The new 911 Turbo is also
available with an optional high-
performance braking system:
the Porsche Ceramic Composite
Brake (PCCB). Successfully
tested in the toughest endurance
racing, this unique technology
has been further refined for even
greater road performance.The key components in PCCB
are the moulded ceramic discs
(front/rear diameter: 380 mm/
350 mm). The larger front discs
provide greater leverage and
therefore better brake performance.
Thediscsaremadefrom a
specially treated carbon-fibre
compound that is silicated in a
high-vacuum process at 1,700 ºC.
The resulting material is not
only much harder than metal, it
is also more resistant to heat.
Even at high temperatures, the
thermal resistance of the PCCB
disc ensures excellent dimensional
stability. The ceramic material is
totally resistant to corrosion and
offers excellent acoustic damping
properties.The pads are mounted in six-
piston monobloc aluminium
fixed calipers at the front, with
four-piston units at the rear.
The resulting brake forces are
not only extremely high, they are
also exceptionally consistent.
The pedal response is fast andprecise, with only moderate input
required.
The key advantage of PCCB is the
total weight saving over comparable
metal discs of approximately 50 %.
As well as enhancing performance
and fuel economy, this represents
a major reduction in both the
unsprung and rotating masses.
This, of course, produces
additional benefits in terms of
comfort and road-holding on
uneven road surfaces as well as
general handling and agility.
For more information, see thelatest PCCB brochure available
from your Porsche Centre.
· 70 ·· 71 ·The new 911 Turbo |
Safety
PCCB
Porsche Ceramic Composite Brake (PCCB).
When it comes to developing new brake technology,
nothing holds us back.
Page 32 of 61
The 911 Turbo easily complies
with all statutory requirements in
all markets worldwide in respect
of frontal, side, diagonal and rear
impact protection.
The reinforced bodyshell contains
a highly resilient passenger
cell offering exceptional crash
protection. At the front of the
car, the cell is protected by apatented system of longitudinal
and transverse members (1). In
the event of an accident, energy
is absorbed by three separate
load paths, one above the other,
which disperse the force of
impact and minimise deformation
of the passenger cell.The upper section of each door
features additional reinforcements
(4) which enhance the rigidity of
the car. An additional load path
(5) is used to channel energy
through the upper part of the shell
and protect the passenger cell.
In 1985, Porsche began using
super high-strength steel elements
in its door design to provide
greater occupant protection. On
the new 911 Turbo, this integral
reinforcement is made from
robust yet lightweight aluminium.
By increasing the proportion ofaluminium alloys and high-strength
steel, we’ve also increased the
car’s power-to-weight ratio. No less
than 20 % of the new 911 Turbo
is made from aluminium.
As you would expect, the entire
bodyshell structure receives
a highly effective anti-corrosion
treatment. Thirty years ago,
Porsche became the first manu-
facturer in the world to use
a hot-dip galvanised steel shell.
This exacting proces s is
absolutely fundamental to the
legendary durability of our cars.It also
ensures a consistently
high standard of crash protection,
even after many years on the
road. To underline our confidence
in this exceptional build quality,
the 911 Turbo comes with a
ten-year anti-corrosion warranty,
three-year paint warranty and
two-year warranty on the car as
a whole.
· 72 ·· 73 ·The new 911 Turbo |
Safety
1
1
1
5
4
3
3
12
Sheet steel
Tailored blanks
High-strength steel
Super high-strength steel
Aluminium Passive safety: bodyshell structure.
Adding strength, reducing weight.
Additional features include an
ultra-rigid bulkhead cross-member
(2) made from super high-strength
steel. This element is designed
to absorb impact forces from the
longitudinal members and thus
protect the front footwells. In a
minor collision, a system of easily
replaceable impact absorbers
(3) prevents costly damage to the
underlying bodyshell structure.
Page 33 of 61
Complementing the front airbags
is the latest generation of Porsche
Side Impact Protection (POSIP).
This comprehensive package
includes two additional airbags for
each front seat: a thorax airbag
in the side of each backrest,
and a head airbag located in each
door. Each side airbag has anapproximate volume of 8 litres,
ensuring maximum protection
over the entire seat adjustment
range. Also incorporated within
the POSIP package are side-
impact protection beams in the
doors.Other standard features include
integral head restraints, an
energy-absorbing steering column,
height-adjustable three-point seat
belts with pre-tensioners and
force limiters, energy-absorbing
structures in the dashboard area
and flame-retardant materials
throughout the interior. The new 911 Turbo has a unique
passive protection system
featuring six separate airbags.
