TECHNICAL SPECIFICATIONS401
FUEL REQUIREMENTS – DIESEL ENGINE
Use good quality diesel fuel from a reputable
supplier in your vehicle. Federal law requires that
you must fuel this vehicle with Ultra Low Sulfur
Highway Diesel fuel (15 ppm Sulfur maximum) and
prohibits the use of Low Sulfur Highway Diesel fuel
(500 ppm Sulfur maximum) to avoid damage to the
emissions control system.
For most year-round service, Number 2 diesel fuel
meeting ASTM (formerly known as the American
Society for Testing and Materials) specification
D-975 Grade S15 will provide good performance. If
the vehicle is exposed to extreme cold (below 20°F
or -7°C), or is required to operate at
colder-than-normal conditions for prolonged
periods, use climatized Number 2 diesel fuel or
dilute the Number 2 diesel fuel with 50% Number
1 diesel fuel. This will provide better protection
from fuel gelling or wax-plugging of the fuel filters. Diesel fuel is seldom completely free of water. To
prevent fuel system trouble, drain the
accumulated water from the fuel/water separator
using the fuel/water separator drain provided on
both fuel filters. If you buy good quality fuel and
follow the cold weather advice above, fuel
conditioners should not be required in your vehicle.
If available in your area, a high cetane “premium”
diesel fuel may offer improved cold-starting and
warm-up performance.
FUEL SPECIFICATIONS
The Cummins® Turbo Diesel engine has been
developed to take advantage of the high energy
content and generally lower cost Number 2 Ultra
Low Sulfur diesel fuel or Number 2 Ultra Low Sulfur
climatized diesel fuels. Experience has shown that
it also operates on Number 1 Ultra Low Sulfur
diesel fuels or other fuels within specification.
NOTE:
If you accidentally fill the fuel tank with gasoline
on your diesel vehicle, Do not start the vehicle.
If you restart your vehicle you risk damaging the
engine and fuel system. Please call an autho-
rized dealer for service.
A maximum blend of 20% biodiesel meeting
ASTM specification D-7467 may be used with
your Cummins® diesel engine. (Models config
-
ured with B20 Capability.)
In addition, commercially available fuel addi -
tives are not necessary for the proper operation
of your Cummins® diesel engine. However, if
seasonably adjusted fuel is not available and
you are operating below 20°F (-6°C), Mopar®
Premium Diesel Fuel Treatment (or equivalent)
may be beneficial to avoid fuel gelling.
Number 1 Ultra Low Sulfur diesel fuel should
only be used where extended arctic conditions
(0°F or -18°C) exist.
BIODIESEL FUEL REQUIREMENTS
Chassis Cab Models Ordered With
B20 Option
Your vehicle has been validated and approved for
the use of biodiesel in blends up to 20% (B20)
provided that you comply with the requirements
outlined below. It is important that you understand
and comply with these requirements. Failure to
WARNING!
Do not use alcohol or gasoline as a fuel blending
agent. They can be unstable under certain
conditions and hazardous or explosive when
mixed with diesel fuel.
CAUTION!
If the Water in Fuel Indicator Light remains on,
DO NOT START engine before you drain the water
from the fuel filter(s) to avoid engine damage
Ú page 347.
9

