Ram ProMaster City 2015 Owner's Manual

PARKVIEW® REAR BACK UP CAMERA — IF
EQUIPPED
Your vehicle may be equipped with the ParkView® Rear
Back Up Camera that allows you to see an on-screen
image of the rear surroundings of your vehicle whenever
the shift lever is put into REVERSE. The image will be
displayed on the touchscreen display along with a cau-
tion note to “check entire surroundings” across the top of
the screen. After five seconds this note will disappear.
The ParkView® camera is located on the rear of the
vehicle above the rear License plate.
When the vehicle is shifted out of REVERSE or when the
Camera Delay is turned OFF on the rear camera settings
menu, the rear camera mode is exited and the navigation
or audio screen appears again.
When the transmission is shifted out of REVERSE, with
the delay camera activated ON in the menu screen, thecamera image will continue to be displayed up to 10
seconds after placing the vehicle in the reverse position,
unless the speed of the vehicle is not greater than 8 mph
(13 km/h), the transmission is in PARK position or the
ignition key is in the OFF position.
When the vehicle is in reverse, there is a provided
touchscreen display to turn the camera image off. The
display of the camera image after switching off the
touchscreen display can be enabled or disabled through
the rear camera settings menu.
When displayed, static grid lines will illustrate the width
of the vehicle and will show separate zones that will help
indicate the distance to the rear of the vehicle. The
following table shows the approximate distances for each
zone:
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129

ZoneDistance to the rear of the vehicle
Red 0 - 1 ft (0 - 30 cm)
Yellow 1 ft - 3 ft (30 cm - 1 m)
Green 3 ft or greater (1 m or greater)
WARNING!
Drivers must be careful when backing up even when
using the ParkView® Rear Back Up Camera. Always
check carefully behind your vehicle, and be sure to
check for pedestrians, animals, other vehicles, ob-
structions, or blind spots before backing up. You are
responsible for the safety of your surroundings and
must continue to pay attention while backing up.
Failure to do so can result in serious injury or death.
CAUTION!
•To avoid vehicle damage, ParkView® should only
be used as a parking aid. The ParkView® camera is
unable to view every obstacle or object in your
drive path.
• To avoid vehicle damage, the vehicle must be
driven slowly when using ParkView® to be able to
stop in time when an obstacle is seen. It is recom-
mended that the driver look frequently over his/her
shoulder when using ParkView®.
130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

NOTE:If snow, ice, mud, or any foreign substance
builds up on the camera lens, clean the lens, rinse with
water, and dry with a soft cloth. Do not cover the lens.
POWER OUTLETS
Passenger Compartment Power Outlets
The cigar lighter and the power socket are located in the
center console, and both operate with the ignition key in
the MAR (ACC/ON/RUN) position.
Load Compartment Power Outlet
The Load Compartment Power Outlet is located on the
left side of the rear cargo compartment. The outlet can be
used for powering 12 Volt adaptive accessories and
recharging communications devices.
Passenger Compartment Power Outlets
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131

NOTE:Do not connect devices with power higher than
180W to the outlet. Using unsuitable adaptors may
damage the outlet.
Load Compartment Power OutletUnderhood Power Outlet Fuse Locations
1 — #85 Fuse 15A Blue Rear Power Outlet 12V
2 — #86 Fuse 15A Blue IP Power Outlet 12V
132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

WARNING!
To avoid serious injury or death:
•Only devices designed for use in this type of outlet
should be inserted into any 12 Volt outlet.
• Do not touch with wet hands.
• Close the lid when not in use and while driving the
vehicle.
• If this outlet is mishandled, it may cause an electric
shock and failure.
Interior Fuse Panel Power Outlet Fuse Location
1 — #05 Fuse 15A Blue Second IP Power Outlet 12V
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133

CAUTION!
•Many accessories that can be plugged in draw
power from the vehicle’s battery, even when not in
use (i.e., cellular phones, etc.). Eventually, if
plugged in long enough, the vehicle’s battery will
discharge sufficiently to degrade battery life and/or
prevent the engine from starting.
• Accessories that draw higher power (i.e., coolers,
vacuum cleaners, lights, etc.) will degrade the bat-
tery even more quickly. Only use these intermit-
tently and with greater caution.
• After the use of high power draw accessories, or
long periods of the vehicle not being started (with
accessories still plugged in), the vehicle must be
driven a sufficient length of time to allow the
generator to recharge the vehicle’s battery.
CIGAR LIGHTER AND ASH RECEIVER — IF
EQUIPPED
A removable ash receiver and cigar lighter are available.
Push the cigar lighter button to activate the cigar lighter
when the ignition key is in the MAR position.
After a few seconds the button returns to its initial
position and the cigar lighter is ready for use.
NOTE: Always check that the cigar lighter has turned
itself off.
WARNING!
The cigar lighter becomes very hot. Handle it care-
fully and make sure children don’t touch it: risk of
fire and/or burning.
134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CUPHOLDER
A cupholder is located in the front and rear of the center
console.
STORAGE
Glove Compartment
The glove compartment is located on the passenger side
of the instrument panel. Pull on the release handle to
open the glove compartment.
NOTE:The glove compartment handle is equipped with
a lock. To lock the glove compartment, remove the
emergency key from the key fob, insert emergency key
into glove compartment handle lock cylinder and turn
the key to the lock position and remove the key. Use the
reverse sequence to unlock the glove compartment.
Glove Compartment Release Handle
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135

Dash Storage
The dash storage is located on the right side of the
instrument panel above the glove compartment.
Overhead Console Storage
There is additional shelf storage above the front sun
visors.
Dash StorageOverhead Console Storage Location
136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE

CARGO AREA FEATURES
Rear Cargo Tie-Downs
To make it easier to secure your load, there are hooks (if
equipped) fixed to the floor.
WARNING!
•To help protect against personal injury, passengers
should not be seated in the rear cargo area. The rear
cargo space is intended for load carrying purposes
(Continued)
Rear Cargo Tie-Downs (Cargo Version)
Rear Cargo Tie-Downs (Passenger Version)
3
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137

WARNING!(Continued)
only, not for passengers, who should sit in seats
and use seat belts.
• Cargo tie-down hooks are not safe anchors for a
child seat tether strap. In a sudden stop or accident,
a hook could pull loose and allow the child seat to
come loose. A child could be badly injured. Use
only the anchors provided for child seat tethers.
The weight and position of cargo and passengers can
change the vehicle center of gravity and vehicle
handling. To avoid loss of control resulting in per-
sonal injury, follow these guidelines for loading your
vehicle:
• Do not carry loads which exceed the load limits
described on the label attached to the left door or
left door center pillar.
(Continued)
WARNING! (Continued)
•Always place cargo evenly on the cargo floor. Put
heavier objects as low and as far forward as pos-
sible.
• Place as much cargo as possible in front of the rear
axle. Too much weight or improperly placed weight
over or behind the rear axle can cause the rear of
the vehicle to sway.
• Do not pile luggage or cargo higher than the top of
the seatback. This could impair visibility or be-
come a dangerous projectile in a sudden stop or
accident.
Rear Cargo Lights
Your vehicle may be equipped with rear cargo lights that
can be set to three different positions (On/Left Position,
Center Position, On/Right Position). Using the interior
light lens, push the lens to the right or left from its center
138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE
