PORSCHE CAYNNE TURBO 2005 1.G Owners Manual

Controls, Safety, Instruments
171
Fire ExtinguisherIf the vehicle is equipped with a fire extinguisher, it
is mounted underneath the left or right front seat,
depending on equipment level.
Fire extinguisher under the left front seat
fTo remove the fire extinguisher in case of an
emergency, hold the fire extinguisher with one
hand, and press the PRESS button on the fire
extinguisher holder with the other hand
(arrow).
Fire extinguisher under the right front seat
fTake the fire extinguisher out of the drawer
under the seat.Note
fPay attention to the expiration date on the fire
extinguisher. If the fire extinguisher is used
after its expiration date has elapsed, it may not
function properly.
fFollow the operating instructions for the fire
extinguisher.
fThe functional ability of the fire extinguisher
should be checked by a specialist workshop
every 1-2 years.
fAfter use, have the fire extinguisher refilled.

172
Controls, Safety, Instruments
Storage
Warning!
Unsecured luggage and heavy objects may
come loose during braking, rapid directional
changes or in an accident and cause serious
personal injury or death.
fDo not carry items of luggage or objects in the
passenger compartment unsecured.
fDo not transport any heavy objects in open
storage trays.
fAlways keep the storage trays closed while
driving.
fAlways protect the passenger compartment
with a safety net and a luggage compartment cover.
fPlease observe the chapter “LOADING INFOR-
MATION” on Page 191.
Storage options– In the glasses case in the roof console
– In the glove compartment, pen holder
– In the front and rear armrests
– In the drawer underneath the passenger’s seat
– In the storage compartments at the sides of
the luggage compartment
– In the door trim panels
– In the center console, front and rear
– On the back of the front seats
– Coat hook on the rear grab handles
– Under the load compartment floor
– In the front and rear cupholders
Glasses case in the roof consoleSunglasses (for example) can be stored in this
storage compartment.
Opening
fPress button (arrow).
Closing
fClose the lid until it clicks audibly into place.

Controls, Safety, Instruments
173
Glove compartment
Warning!
Risk of injury by the glove compartment lid in
case of an accident.
fKeep the glove compartment closed while driv-ing.
A drawer, designed to hold the vehicle folder, is lo-
cated in the glove compartment.Opening
fPress button A and open cover.
Locking
fAlways lock button A with the car key to secure
the contents from unauthorized access.
B- Control for glove compartment cooling
C- Holder for pensfRotate thumb wheel B leftwards.
fRotate thumb wheel B rightwards.
Cooling the glove compartment.
Switch cooling off

174
Controls, Safety, Instruments
Storage trays in the armrest between the
front seatsTwo storages trays are located in the armrest.
Opening the top tray
fPress button A and lift the cover.Opening the lower tray
fPress button B and lift top tray with the cover
closed.
Storage tray in the rear armrestOne storage tray is located in the armrest.
Opening the storage tray in the armrest
1. Fold down the armrest completely.
2. Press button C and lift the cover.

Controls, Safety, Instruments
175
Drawer underneath the passenger’s seatThere is room for the fire extinguisher in the draw-
er underneath the right front seat. On vehicles with
DVD navigation, the DVD player is under the right
front seat.
Please observe the chapter “DVD PLAYER UNDER
THE RIGHT FRONT SEAT” on Page 177.
Opening
fLift the unlocking handle and pull out the draw-
er.
Closing
fClose the drawer until it clicks audibly into
place.
Side storage compartments in the
luggage compartmentSpace is provided for the warning triangle in the
right-hand storage compartment.
Depending on how the vehicle is equipped, there
is an additional storage option in the left-hand
storage compartment.
The intermediate base can be removed to
increase the size of the drawer.Opening the storage compartment
fPull off the cover on the handle recess.
Closing the storage compartment
fFirst, insert the cover at the bottom and then
close it until it clicks audibly into place.
Caution!
Risk of damage.
fBecause of the heat, the right-hand storage
compartment cannot be used as such in
vehicles that have air suspension with level control and height adjustment.

