Opening and Locking
19
Notes on the Key and Central
Locking System KeyYou are provided with two vehicle keys with
integrated emergency key. These keys operate
all the locks on your vehicle.
fBe careful with your vehicle keys: do not
part with them except under exceptional
circumstances.
f Remove and take the ignition key with you,
even if leaving the vehicle only briefly.
Do not leave the ignition key in the vehicle.
f Inform your insurance company of any loss or
theft of car keys or if extra or replacement
keys have been cut.
f Third parties can still operate the mechanical
locks with a lost key.
Note on operation
Different vehicle settings are stored on the respec-
tive key when the vehicle is locked, provided the
vehicle is fitted with the relevant equipment.
For information on storing vehicle settings on
the key:
f Please see the chapter “STORING VEHICLE
SETTINGS” on Page 40.
Emergency operationfPlease see the chapter “EMERGENCY OPERA-
TION – UNLOCKING THE IGNITION KEY” on
Page 166.Replacement keysCar keys can only be ordered through an autho-
rized Porsche dealer. Sometimes, this may take a
long time.
You should therefore always keep a spare key on
your person. Keep it in a safe place, but under no
circumstances in or on the vehicle.
The key codes of new keys have to be “reported”
to the vehicle control mo dule by an authorized
Porsche dealer. All keys belonging to the vehicle
must also be reported again.
Note
Third parties can continue to operate the mecha-
nical locks using the lost key.
Panic buttonIn dangerous situations or when one's own safety
is threatened, it is possible to draw attention to
the situation by triggering an alarm.
To trigger an alarm
f Press button.
The horn sounds and the emergency flasher
flashes.
To stop the alarm
f Press button again.
The horn becomes silent and the emergency
flasher goes out.
Page 22 of 343
20
Opening and Locking
Emergency keyRemoving emergency key
1. Push the release button to the side.
2. Pull out the key.
Inserting emergency key
fSlide in the key until the release button
audibly engages.
Central Locking SystemThis device complies with:
Part 15 of the FCC Rules
RSS-210 of Industry Canada.
Operation of this device is subject to the following
two conditions:
– This device may not cause harmful interfe-
rence, and
– this device must accept any interference received including interference that may cause
undesired operation.
Note
The manufacturer is not responsible for any radio
or TV interference caused by unauthorized modifi-
cations to this equipment.
Such modification could void the user's authority
to operate the equipment.
Warning!
Any changes or modifications not expressly
approved by Porsche could void the user’s autho-
rity to operate this equipment. Your vehicle is equipped with a central locking
system. The following are unlocked or locked
together:
– Doors
–Rear lid
– Filler flap
The central locking system is always activated
when the vehicle is unlocked and locked.
On the multi-function di
splay of the instrument
panel, you can set different variants for locking
and unlocking the doors and rear lid. You can open
all doors irrespective of the setting made.
The vehicle cannot be locked if the driver’s door is
not completely closed.
If one of the following components is not comple-
tely closed when you try to lock the vehicle the
door/lid is not locked:
–vehicle doors
– rear lid
– engine compartment lid
The indication by the emergency flasher and by
the acoustic signal will be provided after all doors
and lids are closed.USA: KR55WK50138
Canada: 7812D-5WK50138
Page 23 of 343
Opening and Locking
21
Brief Overview – Opening and
Locking From OutsideThe Porsche Entry & Drive option can be
recognized by the buttons A in the door handles.
This brief overview does not replace the
information provided under “OPENING AND
LOCKING FROM OUTSIDE”.
Warnings, in particular, are not replaced by this
brief overview.
Key Porsche Entry & Drive
What do I want to do?
What do I have to do?
What happens?
Unlocking
Using the key:
Press the button on the key once.
Press the button on the key twice.
With Porsche Entry & Drive:
Grip the door handle fully. The emergency flasher flashes once.
The driver’s door can be opened.
All vehicle doors and the rear lid can be opened.
The doors and the rear lid can be opened.
Closing
Using the key:
Press the button on the key.
With Porsche Entry & Drive:
Press the button A
on the door handle.
The emergency flasher flashes twice and an
acoustic signal will sound twice.
The doors are locked.
Lock if persons/animals
are remaining in vehicle (Switch off the alarm system’s interior
surveillance) Please see the chapter “SWITCHING OFF INTERIOR
SURVEILLANCE AND INCLINATION SENSOR” on
page 247.Switching off alarm
Press the button on the key.
Page 24 of 343
22
Opening and Locking
Opening and Locking From OutsideDepending on your vehicle equipment, you
can unlock and lock the vehicle either with the car
key or without a key by means of Porsche Entry &
Drive.
