RENAULT SCENIC 2011 J95 / 3.G Engine And Peripherals Owner's Guide

13B-31
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF009
PRESENTPEDAL POTENTIOMETER CIRCUIT GANG 2CO.0: Open circuit or short circuit to earth.
CC.1: Short circuit to +12 volts.
NOTESPriority when dealing with a number of faults:
– Deal with fault DF122 Potentiometer gang 2 supply voltage first.
Special notes: if fault DF009: the engine speed is maintained above 1000 rpm and
the level 1 warning light illuminates along with the message Faulty injection.
If DF009 and DF008: the engine speed fixed at 1300 rpm and the level 1 warning
light illuminates along with the message Faulty injection.
CC.0
NOTESNone.
Check the connection and condition of the 6-track connector for the pedal potentiometer.
Repair if necessary.
Check the connection and condition of the black 32-track computer connector A.
Repair if necessary.
Measure the resistance between tracks 2 and 6 of the pedal potentiometer.
Replace the pedal potentiometer if the resistance is not 2.85 kΩ +
2.05 kW.
Disconnect computer connector A and the pedal potentiometer connector.
Check the insulation from earth on track F3 of computer connector A.
Repair if necessary.
Check the continuity of the connection between:
Sensor connector track 1 Track F3 computer connector A
Repair if necessary.
DDCR_V44_DF009P/DDCR_V48_DF009P

13B-32
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF009
CONTINUED
CC.0NOTESNone.
Check the connection and condition of the 6-track connector for the pedal potentiometer.
Repair if necessary.
Check the connection and condition of the black 32-track computer connector A.
Repair if necessary.
Measure the resistance between tracks 2 and 6 of the pedal potentiometer.
Replace the pedal potentiometer if the resistance is not 2.85 kΩ +
2.05 kΩ.
Check the continuity, insulation, and the absence of interference resistance on the following connection:
Sensor connector track 2 Track F2 computer connector A
Repair if necessary.
Disconnect computer connector A and the pedal potentiometer connector.
Check the insulation against the 12 V feed of tracks F2 and F3 on computer connector A.
Repair if necessary.
Check the continuity of the following connections:
Sensor connector track 2 Track F2 computer connector A
Sensor connector track 6 Track F4 computer connector A
Repair if necessary.
Disconnect computer connector A and the pedal potentiometer connector.
Check the insulation between track F2 and track F3 on computer connector A.
Repair if necessary.

13B-33
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF010
STOREDEGR POSITION SENSOR CIRCUITCO.0: Open circuit or short circuit to earth
CC.1: Short-circuit on +12 volts.
1.DEF: Above maximum threshold.
2.DEF: Below minimum threshold.
NOTESPriority when dealing with a number of faults:
- Deal first with fault DF113 Sensor supply voltage.
See Technical Note Wiring Diagrams of the vehicle concerned.
Check the connection and condition of the EGR valve connector, component code 169.
Check the connection and condition of connector B (brown 48-track) of the computer, component code 120.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check for +5 V on connection 3GC of component 169.
Check for earth on connection 3JM of component 169.
If the connection or connections are faulty and if there is a repair method (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
Check the insulation and continuity of the following connections:
–3GC between components 169 and 120,
–3EL between components 169 and 120,
–3JM between components 169 and 120.
If the connection or connections are faulty and if there is a repair method (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
Check the resistance of the EGR valve, component code 169:
– with the engine stopped, the EGR valve will be closed (unless there is a fault),
– wait for the ambient temperature around the valve to stabilise (approximately 20°C),
– measure the resistance between connections 3FB2 and 3GB. The resistance must be between
7.54 Ω < R < 8.5 Ω (at 20°C),
– measure the resistance between connections 3GC and
3JM. The resistance must be between
2.4 KΩ < R < 5.6 KΩ (at 20°C),
– measure the resistance between connections 3JM and 3EL, the resistance should be between
800 Ω < R < 3.6 KΩ (at 20°C),
if the value is not correct, replace the EGR valve, component code 1460 (see MR 364 (Mégane II), MR 370
(Scénic II), Mechanical, 14A, Emission control, Exhaust gas recirculation solenoid valve: Removal -
Refitting). If the EGR valve was replaced, use command RZ002 EGR adaptives to reinitialise the EGR valve
offsets.
If the fault is still present, contact the Techline.
DDCR_V44_DF010M/DDCR_V48_DF010M

13B-34
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF014
PRESENTVEHICLE SPEED SIGNAL CIRCUIT
CC.0NOTESNone.
For this type of vehicle, the ABS computer or an additional unit (if the vehicle does not have ABS) transmits the
vehicle speed on the CAN.
Test the multiplex network to be able to work on the CAN (fault on the CAN H and CAN L lines between the injection
and the ABS). Also check there are no faults in the ABS section or in the system which supplies the vehicle speed.
DDCR_V44_DF014P/DDCR_V48_DF014P

13B-35
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF015
PRESENTMAIN RELAY control CIRCUIT1.DEF: Permanent low level.
2.DEF: Permanent high level.
NOTESSpecial notes: The main relay is built into the UPC.
Check the main relay supply fuse in the engine compartment: (30 A fuse) on the UPC.
Replace the fuse if necessary.
Check the condition and connection of the brown 12-track PEM D and black 4-track PPM1 connectors on the
UPC.
Repair if necessary.
Check the connection and condition of the computer's 32-track grey connector C.
Repair if necessary.
Check the insulation, continuity and the absence of interference resistance on the following connections:
Computer connector C track F1Track 2 brown 12-track connector PEM D of the
UPC.
Computer connector C track G1 Vehicle earth.
Computer connector C track H2Track 1 black 4-track connector PPM1 of the
UPC.
Computer connector C track G2Track 1 black 4-track connector PPM1 of the
UPC.
Repair if necessary
DDCR_V44_DF015P/DDCR_V48_DF015P

13B-36
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF016
STOREDEGR VALVE CONTROL CIRCUITCO.0: Open circuit or short circuit to earth.
CC.1: Short circuit to +12 volts.
NOTESConditions for applying fault finding procedures to stored faults:
The fault is present with the engine idling.
Special notes:
If fault DF016 is present: the engine is unstable and may even stall.
Starting difficult or even impossible when cold.
See Technical Note Wiring Diagrams of the vehicle concerned.
Check the connection and condition of the exhaust gas recirculation solenoid valve connector, component code
169.
Check the connection and condition of connector B (brown 48-track) of the injection computer, component code
120.
If the connector or connectors are faulty and if there is a repair procedure (see Technical Note 6015A, Repairing
electrical wiring, Wiring: Precautions for repair), repair the connector, otherwise replace the wiring.
Check for the supply: 13 V < X < 14 V (with the engine running), 11.5 V < X < 12.5 V (with the ignition on and
the engine stopped) on connection 3FB2 of component 169.
Check the insulation and continuity of the following connections:
–3GB between components 169 and 120,
–3FB2 between components 169 and 120.
If the connection or connections are faulty and if there is a repair method (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
Measure the resistance of the EGR valve, component code 169:
– with the engine stopped, the EGR valve will be closed (unless there is a fault),
– wait for the ambient temperature around the valve to stabilise (approximately 20°C),
– measure the resistance between connections 3FB2 and 3GB of component 169. The resistance must be
between
7.5 Ω
< R < 8.5 Ω (at 20°C),
– measure the resistance between connections 3GC and 3JM of component 169. The resistance must be between
2.4 KΩ < R < 5.6 KΩ (at 20°C),
– measure the resistance between connections 3JM and 3EL of component 169. The resistance must be between
800 Ω < R < 3.6 KΩ (ατ 20°C),
if the value is not correct, replace the EGR valve (see MR 364 (Mégane II), MR 370
(Scénic II), Mechanical, 14A, Emission control, Exhaust gas recirculation solenoid valve: Removal -
Refitting). If the EGR valve was replaced, use command RZ002 EGR adaptives to reinitialise the EGR valve
offsets.
If the fault is still present, contact the Techline.
DDCR_V44_DF016M/DDCR_V48_DF016M

