Practical Tips, Minor Repairs
321
Closing spare wheel bracket
Warning!
Danger of injury and risk of accident if the
spare wheel bracket is operated improperly.
fOperate the spare wheel bracket only using
button B.
fIf the vehicle is tilted to the side, more effort
will be required to swing the spare wheel
bracket.
fMake sure that no persons or animals are with-
in the range of movement of the spare wheel bracket.
1. Check whether additional lock C is engaged. If
necessary, slide additional lock C to the right.
2. Swing spare wheel bracket closed with force.
3. Check lock and observe indication on the multi-
purpose display of the instrument panel.
The indicator light must go out when the spare
wheel bracket is locked.
Automatic locking
In the multi-purpose display of the instrument pan-
el, you can set different variants of locking and un-
locking the doors and the rear lid as well as the
check-back signal when locking and unlocking the
vehicle and save them on the respective remote
control.
fPlease observe the chapter “TAILGATE” on
Page 117.
D- Towing lug cover (left)
E- Emergency release cableEmergency release for the spare wheel
bracketIf the battery is flat, the only way to open the spare
wheel bracket is by using the mechanical emer-
gency release.
Warning!
Danger of injury and risk of accident if the
spare wheel bracket is operated improperly.
fPerform emergency unlocking of the spare
wheel bracket only when the vehicle is on a lev-el surface.
1. Remove cover of left towing lug D.
2. Pull emergency release cable E in the direction
of the arrow.
The spare wheel bracket is now unlocked and
can be operated.

322
Practical Tips, Minor Repairs
Electrical SystemIn order to avoid damage and faults in electrical or
electronic systems, electrical accessories should
be installed at your authorized Porsche dealer.
fUse only accessories authorized by Porsche.
Warning!
Risk of short circuit and fire.
Replacing fuses or relays with engine running
or the ignition on could cause electrical
shock.
fDisconnect the battery during all work on the electrical system.
RelaysRelays should be checked or changed only by an
authorized workshop.Alarm system, central lockingThe status of the central locking and alarm system
is not changed by disconnecting the battery.
When the battery is disconnected, the alarm
system ceases to function.
SocketsElectrical accessories can be connected to the
12 V sockets.Note on operation
The sockets and thus the connected electrical ac-
cessories function even if the ignition is swi tched
off or the ignition key is withdrawn.
If the engine is not running and the accessories
are switched on, the vehicle battery will be
discharged.

Practical Tips, Minor Repairs
323
Changing fusesIn order to prevent damage to the electrical
system due to short circuits and overloads, the in-
dividual circuits are protected by fuses.
One fuse box is in the engine compartment. Two
additional fuse boxes are located in the outer ends
of the dashboard.
1. Switch off the consumer with the defective
fuse. Before replacing a fuse, switch off all
electrical consumers and remove the ignition
key.
2. Open the fuse-box lid.
3. Remove the corresponding fuse from its slot to
check it using the plastic gripper.
A blown fuse can be identified by the melted
metal strip.
4. Replace only with fuses of the same rating.
Note
If a fuse blows repeatedly, please consult an au-
thorized Porsche dealer immediately, so that the
short circuit can be located and corrected.
Never try to “repair“ fuses: you may cause serious
damage to other parts of the electrical system.
Cover of engine-compartment fuse boxOpening fuse-box lid in engine compartment
1. Rotate the turn-locks 90° anti-clockwise with a
screwdriver and remove the cover.
Fuse box in engine compartment2. Rotate the turn-locks of the fuse-box lid
90° anti-clockwise with a screwdriver and re-
move the lid.
f f f

324
Practical Tips, Minor Repairs Opening fuse-box lid in the dashboard
1. Carefully pry off the plastic cover with a screw-
driver (arrow) and remove.
The fuse plan is located on the inside of the
cover.
A- Fuse puller2. Remove the fuses carefully with the fuse puller.

