PORSCHE CAYNNE TURBO 2005 1.G Owners Manual

Shifting Gear, Traction Systems
201
Kickdown
The kickdown function is active in selector lever
position D.
fFor optimum acceleration, e.g. when overtak-
ing, depress the accelerator pedal beyond the
full-throttle point (kickdown).
The transmission shifts down depending on the
speed of travel and engine speed.
Upward shifts occur at the highest possible engine
speeds.
These gear-changing speeds remain active until
the accelerator is released to approx. 80% of the
full-throttle position.D - Automatic selection mode (in the off-
road driving program)The functions of selector lever positions Dand M
differ in the on-road program, High Range, and in
the off-road program, Low Range.
fUse selector lever position D for “normal” driv-
ing.
The gears are shifted automatically according
to the accelerator position and speed.
The gears are shifted automatically according to
the accelerator position and speed. The gear-
changing points have been adjusted to achieve the
best possible vehicle control on difficult terrain.Depending on the route profile, the gear-changing
points are shifted towards higher or lower engine-
speed ranges. On steep downhill stretches, up-
ward shifts are prevented until medium engine
speeds are reached (at least 2,500 rpm).
When the car is overrunning, an automatic upshift
does not occur when the engine speed limit is
reached.
Moving off
The car moves off in 1st gear.
Shifting gear on the steering wheel
By shifting gear with the rocker switches on the
steering wheel, you can temporarily change from
automatic selection mode D to manual selection
mode M.
Advantages
– Shifting down on downward slopes (engine
braking).
– Shifting down for brief spurts of acceleration.
– Selecting 1st/2nd or 3rd gear for moving off.
The manual selection mode remains engaged:
– For overrunning
– Depending on lateral acceleration
– When the vehicle is stationary (e.g. at a junc-
tion).The system leaves manual selection mode:
– Automatically after around 8 seconds
(unless car is subject to high lateral accelera-
tion, is overrunning or stationary),
– if you depress the accelerator to kickdown.
Kickdown
The kickdown function is active in selector lever
position D.
fFor optimum acceleration, e.g. when overtak-
ing, depress the accelerator pedal beyond the
full-throttle point (kickdown).
The transmission shifts down depending on the
speed of travel and engine speed.
Upward shifts occur at the highest possible engine
speeds.
These gear-changing speeds remain active until
the accelerator is released to approx. 80% of the
full-throttle position.
Tip on driving
Unlike in the on-road driving program, an auto-
matic upshift is not performed in manual selection
modeM when the engine-speed limit is reached.

202
Shifting Gear, Traction Systems
M - Manual selection mode (in the road
driving program)The functions of selector lever positions Dand M
differ in the on-road program, High Range, and in
the off-road program, Low Range.
The currently selected gear is retained if you
change from D to M.
If you change from M to D, the gear-changing map
suitable for your current driving style is selected
and the appropriate gear is selected.
Warning!
The kickdown function is not active in manual
selection mode “M“.
The kickdown function cannot be used to
downshift in manual selection mode “M“.
fTherefore shift down manually when accelerat-ing (e.g. to overtake).
Shifting up
fPress upper part (+) of a rocker switch Aor
fPush selector lever B forward in the M gate.
Shifting down
fPress lower part (–) of a rocker switch Aor
fPush selector lever B back in the M gate.
Depending on driving speed and engine speed,
you can shift up or down at any time. Gear chang-
es which would exceed the upper or lower engine-
speed limit are not executed by the control unit.You can change down two gears by quickly press-
ing rocker switches A or selector lever B twice.
If PSM is active and the engine-speed limit is
reached, an automatic upward shift is performed
or, just before idling speed is reached, a down-
ward shift is performed.
fSelect an appropriately low gear on upward
and downward slopes.
This will ensure optimum use of engine power
and engine braking.
If manual mode fails, the control electronics
switch to automatic mode.
In this event, the instrument panel will display se-
lector lever position D.
fTo remedy the fault, please consult an autho-
rized Porsche dealer.

