Parking
241
A-Control switch for door mirror adjustment
C- Passenger mirror settingSwivelling down mirror glass as
parking aidWhen reverse gear is engaged, the mirror glass
on the passenger's side swivels down slightly to
show the curb area.Preconditions
– Vehicle must be equipped with seat memory.
–Control switch A must be turned to position C
(passenger mirror’s setting).
– Reverse gear must be engaged.
Moving mirror to its initial position
The mirror glass swivels to its initial position when:
– The car is shifted out of reverse gear or
– The position of the control switch for the door
mirror setting is changed.
A- Programmable keypad
B- Light-emitting diode for status identification
C- HomeLink transmitterGarage door openerThe garage door opener of your Porsche replaces
up to three original remote controls used to
operate various devices.
You have the option of programming each of the
buttons on the keypad A with functions of the
original remote controls if the original remote
control is compatible with the HomeLink system.
Further information is available from your author-
ized Porsche dealer.
10_Cayenne_21_KW17.book Seite 241 Donnerstag, 9. April 2009 3:33 15

242
Parking
Warning!
Risk of accidents when using the garage
door opener if persons, animals or objects
are within the range of movement of the
equipment that is being operated.
fWhen using the garage door opener, ensure
that no persons, animals or objects are within
the range of movement of the equipment that
is being operated.
fObserve the safety notes for the original remote control.
Notes on operation
fWhen a button is pressed, the transmitter
sends a corresponding signal forwards in
driving direction.
Always position the vehicle in line with the
receiver. Otherwise, range restrictions cannot
be ruled out.
fPlease read the instructions for the original
remote control to find out whether the original
remote control has fixed or changeable code.
fWhen operating and programming the garage
door opener, the ignition must be switched on
and the vehicle must be within range of the
receiver.
Assigning garage door opener signal to
buttonNotes on assigning signals for fixed-code or
changeable code systems
– Several attempts with different distances
between the HomeLink transmitter and the
original remote control may be necessary.
– The original remote control must transmit
continuously during programming. The button
on the remote control must be pressed several
times in the case of remote controls with
standby function.
– The teaching time may be up to 60 seconds.
fPlease refer to the operating instructions for
the original remote control.
Deleting all programmed buttons
fKeep the two outer buttons of keypad A
depressed for approximately 20 seconds until
LED B begins to flash quickly.
All the programmed buttons are deleted.
Note
fBefore selling the vehicle, delete the
programmed buttons of the HomeLink.
10_Cayenne_21_KW17.book Seite 242 Donnerstag, 9. April 2009 3:33 15

Parking
243
Programming a button on the keypad
Caution!
Risk of damage. When programming a gara-
ge door or gate, the door or gate may open
and close several times in quick succession,
causing the motor to overheat.
fUnplug the garage door or gate during the pro-
gramming procedure to prevent the motor from overheating.
1. Press and hold the desired button on the
keypad until light-emitting diode B starts to
flash slowly (may take up to 20 seconds).
Do not release the button before step 3 has
been completed.2. Hold the original remote control approx.
5–30 cm in front of the marked position C.
Make sure that the battery in the original
remote control is new.
3. Press and hold the button on the original remo-
te control until light-emitting diode B flashes ra-
pidly.
The rapidly flashing LED B confirms that the re-
mote control function has been programmed
successfully.
Only release both buttons when LED B flashes.
4. Press the programmed button on keypad A.
If the light-emitting diode B lights up conti-
nuously after programming, this means that
the system is a fixed-code system. Program-
ming is now completed.
If light-emitting diode B again flashes rapidly
for a short time after programming and then
lights up continuously for approx. 2 seconds,
this means that the system is a changeable-
code system. HomeLink must then be synchro-
nized with the receiver of the garage door ope-
ner after programming.
5. Repeat steps 1 to 4 to program the other
buttons.
Synchronization for changeable-code
systems
1. To synchronize the system:
Press the programming button on the receiver
of the garage door opener.
Afterwards, you usually have approx.
30 seconds to initiate step 2.2. Press the previously programmed button on
the keypad three times (for approx. 1 second).
Changeable-code synchronization is now com-
pleted.
3. Repeat steps 1 to 2 to synchronize other
signals to the other buttons.
Note
fPlease consult an authorized Porsche dealer if
you have not been able to successfully assign
signals to the buttons even though you have
carefully followed the instructions in this
section and the operating instructions for the
original remote control. Your authorized
Porsche dealer also has a list of all compatible
garage door opener systems.
Operating the garage door openerfPress the corresponding button on keypad A.
Light-emitting diode B lights up continuously
during signal transmission with fixed-code
systems.
In the case of signal transmission for change-
able-code systems, light-emitting diode B
repeatedly lights up rapidly for a short time
and then lights up continuously for approx.
2seconds.
10_Cayenne_21_KW17.book Seite 243 Donnerstag, 9. April 2009 3:33 15

