PORSCHE 911 TURBO 2004 4.G Information Manual
Manufacturer: PORSCHE, Model Year: 2004, Model line: 911 TURBO, Model: PORSCHE 911 TURBO 2004 4.GPages: 61, PDF Size: 2.14 MB
Page 41 of 61
The BOSE®Surround Sound
System has a unique acoustic
presence. Just like the new
911 Turbo. Which is why we chose
to develop them together as a
single, integrated whole.
The standard BOSE®Surround
Sound System in the new
911 Turbo has a nominal output
of 325 Watts. Power is supplied
by a seven-channel MOST
®-based
digital amplifier, featuring
5 x 25-Watt linear amps and
2 x 100-Watt switching units.
MOST®(Media Orientated
Systems Transport) is a
fibre-optic bus network offering
fast data transfer and perfect
signal quality.
A total of 13 loudspeakers,
including active subwoofer and
centerfill speaker, create a unique
sound at all four seat positions
that complements the driving
experience. The balanced, lifelike
and crystal-clear sound is
the product of numerous audio
technologies.
BOSE
®Surround Sound uses
independent channels at front and
rear to create a push-button
panorama of space and sound.
Adding to this experience is
the patented BOSE
®Centerpoint®
technology, which can split
even stereo recordings into five
separate channels. These are
then passed to selected speakers
with the aid of BOSE®
SurroundStage™ signal
processing.
acoustics of the new 911 Turbo.
The dynamic loudness function
offers a considerable
improvement over conventional
loudness circuitry. By enhancing
the lower frequencies in low-
volume sound, it actively
compensates for the reduced
sensitivity of the human ear at
the lower end of the audio
spectrum. Another important
feature of the BOSE
®Surround
Sound System is AudioPilot
®
Noise Compensation Technology.
Using a microphone in the
dashboard, AudioPilot®monitors
the sound in the cockpit and
automatically compensates forany ambient noise. The result is
a clearer and more consistent
sound, with no need for manual
adjustment.
BOSE®and Porsche: two
legendary sounds, perfectly
matched in the new 911 Turbo.
· 90 ·· 91 ·The new 911 Turbo |
Comfort
2.5-cm Neodym high-range speakers
8.0-cm Neodym mid-range speaker
20.0-cm Nd®low-range speaker
2.5-cm Neodym high-range speaker
8.0-cm-Neodym mid-range speaker
System electronics
7.0-cm mid-range
centerfill speaker
AudioPilot®microphone2 x 13.0-cm low-range speakers in 14-litre
bass reflex enclosure with TSM switching amplifier
Mid-range speaker in door
BOSE®Surround Sound System.
One powerful sound experience meets another.
Extensive equalisation circuitry
ensures perfectly tailored sound
in every situation.
Since the system was developed
in conjunction with the car, all
sound output, across the entire
frequency spectrum, is custom-
engineered to the unique interior
Page 42 of 61
· 92 ·· 93 ·The new 911 Turbo |
Environment
We’ve always believed that less is more.
Which is why we make the most of every resource.
Environment
Page 43 of 61
At Porsche, we’re exploring every
possibility to improve the environ-
mental compatibility of our cars:
modern materials, reduced fuel
consumption, cleaner emissions,
fewer pollutants and better
recyclability. This commitment is a
Porsche tradition that began in
the 1960s. With the latest evolutionof the 911 Turbo, the rewards are
even greater than ever.
Exhaust emission control.
Combine engineering expertise
with a commitment to the
environment and the resulting
benefits are twofold: exceptional
performance and lower emissions.
One of the cleanest sportscars
in the world today, the new
911 Turbo easily complies with
both the stringent Euro 4 standard
in the European Union as well
as LEV II regulations in the United
States.The technologies used to achieve
this compliance include twin
‘lambda’ or oxygen sensors for
each of the two cylinder banks.
One pair of sensors is used to
measure the levels of oxygen in
each of the twin exhaust tracts.
An additional pair of sensors –
again, one in each tract – enablethe engine management system
to monitor the efficiency of the
catalytic converters.*
Recycling.
Lightweight construction, long-
term durability, exceptional
recyclability: just three of the
techniques employed by Porsche
to improve the environmental
compatibility of our cars.
On the new 911 Turbo, we’ve
used weight-saving design and
lightweight materials to achieve
excellent fuel economy.
