Fonction Stop and Start (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
Deactivating, activating the
function
Press switch 1 to deactivate the func-
tion. Warning light 2 in the switch lights
up.
Pressing again will reactivate the
system. Warning light 2 in switch 1
goes out.
STOP AND START function (3/3)
The system is automatically reacti-
vated each time the vehicle is started
(see “Starting, stopping the engine” in
Section 2).
Operating faults
When the warning light 2 built in to
switch 1 is lit, the system is deacti-
vated.
Please consult an authorised dealer.
Before getting out of the
vehicle, you must switch
off the ignition (please see
section on “Starting, stop-
ping the engine”).
12
Special feature of the automatic
engine re-start
Under certain conditions, the engine
can restart on its own in order to gua-
rantee your safety and comfort.
This can occur especially when:
– The outdoor temperature is too low
or too high (less than around 0°C or
higher than around 30°C);
– the battery is not sufficiently char-
ged;
– the vehicle speed is above 3 mph
(5 km/h) (downhill slope, etc.);
– repeated pressing on the brake
pedal or braking system require-
ment;
– ...
Special note: with the engine on
standby, press switch 1 to automa-
tically restart the engine.Special note: for some of these
conditions the automatic restarting
of the engine is inhibited if a front
door is open.

JauneNoir Noir texte
2.10
ENG_UD18237_9
Particularités des versions essence (B90 - U90 - L90 Ph2 - F90 Ph2 - R90 Ph2 - H79 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
SPECIAL FEATURES OF PETROL VERSIONS
The following operating conditions:
– driving for long periods when the low
fuel level warning light is lit;
– using leaded petrol;
– using oil or fuel additives which are
not approved by the manufacturer.
Or operating faults such as:
– faulty ignition system, running out of
fuel or disconnected spark plugs re-
sulting in the engine misfiring or cut-
ting out when driving;
– loss of power,
may cause the catalytic converter to
overheat, reducing its efficiency which
may irreparably damage it and cause
heat damage to the vehicle.If you notice any of the above operating
faults, have the necessary repairs car-
ried out as soon as possible by an ap-
proved Dealer.
These faults may be avoided by reg-
ularly taking your vehicle to your ap-
proved dealer at the intervals speci-
fied in your Maintenance Service
Document.
Starting problems
To avoid damaging the catalytic con-
verter, do not keep trying to start the
engine (using the start button, or by
pushing or towing the vehicle) without
having identified and corrected the
starting fault.
If the fault cannot be identified, do not
continue to try and start the engine, but
contact an approved dealer.
Do not park the vehicle or
run the engine in locations
where combustible sub-
stances or materials such
as grass or leaves can come into
contact with a hot exhaust system.

JauneNoir Noir texte
2.11
ENG_UD14105_1
Particularités des versions diesel (H79 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
SPECIAL FEATURES OF DIESEL VERSIONS
Diesel engine speed
Diesel engines are fitted with an injec-
tion pump which prevents the engine
speed being exceeded irrespective of
the gear selected.
If the
Ä and Ò warning lights
come on, consult an approved dealer
as soon as possible.
When driving, depending on the fuel
grade used, it is possible that white
smoke may be emitted.
This is due to the exhaust particle filter
being cleaned automatically, and does
not affect the way the vehicle runs.
Running out of fuel
If the tank has been completely
drained, the system must be reprimed
after the tank is refilled: see information
on the “Fuel tank” in Section 1 before
restarting the engine.
Precautions to be taken in
winter
To avoid any faults in icy weather:
– ensure that the battery is always fully
charged;
– always keep the diesel tank rela-
tively full to avoid water vapour con-
densing in it and accumulating at the
bottom of the tank.
Do not park the vehicle or
run the engine in locations
where combustible sub-
stances or materials such
as grass or leaves can come into
contact with a hot exhaust system.

JauneNoir Noir texte
2.12
ENG_UD39326_3
Particularités des versions GPL (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
Fuel gauge warning light A
The warning lights A (4 green lights and
1 red light) indicate the level in the LPG
tank.
The red warning light indicates the fuel
tank.
The amount of LPG indicated is an in-
dicative value.
The red warning light indicates that
the tank is almost empty and that the
engine is operating using the fuel tank
(approximately 11 to 13 litres).
SPECIAL FEATURES OF LPG VERSIONS (1/3)
LPG vehicles
These vehicles operate using petrol or
LPG.
They have two separate tanks.
What is LPG?
LPG stands for Liquefied Petroleum
Gas.
It can be readily identified by its charac-
teristic smell.
An LPG installation on
a vehicle may lead to
changes to the vehicle’s
features, compared to
petrol versions. This may relate to
the number of seats, mass (usable
capacity) and towing capacity.
Contact an authorised dealer.
LPG/petrol fuel mode selection
control C
This enables the driver to switch from
one fuel to another.
Green warning light D
A lit warning light indicates that LPG
mode is active.
Rapid flashing of the warning light D
indicates that the system is waiting for
the necessary conditions to switch to
LPG mode.
Yellow warning light B
A lit warning light indicates that petrol
mode is active.
If the yellow warning light is
on while the green warning
light flashes slowly and a
beep is heard, please take
your vehicle to an authorised dealer
for inspection.
A
DCB

