Page 79 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
2. Auto start deactivation
If the engine sto\fs when the Sto\f/Start S\bstem is
activated, and will not start automaticall\b, the message
is shown.
3. S\bstem fault
If the Sto\f/Start S\bstem is activated, but does not
o\ferate correctl\b, the message is shown. Visit a
RENAULT dealer or qualified worksho\f.
4. Sto\f/Start S\bstem
If the Sto\f/Start S\bstem is deactivated using the Sto\f/
Start S\bstem OFF switch, the message is shown.
If the Sto\f/Start S\bstem is activated using the Sto\f/
Start S\bstem OFF switch, the "STOP/START ON"
message is shown.
TRIP COMPUTER (for T\b\fe C)
JVI0006X
Switches for the tri\f com\futer are located on the left
or right side of the combination meter \fanel. To
o\ferate the tri\f com\futer, \fush the switches as shownabove.
*AENTER switch
*BNEXT switch
When the ignition switch is \fushed to the ON \fosition,
modes of the tri\f com\futer can be selected b\b
\fushing the
switch*A.
Each time the
switch*Ais \fushed, the dis\fla\b
will change as follows:
CO2 saved (if equi\f\fed) ?Current fuel consum\ftion
? Average fuel consum\ftion and s\feed ?Ela\fsed
time and tri\f odometer (if equi\f\fed) ?Distance to
em\ft\b ?Outside air tem\ferature ?Idling sto\f (if
equi\f\fed) ?Setting ?Warning check
CO2 saved (if equi\f\fed)
JVI0268X
The CO2 saved mode shows the estimated quantit\b of
CO2 exhaust emissions \frevented b\b the Sto\f/Start
S\bstem ever\b time the engine is automaticall\b sto\f\fed.
For more information, see “Sto\f/Start S\bstem (CO2
savings ) (if equi\f\fed for Euro\fe)” (P.2-28) .
Current fuel consum\ftion (km/l or l/100 km or
MPG)
JVI0007X
The current fuel consum\ftion mode shows the current
fuel consum\ftion.
Average fuel consum\ftion (km/l or l/100 km
or MPG) and s\feed (km/h or MPH)
JVI0008X
Fuel consumption:
The average fuel consum\ftion mode shows the
average fuel consum\ftion since the last reset. Reset-
ting is done b\b \fushing the
switch*Bfor longer
than 1 second. (The average s\feed is also reset at the
same time.)
Instruments and controls2-25
& R Q G L W L R Q
Page 82 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
2-28Instruments and controls
.WEDDING DAY
Select this s\fbmen\f t\b adj\fst the date \bf the
wedding day message.
MAINTENANCE:
The maintenance intervals \bf the f\bll\bwing items can
be set \br reset f\br the reminders.
. OIL
Select this s\fbmen\f t\b set \br reset the distance
f\br changing the engine \bil.
. FILTER
Select this s\fbmen\f t\b set \br reset the distance
f\br replacing the \bil filter.
. TIRE
Select this s\fbmen\f t\b set \br reset the distance
f\br replacing tires.
. OTHER
Select this s\fbmen\f and set \br reset the distance
f\br replacing items \bther than the engine \bil, \bil
filter and tires.
T\b ret\frn t\b the t\bp page \bf the setting m\bde, select
“BACK”.
OPTIONS (UNIT) (except for Hong Kong):
The \bpti\bn men\f bel\bw can be set t\b y\b\fr preference.
. UNIT
Select this s\fbmen\f t\b ch\b\bse the \fnit.
. LANGUAGE
Select this s\fbmen\f t\b ch\b\bse the display
lang\fage.
. STOP/START (if eq\fipped f\br E\fr\bpe)
Select this s\fbmen\f t\b ch\b\bse the CO2 savings
\br the engine st\bp time \fsing the St\bp/Start
System.
(See “St\bp/Start System (CO2 savings ) (if
eq\fipped f\br E\fr\bpe)” (P.2-28) .) T\b ret\frn t\b the t\bp page \bf the setting m\bde, select
“BACK”.
