Luggage Compartment, Loadspace and Storage
221
iPod, USB and AUXThe iPod, USB and AUX interfaces are located in
the storage box between the front seats.
Note
Do not leave your iPod, USB storage device or an
external audio source in the vehicle for extended
periods of time because extreme ambient conditi-
ons (temperature fluctuations, humidity) can occur
in the vehicle.
iPodUse the supplied connecting cable to connect one
of the iPod models listed:
– iPod 4th generation,
– iPod 5th generation,
– iPod nano,
– iPod nano 2nd generation,
–iPod mini,
– iPod photo or
– more modern iPod models (the operation of
more modern iPods cannot be guaranteed on
PCM).
fPlease refer to the section “iPod” in the sepa-
rate PCM operating instructions.
USBYou can connect a USB storage device to the USB
interface.
Yo u c a n
– play audio data (supported formats: MP3,
WMA and AAC-LC),
– download data from the Sport display and
– download data from the PCM logbook.
fPlease refer to the section “USB” in the sepa-
rate PCM operating instructions.
Note
The LED display of a standard USB storage device
is turned away from the driver when connected to
the USB interface.AUX
External audio sourceYou can connect an external audio source to the
AUX interface. This external audio source is then
operated on the audio source rather than on the
PCM or radio system.
fPlease refer to the section “External audio
source” in the separate PCM or radio opera-
ting instructions.
10_Cayenne_21_KW17.book Seite 221 Donnerstag, 9. April 2009 3:33 15

222
Luggage Compartment, Loadspace and Storage
Storage
Warning!
Unsecured luggage and heavy objects may
come loose during braking, rapid directional
changes or in an accident and cause serious
personal injury or death.
fDo not carry items of luggage or objects in the
passenger compartment unsecured.
fDo not transport any heavy objects in open
storage trays.
fAlways keep the storage trays closed while
driving.
fAlways protect the passenger compartment
with a safety net and a luggage compartment cover.
Note on operation
An unsecured or incorrectly positioned load can
slip out of place or endanger the vehicle occup-
ants during braking, direction changes or in
accidents:
fPlease see the chapter “LOADING
INFORMATION” on Page 231.
Storage options– In the glasses case in the roof console
– In the glove compartment, pen holder
– In the front and rear armrests
– In the drawer underneath the passenger’s seat
– In the storage compartments at the sides of
the luggage compartment
– In the door trim panel
– In the center console, front and rear
– On the back of the front seats
– Coat hook on the rear grab handles
– Under the load compartment floor
– In the front and rear cupholders
Glasses case in the roof consoleSunglasses (for example) can be stored in this
storage compartment.
Opening
fPress button (arrow).
Closing
fClose the lid until it clicks audibly into place.
10_Cayenne_21_KW17.book Seite 222 Donnerstag, 9. April 2009 3:33 15

Luggage Compartment, Loadspace and Storage
223
Glove compartment
Warning!
Risk of injury by the glove compartment lid in
case of an accident.
fKeep the glove compartment closed while driving.
A drawer, designed to hold the welcome kit, is
located in the glove compartment.Opening
fPress button A and open cover.
Locking
fAlways lock button A with the car key to secure
the contents from unauthorized access.
B- Thumb wheel for cooling the glove compartment
C- Holder for pensfRotate thumb wheel B leftwards.
fRotate thumb wheel B rightwards.
Cooling the glove compartment
Switch cooling off
10_Cayenne_21_KW17.book Seite 223 Donnerstag, 9. April 2009 3:33 15

224
Luggage Compartment, Loadspace and Storage
Storage trays in the armrest between the
front seatsTwo storages trays are located in the armrest.
Opening the top tray
fPress button A and lift the cover.Opening the lower tray
fPress button B and lift top tray with the cover
closed.
Storage tray in the rear armrestOne storage tray is located in the armrest.
Opening the storage tray in the armrest
1. Fold down the armrest completely.
2. Press button C and lift the cover.
10_Cayenne_21_KW17.book Seite 224 Donnerstag, 9. April 2009 3:33 15

Luggage Compartment, Loadspace and Storage
225
Drawer underneath the right front seatThere is room for the fire extinguisher in the
drawer underneath the right front seat.
Opening
fLift the unlocking handle and pull out the
drawer.
Closing
fClose the drawer until it clicks audibly into
place.
Side storage compartments in the
luggage compartmentDepending on how the vehicle is equipped, there
is an additional storage option in the left-hand
storage compartment.
The intermediate base can be removed to
increase the size of the drawer.Opening the storage compartment
fPull off the cover on the handle recess.
Closing the storage compartment
fFirst, insert the cover at the bottom and then
close it until it clicks audibly into place.
Caution!
Risk of damage.
fBecause of the heat, the right-hand storage
compartment cannot be used as such in
vehicles that have air suspension with level control and height adjustment.
10_Cayenne_21_KW17.book Seite 225 Donnerstag, 9. April 2009 3:33 15

