Ram ProMaster 2015 Owner's Manual

Cleaning Interior Trim
Interior trim should be cleaned starting with a damp
cloth, a damp cloth with MOPAR® Total Clean or equiva-
lent, then MOPAR® Spot & Stain Remover or equivalent
if absolutely necessary. Do not use harsh cleaners or
Armor All®. Use MOPAR® Total Clean or equivalent to
clean vinyl upholstery.
Cleaning Leather Upholstery
MOPAR® Total Clean or equivalent is specifically recom-
mended for leather upholstery.
Your leather upholstery can be best preserved by regular
cleaning with a damp soft cloth. Small particles of dirt
can act as an abrasive and damage the leather upholstery
and should be removed promptly with a damp cloth.
Stubborn soils can be removed easily with a soft cloth
and MOPAR® Total Clean or equivalent. Care should be
taken to avoid soaking your leather upholstery with anyliquid. Please do not use polishes, oils, cleaning fluids,
solvents, detergents, or ammonia-based cleaners to clean
your leather upholstery. Application of a leather condi-
tioner is not required to maintain the original condition.
CAUTION!
•
Do not use volatile solvents for cleaning purposes.
Many are potentially flammable, and if used in
closed areas they may cause respiratory harm.
• Do not use power washers to clean the inside of the
vehicle, plastic parts can be permanently damaged
and the amount of water can cause problems with
the electrical components of your vehicle.
Cleaning Headlights
Your vehicle is equipped with plastic headlights and fog
lights that are lighter and less susceptible to stone break-
age than glass headlights.
7
MAINTAINING YOUR VEHICLE 359

Plastic is not as scratch resistant as glass and therefore
different lens cleaning procedures must be followed.
To minimize the possibility of scratching the lenses and
reducing light output, avoid wiping with a dry cloth. To
remove road dirt, wash with a mild soap solution fol-
lowed by rinsing.
Do not use abrasive cleaning components, solvents, steel
wool or other aggressive material to clean the lenses.
Glass Surfaces
All glass surfaces should be cleaned on a regular basis
with MOPAR® Glass Cleaner, or any commercial
household-type glass cleaner. Never use an abrasive type
cleaner. Use caution when cleaning the inside rear win-
dow equipped with electric defrosters or windows
equipped with radio antennas. Do not use scrapers or
other sharp instrument that may scratch the elements.When cleaning the rear view mirror, spray cleaner on the
towel or cloth that you are using. Do not spray cleaner
directly on the mirror.
Cleaning Plastic Instrument Cluster Lenses
The lenses in front of the instruments in this vehicle are
molded in clear plastic. When cleaning the lenses, care
must be taken to avoid scratching the plastic.
1. Clean with a wet soft cloth. A mild soap solution may
be used, but do not use high alcohol content or
abrasive cleaners. If soap is used, wipe clean with a
clean damp cloth.
2. Dry with a soft cloth.
Seat Belt Maintenance
Do not bleach, dye, or clean the belts with chemical
solvents or abrasive cleaners. This will weaken the fabric.
Sun damage can also weaken the fabric.
360 MAINTAINING YOUR VEHICLE

If the belts need cleaning, use MOPAR® Total Clean, a
mild soap solution, or lukewarm water. Do not remove
the belts from the vehicle to wash them. Dry with a soft
cloth.
Replace the belts if they appear frayed or worn or if the
buckles do not work properly.
WARNING!
A frayed or torn belt could rip apart in a collision and
leave you with no protection. Inspect the belt system
periodically, checking for cuts, frays, or loose parts.
Damaged parts must be replaced immediately. Do
not disassemble or modify the system. Seat belt
assemblies must be replaced after a collision if they
have been damaged (i.e., bent retractor, torn web-
bing, etc.).
Cleaning The Instrument Panel Cupholders
Removal
Pull the flexible liner from the cupholder drawer starting
at one edge to ease removal.
Cleaning
The liner is top shelf dishwasher safe, or you may follow
the cleaning procedure below.
Soak the liner in a mixture of medium hot tap water and
one teaspoon of mild liquid dish soap. Let soak for
approximately 30 minutes. After 30 minutes, pull the
liner from the water and dip it back into the water about
six times. This will loosen any remaining debris. Rinse
the liner thoroughly under warm running water. Shake
the excess water from the liner and dry the outer surfaces
with a clean soft cloth.
7
MAINTAINING YOUR VEHICLE 361