All materials and manufacturing
processes have been carefully
selected and specifically refined
to reduce any impact on the
environment. A prime example is
the twin exhaust system, which is
made entirely from stainless steel.
All lightweight materials are easily
recyclable, while the variety ofsynthetics has been significantly
reduced. Recycled plastics are
used in every area of the car
where our exacting specifications
allow. To simplify processing, all
materials are labelled for separate
recycling. Approximately 85 % of
today’s 911 Turbo is compatible
with current recycling techniques.
Water-based paints are used
throughout the car, thus reducing
the need for chemical solvents in
both production and subsequent
servicing. Other harmful materials
omitted from the vehicle include
asbestos, CFCs, and components
manufactured using CFCs.
The result is a car in which
environmental protection is an
integral part of the overall design.
· 94 ·· 95 ·The new 911 Turbo |
Environment
* Not in markets with leaded fuel.
The 911 Turbo is dedicated to performance.
Also with respect to the environment.
Page 44 of 61
Servicing.
Longer service intervals are not
only easier on resources, they
also reduce ownership costs. The
new 911 Turbo has very modest
servicing requirements of 18,000
miles or every two years (standard
service) and 36,000 miles or
every four years (major service).
The replacement intervals for
parts and fluids have also been
significantly extended: engine
oil and filter every 18,000 miles,
air filter every 36,000 miles,
spark plugs every 36,000 miles
or four years, and fuel filter every
56,000 miles.
Noise.
The new 911 Turbo complies with
all noise regulations worldwide.
Instead of resorting to engineencapsulation, we’ve eliminated
noise at source: engine com-
ponents are more rigid, moving
parts are lighter, and tolerances
have been reduced to a minimum.
High-efficiency silencers in durable
stainless steel help to minimise
noise throughout the life of the
car. All that remains, both inside
and out, is the famous Porsche
sound.
Fuel system.
Key developments in the fuel
supply system include a further
reduction in the evaporation of
hydrocarbons. This is achieved
through a combination of active
carbon filter and specially coated
fuel tank. All fuel lines are made
from robust aluminium, while
those carrying vapours use multi-
layer plastic.
· 96 ·· 97 ·The new 911 Turbo |
Environment
Page 45 of 61
· 98 ·· 99 ·The new 911 Turbo |
Personalisation
Our only limits:
The ones that you set.
Personalisation
Page 46 of 61
· 100 ·· 101 ·The new 911 Turbo |
Personalisation
Colours.
The 911 Turbo is a powerful
expression of character and
individuality. One of the most
important considerations in this
respect is, of course, your choice
of colour. Exterior options range
from four solid and eight metallic
colours to five special paint
finishes. These can be combined
with a choice of nine interior
colours as well as three different
two-tone combinations.
If you cannot find the colour you
require, we can usually prepare
it for you. After all, when you
choose a car as special as the
new 911 Turbo, it should look
exactly how you want it to.
To see the colours as they
appear on the car, visit
www.porsche.com and use the
Porsche Car Configurator.
Page 47 of 61
Black
· 102 ·· 103 ·
Solid exterior colours.*
Guards Red
Carrara White
Speed Yellow
Basalt Black Metallic
Metallic exterior colours.*
Arctic Silver Metallic
Midnight Blue Metallic
Carmon Red Metallic
Atlas Grey Metallic
Meteor Grey Metallic**
Cobalt Blue Metallic
Forest Green Metallic
Slate Grey Metallic
Special exterior colours.
GT Silver Metallic
Lapis Blue Metallic
Lagoon Green Metallic
Dark Olive Metallic
* Solid and metallic colours are all no-cost options.
** Introduction planned for 08/2006.
Page 48 of 61
· 106 · · 105 · · 104 ·
Black
Standard interior colours.
Stone Grey
Sand Beige
Palm Green
Ocean Blue
Leather/soft-touch paint.1)
Black
Stone Grey
Sand Beige
Palm Green
Ocean Blue
Carpet.
Black
Stone Grey
Sand Beige
Palm Green
Ocean Blue
Rooflining.2)
Black and Terracotta6)
Two-tone interior.5)
Black and Stone Grey7)
Black and Sand Beige7)
Leather/soft-touch paint.
Terracotta
Stone Grey
Sand Beige
Carpet.
Black
Black
Black
Rooflining.2)
Terracotta
Special interior colours.
