Practical Tips, Minor Repairs
301
CompressorOn vehicles without level-control systems, there is
an additional compressor with pressure tester un-
der the loadspace floor.
fPlease observe the chapter “INFLATING TIRES
ON VEHICLES WITHOUT AIR SUSPENSION” on
Page 315.
On vehicles with level control, you can use the
compressor of the level-control system to fill the
tires.
The filler hose required for this purpose can be
found under the left rear seat.
fPlease observe the chapter “FOLDING REAR
SEATS FORWARD” on Page 41.
Wheel BoltsfAlways clean the wheel bolts before installing.
Maintenance note
fWheel bolts must not be greased.
fReplace damaged wheel bolts.
Only use the original Porsche wheel bolts spe-
cially designed for this vehicle type.Tightening torque
Tightening torque of the wheel bolts 118 ftlb.
(160 Nm).
Security wheel boltsThe adapter (wrench socket) for the security
wheel bolts is located in the tool box.
To loosen or tighten the wheel bolt with anti-theft
protection, the adapter must be used between the
wheel bolt and the wheel bolt wrench.
fWhen positioning the wrench socket, ensure
that it engages fully in the teeth of the wheel
bolt.
Note on operation
fOn vehicles with 17 mm spacers on the rear
axle, the wheels are secured with steel nuts.
There is no anti-theft protection for the wheel
nuts.
fIf the wheels have to be removed at the work-
shop, please do not forget to hand over the
socket for the security wheel bolts along with
the car key.

302
Practical Tips, Minor Repairs
SpacersfUse the spacers only together with wheels
approved by Porsche.
Before having spacers fitted, find out about the
current approval status.
fRemove spacers if 18 inch tires, snow chains
or a collapsible spare wheel are mounted.
Danger!
Risk of accident if the spacers are not re-
moved before mounting 18 inch tires or col-
lapsible spare wheel.
f17 mm spacers are always to be removed be-
fore mounting 18 inch tires or a collapsible
spare wheel, because the wheel cannot be fit-ted correctly. Caution!
Risk of damage to wheel housings if the
spacers on the rear axle are not removed be-
fore fitting the snow chains.
f17 mm spacers must always be removed from the rear axle when snow chains are to be fitted.Note on operation
fTo remove or mount the spacers:
Please observe the chapter “CHANGING A
WHEEL WITH REMOVAL OF 17 MM SPACER”
on Page 311.
Please observe the chapter “FITTING THE
17 MM SPACER” on Page 312.

Practical Tips, Minor Repairs
303
Changing Wheels
Warning!
Failure to follow these instructions may result
in serious personal injuries to you or to by-
standers.
Before changing the wheel
fIf you have a flat tire, move a safe distance off
the road. Turn the emergency flasher on and
use other warning devices to alert other motor-
ists.
fDo not park your vehicle where it may contact
dry grass, brush or other flammable materials.
The hot parts of the exhaust system could set
such materials on fire, thereby causing both
property damage and severe or fatal physical
injury.
fPassengers must not be in the vehicle when it
is jacked up.
fBefore you change a wheel, be sure the ground
is level and firm. If necessary, use a board un-
der the jack to ensure that the jack does not
sink into the ground.
fSet the parking brake and block the wheels op-
posite the flat tire on the other side of the vehi-
cle.While operating the jack
fThe jack is only to be used for changing a
wheel. Do not use it as a support to work under
the car.
fThe car must be jacked up only at the illustrat-
ed jacking points.Lifting at any other place
may damage the vehicle or may result in per-
sonal injury. Never jack the car up by the body
or the bumpers.
fFor safety reasons do not use tire inflating bot-
tles. Do not use commercially available sealant
bottles. Use only the tire inflating bottle locat-
ed in the luggage compartment.
Sequence of operation
Warning!
The jack must be used only to raise the car
for wheel changing.The jack must never be
used as a support to work underneath the ve-
hicle. If the jack is accidentally dislodged,
you or bystanders could suffer severe per-
sonal injury.
fNever jack up other vehicles or other loads
with the jack.
fAlways place the car on stable supports if you
have to work under it. When working under the
vehicle, always use safety stands specifically designed for this purpose.
fPlease use a suitable knee rest to protect your
clothing against soiling.

304
Practical Tips, Minor Repairs
Flat Tire1. Stop the vehicle as far away from the driving
lane as possible.
The car must be parked on a firm and flat
surface offering adequate grip.
2. Switch on the emergency flashers.
3. Fully apply the parking brake.
4. Move the selector lever to position P.
5. Straighten the front wheels.
6. Withdraw the ignition key to lock the steering
and prevent the engine from being started.
7. Have any passengers leave the vehicle.
8. Set up a warning triangle at a suitable
distance.
A-Folding wedgesSecuring the vehicle against rollingFor this purpose, use the two folding wedges A
fastened on the tool box.
1. Unfold the wedges.
2. Engage the wedges.3. Place one wedge directly in front of and anoth-
er directly behind the diagonally opposite
wheel.

Practical Tips, Minor Repairs
305
A- Filler bottle
B- Filler hoseTire sealantThe tire sealant can be used to seal small cuts, es-
pecially in the tire tread.
Sealing the tire with the tire sealant is only an
emergency repair, so you can drive to the next
workshop. Even with the tire air-tight, it may be
used only for short journeys in an emergency.
On vehicles without level control, the tire sealant
and a compressor with pressure tester can be
found under the cargo floor in the luggage com-
partment.The tire sealant comprises:
– A filler bottle
– A filler hose
– A valve turner and
– A spare valve insert.
Danger!
Risk of accident.
fUse the tire sealant only in the case of cuts or
punctures no larger than 0.15 in. (4 mm).
fNever use the tire sealant if the rim is dam-aged.
Warning!
The sealant is highly flammable and harmful
to health.
fFire, naked flame and smoking are prohibited
when handling tire sealant.
fAvoid contact with skin, eyes or clothing.
fKeep tire sealant away from children.
fDo not inhale vapours.
In case of contact with the sealant:
fIf sealant gets on the skin or in the eyes,
thoroughly rinse the affected part of the body
off without delay.
fChange soiled clothing immediately.
fVisit a doctor immediately in the event of an al-
lergic reaction.
fIf sealant was swallowed, thoroughly rinse out
the mouth without delay and drink plenty of wa-
ter.
Do not induce vomiting.
See a doctor immediately.

