Taillight,left
Taillight
Changingbulbs
1.Turnlockofthelightcoverapprox.90°andtakeoffcover.
2.Pulloutsidecarpeting.3.Pressthemountingofthelampbracketupwards.Pulltheunlockedlampbracketoutalittle(approx.0.79in./2cm),tipitdownwardsslightlyandthenremoveitfully.
PracticalTips,EmergencyService279
Page 282 of 314
A-TurnsignallightB-ReversinglightC-Rearfoglight,rearlightD-TaillightE-Brakelight,rearlight
4.Replacethedefectivebulb(bayonetfitting).
5.Insertlampbracket.Makesurethatthemountingisfelttoengage.
6.Refitsidecarpeting.
7.Insertthelightcoverintothethreereceptaclesandlockthecover.
8.Checkoperationoflights.
Additionalbrakelight
Thelight-emittingdiodesoftheadditionalbrakelightcannotbereplacedindividually.
HavethedefectivebrakelightreplacedatanauthorizedPorschedealer.
280PracticalTips,EmergencyService
Page 283 of 314
Licenseplatelights
Changingbulb
1.Unscrewbothscrewsandremovethelightlens.
2.Removedefectivebulbfrombetweenthecontactspringsandreplaceit.
3.Reassembleinreverseorder.Checkoperationofthelight.
PracticalTips,EmergencyService281
Page 284 of 314
Example:Frontluggagecompartmentlight
Frontluggage
compartment/footwelllights
Changingbulb
1.Withascrewdriver(arrow),carefullypushoutthelight.
2.Removedefectivebulbfrombetweenthecontactspringsandreplace.
3.Insertthelightintothecut-out,firstfromonesidethenfromtheother.Checkoperation.
282PracticalTips,EmergencyService
Page 285 of 314
Doorguard/curb/rearluggage
compartmentlights
Changingbulb
1.Withascrewdriver(arrow),carefullypushoutthelight.
2.Pullbulbholderoutoflighthousing.Removedefectivebulbandreplace.
3.Installbulbholderandinsertthelight.
PracticalTips,EmergencyService283
Page 286 of 314
AdjustingHeadlights
Adjustment
Pleaseobservethechapter”REPLACINGBULBS”onpage269.
Pleaseobservethechapter”TIREPRESSUREFORCOLDTIRES”onpage299.
Theadjustmentismadewiththevehiclereadytodriveandthefueltankcompletelyfilled.
Thedriver’sseatmustbeloadedbyapersonora165lbs.(75kg)weightandthetirepressuresmustmeettheprescribedvalues.Afterbeingloaded,
thecarmustberolledafewmeterssothatthesuspensioncansettle.
Forcheckingtheheadlightadjustment,theverticalpositionofthecutoffofthelowbeam(seefig.)hastobeprojectedonaverticalscreen(wall)indistanceof24.6ft.(7.5m)fromthefrontlensoftheheadlamp.Thecorrectpositionofthecutoffis2.0in.(5cm)at24.6ft.or7.5m(0.4°)belowahorizontalline,xin.fromgroundtothecenteroftheheadlamplens.
284PracticalTips,EmergencyService
Page 287 of 314
Lateraladjustmentoftheheadlightsshouldbecarriedoutataspecialistworkshopwithanopticaladjustmentunit.
Distance
Visualaimshallbeperformedatnotlessthan24.6ft.(7.5m)(thisvalueisaroundeddownconversionfromthe25-footdistancetypicaloffieldaimusingascreen).The24.6ft.(7.5m)distanceismeasuredfromtheheadlamplenstotheviewingscreen.
Floor
Thesurfaceuponwhichthevehiclerestsisflatandapproximatelylevel.
Screen
Thescreenuponwhichheadlampbeamsareprojectedisperpendiculartothefloorandthevehicle’slongitudinalaxis,flat,uniformlylightincolor,unobstructed,andwideandhighenoughtoaccommodatethevehiclebeampatternstobeaimed.
Thescreenshouldbewideenoughtoprovideatleast3.3ft.(1m)ofspaceoutboardofthevehicle’sheadlampspacing.
Adjustmentscrews
Detachsidecarpetinginluggagecompart-ment.UnscrewplasticnutA.Openthecoveroftheappropriateadjustmentscrew.Theset-tingisadjustedbyturningthehexagonsocketscrewsrightorleft,asappropriate.
PracticalTips,EmergencyService285
Page 288 of 314
B-Headlightverticaladjustment
Verticaladjustment(screwB)
turnclockwise=beammovesdown
turncounter-clockwise=beammovesup
Note
Donotalterthelateraladjustment.
286PracticalTips,EmergencyService
Page 289 of 314
Towing
Generalinformation
Certainstatestatutesandlocalordinancesprohibittowingwithachain,ropeorevenatowbar.Inaddition,damagetoyourvehiclemayresultfromimproperprocedures.ConsultyourauthorizedPorschedealerfordetails.
Vehicletowing
FlatbedtowingisthepreferredtypeoftowingtobeusedonPorschevehicles.Undercertaincircumstances,wheelliftsmaybeusedwhenthevehiclewillnotroll.Thevehiclemustbetowedwithallfourwheelsofftheground,otherwisedamagetothevehiclemayresult.
Towinghook
ThetowinghookAisstoredinthetoolboxintheluggagecompartment.
Caution!
Riskofdamagetothevehicle.
Usethetowinghookonlyforanemergencytoremovethevehicleofftheroad.Thetowinghookistobeusedonlytopullthevehicleontotheflatbed,tractorortowingapparatusifthevehiclewillrollfreely.Undernocircumstancesisthevehicletobesecuredusingthetowinghook.
Neverusethetowinghooktotowthisoranyothervehicle.
Bearinmindthelimitedgroundclearenceofyourcaronunevensurfaces.
PracticalTips,EmergencyService287
Page 290 of 314
Fittingtowinghook
Whenfittingontherearofthevehicle,thelicenseplatemustberemoved.
1.Presstheloweredgeoftheappropriateplasticcoverintothebumperuntilthecoverdisengages.
2.Pullcoveroutofthebumperandletithangbyitsthread.
3.CompletelyscrewinthetowinghookA.
Removingtowinghook
1.UnscrewthetowinghookA.
2.Insertplasticcoverattheloweredgeoftheopening.
3.Foldthecoverupandpressonitsupperedgetoengageitinthebumper.
Whenremovingontherearofthevehicle,thelicenseplatemustbemounted.
Pullingvehicleontoatbed
1.Positionwoodenrampsatthebaseoftheflatbedtoreducetheangleofthepull.
2.Reelinthehoistcableandchecktheundersideofthevehicleforanyinterference.
288PracticalTips,EmergencyService
