Replacingbulbs
Generalinformation
Warning!
Riskofshortcircuit.
Alwaysswitchofftherelevantcomponentswhenchangingbulbs.
Danger!
Riskofseriouspersonalinjuryordeath.TheBi-Xenonheadlightsareunderhighvoltagewheninstalled.
ExerciseextremecautionwhenworkingintheareaoftheBi-Xenonheadlights.
Warning!
Riskofdamage.Bulbsofahigherwattagecandamagethelamphousing.
Onlyusethebulbsspecifiedinthebulbchart.
Newbulbsmustbecleanandfreefromoil,greaseandfingerprints.Therefore,nevertouchbulbswithyourbarehands.Useaclothorsoftpaperwhilereplacingbulbs.
Caution!
Riskofdamagetoheadlightsduetoexcessivetemperaturesandabrasion.
Attachnocoverings(e.g.films,“stoneguards”)intheareaoftheheadlights.
Usesoapywateronlytocleanlightlensesandplasticheadlightlenses.Innocasemaychemicalcleanersorothervolatilecleaningfluidsbeused.
Topreventscratches,donotrubwithadryormerelymoistcloth,tissueorinsectsponges.
PracticalTips,EmergencyService269

Bulbchart
Type,rating
HalogenlowbeamH7,55W
LowbeamwithBi-XenonheadlighPhilips,D2S35W
HalogenhighbeamH9,65W
AdditionalhighbeamwithBi-XenonheadlightH11,55W
FoglightH8,35W
Taillight,rearfoglight,brakelight,taillightP21,4W
Taillight,reflectorP21,5W
ReversinglightP21W
Turnsignallight,frontandrearLLPY21W(long-life)
Doorguard-/curblight/footwelllight/luggagecom-partmentlightW5W
ParkinglightW5WBlue-Vision
LicenseplatelightC5W
SidemarkerLightW3W
270PracticalTips,EmergencyService

Headlights
Generalinformation
Caution!
Riskofdamagetoheadlightsduetoabrasionandexcessivetemperatures.
Donotaffixanycoverings(e.g.“stoneguards”orfilms)intheareaoftheheadlights.
Note
Theheadlightscanmistupdependingonthetemperatureandhumidity.
Toensureoptimumventilation,donotcoverthegapbetweenheadlightandbody(e.g.“stoneguards”orfilms).Removal
1.UnscrewplasticnutA.Detachsidecarpeting.
2.Removerubberplugsfromtheunlockingopening.
3.Placesocketwrench(toolkit)ontheunlockingspindle.Thetongueofthewrenchshouldpointhorizontallytotherear.
4.Turnsocketwrenchapprox.180°A.Theheadlightisunlockedandpushedforwardslightlyduringthisprocess.
5.TurnsocketwrenchbackuntilitispointingverticallydownwardBandleaveinposition.
6.Theheadlightisnowunlockedandcanbepulledforwardoutofthefender.
PracticalTips,EmergencyService271

Installing
1.Insertheadlightintotheguiderailsandpushitfullyintothefender.
2.PushheadlighttotherearandatthesametimeturnthesocketwrenchuntilitpointshorizontallytotherearC.Theheadlightlockingdevicemustperceptiblyandaudiblyengage.
3.Inserttherubberplugintotheunlockingopeningandsecurethecarpet.Checkthefunctionofalllights.
Lowbeam,highbeamandadditionalhigh
beam
Openingthelidoftheheadlighthousing
1.Unscrewthe4screwsA.
2.FirstliftreleasetabB,thenpushbothreleasetabsCupwardsandtakeofflid.
Halogenheadlights:Changingbulbforlow
beam
1.PulloffplugA.
2.DisengagefixingloopB.
3.Replacedefectivebulb.Whendoingso,ensurebulbisseatedproperly.
4.Reassembleinreverseorder.
272PracticalTips,EmergencyService

Bi-Xenonheadlight:Changingbulbforlow
beamandhighbeam
1.Turntheplugcounter-clockwise(bayonetlock)andpullitoff.
2.DisengagebothfixingloopsA.
3.ReplacedefectivebulbB.Whendoingso,ensurebulbisseatedproperly.
4.EngagebothfixingloopsA,pushonplugandturnrightasfarasthestop.
PracticalTips,EmergencyService273

Changingbulbforhighbeamoradditionalhigh
beam(Bi-Xenonheadlight)
1.Turnthebulbholder.Turnitcounter-clockwiseontheleftheadlightandclockwiseontherightheadlight.Takebulbholderoutoftheheadlighthousing.
2.Pullbothplugreleasetabsapart.Pullplugoutofthebulbholder.
3.Replacethedefectivebulbwithbulbholder.
4.Reassembleinreverseorder.
Closinglidofheadlighthousing
1.Pushonliduntilitperceptiblyengages.
2.Fastenlidwiththe4screws.
274PracticalTips,EmergencyService

Turnsignallight
Changingbulb
1.Turnlidcounter-clockwiseandpullitoff.
2.Turnbulbholdercounter-clockwise(bayonetlock).
3.Replacethedefectivebulb(bayonetfitting).
4.Insertlampholderandturnitclockwise.
5.Replacelidandclose.
PracticalTips,EmergencyService275

A-Foglightheightadjustment
Foglight/parkinglight
Changingbulb
Basedonthesystem,arelativelylargeamountofeffortisrequiredtoremovethelightcover.Incaseofdoubt,pleaseconsultaqualifiedspecialistworkshop.WerecommendanauthorizedPorschedealerforthisworkastheyhavetrainedworkshoppersonnelandthenecessarypartsandtools.
1.Unclipthelightcoverusingbothhands,beginningonthecoverunderneaththefoglightandthentowardthecenterofthevehicle.
2.Loosenthe3screwsBandtakeoutthelighthousing.
C-FoglightD-Parkinglight
276PracticalTips,EmergencyService

Changingfoglightbulb
3.Pressthereleasetab(arrow)oftheplugandpullplugoff.
4.Turnbulbholderclockwise(bayonetlock)andremoveholder.
5.Replacedefectivebulb.
6.Insertthebulbholderandturnitcounter-clockwise.
7.Pushonpluguntilitisfelttoengage.
Changingparkinglightbulb
8.Turnbulbholdercounter-clockwise(bayonetlock)andremoveholder.
9.Removedefectivebulbandreplace.
10.Insertthebulbholderandturnitclockwise.
11.Insertbulbhousingandtightenwithth3screwsB.
12.Firstinsertthelightcoverintothesidecut-out1andthenpressdownthecoveratpoints2-7oneaftertheother.Makesurethattheframeiscompletelyclippedin.
13.Checkoperationoflights.
PracticalTips,EmergencyService277

Sidemarkerlight
Changingbulb
1.Removethecapinthewheelhousinglinerwithascrewdriver.
2.Insertthescrewdriverintotheopeninginthewheelhousinglineratrightanglestotheturnsignalhousing.Bypressingwiththescrewdriver,disengagethesecuringspringBofthedirectionindicatorhousing.
3.Swivelouttheindicatorlightandundobulbholder(bayonetlock).
4.Removethebulbfromtheholderandreplaceit.Insertholder.Checkoperationofthelight.
5.Inserttheturnsignal’sretaininglugsAintothesidesectionatthefront.PushinturnsignaluntilthesecuringspringBisfelttoengage.
6.Pressthecapintothewheelhousingliner.