22_DPF_OM_EN_USC_t.book Page 401

402TECHNICAL SPECIFICATIONS
comply with Oil Change requirements for vehicles
operating on biodiesel blends up to B20 will result
in premature engine wear. Such wear is not
covered by the New Vehicle Limited Warranty.
Biodiesel is a fuel produced from renewable
resources typically derived from animal fat,
rapeseed oil (Rapeseed Methyl Ester (RME) base),
or soybean oil (Soy Methyl Ester (SME or SOME)
base). Biodiesel fuel has inherent limitations which
require that you understand and adhere to the
following requirements if you use blends of
biodiesel greater then 5% but not greater than
20% (B6-B20). There are no unique restrictions for
the use of B5. Use of blends greater than 20% is
not approved. Use of blends greater than 20% can
result in engine damage. Such damage is not
covered by the New Vehicle Limited Warranty.
Fuel Quality — Must Comply With ASTM
Standards
The quality of biodiesel fuel may vary widely. Only
fuel produced by a BQ9000 supplier to the
following specifications may be blended to meet
biodiesel blend (B6–B20) fuel meeting ASTM
specification D-7467:
Petrodiesel fuel meeting ASTM specification
D-975 and biodiesel fuel (B100) meeting ASTM
specification D-6751.
Fuel Oxidation Stability — Must Use Fuel
Within Six Months Of Manufacture
Biodiesel fuel has poor oxidation stability which
can result in long term storage problems. Fuel
produced to approved ASTM standards, if stored
properly, provides for protection against fuel
oxidation for up to six months.
Fuel Water Separation — Must Use
Mopar®/Cummins® Approved Fuel Filter
Elements
You must use Mopar®/Cummins® approved fuel
filter elements in both your engine mounted filter
and frame mounted filter.
Biodiesel fuel has a natural affinity to water and
water accelerates microbial growth. Your Mopar®/
Cummins® filtration system is designed to provide
adequate fuel water separation capabilities.
Biodiesel Fuel Properties — Low Ambient
Temperatures
Biodiesel fuel may gel or solidify at low ambient
temperatures, which may pose problems for both
storage and operation. Precautions can be
necessary at low ambient temperatures, such as
storing the fuel in a heated building or a heated
storage tank, or using cold temperature additives.
Fuel In Oil Dilution — Must Adhere To
Required Oil Change Interval
Fuel dilution of lubricating oil has been observed
with the use of biodiesel fuel. Fuel in oil must not
exceed 5%. To ensure this limit is met your oil
change interval must be maintained to the
following schedule:
Ram 3500/4500/5500 Chassis Cab —
12,500 Miles (20,000 km)*
(*unless otherwise notified with a oil service
message)
CAUTION!
Under no circumstances should oil change
intervals exceed 12,500 miles (20,000 km) if
operation occurs with greater than 5%
biodiesel blends. Oil change intervals should
not exceed six months in either case. Failure to
comply with these Oil Change requirements for
vehicles operating on biodiesel blends up to
B20 may result in premature engine wear.
Such wear is not covered by the New Vehicle
Limited Warranty.
B20 Biodiesel capable: The engine may suffer
severe damage if operated with concentra -
tions of Biodiesel higher than 20%.

22_DPF_OM_EN_USC_t.book Page 402

TECHNICAL SPECIFICATIONS403
FLUID CAPACITIES
6.4L GASOLINE ENGINE
6.7L DIESEL ENGINE
USMetric
Fuel (Approximate)
Standard Rear Tank 52 Gallons197 Liters
Optional Midship Tank 22 Gallons83 Liters
Engine Oil With Filter
6.4L Engine 7 Quarts6.6 Liters
Cooling System
6.4L Engine 16.6 Quarts15.7 Liters
USMetric
Fuel (Approximate)
Standard Rear Tank 52 Gallons197 Liters
Optional Midship Tank 22 Gallons83 Liters
Diesel Exhaust Fluid Tank (Approximate) 8.7 Gallons33 Liters
Engine Oil With Filter
6.7L Turbo Diesel Engine 12 Quarts11.4 Liters
Cooling System
6.7L Engine Chassis Cab 3500/4500 with AS69RC 22.3 Quarts21.1 Liters
6.7L Engine Chassis Cab 5500 with AS69RC 22.8 Quarts21.6 Liters
9