Warning check
JVI0014X
T\b see if there are any \bf the f\bll\bwing warnings and
c\brresp\bnding details, select this men\f.
.
Seat belt warning
. N\b key warning
. L\bw f\fel warning
. Parking brake release warning
. D\b\br/back d\b\br \bpen warning
SKIP:
P\fsh the
switch*At\b m\bve t\b the warning
check m\bde.
P\fsh the
switch*Bt\b select \bther men\fs.
ALERT:
This item is available \bnly when a warning is displayed.
Select this men\f t\b see the details \bf warnings.
Resetting displays
When the average f\fel c\bns\fmpti\bn, average speed,
elapsed time is displayed, p\fsh the trip c\bmp\fter
m\bde switch
*Af\br l\bnger than 3 sec\bnds. The
display \bf average f\fel c\bns\fmpti\bn, average speed,
elapsed time, trip \bd\bmeter, acc\fm\flated time (f\br
Idling St\bp System) and c\frrent saved f\fel c\bns\fmp-
ti\bn (f\br Idling St\bp System) will be reset at the same
time.
STOP/START SYSTEM (CO2 savings ) (if
eq\fipped f\br E\fr\bpe)
JVI0269XType A
JVI0270XType BThe CO2 savings and the engine st\bp time (f\br Type
& R Q G L W L R Q
Page 83 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
B) using the Stop/Start System are kept in a su\fmenu.
Trip Saving \bType A)
The Trip Saving mode shows the estimated CO2
exhaust emissions prevented since last reset.
It is possi\fle to reset using the [RESET] su\fmenu then
push the
switch*Ato set to zero.
NOTE:
The [Trip Saving] value is the same information
that is displayed when the engine is automati-
cally stopped by the Stop/Start System.
Total Saving \bType B)
The Total Saving mode shows:
. The estimated CO2 exhaust emissions prevented.
. The time that the engine has \feen stopped \fy the
Stop/Start System.
NOTE:
The [Total Saving] values cannot be reset and
show accumulated Stop/Start System informa-
tion since the vehicle was built.
HEADLIGHT SWITCH
SIC3782Type A
SIC3783Type BRENAULT recommends that you consult the local
regulations concerning the use of lights.
AUTO position \bif equipped)
When the ignition switch is in the “ON” position and
the headlight switch is in the “AUTO” position, the
headlights, front clearance lights, instrument panel
lights, rear com\fination light, and other lights turn on
automatically depending on the \frightness of the
surroundings.
The headlights will turn on automatically at twilight or in rainy weather \bwhen the windshield wiper is operated
continuously) \bfor Hong Kong) .
When the ignition switch is turned to the “OFF”
position, the lights will turn off automatically.
JVI0023X
CAUTION:
Do not place any objects on top of the sensor*A. The sensor senses the brightness level and
controls the autolight function. If the sensor is
covered, it reacts as if it is dark, and the
headlights will illuminate.
position
Theposition turns on the front clearance lights,
instrument panel lights, rear com\fination lights and
other lights.
Instruments and controls2-29
HEADLIGHT AND TURN SIGNAL
SWITCH
& R Q G L W L R Q
Page 89 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
Washer operation
To operate the washer, push the lever toward the front
of the vehi\fle*3until the desired amount of washer
fluid is spread on the rear window. The wiper will
automati\fally operate several times.
\bIC4127Type A
\bIC4145Type BThe rear window defogger swit\fh operates when the
ignition swit\fh is in the “ON” position.
The defogger is used to redu\fe the moisture, fog or
frost on the rear window surfa\fe and outside door
mirror surfa\fe (if equipped) to improve the rear view.
When the defogger swit\fh
*1is pushed, the indi\fator
light*2illuminates and the defogger operates for
approximately 15 minutes. After the preset time has
passed, the defogger will turn off automati\fally.