JauneNoir Noir texte
2.13
ENG_UD39326_3
Particularités des versions GPL (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
SPECIAL FEATURES OF LPG VERSIONS (2/3)
Changing fuel while driving
To switch from petrol to LPG
Press control C. The vehicle will switch
to LPG the next time the accelerator
pedal is pressed.
The LPG fuel level A is activated. The
yellow warning light B goes out and the
green warning light D flashes quickly to
confirm that LPG has been selected,
then stops flashing when LPG mode is
active.
Pressing control C stops the beep from
sounding and only the yellow warning
light B stays on.
To switch from LPG to petrol.
Release the accelerator pedal and
press the control C.
Petrol mode is indicated by the yellow
warning light B.Automatic switch to petrol
The system automatically switches to
petrol mode if there is no more LPG
remaining in the tank. You will be in-
formed by:
– the green D and yellow B warning
lights coming on;
– a beep sounds.
Pressing control C stops the beep from
sounding and only the yellow warning
light B stays on.
Depending on the vehicle, under certain
conditions of use, the system may opt to
temporarily switch back to petrol mode
(the green warning light D flashes wi-
thout any beep sounding, for example,
during strong acceleration). Once the
suitable conditions are present once
again, it will automatically switch back
to LPG mode. After several unsuccess-
ful attempts, the system may decide to
remain in petrol mode for the current
driving session. A further attempt may
be made after the engine has been at a
complete stop for 1 minute.
DCB
A
C

JauneNoir Noir texte
2.14
ENG_UD39326_3
Particularités des versions GPL (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
SPECIAL FEATURES OF LPG VERSIONS (3/3)
If driving under severe
conditions
If driving under severe conditions (hea-
vily laden vehicle, high outside tempe-
rature, starting on a steep slope, etc),
you are recommended to switch to
petrol mode.
At temperatures close to 0°C or less, it
is recommended to use ECO mode to
maximise the use of LPG. Please refer
to the information on “Driving advice,
Eco-driving” in Section 2.
In the event of an accident
The main precautions to be taken are
the same as with petrol vehicles:
– apply the handbrake;
– stop the engine (a safety device that
stops LPG from entering the engine
is automatically triggered);
– switch off the ignition;
– observe local regulations.
LPG has a very specific
smell so you will be able to
detect any leaks easily. If
you smell gas in your vehi-
cle or immediately surrounding your
vehicle:
– switch to petrol mode immedia-
tely and make sure there are no
flames or sources of fire near the
vehicle;
– go to an authorised dealer.
Do not touch, hit or dis-
mantle any part of the LPG
system components.
Operating fault
In the event of a fault which may affect
the correct operation of the engine, the
system automatically switches from
LPG to petrol mode.
This is confirmed by:
– the appearance of the yellow war-
ning light B;
– slow flashing of the green warning
light D;
– a beep sounds.

JauneNoir Noir texte
2.16
ENG_UD35353_1
Conseils de conduite, eco conduite (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
DRIVING ADVICE, ECO-DRIVING (2/5)
ECO mode
ECO mode is a function which opti-
mises fuel consumption. This acts on
certain consumption components, such
as the engine.
Activating the function
Press switch 3.
The 2
 warning light comes on on
the instrument panel to confirm activa-
tion.
While driving, it is possible to leave the
ECO mode temporarily in order to im-
prove engine performance.
To do this, press the accelerator pedal
firmly and fully.
ECO mode is reactivated when you
take pressure off the accelerator pedal.
Disabling the function
Press switch 3.
The 2
 light goes out on the in-
strument panel to confirm deactivation.
2
3