Shifting Gear, Traction Systems
203
M - Manual selection mode (in the off-
road driving program)The functions of selector lever positions Dand M
differ in the on-road program, High Range, and in
the off-road program, Low Range.
The currently selected gear is retained if you
change from D to M.
If you change from M to D, the gear-changing map
suitable for your current driving style is selected
and the appropriate gear is selected.
Warning!
The kickdown function is not active in manual
selection mode “M“.
The kickdown function cannot be used to
downshift in manual selection mode “M“.
fTherefore shift down manually when accelerat-ing (e.g. to overtake).
Tip on driving
The kickdown function is not active in selector le-
ver position M.
Unlike in the road driving program, an automatic
upshift is not performed when the engine-speed
limit is reached.
Shifting up
fPress upper part (+) of a rocker switch Aor
fPush selector lever B forward in the M gate.Shifting down
fPress lower part (–) of a rocker switch Aor
fPush selector lever B back in the M gate.
Depending on driving speed and engine speed,
you can shift up or down at any time. Gear chang-
es which would exceed the upper or lower engine-
speed limit are not executed by the control unit.
You can change down two gears by quickly press-
ing rocker switches A or selector lever B twice.
The gear is changed down automatically just be-
fore idle speed is reached.
fSelect an appropriately low gear on upward
and downward slopes.
This will ensure optimum use of engine power
and engine braking.
If manual mode fails, the control electronics
switch to automatic mode. In this event, the instru-
ment panel will display selector lever position D.
fHave the fault eliminated at your authorized
Porsche dealer.
StoppingfFor a brief stop (e.g. at a traffic light), leave the
selector lever in drive position and hold the ve-
hicle with the brake pedal.
fDo not hold the car on a slope using the accel-
erator. Use the brake pedal or the parking
brake instead.
fBefore leaving the vehicle, always apply the
handbrake and move the selector lever to
positionP.
Tip on driving
In selector lever positions D and M, the Hillholder
prevents the car from rolling backward when it has
been stopped on an upward slope with the engine
running.
fPlease observe the chapter “HILLHOLDER” on
Page 218.

204
Shifting Gear, Traction Systems
ParkingfGo easy on the accelerator.
fWhen parking or maneuvring in a small space,
control the speed by careful use of the foot-
brake.Driving in winterIn wintry road conditions it is advisable to take
steep inclines in manual mode M. This prevents
the occurrence of gear changes that could cause
wheelspin.
Reduced driving programIf there is a fault in the transmission:
– All gear indicators light up
– The transmission no longer shifts.
fTo remedy the fault, immediately consult an au-
thorized Porsche dealer.
Warning!
Reverse gear lock monitoring is disabled in
the emergency running program.
Damage to the vehicle may result as well as
loss of control, if the vehicle is moving for-
ward fast enough to cause rear wheel lockup.
fDo not shift into R while the vehicle is moving forward.Tip on driving
3rd or 5th gear in selector position D and reverse
gearR are now available and will allow you to
reach the nearest authorized Porsche dealer.
fPlease go to your authorized Porsche dealer
as soon as possible.

Shifting Gear, Traction Systems
205
Selector lever emergency releaseIn the event of an electrical fault, the selector lever
lock in position P can be manually released (for
towing the vehicle, for example).
1. Raise center armrest.
2. Use the key for emergency operation of the
sliding/lifting roof to undo screws A.
Please observe the chapter “EMERGENCY
OPERATION OF SLIDING/LIFTING ROOF” on
Page 149.
3. Remove trim mounting B.4. Lift trim C at the rear and carefully pull it off.
5. Unplug plug connection D.6. Press foam aside.
7. Press locking lever E aside (to the left) using a
suitable object.
8. Move selector lever to position N.
9. Reassemble in reverse order.
Danger!
Risk of loss of control and personal injury.
fEnsure that the parking brake of the vehicle is set and that vehicle does not move on its own.

206
Shifting Gear, Traction Systems
Driving Programs for On-Road and
Off-Road DrivingTwo different driving programs with special power-
transmission and running-gear control systems
(such as ABS, off-road ABS and PSM, etc.) are pro-
vided in your Porsche, with the aim of realising the
best possible driving dynamics combined with
maximum safety.
All control systems meet these requirements for
both off-road and normal driving.With rocker switch A, you can easily select the ap-
propriate driving program to suit the special re-
quirements for the respective terrain.
Off-road program Low Range
(with reduction)
When Low Range is active, the power transmis-
sion and running-gear control systems are
automatically adapted to the requirements for
off-road driving.
On-road driving program High Range
(without reduction)
When High Range is active, the power-transmis-
sion and running-gear control systems are auto-
matically adapted to the requirements for on-road
driving.
UseRocker switch A is located in the center console
of the vehicle. It features a multi-step function and
can be operated in both directions. Each time the rocker switch is pushed forward,
the vehicle becomes one step more suitable for
off-road driving. This is realised by changing from
the on-road to the off-road driving program or by
engaging the differential locks in stages.
The number of differential locks that can be en-
gaged in Low Range depends on the equipment of
your vehicle.
Each time the rocker switch is pushed back, the
vehicle becomes one step more suitable for on-
road driving.
Once the driving program has been selected, the
rocker switch springs back to home position.
fPlease observe the chapter “POWER-TRANS-
MISSION AND RUNNING-GEAR CONTROL SYS-
TEMS” on Page 211.
Notes on operation
If the Low Range indicator light beside the rocker
switch flashes rapidly after the ignition is
switched on, there is a fault in the shifting
system.
fPlease have the vehicle checked immediately
at an authorized Porsche dealer.