With the key
Use the buttons on the key to unlock and lock
the vehicle. With Porsche Entry & Drive
On vehicles with Porsche Entry & Drive, you
can unlock, lock and st
art the vehicle without
using the key.
You simply have to carry the key with you,
e.g. in your trouser pocket.
f Do not expose the car key to a high level
of electromagnetic radiation. This could
adversely affect Porsche Entry & Drive. Note on operation
The factory settings of the vehicle are described
in this section.
In the multi-function display in the instrument
panel, you can change the settings and store them
on the respective key fo
r vehicles with comfort
memory.
For information on modifying the opening and
locking settings:
f Please see the chapter “LOCKING SETTINGS”
on page 145.
Page 25 of 343
Opening and Locking
23
Unlocking and opening doorsUnlocking with the key
1. Press button .The emergency flasher flashes once.
The driver’s door is unlocked.
2. Pull the door handle. Unlocking with Porsche Entry & Drive
(keyless)
Either door can be unloc
ked if you position
yourself on the side of the vehicle (driver’s side,
passenger’s side) that you wish to open together
with the key.
1. Grip the door handle fully. The emergency flasher flashes once.
The doors are unlocked.
2. Pull the door handle. Note on operation
The vehicle is locked automatically after
30 seconds if none of the doors or the tailgate is
opened. The alarm system is not activated.
If the interior surveillance system and inclination
sensor have been switched off (restricted anti-
theft protection), this also remains the case after
automatic relocking.
As a result, the doors can be opened from inside
by pulling once on the front door opener or by
pulling twice on the rear door opener.
f
Inform any persons remaining in the vehicle
that the alarm system will be triggered if the
door is opened.
When locked again, the interior surveillance
system and inclination sensor are activated once
more.
Switching off operational readiness
(for vehicles with Porsche Entry & Drive)
Operational readiness of Porsche Entry & Drive is
switched off after 96 hours for the driver’s door
and after 36 hours for the passenger doors if the
vehicle is not unlocked within this time.
1. Pull the door handle once to activate the
system again.
2. Pull the door handle again to open the door.
Page 26 of 343
24
Opening and Locking
Locking doorsLocking with the key
1. Close the door.
2. Press button once.
The emergency flasher flashes twice and an
acoustic signal will sound twice.
The doors cannot be opened from outside.
or
If persons or animals are remaining in the
vehicle, press button twice.
The emergency flasher flashes twice and an
acoustic signal will sound twice.
The doors can be opened from inside by
pulling once on the front door opener or by
pulling twice on the rear door opener.
3. Inform any persons re maining in the vehicle
that the alarm system will be triggered if the
door is opened.
Note on operation for locking the doors with
the key
The vehicle cannot be locked if the driver’s door is
not completely closed.
The emergency flasher indicates that the vehicle
has been locked successfully only when all the
doors, the engine compartment lid and the
tailgate are closed. Locking with Porsche Entry & Drive (keyless)
You must carry the key with you.
1. Close the door.
2. Briefly press the Porsche Entry & Drive locking
button A on the door handle.
The emergency flasher flashes twice and an
acoustic signal will sound twice.
The doors cannot be opened from outside.
or
If persons or animals are remaining in the
vehicle, press the Porsche Entry & Drive
locking button A on the door handle twice.
The emergency flasher flashes twice and an
acoustic signal will sound twice. The doors can be opened from inside by
pulling once on the front door opener or by
pulling twice on the rear door opener.
3. Inform any persons re maining in the vehicle
that the alarm system will be triggered if the
door is opened.
Note on operation for locking the doors with
Porsche Entry & Drive (keyless)
– The vehicle cannot be locked if the any of the doors or the tailgate are not completely
closed.
A warning signal sounds in the passenger
compartment and a warning message
appears on the multi-function display.
– The key must be outside the vehicle when locking the vehicle do ors, otherwise the
vehicle doors cannot be locked.
– If the key is out of rang e, the vehicle doors can
no longer be opened after they are locked.
Page 27 of 343
Opening and Locking
25
Automatic door locking and automatic
door unlocking
Warning!
In an emergency situation where you need to
exit the car through an automatically locked
door, remember the following procedure to
open the door.
f Unlock the doors by pressing the central
locking button or
f Pull the inside door handle on the front door
once or on the rear door twice to open the door.
In the multi-function display of the instrument
panel, you have the option of selecting diverse
variants of automatic door locking and automatic
door unlocking.
For information on modifying the opening and
locking settings:
f Please see the chapter “LOCKING SETTINGS”
on page 145.