244
Alarm System and Theft Protection
Alarm System and Theft ProtectionAlarm System and
Passenger Compartment Monitoring ............ 245
10_Cayenne_21_KW17.book Seite 244 Donnerstag, 9. April 2009 3:33 15

Alarm System and Theft Protection
245
Alarm System and Passenger
Compartment MonitoringThis device complies with:
Part 15 of the FCC Rules
RSS-210 of Industry Canada.
Operation of this device is subject to the following
two conditions:
– It may not cause harmful interference, and
– it must accept any interference received inclu-
ding interference that may cause undesired
operation.
Note
fThe manufacturer is not responsible for any
radio or TV interference caused by
unauthorized modifications to this equipment.
Such modification could void the user's
authority to operate the equipment.
Warning!
Any changes or modifications not expressly ap-
proved by Porsche could void the user’s authority
to operate this equipment.Avoiding false alarmsfIf people or animals are remaining in the locked
vehicle or the vehicle is being transported on a
train or ship, for example, the passenger
compartment monitoring system must
temporarily be switched off.
fAlways close the sliding/lifting roof or the
Panorama roof system, and all door windows.
fDo not leave a mobile phone switched on in the
glasses case of the roof console.
fAlways turn off the alarm system before you
attach or uncouple a trailer. The alarm system
could trigger an alarm unintentionally.Switching off the alarm system if it is
triggeredfUnlock vehicle doors with the remote control
or
fSwitch ignition on.
The following alarm contacts are
monitored– Doors
– Engine compartment lid
– Rear lid
–Rear window
– Passenger compartment
fIf one of these alarm contacts is interrupted,
the alarm horn sounds for approx. 30 seconds
and the emergency flashers flash.
After 5 seconds of interruption the alarm is
triggered again. This cycle is repeated ten
times. USA: KR55WK45032
Canada: CAN 267 104 187
10_Cayenne_21_KW17.book Seite 245 Donnerstag, 9. April 2009 3:33 15

246
Alarm System and Theft Protection
Switching onfLock the vehicle.
The alarm system and passenger compart-
ment monitoring system are switched on.
fPlease see the chapter “UNLOCKING AND
LOCKING FROM OUTSIDE” on Page 19.Switching offfUnlock the vehicle.
The alarm system and passenger compart-
ment monitoring system are switched off auto-
matically.
Note on operation
If you unlock the vehicle with the key at the door
lock, you must switch the ignition on (ignition lock
position 1) within 15 seconds of opening the door
in order to prevent the alarm system from being
triggered.
Temporarily deactivating passenger
compartment monitoring systemIf people or animals are remaining in the locked
vehicle or the vehicle is being transported on a
passenger train or ship, for example, the passen-
ger compartment monitoring system must be
deactivated.
When locked again, the passenger compartment
monitoring is activated again. The rocker switch to switch off the passenger
compartment monitoring system is located next
to the driver's seat under the seat belt height ad-
justment.
Note on operation
You can also temporarily deactivate the passen-
ger compartment monitoring system on the multi-
purpose display in the instrument panel:
fPlease see the chapter “SWITCHING OFF PAS-
SENGER COMPARTMENT MONITORING ON
THE MULTI-PURPOSE DISPLAY” on Page 142.
10_Cayenne_21_KW17.book Seite 246 Donnerstag, 9. April 2009 3:33 15

Alarm System and Theft Protection
247
1. Apply the parking brake.
2. Remove ignition key.
On vehicles with Porsche Entry & Drive:
Switch off the ignition.
3. Open the driver‘s door.
4. Press the rocker switch.
The rocker switch symbol lights permanently.
5. Lock the vehicle.
Emergency flasher flashes twice and an acous-
tic signal will sound twice.
The vehicle doors, the rear lid and the rear window
are locked but the doors can be opened from the
inside by pulling the inner door handle twice.
fInform any persons remaining in the vehicle
that the alarm system will be triggered if the
door is opened.
Note on operation:
If the ignition is switched on after pressing the
rocker switch, the passenger compartment
monitoring system is activated again. The symbol
on the rocker switch will flash.Activating the alarm system and the
passenger compartment monitoring system
fUnlock the vehicle and lock it again.
Fault indication
If the monitoring system could not be deactivated
the symbol on the rocker switch will flash (e.g. the
rocker switch is pressed with the ignition on).
For deactivating the passenger compartment
monitoring:
fSwitch off ignition.
fPress the rocker switch.
fLock the vehicle.
A- Light-emitting diode for alarm systemFunction indicationThe locking condition of the vehicle is indicated by
a rapid flashing of the light-emitting diodes A in the
front doors.
The light-emitting diodes go out when the vehicle
is unlocked. Deactivating passenger
compartment monitoring system
10_Cayenne_21_KW17.book Seite 247 Donnerstag, 9. April 2009 3:33 15