22_DPF_OM_EN_USC_t.book Page 403

404TECHNICAL SPECIFICATIONS
ENGINE FLUIDS AND LUBRICANTS
6.4L GASOLINE ENGINE
Component Fluid, Lubricant, or Genuine Part
Engine Coolant We recommend using Mopar® Antifreeze/Coolant 10–Year/150,000 Mile
(240,000 km) Formula OAT (Organic Additive Technology).
Engine Oil We recommend using Mopar® API Certified SAE 0W-40 Full Synthetic Engine
Oil which meets the requirements of the manufacturer Material Standard
MS-A0921. Equivalent full synthetic SAE 0W-40 engine oil can be used but
must have the API Donut trademark Ú
page 342.
Engine Oil Filter We recommend using a Mopar® Engine Oil Filter. If a Mopar® Engine Oil Filter
is unavailable only use filters that meet or exceed SAE/USCAR-36 Filter
Performance Requirements.
Fuel Selection 87 Octane (R+M)/2 Method, 0-15% Ethanol (Do not use E-85).

22_DPF_OM_EN_USC_t.book Page 404

TECHNICAL SPECIFICATIONS405
6.7L DIESEL ENGINE
Component Fluid, Lubricant, or Genuine Part
Engine Coolant We recommend using Mopar® Antifreeze/Coolant 10 Year/150,000 Mile
(240,000 km) Formula OAT (Organic Additive Technology).
Engine Oil In ambient temperatures above 0°F (-18°C), we recommend using 10W-30
engine oil such as Mopar®, Shell Rotella and Shell Rimula that meets the
manufacturer Material Standard MS-10902 and the API CK-4 engine oil
category is required. Products meeting Cummins® CES 20081 may also be
used. The identification of these engine oils is typically located on the back of
the oil container.
In ambient temperatures below 0°F (-18°C), we recommend using 5W-40
synthetic
engine oil such as Mopar®, Shell Rotella and Shell Rimula that
meets the manufacturer Material Standard MS-10902 and the API CK-4
engine oil category is required.
Engine Oil Filter We recommend using a Mopar® Engine Oil Filter. If a Mopar® Engine Oil Filter
is unavailable only use filters that meet or exceed SAE/USCAR-36 Filter
Performance Requirements.
Fuel Filters We recommend using Mopar® Fuel Filter. Must meet 3 micron rating (engine
mounted filter). Must meet 5 micron rating (chassis mounted filter).
Using a
fuel filter that does not meet the manufacturer’s filtration and water
separating requirements can severely impact fuel system life and reliability.
Crankcase Ventilation Filter We recommend using Mopar® CCV Filter.
9

22_DPF_OM_EN_USC_t.book Page 405

406TECHNICAL SPECIFICATIONS
(Continued)
Fuel Selection
Use good quality diesel fuel from a reputable supplier in your vehicle. Federal
law requires that you must fuel this vehicle with Ultra Low Sulfur Highway
Diesel fuel (15 ppm Sulfur maximum) and prohibits the use of Low Sulfur
Highway Diesel fuel (500 ppm Sulfur maximum) to avoid damage to the
emissions control system.
For most year-round service, Number 2 diesel fuel meeting ASTM specification
D-975 Grade S15 will provide good performance.

If climatized or diesel Number 1 ULSD fuel is not available, and you are
operating below (20°F/-6°C), in sustained arctic conditions, Mopar® Premium
Diesel Fuel Treatment (or equivalent) is recommended to avoid gelling.

This vehicle is fully compatible with biodiesel blends up to 5% biodiesel
meeting ASTM specification D-975.
Pickup models, and Chassis Cab models
configured with optional B20 capability, are additionally compatible with 20%
biodiesel meeting ASTM specification D-7467.
Diesel Exhaust Fluid Mopar® Diesel Exhaust Fluid (API Certified) (DEF) or equivalent that has been
API Certified to the ISO 22241 standard. Use of fluids not API Certified to ISO
22241 may result in system damage. You can receive assistance in locating
DEF in the United States by calling 866-RAM-INFO (866-726-4636). In Canada
call 1–800–465–2001 (English) or 1–800–387–9983 (French).
Component
Fluid, Lubricant, or Genuine Part
CAUTION!
Mixing of engine coolant (antifreeze) other than specified Organic Additive Technology (OAT) engine coolant (antifreeze), may result in engine damage and
may decrease corrosion protection. Organic Additive Technology (OAT) engine coolant is different and should not be mixed with Hybrid Organic Additive Tech -
nology (HOAT) engine coolant (antifreeze) or any “globally compatible” coolant (antifreeze). If a non-OAT engine coolant (antifreeze) is introduced into the
cooling system in an emergency, the cooling system will need to be drained, flushed, and refilled with fresh OAT coolant (conforming to MS.90032), by an
authorized dealer as soon as possible.