Installation
Place the liner into the cupholder drawer and push the
liner into place so that the retention tabs seat into the
corresponding openings in the drawer.
FUSES
WARNING!
•When replacing a blown fuse, always use an ap-
propriate replacement fuse with the same amp
rating as the original fuse. Never replace a fuse
with another fuse of higher amp rating. Never
replace a blown fuse with metal wires or any other
material. Failure to use proper fuses may result in
serious personal injury, fire and/or property dam-
age.
(Continued)
WARNING! (Continued)
•Before replacing a fuse, make sure that the ignition
is off and that all the other services are switched off
and/or disengaged.
• If the replaced fuse blows again, contact an autho-
rized dealer.
• If a general protection fuse for safety systems (air
bag system, braking system), power unit systems
(engine system, gearbox system) or steering system
blows, contact an authorized dealer.
362 MAINTAINING YOUR VEHICLE

Underhood Fuses
The Front Power Distribution Center is located on the
driver ’s side of the engine compartment. To access the
fuses, remove the cover.The ID number of the electrical component correspond-
ing to each fuse can be found on the back of the cover.
Front Power Distribution Center
7
MAINTAINING YOUR VEHICLE 363

CavityMaxi Fuse Mini Fuse Description
F01 40 Amp Orange Electronic Stability Control (ESC) Pump
F02 20 Amp Yellow (3.6 Gasoline Engine) Starter Relay 3.6L (3.6 Gasoline Engine)
F02 50 Amp Red (3.0 Die- sel Engine) Glow Plug Unit (3.0 Diesel Engine)
F04 50 Amp Red (3.6
Gasoline Engine) Secondary Power Distribution Center
(PDC) (Trans Power Relay, Vacuum
Pump, KL30 for the Shifter Transmission
Module [STM]) (3.6 Gasoline Engine)
F04 40 Amp Orange (3.0 Diesel Engine) Fuel Filter Heater (3.0 Diesel Engine)
F05 30 Amp Green SELESPEED Pump RELE (3.0 Diesel En-
gine) - If Equipped
F06 40 Amp Orange (non A/C)
60 Amp Blue (A/C) Engine Cooling Fan - 2nd Speed
364 MAINTAINING YOUR VEHICLE

CavityMaxi Fuse Mini Fuse Description
F07 50 Amp Red (non
A/C)
60 Amp Blue (A/C) Engine Cooling Fan - 1st Speed
F08 40 Amp Orange Passenger Compartment Blower
F09 15 Amp Blue Rear Power Outlet
F10 15 Amp Blue Horn
F11 15 Amp Blue Fuel Pressure Regulator (MPROP)-DRV
(3.0 Diesel Engine) — If Equipped
F14 20 Amp Yellow Power Outlet
F15 7.5 Amp Brown USB Charger
F16 7.5 Amp Brown KL15 Shifter Transmission Module
(STM) (3.6), KL15 Starter Relay Coil (3.6
Gasoline Engine)
7
MAINTAINING YOUR VEHICLE 365

CavityMaxi Fuse Mini Fuse Description
F16 7.5 Amp Brown KL15 Manual Transmission Automated
(MTA), KL15 Shift Lever Unit, KL15 En-
gine Control Module (ECM), KL15
Starter Relay Coil (3.0 Diesel Engine)
F17 20 Amp Yellow Engine Control Module (ECM), Injectors
(3.6 Gasoline Engine)
F17 20 Amp Yellow Secondary Loads, Engine Control Mod-
ule (ECM) (3.0 Diesel Engine)
F18 7.5 Amp Brown KL30 Engine Control Module (ECM),
KL30 Main Relay Coil (3.6 Gasoline En-
gine)
F18 7.5 Amp Brown KL30 Manual Transmission Automated
(MTA), KL30 Engine Control Module
(ECM), KL30 Main Relay Coil (3.0 Diesel
Engine)
F19 7.5 Amp Brown A/C Compressor (If Equipped)
366 MAINTAINING YOUR VEHICLE

CavityMaxi Fuse Mini Fuse Description
F20 30 Amp Green Windshield Wiper
F21 15 Amp Blue Fuel Pump
F22 20 Amp Yellow Engine Control Module (ECM), Ignition
Coils (3.6 Gasoline Engine)
F22 20 Amp Yellow Engine Control Module (ECM), Primary
Loads (3.0 Diesel Engine)
F23 20 Amp Yellow Electronic Stability Control (ESC) Valves
F24 7.5 Amp Brown KL15 Vacuum pump relay coil (3.6
Gasoline Engine) — If Equipped
F30 15 Amp Blue Heated Mirrors
7
MAINTAINING YOUR VEHICLE 367

Front PDC Additional Fuses
The additional fuse box is located inside the front PDC
Box.
Front Power Distribution Center Additional Fuses