248
Alarm System and Theft Protection The passenger compartment monitoring is
switched on
– The light-emitting diodes flash for 2 seconds,
rapidly, then slowly.
The passenger compartment monitoring is
switched off
– The light-emitting diodes flash for 2 seconds,
rapidly, then slowly.
The passenger compartment monitoring is
switched off in the multi-purpose display in
the instrument panel
– The light-emitting diodes flash rapidly for
2 seconds, go out for 28 seconds and then
flash slowly.
Faults of the central locking system and the
alarm system
– The light-emitting diodes flash rapidly for
2 seconds, shine for 28 seconds and then
flash slowly.
ImmobilizerThere is a transponder (an electronic component),
containing a stored code, in each key.
Before the ignition is switched on, the ignition lock
checks the code.
The immobilizer can be switched off and the en-
gine started only using an authorized ignition key.
Switching off the immobilizer
fInsert the ignition key into the ignition lock.
Switching on the immobilizer
fWithdraw the ignition key.
10_Cayenne_21_KW17.book Seite 248 Donnerstag, 9. April 2009 3:33 15

Maintenance and Car Care
249 Maintenance and Car Care
Exercise Extreme Caution
when Working on your Vehicle ..................... 250
Engine Oil .................................................. 251
Checking Engine Oil Level ........................... 252
Topping up Engine Oil ................................. 253
Coolant Level ............................................. 255
Brake-Fluid Level ........................................ 257
Washer Fluid .............................................. 258
Power Steering .......................................... 259
Changing Air Cleaner.................................. 260
Changing Particle Filter ............................... 260
Automatic Transmission Fluid ...................... 260
Manual Transmission Oil ............................. 260
Wiper Blades ............................................. 261
Emission Control System ............................ 263
How Emission Control Works ...................... 264
Fuel Economy ............................................ 265
Operating Your Porsche in other Countries ... 266
Fuel........................................................... 266
Portable Fuel Containers ............................. 268
Fuel Recommendations............................... 269
Fuel Evaporation Control ............................. 270
Car Care Instructions.................................. 270
10_Cayenne_21_KW17.book Seite 249 Donnerstag, 9. April 2009 3:33 15

250
Maintenance and Car Care
Exercise Extreme Caution when
Working on your Vehicle
Danger!
Ignoring the following instructions may cau-
se serious personal injury or death.
fThe engine compartment of any motor vehicle
is a potentially hazardous area. If you are not
fully familiar with proper repair procedures, do
not attempt the adjustments described on the
following pages.
This caution applies to the entire vehicle.
fO n l y w o r k o n y o u r v e h i c l e o u t d o o r s o r i n a w e l l
ventilated area.
fEnsure that there are no open flames in the
area of your vehicle at any time when fuel
fumes might be present. Be especially
cautious of such devices such as hot water
heaters which ignite a flame intermittently.
fBefore working on any part in the engine
compartment, turn the engine off and let it cool
down sufficiently. Hot engine compartment
components can burn skin on contact.
fBe alert and cautious around engine at all
times while the engine is running.
If you have to work on the engine while it is
running, always put the parking brake on and
put the gearshift lever in neutral or the
Tiptronic selector lever in position P or N.fIn particular, be very careful to ensure that
items of clothing (ties, shirt, sleeves etc.),
jewelry, long hair, hand or fingers cannot get
caught in the fan, belts or other moving parts.
The radiator and radiator fans are in the front
of the car.
The fans can start or continue running as a
function of temperature, even with the engine
switched off.
Carry out work in these areas only with the
engine off and exercise extreme caution.
fYour Porsche is equipped with an electronic
ignition system. When the ignition is on, high
voltage is present in all wires connected with
the ignition system; therefore, exercise
extreme caution when working on any part of
the engine while the ignition is on or the engine
is running.
fAlways support your car with safety stands if it
is necessary to work under the car. The jack
supplied with the car is not adequate for this
purpose.
For vehicles with air suspension with level
control and height adjustment switch off level
control.
Please see the chapter “RAISING VEHICLE
WITH THE JACK” on Page 192.fWhen working under the car without safety
stands but with the wheels on the ground,
make sure the car is on level ground, the
wheels are blocked, and that the engine can-
not be started.
Withdraw ignition keys (switch ignition off in
vehicles that have Porsche Entry & Drive).
fDo not smoke or allow an open flame around
the battery or fuel.
Keep a fire extinguisher close at hand.
fIncomplete or improper servicing may cause
problems in the operation of the car. If in doubt
about any servicing, have it done by your
authorized Porsche dealer.
Improper maintenance during the warranty
period may affect your Porsche warranty
coverage.
fSupplies of fluids, e.g. engine oil, washer fluid,
brake fluid or coolant, are hazardous to your
health.
Keep these fluids out of children's reach and
dispose of them in accordance with the appro-
priate regulations.
fSome countries require additional tools and
special spare parts to be carried in your
vehicle. Please make enquiries before driving
abroad.
10_Cayenne_21_KW17.book Seite 250 Donnerstag, 9. April 2009 3:33 15
