Ram ProMaster 2018 Quick Reference Guide

• Do not press the brake and accelerator ped-als at the same time. Use only one foot to
operate the brake and accelerator. When
starting on a hill, it may be helpful to engage
the parking brake to hold the vehicle, and
then release the parking brake as you accel-
erate from the stop.
• If the vehicle is moving, REVERSE engage- ment will only occur if the vehicle speed is
less than 2 mph (3 km/h). Otherwise, a
chime will sound, a "Shift not Allowed" mes-
sage will appear in the instrument cluster
display, and the transmission will shift to
NEUTRAL. Return the gear selector to NEU-
TRAL, bring the vehicle to a complete stop,
and then shift to REVERSE.
• During closed-throttle decelerations in MANUAL (M) mode, the transmission will
shift down through the gears automatically
(to prevent engine lugging), coming to first
gear at a stop. After a stop, the driver should
manually upshift (+) the transmission as the
vehicle is accelerated. • Very aggressive driving may result in some
clutch odor. A warning message will appear
in the instrument cluster display if cool
down actions are needed.
• Like a manual transmission, mechanical sounds may be heard under normal operat-
ing conditions. You may also notice a hy-
draulic pump running occasionally, even be-
fore starting the engine. This is normal and
will not damage the vehicle.
• Never leave your vehicle with the transmis- sion in NEUTRAL (N). Always place your
vehicle in gear when leaving the vehicle. It is
essential to wait until the gear engaged ap-
pears in the display before turning the en-
gine off and releasing the brake pedal. Al-
ways remember to set the parking brake
when leaving the vehicle. For further information, and applicable warn-
ings and cautions, please refer to the Diesel
Supplement at www.mopar.com/en-us/care/
owners-manual.html (U.S. Residents) or
www.owners.mopar.ca (Canadian Residents).
Interior Bulb Replacement
For proper interior bulb replacement proce-
dures, refer to “Bulb Replacement” in "In Case
Of Emergency” located in the Owner’s Manual
at
www.mopar.com/en-us/care/owners-manual.html
(U.S. Residents) or www.owners.mopar.ca (Ca-
nadian Residents).

Winch Operation
Removing The Spare Tire
1. Remove the spare tire before attempting tojack up the vehicle. Attach the lug bolt
adapter to the winch extension and insert it
into the winch mechanism. The winch mechanism is located under the
rear of the vehicle to the right of the spare
tire.
2. Rotate the wheel wrench handle counter- clockwise until the spare tire is on the
ground with enough cable slack to allow you
to pull it out from under the vehicle.
Winch Location
Jack Tools
1 — Wrench Handle
2 — Lug Bolt Adapter
3 — Winch Extension
Winch Location
JACKING AND TIRE
CHANGING

NOTE:
The winch mechanism is designed for use with
the winch extension tube only. Use of an air
wrench or other power tools is not recom-
mended and can damage the winch.3. Pull the spare tire out from under the ve-
hicle to gain access to the spare tire re-
tainer.
4. Lift the spare tire with one hand to giveclearance to tilt the retainer at the end of the
cable.
5. Pull the retainer through the center of the wheel.
Winch Extension
Lowering Spare Tire
Spare Tire

NOTE:
For further information, and applicable warn-
ings and cautions, please refer to the Owner’s
Manual at www.mopar.com/en-us/care/
owners-manual.html (U.S. Residents) or
www.owners.mopar.ca (Canadian Residents).
Jump Starting Procedures
The vehicle’s jump starting remote posts are
located under the hood, in the engine compart-
ment on the driver's side.
NOTE:
If access to the battery is needed, an access
panel on the driver’s side floor will allow for
battery access.
Retainer
Remote Battery Posts
1—Remote Positive(+)Jump Starting
Post
2 — Remote Negative (-)Jump Starting
Post
JUMP STARTING

Connecting The Jumper Cables
1. Connect the positive(+)end of the jumper
cable to the remote positive (+)post of the
discharged vehicle.
NOTE:
The remote positive (+)post is located in the
engine compartment on the driver's side un-
der the cover of the Front Power Distribution
Center.
2. Connect the opposite end of the positive (+)
jumper cable to the positive (+)post of the
booster battery.
3. Connect the negative end (-)of the jumper
cable to the negative (-)post of the booster
battery.
4. Connect the opposite end of the negative (-)
jumper cable to the remote negative (-)post
of the discharged vehicle. NOTE:
The remote negative
(-)post is located in the
front of the engine compartment on the driv-
er's side.
5. Start the engine in the vehicle that has the booster battery. Let the engine idle a few
minutes and then start the engine in the
vehicle with the discharged battery.
6. Once the engine is started, disconnect the jumper cables in the reverse sequence:
Disconnecting The Jumper Cables
1. Disconnect the negative end (-)of the
jumper cable from the remote negative (-)
post of the vehicle with the discharged bat-
tery.
2. Disconnect the opposite end of the negative (-)jumper cable from the negative (-)post of
the booster battery.
3. Disconnect the positive end (+)of the
jumper cable from the positive (+)post of
the booster battery. 4. Disconnect the opposite end of the positive
(+) jumper cable from the remote positive
(+) post of the discharged vehicle.
5. Close the cover of the Front Power Distribu- tion Center.
NOTE:
If frequent jump starting is required to start
your vehicle, you should have the battery and
charging system inspected at your authorized
dealer. Use the provided remote battery posts
provide to prevent any damage to your vehicle.
For further information, and applicable warn-
ings and cautions, please refer to the Owner’s
Manual at
www.mopar.com/en-us/care/owners-manual.html
(U.S. Residents) or www.owners.mopar.ca (Ca-
nadian Residents).

NOTE:
The Owner’s Mobile App content is applicable
to vehicles sold in the U.S. market and are not
available from the Canadian App Store or
Google Play Store.
Key Features
• Owner Information For Your Vehicle
• Accident Assistant
• Online Service Scheduling
• Roadside Assistance
• Maintenance History
• And More
To get this FREE application, go directly to the
App Store or Google Play Store and enter the
search keyword “RAM TOOLBOX”.
The RAM TOOLBOX Application is the essential
app for owners of Ram brand vehicles. The app
puts driver and lifestyle information right in the
palm of your hand, anywhere you go. Whether
it’s providing information about specific prod-
uct features, taking a tour through your vehi-
cle’s equipment, staying up to date on yourvehicle’s health, knowing what steps to take
following an accident, or scheduling your next
appointment, we know you’ll find the app an
important extension of your Ram vehicle. Sim-
ply download the FREE app, select your make
and model and enjoy the ride.Features/Benefits
• Available for free on iOS and Android smart-
phones and tablets.
• Select Ram brand vehicles from model year 2011 to current model year.
• You can also add other Chrysler, Dodge, Jeep, FIAT, or Alfa Romeo vehicles.*
• Easy access to vehicle information anywhere you go using categories, bookmarks, search
and an A-Z index.
• Vehicle information such as operating in- structions, maintenance, service history, ve-
hicle controls and emergency procedures.
• Find a dealer or an FCA-certified repair fa- cility.
• Easily document and email an accident re- port. • A parking reminder that allows you to drop a
pin on your location and navigate back to
your vehicle.
• Contact customer care with one click.
• Access to vehicle heritage, parts, accesso- ries, and social media networks.
• Schedule your next service appointment.
• Available in English and Spanish.
*App supports selected vehicles from model
year 2011 to present.
To get this FREE application, go directly to the
App Store or Google Play Store and enter the
search keyword “RAM TOOLBOX”.
