RAM CHASSIS CAB 2016 Owners Manual

• Trailer Brake
• Output
• Type
• Gain
EVIC Messages
• Front Seatbelts Unbuckled
• Driver Seatbelt Unbuckled
• Passenger Seatbelt Unbuckled
• Service Airbag System
• Traction Control Off
• Washer Fluid Low
• Oil Pressure Low
• Oil Change Due
• Fuel Low • Service Antilock Brake System
• Service Electronic Throttle Control
• Service Power Steering
• Cruise Off
• Cruise Ready
• Cruise Set To XXX MPH
• Tire Pressure Screen With Low Tire(s) “Inflate Tire to
XX”
• Tire Pressure Information System (TPIS)
• Service Tire Pressure System
• Parking Brake Engaged
• Brake Fluid Low
• Service Electronic Braking System 4UNDERSTANDING YOUR INSTRUMENT PANEL 279

• Engine Temperature Hot
• Battery Voltage Low
• Service Electronic Throttle Control
• Lights On
• Right Turn Signal Light Out
• Left Turn Signal Light Out
• Turn Signal On
• Sound Horn with Remote Lock: Off; 1st Press; 2nd
Press
• Vehicle Not in Park
• Key in Ignition
• Key in Ignition Lights On
• Remote Start Active Key to Run • Remote Start Active Push Start Button
• Remote Start Aborted Fuel Low
• Remote Start Aborted Too Cold
• Remote Start Aborted Door Open
• Remote Start Aborted Hood Open
• Remote Start Aborted Trunk Open
• Remote Start Aborted Time Expired
• Remote Start Disabled Start to Reset
• Service Airbag System
• Service Airbag Warning Light
• Driver Seatbelt Unbuckled
• Passenger Seatbelt Unbuckled
• Front Seatbelts Unbuckled280 UNDERSTANDING YOUR INSTRUMENT PANEL

• Door Open
• Doors Open
• Gear Not Available
• Shift Not Allowed
• Shift to Neutral then Drive or Reverse
• Automatic Unavailable Use Autostick Service Req.
• Transmission Getting Hot Press Brake
• Trans. Hot Stop Safely Shift to Park Wait to Cool
• Transmission Cool Ready to Drive
• Trailer Brake Disconnected
• Service Transmission
• Service Shifter
• Engage Park Brake to Prevent Rolling • Transmission Too cold Idle with Engine On
• Washer Fluid Low
• Autostop Duration – If Equipped
The Reconfigurable Telltales section is divided into the
white telltales area on the right, yellow telltales in the
middle, and red telltales on the left.
Screen Setup Menu Item
Push and release the UP or DOWN arrow button
until the Screen Setup menu item is highlighted in the
EVIC. Push and release the RIGHT arrow button
to enter the Screen Setup submenu. The Screen Setup
feature allows you to change what information is
displayed in the instrument cluster as well as the
location that information is displayed. 4UNDERSTANDING YOUR INSTRUMENT PANEL 281

Vehicle Settings Menu Item
Personal Settings allows the driver to set and recall
features when the transmission is in PARK.
Push and release the UP or DOWN arrow button
until Settings displays in the EVIC.
Follow the prompts to display and set any of the follow-
ing Vehicle Settings. NOTE: Your vehicle may or may not be equipped with
all the following settings.
• If equipped with a base radio (Non-Touchscreen)
Vehicle Settings will be included in the EVIC.
• If equipped with a Touchscreen radio, the Vehicle
Settings will be included in the radio head unit.
Setting Names Setting Names Ab-
breviated (Left Sub-
menu Layer) Sub-Menus (Right Submenu Layer)
1 Language Select Language English, Spanish, French, Italian, German, Dutch
2 Units Units U.S.; Metric
3 ParkSense ParkSense • Notification — Sound Only; Sound & Display
• Front Volume — Low; Medium; High
• Rear Volume — Low; Medium; High282 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting Names Setting Names Ab-
breviated (Left Sub-
menu Layer) Sub-Menus (Right Submenu Layer)
4 Tilt Mirror in Re-
verse Tilt Mirror in R On; Off
5 Rain Sensing Wipers Auto Wipers On; Off
6 Hill Start Assist Hill Start Assist On; Off
7 Headlights Off Delay Lights Off Delay 0 seconds; 30 seconds; 60 seconds; 90 seconds
8 Illuminated Ap-
proach Lights w/ Unlock 0 seconds; 30 seconds; 60 seconds; 90 seconds
9 Headlights On with
Wipers Lights w/ Wipers On; Off
10 Automatic High-
beams Auto Highbeams On; Off
11 Daytime Running
Lights — If
Equipped Daytime Lights On; Off 4UNDERSTANDING YOUR INSTRUMENT PANEL 283