Cocoa
Leather/soft-touch paint.3)
Terracotta
Cocoa
Carpet.
Black
Black
Rooflining.2)
Dark Grey4)
Natural leather interior.
Natural Brown3)
Leather/soft-touch paint.
Dark Grey
Natural Brown
Carpet.
Black
Black
Rooflining.2)
See price list for recommended colour combinations.
1)Soft-touch paint in interior colour, film finish in interior colour on sun visors and inner door-sill guards.2)Rooflining in Alcantara.3)Soft-touch paint in interior colour, black film finish on sun visors and inner door-sill guards.4)Black soft-touch paint, black film finish on sun visors and inner door-sill guards.5)Black leather finish on following surfaces: dashboard upper section including instrument shroud, dashboard forward section including
airbag cover, steering wheel rim and airbag module, door upper panel, rear side panel (upper section), A-pillar/windscreen top trim,
B-pillar trim and C-pillar trim. All other surfaces finished in selected interior colour.
6)Soft-touch paint in interior colour or black, black film finish on sun visors and inner door-sill guards.7)Soft-touch paint in interior colour or black, black film finish on sun visors, film finish in interior colour on inner door-sill guards.
Page 49 of 61
· 109 ·The new 911 Turbo |
PersonalisationThe new 911 Turbo |Personalisation
OptionI no. Page
• Special colours•
•Code 103
• Colour to sample
• •Code
• Deletion of model designation
W498
• ParkAssist (parking aid at rear)
• •635 82, 109
• Rear wiper w 425 83
• Grey top tint on windscreen
• •567
• Electric slide/tilt sunroof
• •650 83
• Side skirts painted
• •XAJ 108
• Roof transport system
• •549 84
· 108 ·
The new 911 Turbo has a
comprehensive standard
specification. It also offers
exceptional scope for your
own personalisation ideas.
With the wide range of options
presented here, you can make
the new 911 Turbo unique.
Combined, they enhance the
individuality of your Porsche– inside and out – as well as
its performance and comfort.
Over the following pages, you’ll
find the full range of options listed
by category. For more information
on individual items, please refer
to the 911 Turbo price list.
For the ultimate in personalisation
for the 911 Turbo, ask about thePorsche Exclusive programme
of factory-fitted modifications.
You can also continue to
enhance your car with Porsche
Tequipment aftermarket
accessories.
For more information, please
contact your Porsche Centre.
· 107 ·
911 Turbo with PCCB
Exterior.
• •extra-cost option W no-cost option
For more information on optional equipment, please refer to the 911 Turbo price list.
We’ve realised many dreams with the new 911 Turbo.
Now you can realise yours.
911 Turbo with side skirts painted
ParkAssist Porsche Ceramic Composite Brake (PCCB)
OptionI no. Page
• Tiptronic S•
•249 46
• Porsche Ceramic Composite Brake (PCCB)
• •450 70, 109
• Sport Chrono Package Turbo
• •640 60
• Short shifter
• •XCZ
• Limited-slip rear differential (mechanical)
• •220 56
• Wheels painted in exterior colour
• •XD9
• Stainless steel tailpipes, chrome-plated
• •X54
Engine, transmission and chassis.
Page 50 of 61
Instrument dials in exterior colour (Speed Yellow)
· 110 ·· 111 ·
OptionI no. Page
• Sports seat backrests painted•
•XSA
•
Seat heating• •342
•
Seat belts in Silver Grey/Guards Red/• •XSH/XSX/
Speed YellowXSY
• Rear centre console painted•
•XME
•
Fire extinguisher• •509 82
• Sports-style footrest (only available in LHD markets)
• •XXZ 110
• Floor mats with nubuck edging and embroidered Porsche logo
• •810
(front mats only)
Interior.
OptionI no. Page
• HomeLink®(programmable garage-door opener)•
•608 83
• Cruise control
• •454 83, 110
• Instrument dials in interior colour* Sand Beige
• •XFD
• Instrument dials in exterior colour*
• •XFH/XFJ 111
Speed Yellow/Carrara White
• Preparation for vehicle tracking system*
• •674 84
•
Sports seatswP77 80
• Adaptive sports seats
• •P01 80
Interior.
* Introduction planned for 07/2006.•
•extra-cost option W no-cost option
For more information on optional equipment, please refer to the 911 Turbo price list.Cruise controlSports-style footrest