To turn off the defogger manually, push the defogger
swit\fh again.
CAUTION:
. When operating the defogger continuously,
be sure to start the engine. Otherwise, it may
cause the battery to discharge.
. When cleaning the inner side of the window,
be careful not to scratch or damage the
electrical conductors on the surface of the
window.
NOTE:
When the rear defogger is turned on, the Stop/
Start (Idling Stop) System (if equipped) will not
be activated.
Instruments and controls2-35
DEFOGGER SWITCH (if equipped)
& R Q G L W L R Q
Page 94 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
2-40Instruments and controls
WARNING:
.The storages should not be used while
driving so full attention may be given to
vehicle operation.
. Keep the storage lids closed while driving to
help prevent injury in an accident or a
sudden stop.
GLOVE BOX
SIC4407Type ATo ope\f the g\bove box, pu\b\b the ha\fd\be.
To c\bose, push the \bid i\f u\fti\b the \bock \batches.
JVI0692XType BTo ope\f the g\bove box, tur\f the k\fob cou\fterc\bockwise.
To c\bose, push the \bid i\f a\fd tur\f the k\fob c\bockwise.
UPPER INSTRUMENT BOX (if equipped)
JVC0034X
To ope\f the upper i\fstrume\ft box, push the butto\f.
To c\bose, push the \bid dow\f.
CARD HOLDER (if equipped)
JVI0018X
Pu\b\b the su\f visor dow\f a\fd s\bide a card i\f the card
ho\bder*A.
CUP HOLDERS
CAUTION:
Avoid abrupt starting and braking especially
when the cup holder is being used to prevent
spilling the contents. If the contents are hot, they
could scald you or your passengers.
SIC4408Front
STORAGES
& R Q G L W L R Q
Page 113 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
.The alarm automatically turns off after approxi-
mately \f0 seconds. \bowever, the alarm reacti-
vates if the vehicle is tampered with again.
The alarm is activated by:
. Operating the door without using the Intelligent
Key system.
. Opening the hood.
How to stop alarm:
. The alarm will stop by unlocking a door with the
door handle request switch or “UNLOCK”
button*2on the Intelligent Key.
. The alarm will stop when the ignition switch is
pushed to the “ACC” or “ON” position.
If the system does not operate as described
above, have it checked by a RENAULT dealer.
ANTI-T\bEFT SYSTEM
The Anti-Theft System will not allow the engine to start
without the use of the registered Anti-Theft System
key.
If the engine does not start using the registered Anti-
Theft System key, it may be due to interference caused
by:
. Another Anti-Theft System key.
. Automated toll road device.
. Automated payment device.
. Other devices that transmit similar signals.
Start the engine using the following procedure:
1. Remove any items that may be causing the interference away from the Anti-Theft System key.
2. Leave the ignition switch in the “ON” position for approximately 5 seconds.
\f. Turn the ignition switch to the “OFF” or “LOCK” position, and wait approximately 10 seconds. 4. Repeat steps 2 and \f again.
5. Start the engine.
6. Repeat the steps above until all possible inter-
ferences are eliminated.
If this procedure allows the engine to start, RENAULT
recommends placing the registered Anti-Theft System
key separate from other devices to avoid interference.
FCC WARNING:
Changes or modifications not expressly ap-
proved by the party responsible for compliance
could void the user’s authority to operate the
equipment.
This device complies with Part 15 of the FCC
Rules. Operation is subject to the following two
conditions; (1) This device may not cause harm-
ful interference, and (2) this device must accept
any interference received, including interference
that may cause undesired operation of the
device.
Security indicator light
SIC2045
The security indicator light is located on the meter
panel. It indicates the status of Anti-Theft System.
The light operates whenever the ignition switch is in the “LOCK”, “OFF” or “ACC” position. The security
indicator light indicates that the security systems on
the vehicle are operational.
If Anti-Theft System is malfunctioning, this light will
remain on while the ignition switch is in the “ON”
position.
If the light remains on and/or the engine does
not start, contact a RENAULT dealer for Anti-
Theft System service as soon as possible. Be
sure to bring all Anti-Theft System keys that you
have when visiting a RENAULT dealer for service.
For Right-Hand Drive (RHD) model (for Europe):
If Anti-Theft System is malfunctioning, the security
indicator light will illuminate when the ignition switch is
in the “ON” position. \bowever, if the security indicator
light turns off after 15 minutes, you can start the engine
once. See a RENAULT dealer for Anti-Theft System
service as soon as possible.
Pre-driving checks and adjustments\f-17
& R Q G L W L R Q
Page 118 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
3-22Pre-driving checks and adjustments
Remote control type (if equipped) :
The outside rearview mirror remote contro\f operates
when the ignition switch is in the “\bCC” or “ON”
position.
The outside rearview mirrors automatica\f\fy fo\fd when
the outside rearview mirror fo\fding switch is pushed to
the “CLOSE” position
*1. To unfo\fd, push to the
“OPEN” position*2.
CAUTION:
. Continuously performing the fold/unfold
operation of the outside rearview mirror
may cause the switch to stop the operation.
. Do not touch the mirrors while they are
moving. Your hand may be pinched, and the
mirror may malfunction.
. Do not drive with the mirrors stored. You will
be unable to see behind the vehicle.
. If the mirrors were folded or unfolded by
hand, there is a chance that the mirror will
move forward or backward during driving. If
the mirrors were folded or unfolded by hand,
be sure to adjust them again electrically
before driving.
JVC0025X
Automatic folding function with interlocking
door lock (if equipped):
The outside rearview mirrors fo\fd automatica\f\fy by
inter\focking door \fock. The function can be used whi\fe
the switch is in the “\bUTO” position
*2.
. The outside rearview mirrors fo\fd automatica\f\fy
when the door is \focked by the door hand\fe
request switch or the remote key\fess entry system.
. The outside rearview mirrors unfo\fd when the
ignition switch is p\faced in the “\bCC” or “ON”
position.
CAUTION:
When the outside rearview mirror is folded/
unfolded manually, the mirror may fold/unfold
accidentally while driving. Be sure to fold/unfold
the outside rearview mirror by an electrical
operation after folding/unfolding manually.
WARNING:
.When the outside rearview mirror is folded/
unfolded manually, depending on the switch
position, the outside rearview mirror may
start operation by turning the ignition switch
to the “ACC” or“ON” position.
. When unfolding the outside rearview mirror
with the switch being in the “AUTO” position,
the mirror will be unfolded further by turning
the ignition switch to the “ACC” or“ON”
position.
To return its original position, fold the out-
side rearview mirror once.
The outside rearview mirror remote contro\f operates
when the ignition switch is in the "\bCC" or "ON" position.
The outside rearview mirrors automatica\f\fy fo\fd when
the outside rearview mirror fo\fding switch is pushed to
the "CLOSE" position
*1. To unfo\fd, push to the
"\bUTO" position*2.
CAUTION:
Continuously performing the fold/unfold opera-
tion of the outside rearview mirror may cause
the switch to stop the operation.
Manual control type (if equipped) :
SP\b1829
Fo\fd the outside rearview mirror by pushing it toward
the rear of the vehic\fe.
& R Q G L W L R Q
Page 123 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
Circle type
SAA3126
Adjust t\fe air flo\b direction of t\fe ventilators by
opening, closing or rotating.
WARNING:
.The heater and air conditioner operate only
when the engine is running.
. Never leave children or adults who would
normally require the support of others alone
in the vehicle. Pets should not be left alone
either. They could unknowingly activate
switches or controls and inadvertently be-
come involved in a serious accident and
injure themselves. On hot, sunny days,
temperatures in a closed vehicle could
quickly become high enough to cause se-
vere or possibly fatal injuries to people or
animals.
. Do not use the recirculation mode for long
periods as it may cause the interior air to
become stale and the windows to fog up.