Shifting Gear, Traction Systems
207
If the Low Range indicator light beside the rocker
switch flashes when you attempt to operate rock-
er switch, the conditions for a shift have not been
met:
– Vehicle has exceeded or gone below the limit
speed.
– Selector lever is not in position N.
A- Rocker switch
B- Low Range is engagedChanging from on-road driving program
to off-road driving programfReduce speed to below 9 mph (15 km / h) or
stop vehicle.
fMove selector lever to position N.fPush rocker switch A forward until activation of
the off-road driving program is indicated on the
multi-purpose display of the instrument panel
and by illumination of light-emitting diode B.
The Low Range indicator light on the instru-
ment panel and light-emitting diode B beside
the rocker switch flash several times during
the shifting process.
Low Range is now engaged.
Danger!
Serious risk of injury or death. Risk of
accident due to uncontrolled vehicle
movement. The selector lever is blocked
during the shifting procedure. Shifting when
driving uphill can cause the vehicle to stand
still or even roll backwards, if the shifting
procedure has not yet been completed.
When driving downhill, the vehicle can accel-
erate unintentionally while shifting.
fIncreased brake readiness is required.
fPlease observe the chapter “POWER-TRANS-
MISSION AND RUNNING-GEAR CONTROL SYS-
TEMS” on Page 211.
Low Range indicator light

208
Shifting Gear, Traction Systems
A- Rocker switch
B-Low Range is engaged
C- Center differential lock is fully engagedFully engaging the center differential lock
in Low RangeTip on driving
When the center differential lock is fully engaged,
there is no longer any speed difference between
the front and rear axles. If, for example, both
wheels at the front axle lose traction on an icy
road or soft surface, the rigidly linked drive wheels
will permit the vehicle to continue moving never-
theless.fPush rocker switch A forwards in stages until
engagement of the center differential lock (lon-
gitudinal lock) is indicated on the multi-purpose
display of the instrument panel and by the illu-
mination of the two light-emitting diodes Band
C.
The center differential lock is changed over to
fully engaged state by the automatic control
system.
A- Rocker switch
B- Low Range is engaged
C- Centre differential lock is fully engaged
D- Rear differential lock is fully engagedFully engaging the rear differential lock in
Low RangeTip on driving
When the rear differential lock is fully engaged,
there is no longer any speed difference between
the two rear wheels. If, for example, one drive
wheel at the rear axle loses traction on an icy road
or soft surface, the stiff through-drive function will
permit the vehicle to continue moving neverthe-
less.

Shifting Gear, Traction Systems
209
fPush rocker switch A forwards in stages until
engagement of the rear differential lock (trans-
verse lock) is indicated on the multi-purpose
display of the instrument panel and by the
illumination of the three light-emitting diodes B,
Cand D.
The center and rear differential locks are
changed over to fully engaged state by the
automatic control system.
Note on operation
The rear differential lock can only be engaged
while the engine is running.
Hydraulically disengageable anti-roll barsThe front and rear anti-roll bars can be disengaged
to improve traction and comfort when driving off
road. This feature increases the wheel articulation.
Condition for disengaging the anti-roll bars
– Low Range is engaged.
Note
The anti-roll bars cannot be engaged if the wheel
articulation or lateral acceleration is too great.Disengaging
fPress button E.
Disengagement of the anti-roll bars is indicated
on the multi-purpose display of the instrument
panel and by illumination of light-emitting diode
F.
The light-emitting diode on the button flashes
several times during the disengagement
process.
The anti-roll bars are disengaged.
Note on operation
The anti-roll bars cannot be disengaged manually
at speeds above 25 mph (40 km/h).
Engaging
fPress button E.
Light-emitting diode F on the button flashes
several times during the engagement
process and then goes out.
The anti-roll bars are engaged.
Note on operation
The anti-roll bars are engaged automatically when
a speed of 30 mph (50 km/h) is exceeded or
when the lateral acceleration value is high.
Notes
Engagement of the anti-roll bars is audible.
At temperatures below –4°F (–20 °C), the anti-roll
bars take somewhat longer to engage.

210
Shifting Gear, Traction Systems Indication of a fault by:
– Continuous illumination of the light-emitting
diode in the button
– Illumination of the warning light on the
instrument panel
– A message on the multi-purpose display of the
instrument panel
fAdapt your driving behavior to the changed
conditions.
Drive slowly to the nearest authorized Porsche
delaer and have the fault remedied.
fPlease observe the chapter “WARNING LIGHTS
AND WARNING MESSAGES” on Page 106.
Changing from off-road driving program
to on-road driving programfReduce speed to below 19 mph (30 km / h) or
stop vehicle.
fMove selector lever to position N.
fPull rocker switch A back in stages until light-
emitting diodes B, C and if necessary, D are
out.
The Low Range indicator light on the instru-
ment panel and light-emitting diode B beside
the rocker switch flash several times during
the shifting process.
High Range is active.
Danger!
Serious risk of injury or death. Risk of
accident due to uncontrolled vehicle
movement. The selector lever is blocked
during the shifting procedure. Shifting when
driving uphill can cause the vehicle to stand
still or even roll backwards, if the shifting
procedure has not yet been completed.
When driving downhill, the vehicle can accel-
erate unintentionally while shifting.
fIncreased brake readiness is required.
fPlease observe the chapter “POWER-TRANS-
MISSION AND RUNNING-GEAR CONTROL SYS-
TEMS” on Page 211.
Indicator light and warnings