13B-37
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF017
PRESENTPRE-POSTHEATING UNIT CONTROL CIRCUITCO.0: Open circuit or short circuit to earth.
CC.1: Short circuit to +12 volts.
NOTESSpecial notes: If DF017 is present, starting difficult (or impossible when cold). If
CO.0: the plugs are permanently switched on with risk of damage or even engine
failure.
Check the connection and condition of the preheating unit connector.
Repair if necessary.
Check the connection and condition of the computer's 32-track grey connector C.
Repair if necessary.
Check the insulation, continuity and the absence of interference resistance on the following connections:
+12 V after ignition feed Track 3 preheating unit
Computer connector C track D3 Track 9 preheating unit
Computer connector C track F2 Track 8 preheating unit
Repair if necessary
DDCR_V44_DF017P/DDCR_V48_DF017P

13B-38
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF024
PRESENTLOW PRESSURE ACTUATOR CONTROL CIRCUIT (IMV)CO.0: Open circuit or short circuit to earth.
CC.1: Short circuit to +12 volts.
NOTESSpecial notes: If fault DF024 with CO.0 or CC.1, the level 1 warning light illuminates
along with the message Faulty injection.
The fuel flow actuator is fully open, there is a clicking, and the engine is stopped
to prevent it from racing.
Check the connection and condition of the fuel flow actuator connector.
Repair if necessary.
Check the connection and condition of the computer 48-track brown connector B.
Repair if necessary.
Measure the resistance between tracks 1 and 2 of the flow actuator.
Replace the flow actuator if the resistance is not 5.3 W +
0.5 Ω at 20°C.
Check the insulation, continuity and the absence of interference resistance on the following connection:
Computer connector B track M4 Track 1 fuel flow actuator
Repair if necessary.
DDCR_V44_DF024P/DDCR_V48_DF024p

13B-39
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF025
PRESENTPRE-POSTHEATING UNIT DIAGNOSTIC LINE
NOTESSpecial notes: This fault directs the fault finding only with an open circuit.
Check the connection and condition of the preheating unit connector.
Repair if necessary.
Check the connection and condition of the heater plug connectors.
Repair if necessary.
Check the connection and condition of the computer's 32-track grey connector C.
Repair or replace if necessary.
Measure the resistance of each heater plug. The resistance must be less than 2 Ω.
Replace defective plugs.
Check the insulation, continuity and check for absence of interference resistance on the following
connection:
Computer connector C track F2 Track 8 preheating unit
Repair if necessary.
DDCR_V44_DF025P/DDCR_V48_DF025P

13B-40
AFTER REPAIRDeal with any faults displayed by the diagnostic tool. Clear the computer fault memory.
Carry out a road test followed by another check with the diagnostic tool.
V4 MR-372-J84-13B000$061.mif
DIESEL INJECTION
Fault finding – Interpretation of faults13B
DDCR INJECTION
Vdiag No.: 44, 48
DF026
PRESENT
OR
STOREDCYLINDER 1 INJECTOR CONTROL CIRCUIT
CO: Open circuit.
CC: Short circuit.
1.DEF: At minimum limit
NOTESConditions for applying the fault finding procedure to a stored fault:
The fault is declared present with the engine at idle speed.
Special notes: When this fault appears, the idle speed is stuck at 1000 rpm, there is
engine noise, the engine speed is unsteady, the engine performance is reduced, and the
level 1 warning light illuminates along with the message Faulty injection.
CO - CC
NOTESNone.
Switch off the ignition and wait 15 seconds.
Check the connection and condition of the injector connector.
Repair if necessary.
Check the connection and condition of the computer 48-track brown connector B.
Repair if necessary.
Run command AC005 Cylinder 1 injector.
If a cycle of 5 actuations of injector 1 cannot be heard working, connect the cylinder 2 injector wire to the cylinder
1 injector and run command AC006 Cylinder 2 injector.
Does this injector actuation cycle work?
Note:
If the wires cannot be swapped, continue the procedure by replying YES to the previous question.
DDCR_V44_DF026/DDCR_V48_DF026
