Ram 3500 2016  Diesel Supplement INSTRUMENT CLUSTER — PREMIUM (DID)
Premium DID Instrument Cluster — If Equipped
3
UNDERSTANDING YOUR INSTRUMENT PANEL 19

Page 22 of 338

Ram 3500 2016  Diesel Supplement 1. Tachometer•Indicates the engine speed in revolutions per minute
(RPM x 1000).
2. Engine Coolant Temperature •This gauge shows the engine coolant temperature.
The gauge pointer will likely show

Page 23 of 338

Ram 3500 2016  Diesel Supplement 3. Oil Pressure Gauge•The pointer should always indicate some oil pres-
sure when the engine is running. A continuous high
or low reading under normal driving conditions may
indicate a lubrication s

Page 24 of 338

Ram 3500 2016  Diesel Supplement NOTE:
•The gauge may take up to five seconds to update after
adding a gallon or more of Diesel Exhaust Fluid (DEF)
to the DEF tank. If you have a fault related to the DEF
system, the gauge may not u

Page 25 of 338

Ram 3500 2016  Diesel Supplement Yellow Telltale Indicator Lights
Wait To Start Light — If Equipped
Yellow TelltaleLight What It Means
Wait To Start Light
The “Wait To Start” telltale will illuminate for approximately two secon

Page 26 of 338

Ram 3500 2016  Diesel Supplement Water in Fuel Indicator Light — If Equipped
Yellow TelltaleLight What It Means
Water in Fuel Indicator Light
The “Water In Fuel Indicator Light” will illuminate when there is water detected in t

Page 27 of 338

Ram 3500 2016  Diesel Supplement ELECTRONIC VEHICLE INFORMATION CENTER
(EVIC)
The Electronic Vehicle Information Center (EVIC) fea-
tures a driver-interactive display that is located in the
instrument cluster.This system conveniently

Page 28 of 338

Ram 3500 2016  Diesel Supplement Electronic Vehicle Information Center (EVIC)
Displays — 3.5” Display
The EVIC displays are located in the center portion of the
cluster and consists of seven sections:1. Compass Display
Displays t

Page 29 of 338

Ram 3500 2016  Diesel Supplement •Electronic Speed Control SET
This light will turn on when the electronic
speed control is SET. For further information,
refer to “Electronic Speed Control” in “Under-
standing The Features Of

Page 30 of 338

Ram 3500 2016  Diesel Supplement CAUTION!
Continuous driving with the Transmission Tempera-
ture Warning Light illuminated will eventually cause
severe transmission damage or transmission failure.
WARNING!
If you continue operating t