The full-size front airbags for
driver and front passenger have
a two-stage inflation capability.
With this technology, the
deployment of each airbag is
dependent on the force and
nature of the accident (e.g.,
frontal or diagonal impact). In
a low-speed crash, the airbag
is only partially inflated, thereby
minimising discomfort to the
occupants.
The airbag control unit is located
in the centre tunnel where it
receives additional information
from a pair of impact sensors near
the headlights. This arrangement
enables faster and more accurate
evaluation of impact forces in the
event of a crash.
· 74 ·· 75 ·The new 911 Turbo |
Safety
Passive safety: airbags.
Added side protection with intelligent deployment.
Page 34 of 61
· 76 ·· 77 ·The new 911 Turbo |
Comfort
Uncompromising engineering deserves
to be appreciated.
Which is why we never compromise
on comfort.
Comfort
Page 35 of 61
Porsche Communication
Management (PCM). This
comprehensive system features
satellite navigation with a
separate DVD drive in the
luggage compartment for
the single navigation disc.
The one-touch switches on the
centre console are logically
positioned for optimum ease of
use. All instruments are perfectly
placed within the driver’s field of
vision. The air-conditioning system
is fully automatic and features a
highly effective active carbon filter.
This added convenience gives
you greater freedom to enjoy the
driving experience.
The tinted front glass and generous
rear screen offer excellent fore-
and-aft visibility. The front side
windows have a water-repellent
finish, which automatically
disperses moisture and dirt.
The result: optimum visibility in
poor weather conditions.
Instruments.
The classic arrangement of five
round instruments provides a
clear overview of all key information.
The digital display in the centre-left
dial (speedometer) provides main
and trip odometer readings. The
central rev counter, featuring the
‘turbo’ logo, includes the standard
on-board computer display.
This multi-purpose field contains a
permanent digital speedometer
as well as the following optional
information: boost pressure,
average speed, average fuel
consumption, tyre pressure,
current radio station, navigation
instructions and remaining range
till empty. When ‘Sport’ mode
is selected on the optional Sport
Chrono Package Turbo, the
temporary increase in torque is
clearly indicated using an arrow
symbol in the boost pressure
display. The third display, in the
centre-right dial, contains a
clock and external temperature.
The dot-matrix technology used in
each of these displays provides
a high resolution for icons and
text. Design and legibility are
further enhanced with brilliant
white backlight illumination.
· 78 ·· 79 ·The new 911 Turbo |
Comfort
Interior.
For the pure enjoyment of performance.
The passenger compartment in the
new 911 Turbo is another example
of uncompromising design. As you
would expect, it offers the highest
standards of ergonomics, comfort
and quality. The seats, dashboard,
doors and rear side panels are
finished in leather as standard. Atthe centre of the cockpit is a new
gear lever design that’s exclusive
to the new 911 Turbo.
Other standard features include
a three-spoke sports steering
wheel offering 40 mm of
adjustment for both height and
reach. A three-spoke multi-function
steering wheel – available as
optional equipment – provides
direct access to audio, navigation
and (if fitted) telephone functions.
The standard audio package
is the latest evolution of
Page 36 of 61
· 80 ·
Sports seats.
Available as a no-cost option,
this stylish design offers firmer
upholstery than the standard
seat as well as higher side
bolsters on the backrest and
squab for added lateral support.
The fore/aft position and height
are manually adjustable, while the
backrest is electrically controlled.
Adaptive sports seats.
This alternative seat option offers
full electric adjustment of fore/aft
position, squab height, backrest
angle, lumbar support, squab side
bolsters and backrest side
bolsters. By varying the side
bolsters, you can increase
occupant comfort on long-
distance journeys or maximise
support on the racetrack. A driverThe generous rear storage area
offers valuable loadspace, even
when the seats are in use. Fold
the backrests down and there’s
an additional 190 litres of luggage
space.
Child seats.
The front passenger seat has
been specially designed to carryan ISOFIX-compatible child seat.
For the necessary preparation
– including airbag deactivation –
see the Porsche Tequipment
catalogue for the new 911 Turbo.