Setting Names Setting Names Ab-
breviated (Left Sub-
menu Layer) Sub-Menus (Right Submenu Layer)
12 Flash Lights with
Lock Lights w/ Lock On; Off
13 Auto Lock Doors Auto Lock Doors On; Off
14 Auto Unlock Doors Auto Unlock Doors On; Off
15 Sound Horn with
Remote Start Horn w/ Rmt Start On; Off
16 Sound Horn with
Remote Lock Horn w/ Rmt Lock Off; 1st Press; 2nd Press
17 Remote Unlock Se-
quence Remote Unlock Driver Door; All Doors
18 Key Fob Linked to
Memory Key in Memory On; Off
19 Passive Entry Passive Entry On; Off284 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting Names Setting Names Ab-
breviated (Left Sub-
menu Layer) Sub-Menus (Right Submenu Layer)
20 Remote Start Com-
fort System Rmt Start Comfort Off; Remoter Start; All starts
21 Easy Exit Seat Easy Exit Seat On; Off
22 Key-off Power Delay Power Off Delay Off; 45 seconds; 5 minutes; 10 minutes
23 Commercial Settings Commercial • Aux Switches
• Power Take-Off
• PIN Setup
• ParkSense Setup
24 Horn w/ Remote
Lower Horn w/ Rmt Lwr On; Off
25 Lights w/ Remote
Lower Lights w/ Rmt Lwr On; Off
26 Trailer Select Trailer Select Trailer 1; Trailer 2; Trailer 3; Trailer 4 4UNDERSTANDING YOUR INSTRUMENT PANEL 285

Setting Names Setting Names Ab-
breviated (Left Sub-
menu Layer) Sub-Menus (Right Submenu Layer)
27 Brake Type Brake Type Light Electric; Heavy Electric; Light EOH; Heavy
EOH
28 Trailer Name Trailer Name • Trailer # (# is equal to slot position)
• Boat
• Car
• Cargo
• Dump
• Equipment
• Flatbed
• Gooseneck
• Horse
• Livestock
• Motorcycle
• Snowmobile
• Travel286 UNDERSTANDING YOUR INSTRUMENT PANEL

Setting Names Setting Names Ab-
breviated (Left Sub-
menu Layer) Sub-Menus (Right Submenu Layer)
• Utility
• 5th Wheel
29 Compass Variance Compass Var 1-15 increments of 1
30 Calibrate Compass Compass Cal Cancel; Calibrate
Turn Menu OFF
Push and release the RIGHT arrow button to exit the
main menu.
Push and release any EVIC control button to enter the
EVIC main menu again. DRIVER INFORMATION DISPLAY (DID)
The Driver Information Display (DID) features a driver-
interactive display that is located in the instrument
cluster. 4UNDERSTANDING YOUR INSTRUMENT PANEL 287

The DID Menu items consists of the following:
• Digital Speedometer
• Vehicle Info • Fuel Economy Info
• Trip A
• Trip B
• Stop/Start Info (If Equipped)
• Trailer Tow
• Audio
• Stored Messages
• Screen Setup
• Vehicle Settings (Not Equipped with a Uconnect 5.0 &
8.4 radio)Driver Information Display (DID)288 UNDERSTANDING YOUR INSTRUMENT PANEL