Unlocking and opening tailgateWhen the tailgate is unlocked, the vehicle doors
are also unlocked.
The vehicle is locked ag ain automatically after
30 seconds if none of the vehicle doors or the
tailgate is opened.
Danger!
Risk of carbon monoxide poisoning! Exhaust
gases can enter the passenger compartment
when the tailgate is open and render the
occupants unconscious if longterm exposure
occurs, resulting in an accident. In a stopped
vehicle, carbon monoxide can also lead to
death.
f Always keep the tailgate closed when the
engine is running.
fAlways keep the tailgate closed while driving.
Unlocking with the key
1. Press button .
2. Press the unlocking handle ( arrow) on the
tailgate and open the tailgate.
Page 28 of 343
26
Opening and Locking
Unlocking with Porsche Entry & Drive
(keyless) Warning!
Risk of being locked out of vehicles with
Porsche Entry & Drive.
f Do not leave the key in the vehicle if the vehicle
is locked and access can be gained through
the tailgate. The vehicle is automatically
locked when the tailgate is closed.
If the key is left in the vehicle, the emergency
flasher flashes once and a horn signal sounds.
Within approximately 30 seconds, the tailgate
can be opened by pressing the unlocking
handle ( arrow).
After 30 seconds have elapsed, the
vehicle can be unlocked again only with the second key.
If you are in the rear area of the vehicle with the
key and press the unlocking handle, the tailgate is
unlocked.
f Press the unlocking hand le on the tailgate and
open the tailgate.
Locking the tailgate
Warning!
Danger of crushing. The tailgate
automatically closes.
f Make sure that your fingers are not under
the tailgate.
f Keep foreign objects or limbs away from
moving parts (lock striker) of the power
closing mechanism.
f Children must be kept away from the tailgate
when closing.
Children could be killed or severely injured by such a closing. The tailgate has a power closing mechanism.
1. Pull down the tailgate by means of the closing
handle ( arrow) and press gently into the lock.
The tailgate is automatically pulled closed.
2. Briefly press button on the key once. The vehicle is locked.
Note on operation
On vehicles with Porsche Entry & Drive, the
tailgate can no longer be opened when the car key
with remote control is out of range.
Page 29 of 343
Opening and Locking
27
Powerlift tailgateOpening and closing tailgate automatically
Warning!
Risk of poisoning! Exhaust gases can enter
the passenger compartment when the
tailgate is open.
f Always keep the tailgate closed when the
engine is running.
f Always keep the tailgate closed while driving.
Risk of injury and damage if the tailgate is
automatically opened or closed in an
uncontrolled way!
f Do not leave children in the car unattended.
f Open or close the tailgate only when the
vehicle is stationary.
f Never drive with the ta ilgate open. Exhaust
gases can enter the passenger compartment.
f Open or close the tailgate only when there are
no persons, animals or objects within its
movement range.
f Always keep a close eye on the opening and
closing operation so that movement can be
stopped at any time in the event of danger.
f Make sure there is sufficient clearance behind
and above the vehicle (e.g. roof transport systems, garage ceiling). Acoustic indication du
ring opening/closing
of the tailgate
Opening and closing of the tailgate are indicated
by warning tones.
You can have the warning tones activated/
deactivated at your authorized Porsche dealer.
Opening tailgate automatically
There are three ways of opening the tailgate:
Variant 1
f Use the unlocking handle ( arrow) on the
tailgate. The vehicle must be unlocked for this.
Vehicles with Porsche Entry & Drive need not
be unlocked. You simply have to carry the car
key with you, e.g. in your trouser pocket.
Page 30 of 343
28
Opening and Locking
Variant 2
f
When the ignition is switched off, press the
button on the key for approximately
1second.
If the vehicle is locked, either the driver’s door
or the entire vehicle will be unlocked,
depending on the settings in the multi-function
display.
For information on locking and unlocking settings
in the multi-function display:
f Please see the chapter “LOCKING SETTINGS”
on page 145. Variant 3
f
With the ignition switched on, press and hold
the button in the driver’s door until the
tailgate has opened fully.
Opening is interrupted if the button is released
prematurely.
A – Closing the tailgate auto matically without Porsche
Entry & Drive
A and B – Closing the tailgate au tomatically and locking
with Porsche Entry & DriveClosing tailgate automatically
Make sure that the load is not in the area of the
tailgate when the tailgate is closed because
otherwise the closing operation will be interrupted
after contact with the load and the tailgate will
open again.
f Press the button A in the trim panel on the
tailgate.
The tailgate is closed.