A comprehensive range of
child seats, also from Porsche
Tequipment, is available at your
Porsche Centre.
· 81 ·The new 911 Turbo |
Comfort
Standard seats.
The standard seats feature full
electric adjustment of fore/aft
position, height, backrest angle,
squab angle and lumbar support.
Comfort is assured thanks
to excellent lateral support, a
lowered seat base offering
greater headroom, and a
dedicated spring system that
is specifically designed to
match the car’s suspension
characteristics. The high side
bolsters provide excellent lateral
support, without restricting
occupant comfort. The generous
range of adjustment options
means that virtually every driver
can find the ideal position,
regardless of physical build. A
memory function stores personal
preferences for seat position,
lumbar support and exterior
mirrors.
· 80 · Standard seat (full electric adjustment)
Adaptive sports seat
Rear seat and storage area
memory function includes the
exterior mirror position on
the driver’s side as well as all
seat settings except for the
squab and backrest side bolsters.
Rear seats.
The folding rear seats are
surprisingly comfortable for a car
of this performance capability.
Page 37 of 61
Storage compartments.
The new 911 Turbo is not only
a powerful performer, it is also
highly versatile. Added to the
comfort and ergonomics of the
interior are a range of practical
features.
The storage compartments in the
doors and centre console feature
matching upholstered lids. These
are positioned at precisely the
same height to form comfortable
armrests on longer journeys.
Beneath the front passenger
airbag, behind a fold-down trim,
are two cupholders for driver and
front passenger. Beneath the
cupholders is a lockable glove
compartment featuring integral
CD storage.
Two 12 V sockets (including the
cigar lighter) provide power for
electrical equipment. An optional
fire extinguisher is also available,
installing neatly out of sight but
always within reach directly ahead
of the driver’s seat.
‘Welcome Home’ lighting.
This standard function provides
generous illumination via the
foglight units when the key remote
is used to lock or unlock the
car. As the name suggests, it is
particularly convenient when
returning home after dark. On
vehicles equipped with the optional
Sport Chrono Package Turbo, the
timing delay can be programmed
via the Porsche Communication
Management (PCM) terminal.
ParkAssist.
This optional parking aid is auto-
matically enabled whenever you
select reverse gear. Move too
close to a stationary object and
a warning signal is emitted.
Continue to reverse and the tone
increases in frequency. The
ultrasonic sensors are neatly
concealed within the rear apron
moulding.
Cruise control.
This optional system is available
from 30 to 240 km / h
(20 – 149 mph) and can even be
used in first gear. The system is
operated using a separate control
stalk on the steering column.
HomeLink®.
This optional garage-door opener
is integral to the car and offers
full remote control for up to three
garage doors. It can also be used
with gate, home lighting and alarm
systems. Compatible with virtually
all garage and gate systems.
Rear wiper.
Also available as an option, the
rear wiper system includes a flat
and streamlined ‘aero’ blade which
blends with the exterior of the car.
Interior and exterior mirrors.
All three rear-view mirrors on the
new 911 Turbo feature auto-
dimming glass as standard. The
interior mirror also includes an
integral rain sensor for the front
wiper system.
Slide /tilt sunroof.
This electrically operated and
steplessly adjustable slide/tilt
sunroof is also available as an
option. In the tilted position,
it offers comfortable ventilation
of the passenger compartment,
even when travelling at high speed.
· 82 ·· 83 ·The new 911 Turbo |
Comfort
Glove compartment
Slide/tilt sunroof
Page 38 of 61
· 85 ·The new 911 Turbo |
Comfort
Luggage compartment.
In addition to the loadspace in the
rear seat area, the new 911 Turbo
has a 105-litre front luggage
compartment. The bulkhead
panelling conceals the standard
audio amplifier for the BOSE
®
Surround Sound System, as well
as the DVD drive for the
navigation module. The optional
CD autochanger is installed on the
right-hand side of the compartment
(looking forwards). The entire
compartment is lined with high-
quality, scratch-resistant
materials.
Roof transport system.
The optional roof transport
system is made from lightweight
aluminium, making it extremely
easy to fit. It is also styled to
match the exterior design as well
as the car’s aerodynamics. The
basic load-carrying bars can
be
combined with a range of
attachments from Porsche
Tequipment, including a roof box
and carriers for bikes, snowboards
and skis. Maximum roof load is
75 kg.