306
Practical Tips, Minor Repairs
A- Filler bottle
B- Filler hose
C- Plug of the filler hose
D-Valve turner
E-Valve insert
F- Tire valveInserting sealant
1. Leave the object that caused the puncture in
the tire.
2. Remove sealant and the enclosed sticker from
the luggage compartment.
3. Adhere the sticker in the driver's field of vision.
4. Shake filler bottle A.5. Screw filler hose B onto the filler bottle.
The filler bottle is now open.
6. Unscrew valve cap from tire valve F.
7. Remove valve insert E from the tire valve with
valve turner D.
Keep the valve insert in a clean and dry place.
8. Remove plug C of the filler hose B.
9. Push filler hose onto the tire valve.
10.Hold filler bottle higher than the level of the tire
valve and press it together forcefully until the
bottle is completely emptied into the tire.
11.Pull filler hose off the tire valve.
12.Twist the valve insert firmly into the tire valve
using the valve turner.
13.Inflate the tire.
Set the prescribed tire pressure.
Please observe the chapter “TIRE PRESSU-
RES, COLD” on Page 370.
Please observe the chapter “TIRE SEALANT/
SEALING SET” on Page 106.
14.Screw valve cap onto the tire valve.
15.Check the tire pressure after driving for around
10 minutes.
If the tire pressure is less than 22 psi (1.5 bar),
do not continue driving.
If a value of more than 22 psi (1.5 bar) is indi-
cated, correct the pressure to the prescribed
value.16.Please consult your authorized Porsche
dealer.
Care Instructions
After drying, any sealant that emerges can be
peeled off like a film.
Warning!
Risk of accident.
fHave the tire replaced by a specialist work-
shop as soon as possible.
fAvoid hard acceleration and high cornering
speeds.
fDo not exceed maximum speed of 50 mph
(80 km/h).
fPlease always observe the safety and operat-
ing instructions, which can be found in the sep-
arate operating instructions for the sealant and on the compressor.

Practical Tips, Minor Repairs
307
Lifting the vehicle with a jack
Warning!
Danger of injury. The car may slip off the
jack.
fMake sure that no one is in the vehicle when
jacking up and changing a wheel.
fNever jack up the vehicle when it is parked on
a surface that slopes up, down or to the side.
fUse the jack only to raise the car for wheel
changing.
fAlways place the car on stable supports if work
has to be carried out under the car.
The car jack is not suitable for this.
Danger of injury if the level-control system
operates during the wheel change.
fSet the car to jacking mode before raising the
car.
Please observe the chapter “RAISING VEHICLE
WITH THE JACK” on Page 246.
Risk of injury and damage if the vehicle is not
secured.
fSecure the vehicle against rolling.
fPlease observe the chapter “SECURING THE VEHICLE AGAINST ROLLING” on Page 304.Maintenance note
The jacking point on the vehicle must be free of
dirt.
1. Slightly slacken the wheel bolts of the wheel to
be changed.
2. Only set up the jack at the rear jacking point
designed for the purpose. The jack foot must
be in contact over its whole area and must be
positioned directly below the head piece.
Use a suitable support if necessary.
3. Hold jack still and wind it up until its head en-
ters the jacking point on the vehicle.
Only jack vehicle up until the wheel to be
changed is completely off the ground.
4. After lowering the vehicle, remove the jack.
Front jacking pointJacking points
fSet up jack only at the points provided A or B.

308
Practical Tips, Minor Repairs
Rear jacking point Front jacking point
Jacking points for vehicles with a running
board
fSet up jack only at the points provided C or D.
Rear jacking point

Practical Tips, Minor Repairs
309
Front jacking pointJacking points for vehicles with side member
panels
The jacking points are accessible after removing
the plastic caps from the side member panels.
1. Open cover cap E or G to the front in the side
member panel via the internal handle recess
and pull off (arrow).
Rear jacking point2. Set up jack only at the points provided F or H.
3. Insert the cover cap E or G completely with
both centering lugs in the slots of the side
member panel and fold back until it can be felt
to engage.

310
Practical Tips, Minor Repairs
Wheel change1. Remove the top wheel bolt with the wheel bolt
wrench from the tool kit.
Screwing in assembly aid 2. Remove assembly aid from the tool kit and
screw in instead of the wheel bolt.
3. Remove the remaining wheel bolts.
Please observe the chapter “WHEEL BOLTS”
on Page 301.
4. Change wheel.5. Insert wheel bolts and tighten by hand. Re-
move assembly aid and screw in remaining
wheel bolt.
Initially tighten bolts in diagonally opposite se-
quence so that the wheel is centered.
6. Inflate the tire if necessary.
Please observe the chapter “TIRE PRESSU-
RES, COLD” on Page 370.
In vehicles with tire pressure monitoring:
Please observe the chapter “TIRE PRESSURE
MENU” on Page 102.
7. Lower car and remove jack.
8. Tighten wheel bolts in diagonally opposite se-
quence.
Maintenance note
fImmediately after changing a wheel, use
a torque wrench to check the prescribed
tightening torque of the wheel bolts
(118 ftlb./160 Nm).