JauneNoir Noir texte
2.17
ENG_UD35353_1
Conseils de conduite, eco conduite (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
DRIVING ADVICE, ECO-DRIVING (3/5)
– Avoid sudden acceleration.
– Brake as little as possible. If you an-
ticipate an obstacle or bend in ad-
vance, you may then simply release
the accelerator pedal.
– Do not try to maintain the same
speed up a hill, accelerate no more
than you would on the level. Keep
your foot in the same position on the
accelerator pedal.
– Double declutching and accelerating
before switching off are unnecessary
in modern vehicles.
On versions with an automatic gear-
box, it is preferable to keep the gear
lever in position D.
Vehicles with 4x4 (4WD) trans-
mission
On flat, level ground, with the vehi-
cle unladen, you are recommended
to start in second gear.
Driving advice, Eco-driving
Behaviour
– Drive carefully for the first few miles
until the engine reaches its normal
operating temperature, rather than
let it warm up while the vehicle is sta-
tionary.
– Speed is expensive.
– Sporty driving uses a lot of fuel: drive
with a light right foot.
– Do not overrev the engine in the in-
termediate gears.
You should always use the highest
gear possible.
Driving problems
On the driver’s side, only
use mats specially adapted
for the vehicle and attached
to prefitted devices. Check regularly
to make sure they are secure. Do
not overlay several mats.
Risk of pedals jamming.

JauneNoir Noir texte
2.19
ENG_UD35353_1
Conseils de conduite, eco conduite (H79 Ph2 - Dacia) ENG_NU_1079-6_H79Ph2_Dacia_2
DRIVING ADVICE, ECO-DRIVING (5/5)
– In vehicles fitted with air condi-
tioning, it is normal to observe an
increase in fuel consumption (es-
pecially in urban conditions) when
it is used. For vehicles fitted with
manual air conditioning, switch off
the system when it is not required.
Advice for reducing consumption
and therefore helping to preserve
the environment:
If the vehicle has been parked in the
sun, open the doors for a few mo-
ments to let the hot air escape before
starting the engine.
– Do not leave an empty roof rack
fitted to the vehicle.
– It is better to fit a trailer for bulky ob-
jects.
– When towing a caravan, fit a wind
deflector and adjust it carefully.
– Avoid using the car for door-to-door
calls (short journeys with long waits
in between) because the engine
never reaches its normal operating
temperature. Advice on use
– Favour ECO mode.
– Electricity is fuel; switch off all the
electrical components which are
not really needed. However (safety
first), keep your lights on when the
visibility is bad (“see and be seen”).
– Use the air vents. Driving with the
windows open at 60 mph (100 km/h)
will increase fuel consumption by
4%.
– Never fill the fuel tank right to the
brim to avoid overflow.

JauneNoir Noir texte
2.20
ENG_UD35404_3
Conseils entretien et antipollution (X95 - E95 - J95 - R95 - H79 - X67 - X92 - X98 - X52 - X87 - H79 Ph2 - X07 - Renault) ENG_NU_1079-6_H79Ph2_Dacia_2
MAINTENANCE AND ANTIPOLLUTION ADVICE
Your vehicle complies with criteria for
recycling and recovering vehicles at the
end of their service life, which will come
into force in 2015.
Some of the parts on your vehicle have
been designed to be recycled later.
These parts are easily removable in
order to be collected and reprocessed
in recycling networks.
Furthermore, by virtue of its design,
moderate fuel consumption and initial
settings, your vehicle also conforms
to current anti-pollution regulations.
The manufacturer is actively striving
to reduce pollutant exhaust gas emis-
sions and to save energy. However,
the fuel consumption of your vehicle
and the level of pollutant exhaust gas
emissions are also your responsibility.
Ensure that it is maintained and used
correctly.Maintenance
It is important to remember that fail-
ure to respect anti-pollution regulations
could lead to legal action being taken
against the vehicle owner.
In addition, replacing engine, fuel
supply system and exhaust compo-
nents with parts other than those origi-
nally recommended by the manufac-
turer may alter your vehicle so that it
no longer complies with anti-pollution
regulations.
Have your vehicle adjusted and
checked by an authorised dealer, in ac-
cordance with the instructions given in
your maintenance schedule: they will
have all the equipment necessary for
ensuring that your vehicle is maintained
to its original standard.
Engine adjustments
– Air filter, fuel filter: a choked ele-
ment will reduce efficiency. It must
be replaced.
– Idle speed: no adjustment is needed.
Exhaust gas monitoring
system
The exhaust gas monitoring system will
detect any operating faults in the vehi-
cle’s antipollution system.
If this system malfunctions, toxic sub-
stances may be released into the at-
mosphere or damage may occur.
ÄThis warning light on the in-
strument panel will indicate if
there are any faults in the system:
This lights up when the ignition is
switched on and goes out when the
engine is started.
– If it lights up continuously, consult an
approved Dealer as soon as possi-
ble;
– if it flashes, reduce the engine speed
until the light stops flashing. Contact
an authorised dealer as soon as pos-
sible.