22_DPF_OM_EN_USC_t.book Page 406

TECHNICAL SPECIFICATIONS407
CHASSIS FLUIDS AND LUBRICANTS
6.4L GASOLINE ENGINE
Do not use water alone or alcohol-based engine coolant (antifreeze) products. Do not use additional rust inhibitors or antirust products, as they may not be
compatible with the radiator engine coolant and may plug the radiator.
This vehicle has not been designed for use with propylene glycol-based engine coolant (antifreeze). Use of propylene glycol-based engine coolant (antifreeze)
is not recommended.
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission – 8-Speed Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid, or
equivalent. Failure to use the correct fluid may affect the function or
performance of your transmission.
Automatic Transmission – 6-Speed Use only Mopar® ASRC Automatic Transmission Fluid or equivalent. Failure to
use the proper fluid may affect the function or performance of your
transmission.
Transfer Case We recommend using Mopar® Transfer Case Lubricant for Borg Warner 44-44
and 44-45.
Front and Rear Axle Fluid We recommend using SAE 75W-85 HD Ram GL-5 Synthetic Axle Lubricant.
Limited slip additive is required for limited slip axles. If the axle fluid is not
pre-mixed with limited slip additive we recommend using Mopar®
MS-10111 Limited Slip Additive.
Brake Master Cylinder We recommend using Mopar® DOT 3 and SAE J1703.
Power Steering Reservoir
We recommend using Mopar® Power Steering Fluid +4, Mopar® ATF+4 Automatic
Transmission Fluid.

CAUTION!
9

22_DPF_OM_EN_USC_t.book Page 407

408TECHNICAL SPECIFICATIONS
6.7L DIESEL ENGINE
Component Fluid, Lubricant, or Genuine Part
Automatic Transmission Only use Mopar® ASRC Automatic Transmission Fluid or equivalent. Failure to
use the proper fluid may affect the function or performance of your
transmission.
Transfer Case We recommend using Mopar® BW44–44 Transfer Case Fluid.
Front and Rear Axle Fluid We recommend using SAE 75W-85 HD Ram GL-5 Synthetic Axle Lubricant.
Limited slip additive is required for limited slip axles. If the axle fluid is not
pre-mixed with limited slip additive we recommend using Mopar®
MS-10111 Limited Slip Additive.
Brake Master Cylinder We recommend using Mopar® DOT 3 and SAE J1703.

22_DPF_OM_EN_USC_t.book Page 408

410CUSTOMER ASSISTANCE
MEXICO
Av. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D.F.
In Mexico City: 800-505-1300
Outside Mexico City: +(52)55 50817568
PUERTO RICO AND US VIRGIN ISLANDS
FCA Caribbean LLC
P.O. Box 191857
San Juan 00919-1857
Phone: (866) 726-4636
Fax: (787) 782-3345
CUSTOMER ASSISTANCE FOR THE
H
EARING OR SPEECH IMPAIRED
(TDD/TTY)
To assist customers who have hearing difficulties,
FCA US LLC has installed special TDD (Telecommu -
nication Devices for the Deaf) equipment at its
customer center. Any hearing or speech impaired
customer, who has access to a TDD or a
conventional teletypewriter (TTY) in the United
States, can communicate with FCA US LLC by
dialing 1-800-380-2479. Canadian residents with hearing difficulties that
require assistance can use the special needs relay
service offered by Bell Canada. For TTY
teletypewriter users, dial 711 and for Voice callers,
dial 1-800-855-0511 to connect with a Bell Relay
Service operator.
SERVICE CONTRACT