226
Luggage Compartment, Loadspace and Storage
CupholderYou can place drinks cans and cups in the cup-
holder.
fKeep the cupholder closed while driving.
Warning!
Risk of accident, scalding or damage due to
spilling drinks.
fOnly use cupholder when safe to do so it is.
fOnly use containers which fit.
fNever put overfull containers in the cupholder.
fNever place hot drinks in the cupholder.
Opening front cupholderfOpen shutter A (arrow).
Removing cupholder insertThe cupholder insert can be removed for cleaning.
Removing the insert makes an additional storage
tray available.
fOpen shutter A.
fPress together the cupholder insert at the two
engagement recesses B.
fRemove the cupholder insert.
10_Cayenne_21_KW17.book Seite 226 Donnerstag, 9. April 2009 3:33 15

Luggage Compartment, Loadspace and Storage
227
Opening rear cupholderfPress on the cover of the cupholder (arrow).Closing rear cupholderfClose and engage the cupholder.
AshtrayAshtray, front
Warning!
Danger of fire.
fNever use ashtray for waste paper disposal, as it could pose a fire hazard.
Opening
fPress ashtray lid briefly.Emptying
fMove unlocking button A to the right; the
ashtray insert pops out.
fOnce you have emptied the ashtray, replace
the insert and push it down until it clicks
audibly into place.
10_Cayenne_21_KW17.book Seite 227 Donnerstag, 9. April 2009 3:33 15

228
Luggage Compartment, Loadspace and Storage
Ashtray, rearDepending on how the vehicle is equipped, an
ashtray can be installed in the rear door panels.
Opening
fPress ashtray lid briefly.
Emptying
fOpen ashtray cover and press carefully to the
door trim panel.
The insert is raised slightly.
fRemove and empty insert.
Cigarette Lighter
Warning!
Danger of fire and burning. The cigarette
lighter is ready for use, regardless of the
ignition lock position.
fDo not leave children in the car unattended.
fNever touch the heating element or sides of
the lighter.
fHold the lighter by the knob only.
The cigarette lighter is ready for use regardless of
the ignition lock position.Lighter, frontfPress ashtray lid briefly. Ashtray opens inde-
pendently.
fPress lighter into the receptacle. When the ele-
ment is red hot the lighter jumps back to its in-
itial position.
Lighter, rearfPress lighter into the receptacle (arrow). When
the element is red hot the lighter jumps back
to its initial position.
10_Cayenne_21_KW17.book Seite 228 Donnerstag, 9. April 2009 3:33 15

Trailer Hitch
229 Trailer Hitch
Trailer Coupling.......................................... 230
Loading Information.................................... 231
10_Cayenne_21_KW17.book Seite 229 Donnerstag, 9. April 2009 3:33 15

230
Tr a i l e r H i t c h
Trailer Coupling
Warning!
Risk of accident.
fFollow the operating instructions for the trailer
recommended by the trailer manufacturer.
fDo not modify or repair the trailer coupling.
fBefore having new ADAPTER fitted, find out
from your authorized Porsche dealer about the
current authorization status.
fUse only ADAPTER makes tested and
approved by Porsche.fEnsure that all trailer equipment conforms to
the appropriate classification for total gross
trailer weight and tongue weight.
fPlease see the chapter “WEIGHTS” on
Page 356.
fPlease see the chapter “LOADING
INFORMATION” on Page 231.
RetrofittingHave a trailer coupling retrofitted only by an
authorized Porsche dealer. The dealer is familiar
with the manufacturer's specifications and any
necessary conversion measures.Electrical connectionYour Porsche is equipped with a 7-pin connector A
for the electrical connection to the trailer.
Warning!
Risk of accident. Failure to keep an electrical
adapter clean may result in corrosion and
affect operation of electrical lines, resulting
in possible trailer brake system failure.
fPeriodically inspect and clean adapter as needed.
Hitching trailerfAlways turn off the alarm system before you
attach a trailer.
fFollow the operating instructions for the trailer
recommended by the trailer manufacturer.
fPlease see the chapter “WEIGHTS” on
Page 356.Unhitching trailerIf the trailer is equipped with an overrun brake, do
not unhitch the trailer when its brake is still ap-
plied.
