PORSCHE CAYNNE TURBO 2005 1.G Owner's Manual

Controls, Safety, Instruments
21
Central Locking SystemThis device complies with:
Part 15 of the FCC Rules
RSS-210 of Industry Canada.
Operation of this device is subject to the following
two conditions:
– It may not cause harmful interference, and
– it must accept any interference received in-
cluding interference that may cause undesired
operation.
Note
The manufacturer is not responsible for any radio
or TV interference caused by unauthorized modifi-
cations to this equipment.
Such modification could void the user's authority
to operate the equipment.
fPlease observe the chapter “POWER WIN-
DOWS” on Page 29.
fPlease observe the chapter “SLIDING/LIFTING
ROOF” on Page 147.The vehicle doors can be centrally unlocked or
locked with the remote control.
All doors are locked or unlocked if central locking
button A is activated in the relevant armrest.
Please observe the chapter “CENTRAL LOCKING
BUTTON” on Page 22.
The vehicle cannot be locked if the driver’s door is
not completely closed.
If you unlock the vehicle with the key at the door
lock, only the driver’s door is opened. In order to
prevent the alarm system from being triggered,
you must switch the ignition on within 15 seconds
of opening the door.
Switching off the alarm system if it is
triggered
fUnlock vehicle doors or
fSwitch ignition on.
Automatic relockingIf the vehicle is unlocked and none of the vehicle
doors is opened within approximately
30 seconds, automatic relocking takes place.
Note on operation
If the passenger compartment monitoring system
and the inclination sensor have been deactivated
(theft protection is limited), the doors can be
opened after automatic relocking by pulling the in-
ner door handle twice.
When locked again, the passenger compartment
monitoring system and inclination sensor are acti-
vated once more.
fPlease observe the chapter “ALARM SYSTEM,
ULTRASOUND PASSENGER COMPARTMENT
MONITORING SYSTEM, INCLINATION SEN-
SOR” on Page 27.
fPlease observe the chapter “ALARM” on
Page 101.Indication by the emergency flashersIf the vehicle doors are unlocked or locked, a re-
sponse is provided by the emergency flashers:
– Unlocking – single flash
– Locking – double flash
fPlease observe the chapter “SIGNAL” on
Page 103.
f f f USA: KR5KESSY
Canada: CAN 267 104 139

22
Controls, Safety, Instruments
Locking conditionsfLock vehicle once.
The doors cannot be opened from the outside.
The alarm system, passenger compartment
monitoring system and inclination sensor are
switched on.
If a person or animal remains in the vehicle:
fQuickly lock vehicle twice.
The doors cannot be opened from the outside.
The passenger compartment monitoring
system and inclination sensor are switched off.
The doors are locked but can be opened from
the inside.
Unlocking the door with the inner door
handle
fPull inner door handle once.
Door lock is unlocked.
fPull inner door handle again.
Door can be opened.
fInform any persons remaining in the vehicle
that the alarm system will be triggered if the
door is opened.
Central locking buttonCentral locking buttons in the armrests let you
lock and unlock the vehicle electrically.
fPress the button A symbol.
All vehicle doors will be locked.
The doors can be opened by pulling the inner
door handle twice.
fPress the button A symbol.
If activated on the rear doors, only the relevant
door will be unlocked.
Note on operation
If the vehicle was locked with the key or by remote
control, it cannot be unlocked with the central
locking button.
The central locking buttons and the power
windows for the rear doors can be disabled using
safety button B in the armrest of the driver’s door.
Switching off
fPress safety button B.
The central locking buttons and power
windows on the rear doors are disabled.
Switching on
fPress safety button B again.
The central locking buttons and power
windows are operational. Locking
Unlocking
Safety button

Controls, Safety, Instruments
23
Emergency operationfLock the vehicle with the key at the door lock.
If there is a defect in the central locking system,
operating the lock barrel in the driver's door will
lock all functioning elements of the central locking
system.
fThe fault should be remedied immediately at
an authorized Porsche dealer.
Note on operation
The alarm system, passenger compartment
monitoring system and inclination sensor are
switched on.
In order to prevent the alarm system from being
triggered, you must switch the ignition on within
15 seconds of opening the door.
Switching off the alarm system if it is
triggered
fUnlock vehicle doors or
fSwitch ignition on.
Automatic door locking
Warning!
In an emergency situation where you need to
exit the car through an automatically locked
door, remember the following procedure to
open the door.
fUnlock the doors by pressing the central lock-
ing button or
fpull the inside door handle twice to open the door.
You can select various options for automatically
locking the doors on the multi-purpose display in
the instrument panel.
fPlease observe the chapter “DOOR OPENING”
on Page 102.
Option 1 (AUTO-LOCK)
Doors lock automatically when a speed of approx.
3 mph (6 km/h) is exceeded.
Option 2
The doors do not lock automatically.
Note on operation
Automatically locked doors can be unlocked with
the central locking button and opened by pulling
on the inside door handle twice.

