Pro is currently available in Germany, Austria
and Switzerland. Porsche Communication Management (PCM) including navigation module

100101
Composure
| Comfor t
route distance, date, time, starting

location and destination. Data can be
downloaded to a USB stick and evaluated
on your home PC using the soft ware
supplied. The soft ware fulfils all statutory
requirements for automatic logbooks
as specified by the German revenue
authorities.

Telephone module.
The optional quadband GSM telephone
module offers convenience and excellent
reception. By inserting a SIM card directly
into the PCM’s integral SIM card reader,
calls can be made using the hands ­free
facility. For even more convenience, the
Bluetooth
® capability of a mobile phone
can be used to make calls via the SIM
Access Profile (SAP).
1) Once automatic
pairing is complete, the mobile phone’s
aerial is switched off to conserve bat tery
charge and the phone operates via the
car aerial. Depending on the mobile phone
Voice control system.
If you require route guidance, need to
make a phone call or want to listen to the
radio, then why not just say so? Almost
all of the functions of PCM can be con ­
trolled using the optional voice control
system with word ­by ­word input. In the
majorit y of cases, you can simply say
the name of the menu item as seen on
the screen. The voice control system
understands complete addresses when
entered as navigation destinations, as
well as phonebook entries and the names
of radio stations. Even lists can be
browsed by voice command. For added
convenience, there is no need to ‘train’
the system.
Electronic logbook.
An electronic logbook is available for
PCM as an option. It enables automatic
logging on every journey of mileage, model, this gives access not only
to the
numbers on the SIM card, but also to the
phone’s internal memory. Depending on
the phone, it can also be controlled using
PCM, the optional multifunction steering
wheel or the optional voice control system,
without it ever leaving your pocket.
The telephone module also enables you
to establish a Bluetooth
® link with those
mobile phones that only support the
Handsfree Profile (HFP). In this case, the
GSM connection is always established
through the aerial of the mobile phone.
1)
PCM acts as a hands ­free system and
you can leave the mobile phone tucked
a w ay.
On request, a cordless handset for the
telephone module is also available. Stored
in the centre console storage compartment,
it features a display and keypad. However,
the handset cannot be used for Bluetooth®
links established using the Handsfree
Profile (HFP).
Mobile phone preparation.
To enable a Bluetooth® connection for
those mobile phones that only support
the Handsfree Profile (HFP),
1) an optional
mobile phone preparation is available. It
enables you to leave your mobile phone
tucked away. The PCM is able to control
only the basic functions of the mobile
phone. The GSM connection is estab ­
lished through the aerial of the mobile
phone.
1)
TV tuner.
The optional T V tuner is capable of
receiving unencrypted analogue and
digital television broadcasts (DVB ­T)
2)
to provide entertainment bet ween jour ­
neys. For your safet y, the T V picture is
switched off while the car is in motion.
Online services.3)
The free AHA Radio app enables you to
listen to internet radio, news feeds, pod ­
casts and audiobooks on the PCM via
your smartphone. You can also receive
local information, e.g. weather reports,
in the form of
voice announcements.
Points of Interest can be searched for
and then transferred to the navigation
system as destinations.
Internet content
is received via your
smartphone but you
operate every thing from the PCM. Online
services can only be used in conjunction
with the standard ­fitted universal audio
interface (iPhone) or the optional mobile
phone preparation or telephone module
(Android phones). The AHA Radio app can
be obtained from iTunes and the Android
Marketplace.
4)
T V tuner
1) See notes on page 130.2) In MPEG ­2 format.3) Available from November 2012 at the earliest.4) In order to use AHA Radio ser vices with the optional telephone module, the HFP function must be activated
in PCM.

102103
Composure
| Comfor t
The sound of a Porsche is a unique char
­
acteristic, and we’re not referring only to
the engine. The optional BOSE
® Surround
Sound System was specially developed for
the 911 and is therefore perfectly tuned
to the car’s specific interior acoustics.
It has a total output of 445 wat ts and
comprises 8 amplifier channels, 12 loud ­
speakers and a patented integral 100 ­
watt active subwoofer. The combined
effect is a balanced acoustic pat tern that
transforms your 911 into a fast ­moving
concert hall. In combination with Porsche Communica
­
tion Management (PCM), the BOSE
®
Surround Sound System enables audio
playback of DVDs and is thus able to
make full use of the impressive sound
spectrum of 5.1 digital recordings. Of
course, you can still play other audio
sources, such as CDs and MP3s, in stereo
or, at the push of a but ton, in one of
the virtual surround modes generated by
BOSE
® Centerpoint® 2. The BOSE
®­
patented AudioPilot® noise
compensation technology uses a micro ­
phone to continuously measure the
ambient noise inside the vehicle and
adapts music playback instantly and
automatically so that a consistent sound
is maintained – whatever the driving
conditions.
The result is a powerful sound and
captivating 360° acoustic experience.
Cue the applause.
When you are seeking a sporting challenge,
you need the right soundtrack.

BOSE
® Surround Sound System.
