RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-45
WIRING HARNESS
Passenger compartment wiring: Connector access
LEFT-HAND DRIVE
88A
9 -  R 259
aR 259 connectors (Passenger compartment / rear
bumper connection).
II -  CONNECTOR OPENING
a
aSwitc

Page 182 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-46
WIRING HARNESS
Passenger compartment wiring: Connector access
LEFT-HAND DRIVE
88A
aDisconnect the R 107 connectors.
2 -  Accessing the R 99 connector
aRemove the dashboard (see Dashboard: Remov

Page 183 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-47
WIRING HARNESS
Passenger compartment wiring: Connector access
LEFT-HAND DRIVE
88A
4 -  Accessing the R 3 connector
aRemove:
-the front left-hand door sill lining (see Front door
sill lining: Re

Page 184 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-48
WIRING HARNESS
Passenger compartment wiring: Connector access
LEFT-HAND DRIVE
88A
7 -  Accessing the R 335 connector
aUnclip the cover (5) under the drivers seat base.
aDisconnect the R 335 co

Page 185 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-49
WIRING HARNESS
Passenger compartment wiring: Connector access
RIGHT-HAND DRIVE
88A
I - LOCATION OF CONNECTORS
1 -  R 107
aR 107 connectors (Dashboard / front of engine con-
nection).
2 -  R 99

Page 186 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-50
WIRING HARNESS
Passenger compartment wiring: Connector access
RIGHT-HAND DRIVE
88A
5 -  R 4
aR 4 connector (Dashboard / passengers door con-
nection).
6 -  R 334
aR 334 connector (Passenger co

Page 187 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-51
WIRING HARNESS
Passenger compartment wiring: Connector access
RIGHT-HAND DRIVE
88A
9 -  R 259
aR 259 connectors (Passenger compartment / rear
bumper connection).
II -  CONNECTOR OPENING
a
aSwit

Page 188 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-52
WIRING HARNESS
Passenger compartment wiring: Connector access
RIGHT-HAND DRIVE
88A
aDisconnect the R 301 connectors.
4 -  Accessing the R 3 connector
aRemove:
-the front right-hand door sill li

Page 189 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-53
WIRING HARNESS
Passenger compartment wiring: Connector access
RIGHT-HAND DRIVE
88A
6 -  Accessing the R 334 connector
aUnclip the cover (3) under the front passenger seat
base.
aDisconnect the

Page 190 of 241

RENAULT TWINGO 2009 2.G Electrical Equipment Workshop Manual 88A-54
WIRING HARNESS
Passenger compartment wiring: Removal - Refitting
LEFT-HAND DRIVE
88A
REMOVAL
I - REMOVAL PREPARATION OPERATION
aPosition the vehicle on a two-post lift (see Vehicle:
Towing and