24
Controls, Safety, Instruments
Porsche Entry & DrivePorsche Entry & Drive facilitates keyless unlock-
ing and locking of vehicle doors, rear lid and rear
window. To use this facility, you need to have only
the car key with remote control with you.
fDo not expose the car key to a high level of
electromagnetic radiation, as this could ad-
versely affect Porsche Entry & Drive.
Caution!
Risk of being locked out of vehicles with
Porsche Entry & Drive.
fIf the vehicle is locked and access is gained
through the rear lid or rear window, do not
leave the key in the vehicle.
The vehicle is automatically locked within ap-
prox. 30 seconds after the rear lid or rear win-
dow is closed.
The vehicle can then be unlocked only with the second key.
Unlocking vehicle doorsfGrip door handle fully.
The vehicle doors will be unlocked.Unlocking rear lid, rear window and spare
wheel bracketfIf you are at the rear section of the vehicle with
the car key, the rear lid, rear window and spare
wheel bracket are unlocked and can be
opened.
Locking rear lid, rear window and spare
wheel bracketfClose rear lid, rear window and spare wheel
bracket.
If the car key with remote control is out of
range, rear lid, rear window and spare wheel
bracket are locked.Locking vehicle doorsfPress button A in the door handle.
The vehicle doors are locked.
If the car key with remote control is out of
range, the vehicle doors are locked.
fPlease observe the chapter “LOCKING CONDI-
TIONS” on Page 22.
fPlease observe the chapter “ALARM SYSTEM,
ULTRASOUND PASSENGER COMPARTMENT
MONITORING SYSTEM, INCLINATION SEN-
SOR” on Page 27.
fPlease observe the chapter “SIGNAL” on
Page 103.

Controls, Safety, Instruments
25
ImmobilizerSwitching off the immobilizer
fSwitch ignition on.
Switching on the immobilizer
fSwitch ignition off and move control unit to the
left for 2 seconds.
fPlease observe the chapter “LOCKING THE
STEERING COLUMN” on Page 59.Switching off readiness for operationIf the vehicle is not unlocked within 3days the
Porsche Entry & Drive readiness for operation is
switched off.
fPull the door handle once, to reactivate the
system.
fPull the door handle again, to open the door.

26
Controls, Safety, Instruments
DoorsOpening unlocked doors from outsidefPull door handle.
Opening unlocked doors from insidefPull inner door handle.Opening locked doors from insidefPull inner door handle twice.
Please observe the chapter “LOCKING CONDI-
TIONS” on Page 22.
Childproof rear door locksChildproof locks are fitted to the rear doors.
The doors cannot be opened from inside once
these locks are engaged.
Locking (Active)
fTurn safety catch to position A.
Unlocking (Inactive)
fTurn safety catch to position B.

Controls, Safety, Instruments
27
A- Light-emitting diode for alarm systemAlarm System, Ultrasound
Passenger Compartment
Monitoring System, Inclination
SensorfPlease observe the chapter “ALARM” on
Page 101.
Avoiding false alarmsfAlways close the sliding/lifting roof and all door
windows.
fDo not leave a mobile phone switched on in the
glasses case of the roof console.
fAlways turn off the alarm system before you at-
tach a trailer. The inclination sensor could trig-
ger the alarm unintentionally.Switching onfLock the vehicle.
The alarm system, passenger compartment
monitoring system and inclination sensor are
switched on.
fPlease observe the chapter “CENTRAL LO-
CKING SYSTEM” on Page 21.Switching offfUnlock the vehicle.
The alarm system, passenger compartment
monitoring system and inclination sensor are
switched off automatically.
Note on operation
If you unlock the vehicle with the key at the door
lock, you must switch the ignition on (ignition lock
position1) within 15 seconds of opening the door
in order to prevent the alarm system from being
triggered.
Switching off the alarm system if it is
triggeredfUnlock vehicle doors or
fSwitch ignition on.Function indicationThe locking condition of the vehicle is indicated by
a rapid flashing of the light-emitting diode A on the
driver’s door.
The light-emitting diode goes out when the vehicle
is unlocked.
Passenger compartment monitoring system
and inclination sensor are switched on
fThe light-emitting diode flashes for 2 seconds,
rapidly, then slowly.
Passenger compartment monitoring system
and inclination sensor are switched off
fThe light-emitting diode flashes rapidly for
2 seconds, goes out for 28 seconds and then
flashes slowly.
Fault indication
fThe light-emitting diode flashes rapidly for
2 seconds, shines for 28 seconds and then
flashes slowly.