Anti-theft protection.
Standard anti-theft equipment
on the new 911 Turbo includes
an engine immobiliser with in-key
transponder. The comprehensive
alarm system features contact-
sensitive exterior protection and
radar-based interior surveillance.
Vehicle tracking system.
Optional protection includes a
factory-fitted preparation enabling
future installation of a vehicle
tracking system from Porsche
Tequipment. In the event of theft,
the system enables remote
tracking of the stolen vehicle
across most European countries.
Also requires special wiring
loom and higher capacity battery.
· 84 ·Luggage compartment
Roof transport system
Page 39 of 61
Satellite navigation.
The PCM system on the new
911 Turbo includes satellite
navigation as standard. The DVD
drive for navigation data is
neatly concealed in the luggage
compartment. The standard
CD drive in PCM can therefore be
used exclusively for audio CDs.
Special features on the GPS
navigation module include
dynamic route guidance with TMC
(Traffic Message Channel).
This function provides a visual
overview of traffic congestion as well as automatic calculation
of alternative routes. Another
feature of the navigation module
is the easy-to-use menu structure.
After you enter your destination,
the system automatically
establishes your current position
before guiding you there via the
best possible route.
The DVD drive offers faster data
access, and therefore faster
route calculation, than equivalent
CD systems. The number of zoom
levels has also been increased
to make map reading easier.
Navigation data for most European
countries is included on a
single DVD.
Navigation expansion module.
In combination with PCM, this
optional expansion module
enables automatic navigation
along a previously recorded route
(reverse route navigation) as
well as compass and GPS-based
navigation in regions not covered
by your navigation DVD.
The standard 911 Turbo is
equipped with Porsche
Communication Management
(PCM) featuring a high-resolution
colour display. PCM is an
integrated system combining
radio, CD player, audio controls,
on-board computer and satellite
navigation, as well as optional
CD autochanger, telephone
module and electronic logbook.
The integral CD drive is also
compatible with MP3 audio files.
In addition, PCM provides direct
control of the performance display
and memory function included
with the optional Sport Chrono
Package Turbo.Radio features include 20 FM
and 20 MW presets, Dynamic
AutoStore, and RDS two-tuner
frequency diversity. The two-tuner
function uses one tuner to play
the selected station and another
to search for the best possible
signal throughout your journey.
· 86 ·· 87 ·The new 911 Turbo |
Comfort
Porsche Communication Management (PCM)
Porsche Communication Management (PCM).
Want to make the most of every journey?
Let PCM show you the way.
Page 40 of 61
Antenna diversity.
The PCM package includes four
separate antennae which are
discreetly incorporated within the
windscreen glass. This simple
solution enables the twin-tuner
radio system to find the strongest
possible signal, thereby enhancing
FM reception.
On-board computer.
The PCM computer offers a wide
range of information, including
average fuel consumption, average
speed, range till empty, journey
time and external temperature.
It can also be used to view data
from the optional Tyre PressureMonitoring (TPM). The computer
is operated using a separate
control stalk, displaying key infor-
mation in the central instrument
dial. The same control stalk
is used to operate the timing
functions in the optional Sport
Chrono Package Turbo.
Electronic logbook.
This optional addition to PCM
enables automatic logging on
every journey of mileage, route
distance, date and time as well as
starting location and destination.
Data can be downloaded from
PCM via an infrared port and
processed on a computer using
software included with the
package. This easy-to-use option
fulfils all the requirements for
automatic logbooks as specified
by the German revenue authorities.
Telephone module.
The optional GSM telephone has
a 12-digit keypad and a hands-
free facility offering excellent callquality. The hands-free microphone
is located next to the steering
column and is ideally positioned
for the driver. The telephone
system supports SMS (text)
messaging as well as card-free
calls to emergency services. An
optional passive (keyless) handset
with leather-trimmed console
enables clearer communication
as well as greater privacy when
making a call.
CDC-4 CD autochanger.
This optional CD autochanger has
a total capacity of six audio
CDs and installs beneath a panel
in the luggage compartment.
An autochanger preparation is
included as standard.
· 88 ·· 89 ·The new 911 Turbo |
Comfort
Passive (keyless) handset