. Do not adjust the heating and air condition-
ing controls while driving so that full atten-
tion may be given to vehicle operation.
T\fe \feater and air conditioner operate \b\fen t\fe
engine is running. T\fe air blo\ber \bill operate \b\fen t\fe
ignition s\bitc\f is in t\fe “ON” position even if t\fe
engine is turned off.
NOTE:
. Odors from inside and outside the vehicle
can build up in the air conditioner unit. Odor
can enter the passenger compartment
through the vents.
. When parking, set the heater and air condi-
tioner controls to turn off air recirculation to
allow fresh air into the passenger compart-
ment. This should help reduce odors inside
the vehicle. For model with Idling Stop System (if equipped
for Thailand):
W\fen t\fe air conditioner or rear defogger (if equipped)
is turned on, t\fe Idling Stop System \bill not be
activated.
For model with Stop/Start System (if equipped
for Europe):
T\fe Stop/Start System \bill not stop t\fe engine under
t\fe follo\bing conditions:
.
T\fe front defogger mode is on. (automatic air
conditioner)
. T\fe air flo\b control dial is in t\fe front defogger
position. (manual air conditioner)
. T\fe rear \bindo\b defogger mode is on.
W\file t\fe engine is stopped by t\fe Stop/Start System,
taking one of t\fe follo\bing actions \bill automatically
start t\fe engine:
. Turn t\fe front defogger mode on. (automatic air
conditioner)
. Turn t\fe air flo\b control dial to t\fe front defogger
position. (manual air conditioner)
. Turn t\fe rear \bindo\b defogger mode on.
W\fen t\fe engine is stopped by t\fe Stop/Start System,
performance of t\fe \feater and air conditioner may be
reduced to minimize t\fe fuel consumption. For t\fe best
\feating and air conditioning performance, restart t\fe
engine by pus\fing t\fe Stop/Start System OFF s\bitc\f.
(See “Stop/Start System OFF s\bitc\f” (P.5-23) .)
Heater and air conditioner, and audio system4-3
HEATER AND AIR CONDITIONER (if
equipped)
& R Q G L W L R Q
Page 137 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
Audio main operation
The audio system operates when the ignition switch is
in the \fACC” or \fO\b” position.
POWER button:
To turn on the audio system, push the Power button.
.The system will turn on in the mode, (radio or CD)
which was used immediately before the system
was turned off.
. If there is no CD loaded, the radio will be turned
on.
To turn off the audio system, push the Power button.
Volume control:
To control the volume, turn the VOL control knob.
Turn the knob clockwise to make the sound louder.
Turn the knob counterclockwise to make the sound
quieter.
MENU button:
To change the audio settings (BASS, TREBLE,
FADER, BALA\bCE, BEEP and CLOCK) , push the
button to select the mode while the CD or radio is
on.
Push the
button until the desired mode appears
on the display.
BASS ?TREBLE ?FADE ?BALA\bCE ?BEEP
O\b ?CLOCK
Audio setting
Push the SEEK/TRACK button (
or) or
TU\bE/FF·REW/FOLDER button (or) to
adjust while the following audio setting is displayed.
:( í) to decrease / (+) to increase
:( í) to decrease / (+) to increase
: (F) to front fade / (R) to rear fade
: (R) to right balance / (L) to left balance
Once the audio settings are set to the desired level,
push the
button until the radio or CD display
appears.
If no action is performed for approximately 5 seconds,
the audio settings mode will automatically return to the
normal mode.
Beep setting
To turn the beep sound off or on, push the SEEK/
TRACK button
oror TU\bE/FF·REW/
FOLDER buttonoruntil the desired mode
is displayed. This turns on or off the beep sound when
audio buttons are pushed.
Clock setting
To display the clock on the screen, push the SEEK/
TRACK button
oror TU\bE/FF·REW/
FOLDER buttonorto select CLOCK O\b.
1. Turn the clock display on.
2. Push the
button while CLOCK O\b is on the
display. The hour and minute digits blink.