176
Controls, Safety, Instruments
CupholderYou can place drinks cans and cups in the cup-
holder.
fKeep the cupholder closed while driving.
Warning!
Risk of accident, scalding or damage due to
spilling drinks.
fOnly use cupholder when safe to do so it is.
fOnly use containers which fit.
fNever put overfull containers in the cupholder.
fNever use hot drinks.
Opening front cupholderfOpen shutter A (arrow).
Removing cupholder insertThe cupholder insert can be removed for cleaning.
Removing the insert makes an additional storage
tray available.
fOpen shutter A.
fPress together the cupholder insert at the two
engagement recesses B.
fRemove the cupholder insert.

Controls, Safety, Instruments
177
Opening rear cupholderfPress on the cover of the cupholder (arrow).Closing rear cupholderfClose and engage the cupholder.
DVD player under the right front seatOn vehicles with DVD navigation, the DVD player is
under the right front seat behind a cover.
Blende öffnen
fPull cover upwards on the handle
(direction of the arrow 1).
fPull out cover towards the front
(direction of the arrow 2).Closing the cover
fInsert the four guide lugs of the cover into their
openings (arrow).
fPress the cover into place.
fPush down the cover until it can be felt clicking
into place.

178
Controls, Safety, Instruments
Rear LidThe equipment features “Porsche Entry & Drive”
and “spare wheel bracket” affect operation of the
rear lid.
fPlease observe the chapter “PORSCHE ENTRY
& DRIVE” on Page 24.
fPlease observe the chapter “SPARE WHEEL”
on Page 299.
Danger!
Risk of poisoning. Exhaust gases can enter
the passenger compartment when the rear
lid is open.
fAlways keep the rear lid closed when the
engine is running.
fAlways keep the rear lid closed while driving.
Unlocking rear lidfPull button A in the driver’s door orfBriefly press button 2 on the remote control.
If the vehicle doors and the rear lid are not
opened, the rear lid will lock automatically after
30 seconds.

Controls, Safety, Instruments
179
Opening rear lidOn vehicles with spare wheel bracket, the bracket
must be swung aside before the rear lid can be
opened.
fPlease observe the chapter “SPARE WHEEL”
on Page 299.
fPress unlocking handle (arrow) and open the
rear lid.
Closing rear lidThe rear lid has a power closing mechanism.
fPull down the rear lid using the closing handle
(arrow) and rest it against the lock.
The rear lid is automatically pulled closed and
locked.
Warning!
Danger of crushing. The rear lid is auto-
matically pulled into the lock and locked.
fMake sure that your fingers are not under the
rear lid.
fKeep foreign objects or limbs away from mov-
ing parts (latch striker) of the power closing
mechanism.
fDo not leave children in the car unattended.
Automatic locking
fPlease observe the chapter “TAILGATE” on
Page 102.

180
Controls, Safety, Instruments
Rear Window
Danger!
Risk of poisoning. Exhaust gases can enter
the passenger compartment when the rear
window is open.
fAlways keep the rear window closed when the
engine is running.
fAlways keep the rear window closed while driving.
fPlease observe the chapter “PORSCHE ENTRY
& DRIVE” on Page 24.
UnlockingfBriefly press button 2 on the remote control.
The rear window can be opened with unlocking
buttonA.OpeningfPress unlocking button Aor
fPress button 2of the remote control for ap-
prox. 2 seconds.
The rear window pops open.ClosingfLower the rear window and press it into the
lock until it can be felt to engage and lock.
Automatic Locking
fPlease observe the chapter “TAILGATE” on
Page 102.
Engine Compartment LidOpening
Caution!
Risk of damage to engine compartment lid or
windshield wipers.
fMake sure that the windshield wipers are not
pulled out forwards when opening the engine
compartment lid.
fAlways switch the windshield wipers off (posi-
tion0) before opening the engine compart-
ment lid.
If the wiper arms are not in position 0, they will
automatically move to this position when the
engine compartment lid is opened. This will
happen even if the ignition is off.
The wiper arms remain in this position until the
lid is closed and the wiper system is switched off and then on again.