28
Controls, Safety, Instruments
The following alarm contacts are
monitored– Doors
– Engine compartment lid
– Rear lid
–Rear window
– Passenger compartment
– Vehicle inclination
If one of these alarm contacts is interrupted, the
alarm horn sounds for approx. 30 seconds and
the emergency flashers flash.
After 10 seconds of interruption the alarm is
triggered again. This cycle is repeated ten times.Temporarily switching off ultrasound
passenger compartment monitoring
system and inclination sensorIf people or animals are remaining in the locked ve-
hicle or the vehicle is being transported on a pas-
senger train or ship, for example, the passenger
compartment monitoring system and inclination
sensor must be switched off.
When locked again, the passenger compartment
monitoring system and inclination sensor are acti-
vated once more.Switching off
fLock the vehicle quickly twice with the remote
control or
fIn vehicles with Porsche Entry & Drive, operate
buttonA in the door handle quickly twice.
The doors are locked but can be opened from the
inside:
1. Pull inner door handle once.
Door lock is unlocked.
2. Pull inner door handle again.
Door can be opened.
fInform any persons remaining in the vehicle
that the alarm system will be triggered if the
door is opened.Switching on
fUnlock the vehicle and lock it again.
Note on operation
You can deactivate the passenger compartment
monitoring system and inclination sensor sepa-
rately on the multi-purpose display in the instru-
ment panel.
fPlease observe the chapter “COMFORT” on
Page 101.

Controls, Safety, Instruments
29
Power Windows
Warning!
Risk of injury when the door windows close.
This applies especially if the windows are
closed with the comfort function, because
with this function the window goes up auto-
matically.
fMake sure nobody can be injured when the win-
dows close.
fAlways withdraw ignition key when leaving the
vehicle or switch ignition off in vehicles that
have Porsche Entry & Drive. Always take the ig-
nition key with you when leaving the vehicle.
Uninformed persons could injure themselves
by operating the power windows.
fIn case of danger, immediately release the car
key or the button in the door handle in vehicles
that have Porsche Entry & Drive.
fDo not leave children in the car unattended.
Risk of an accident.
fDo not put anything on or near the windows that may interfere with the driver's vision.
Readiness for operation of power windows– With ignition switched on or
– A maximum of 10 minutes with door closed
and ignition key withdrawn, but only until driv-
er’s or passenger door is first opened.
The one-touch operation for closing the door
windows is available only when the ignition is
switched on.
A- Power window in driver’s door
B- Power window in passenger’s door
C-Safety button
D- Left rear power window
E- Right rear power windowOpening/closing windowsOpening window with the rocker switch
fPress rocker switch until the window has
reached the desired position.
Closing window with the rocker switch
fPull rocker switch until the window has reached
the desired position.

30
Controls, Safety, Instruments
Power windows in passenger’s door and rear doorsNote on operation
Rocker switches A and B in the driver’s door have
a two-stage function:
– If the switch in question is pressed or pulled to
the first level, the front window is opened or
closed manually.
– If the switch is completely pressed or pulled to
the second level, the front window is opened or
closed automatically (one-touch operation).One-touch operation for front windows
fPull or press rocker switch to its final position
in the driver’s door.
Window moves to its final position.
Press or pull again to stop the window in the
desired position.
Comfort function when unlocking the vehicle
fHold the car key in the door lock in the unlock-
ing position until the windows and the
Panorama roof system have reached the de-
sired position.
If you unlock the vehicle with the key at the door
lock, only the driver’s door is opened. In order to
prevent the alarm system from being triggered,
you must switch the ignition on within 15 seconds
of opening the door.
Comfort function when locking the vehicle
Warning!
Danger of injury. The window will close with
its full closing force.
fTa k e c a r e t o e n s u r e t h a t n o b o d y c a n b e i n j u re d when the windows close.
fHold the car key in the door lock in the locking
position until the windows and the sliding/lift-
ing roof or the Panorama roof system have
reached the desired position.Comfort function when locking for vehicles
with Porsche Entry & Drive
Warning!
Danger of injury. The window will close with
its full closing force.
fTake care to ensure that nobody can be injured when the windows close.
fPush the button in the door lock in the locking
position until the windows and the sliding/lift-
ing roof or the Panorama roof system have
reached the desired position.
Note on operation
The comfort function remains available for approx.
45 seconds after the vehicle has been locked.