3. To adjust the hours, push the SEEK/TRACK button
or.
4. To adjust the minutes, push the TU\bE/FF·REW/ FOLDER button
or.
If no user input is detected for 10 seconds, or when
the \fME\bU” button is pushed, the clock setting mode
will automatically return to the normal mode.
CD player operation
SAA3123
The audio system operates when the ignition switch is
in the \fACC” or \fO\b” position.
Loading:
Insert a CD into the slot with the label side facing up.
The CD will be guided automatically into the slot and
will start playing. To stop playing, push the Power
button.
CAUTION:
Do not force the compact disc into the slot. This
could damage the player.
button:
When the
button is pushed while a CD is loaded,
the CD will start playing automatically.
button:
When the
button is pushed while a CD with a title
is being played, the display will change as follows:
Heater and air conditioner, and audio system4-17
& R Q G L W L R Q
Page 141 of 352
> ( G L W 0 R G H O . $ 2 ( 0 B 5 H Q D X O W @
16. Radio memory buttons (1 - 6\f
17. ME\bU button
Audio main operation
The audio system operates when the ignition switch is
in the “ACC” or “O\b” position.
POWER button:
To turn on the audio system, push the Power button.
.The system will turn on in the mode, (radio or CD\f
which was used immediately before the system
was turned off.
. If there is no CD loaded, the radio will be turned
on.
To turn off the audio system, push the Power button.
Volume control:
To control the volume, turn the VOL control knob.
Turn the knob clockwise to make the sound louder.
Turn the knob counterclockwise to make the sound
quieter.
Sound preference button:
To enter the audio mode (radio, CD or AUX\f , push the
button. When no CD is loaded and AUX is not
connected , the audio system will automatically switch
to the radio mode.
To change the audio settings (BASS, TREBLE,
FADER, BALA\bCE\f , push the
button to select
the mode.
BASS ?TREBLE ?BALA\bCE ?FADER ?BASS
To adjust each audio setting, push the SEEK/TRACK
button or Tune button. BASS: ( í\f to decrease / (+\f to increase
TREB(LE\f: ( í\f to decrease / (+\f to increase
BAL
(A\bCE\f:
(R\f to right balance / (L\f to left balance
FADE(R\f: (F\f to front fade / (R\f to rear fade
If the audio settings mode is unchanged for approxi-
mately 8 seconds, the audio settings mode will
automatically return to the normal mode.
MENU button:
To change the audio settings (BEEP and CLOCK\f ,
push the
button to select the mode while the CD
or radio is on.
Push the
button until the desired mode appears
on the display.
BEEP O\b ?CLOCK
To turn the beep sound off or on, push the SEEK/
TRACK button
oror TU\bE/FF·REW/
FOLDER buttonoruntil the desired mode
is displayed. This turns on or off the beep sound when
audio buttons are pushed.
Clock display:
To display the clock on the screen, perform the
following operations.
1. Push the
button repeatedly until CLOCK O\b
or OFF appears on the display while the audio
system is on.
2. Push the SEEK/TRACK button
oror
TU\bE/FF·REW/FOLDER buttonorto
select CLOCK O\b. Clock adjustment:
To adjust the clock, turn the clock display on and
perform the following operations.
1. Push the
button while CLOCK O\b is on the
display. The hour and minute digits blink.
2. To adjust the hours, push the SEEK/TRACK button
or.
3. To adjust the minutes, push the TU\bE button
or.
If no user input is detected for 10 seconds, or when
the “ME\bU” button is pushed, the clock setting mode
will automatically return to the normal mode.
CD player operation
JVH0002X
The audio system operates when the ignition switch is
in the “ACC” or “O\b” position.
Loading:
Insert a CD into the slot with the label side facing up.
The CD will be guided automatically into the slot and
will start playing. To stop playing, push the Power
button.
Heater and air conditioner, and audio system4-21
& R Q G L W L R Q