Practical Tips, Minor Repairs
325
Fuse assignment – fuse box in left side of dashboard
No. Designation Rating in A1
Center console socket, cigarette lighter
20
2 Parking heater5
3
Sockets in passenger footwell
20
4 Parking heater15
5
Sockets in luggage compartment
20
6
7
Diagnostic socket
5
8 Wiper motor for windscreen30
9
Washer fluid pump, vehicle electrical system control unit
15
10 Power window, rear left25
11
Central locking system
15
12 Interior light, vehicle electrical system control unit20
1314 Power window, front left2515
Tail light, right; central locking system, power windows, mirrors
15
16 Horn, vehicle electrical system control unit20
17
Turn signal, side light, left; vehicle electrical system control unit
10
18 Headlight washer system20
19
Fog lights, vehicle electrical system control unit
15
20
21
Cornering light, vehicle electrical system control unit
15

326
Practical Tips, Minor Repairs 22 Rear differential lock, transfer box30
23
Rear differential lock, disengageable anti-roll bars
10
24 Tire pressure monitoring5
2526 Engine control unit (engine management, radiator fans), airbag, instrument panel 1027282930313233
Steering column
15
34 Passenger compartment monitoring, inclination sensor5
35
Low beam left, high beam left, vehicle electrical system control unit
15
36 Vehicle electrical system control unit10
373839
Heated rear window
5
40 Instrument panel, diagnosis5
41
Steering column lock, ignition lock, central locking system, Porsche Entry & Drive
15
42 Sliding/lifting roof or Panorama roof30
43
Subwoofer
30
44 Electrical seat adjustment, left; electrical steering column adjustment 30 No. Designation Rating in A

Practical Tips, Minor Repairs
327
45
Electrical seat adjustment, left; seat heating, rear
30
46
47
Transfer box
10
48
49
Servotronic, disengageable anti-roll bars
5
50 Heating pipe ventilation10
51
Diagnosis, parking brake switch, Air conditioning
5
52 Rear wiper30
53
Vehicle electrical system control unit, central locking system, power windows, mirrors, light switch, steering column
5
54 Headlight beam adjustment10
5556 Fan, front air-conditioning system4057
Fan, rear air-conditioning system
40
RES 1 Spare fuse 1
RES 2
Spare fuse 2
No. Designation Rating in A

328
Practical Tips, Minor Repairs
Fuse assignment – fuse box in right side of dashboard
No. Designation Rating in A1
Towing attachment
15
2 ParkAssist5
3
Towing attachment
15
4 Telephone/telematics control unit5
5
Towing attachment
15
6 Porsche Stability Management (PSM)30
7
Transfer box (center differential lock), telephone preparation
5
8 Additional high beam, vehicle electrical system control unit 20
9
CD changer, DVD navigation
5
10 TV tuner, satellite receiver5
11
Radio or Porsche Communication System (PCM)
10
12 Radio booster30
1314 Tail light, left; central locking system, power windows, mirrors 1515
Power window, rear right
25
16
17
Low beam, right; high beam, right; vehicle electrical system control unit
15
18 Heated rear window relay30
19
Brake booster, towing attachment
30/25
20
21
Hood open switch, spare wheel release
10

Practical Tips, Minor Repairs
329
22 Electrical seat adjustment, front right; seat heating, front right and rear right 3023
Air conditioning
10
24 Electrical seat adjustment, front right; seat memory, front right 30
25
Air-conditioning system, rear
5
26
27
Level control
15
28
29
Transmission control unit
10
30 Rear lid power closing mechanism20
31
Central locking system, power windows, mirrors
15
32 Central locking, right doors10
3334 Power window, front right2535
Turn signal, side light, right; vehicle electrical system control unit
10
36 Roof module, telephone, compass5
3738 Porsche Stability Management1039
Diagnosis
40 Transfer box (center differential lock)1041
Towing attachment
10
42 Roof module5
43
Back up light
5
44 Heated washer nozzles, running gear, seat heating5 No. Designation Rating in A

330
Practical Tips, Minor Repairs
454647
Telephone preparation
10
48 Level control10
49
Telephone, automatic anti-dazzle mirror
5
50
51
Transmission
20
52 Selector lever switch5
535455
Reversing camera
5
56 Porsche Stability Management (PSM)40
57
Transfer box (center differential lock)
40 No. Designation Rating in A