You may have purchased a service contract for a
vehicle to help protect you from the high cost of
unexpected repairs after FCA US LLC's New Vehicle
Limited Warranty expires. The Mopar® Vehicle
Protection plans are the ONLY vehicle extended
protection plans authorized, endorsed and backed
by FCA US LLC to provide additional protection
beyond your vehicle’s warranty. If you purchased a
Mopar® Vehicle Protection plan, you will receive
Plan Provisions and an Owner Identification Card in
the mail within three weeks of the vehicle delivery
date. If you have any questions about the service
contract, call FCA US LLC’s Service Contract
National Customer Hotline at 1-800-521-9922
(Canadian residents, call (800) 465-2001 English /
(800) 387-9983 French).

FCA US LLC is not responsible for any service
contract you may have purchased from another
manufacturer. If you require service after the FCA
US LLC New Vehicle Limited Warranty expires,
please refer to the contract documents, and
contact the person listed in those documents.We appreciate that you have made a major
investment when you purchased the vehicle. An
authorized dealer has also made a major
investment in facilities, tools, and training to
assure that you are absolutely delighted with the
ownership experience.
WARRANTY INFORMATION
See the Warranty Information for the terms and
provisions of FCA US LLC warranties applicable to
this vehicle and market. Refer to www.mopar.com/
om for further information.
See the Warranty Information for the terms and
provisions of FCA Canada Inc. warranties
applicable to this vehicle and market. Refer to
www.owners.mopar.ca/en for further information.
WARNING!
Engine exhaust (internal combustion engines
only), some of its constituents, and certain
vehicle components contain, or emit, chemicals
known to the State of California to cause cancer
and birth defects, or other reproductive harm. In
addition, certain fluids contained in vehicles and
certain products of component wear contain, or
emit, chemicals known to the State of California
to cause cancer and birth defects, or other
reproductive harm.

22_DPF_OM_EN_USC_t.book Page 410

412CUSTOMER ASSISTANCE
Owner's Manuals
These Owner's Manuals have been prepared with
the assistance of service and engineering
specialists to acquaint you with specific FCA
vehicles.
To access your Owner's Information online, visit
www.mopar.com/om (US) or
www.owners.mopar.ca (Canada).
Or
Call Tech Authority toll free at:
1-800-890-4038 (US)
Owner's Manuals, Radio Manuals and Warranty
Information Books can be ordered through
Archway at:
1-800-387-1143 (Canada)
GENERAL INFORMATION
The following regulatory statement applies to all
Radio Frequency (RF) devices equipped in this
vehicle:
This device complies with Part 15 of the FCC Rules
and with Innovation, Science and Economic
Development Canada license-exempt RSS
standard(s). Operation is subject to the following
two conditions:
1. This device may not cause harmful
interference, and

2. This device must accept any interference received, including interference that may
cause undesired operation.
Le présent appareil est conforme aux CNR
d`Innovation, Science and Economic Development
applicables aux appareils radio exempts de
licence. L'exploitation est autorisée aux deux
conditions suivantes:

1. l'appareil ne doit pas produire de brouillage, et

2. l'utilisateur de l'appareil doit accepter tout brouillage radioélectrique subi, même si le
brouillage est susceptible d'en compromettre
le fonctionnement. La operación de este equipo está sujeta a las
siguientes dos condiciones:

1. es posible que este equipo o dispositivo no
cause interferencia perjudicial y

2. este equipo o dispositivo debe aceptar cualquier interferencia, incluyendo la que
pueda causar su operación no deseada.
NOTE:Changes or modifications not expressly approved
by the party responsible for compliance could void
the user’s authority to operate the equipment.

22_DPF_OM_EN_USC_t.book Page 412
