sensor RENAULT TWINGO 2009 2.G Engine And Peripherals Passenger Compartment Connection Unit OBD Owner's Manual

87B-114
MR-413-X44-87B000$576.mif
V5
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Interpretation of statuses
UCH
Vdiag No.: 44
87B
ET083
ET084
LEFT-HAND INDICATOR REQUEST
RIGHT-HAND INDICATOR REQUEST
NOTESNo faults should be present or stored.
Check the following configurations:
Check that LC008 Daytime running lights is With. Otherwise carry out CF014
"Daytime running lights".
–Check that LC015 Front fog lights is With. Otherwise run CF021 Front fog
lights.
–Check that LC025 "See-me-home lighting" is "With". Otherwise carry out
CF032 "See-me-home lighting".
–Check that LC044 "Rain/light sensor" displays "Present". If not, carry out
CF035 "Rain/light sensor".
–Check that LC095 "Automatic headlight function", displays "With". If not, carry
out CF193 "Automatic headlight function".
SPECIFICATIONSPRESENT
ABSENT
Check that fuses F13 (30A) and F15 (5 A) are sound and correctly fitted in the passenger compartment fuse and
relay box (component code 1016).
Replace the fuse(s) if necessary.
Check the condition and connection of the monolever connector (component code 209) and the UCH 40-track
connector PE2 (component code 645) (tabs bent, broken or oxidised).
If the connector(s) are faulty and there is a repair procedure (see Technical Note 6015A, Electrical wiring
repair, Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
AFTER REPAIRRepeat the conformity check from the start.
Carry out fault finding on the system.
UCH_V44_ET083 / UCH_V44_ET084

87B -128
MR-413-X44-87B000$624.mif
V5
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Interpretation of statuses
UCH
Vdiag No.: 44
87B
ET114
ET115
WIPER REQUEST BY RAIN SENSOR
LIGHT ACTIVATION REQUEST BY LIGHT SENSOR
NOTESThere must be no present or stored faults.
Make sure that the vehicle is fitted with the rain and light sensor.
The status should change to LOW SPEED or HIGH SPEED if there is water on the
windscreen where the sensor is positioned.
The status should change to PRESENT when the light intensity requires the lights to
be switched on with the engine running.
Make sure that the other positions of the wiper control are working properly
Check the following configurations:
–Check that LC008 Daytime running lights is "With". Otherwise run CF014
Daytime running lights.
–Check that LC044 Rain/light sensor displays "Present". If not, run CF035 Rain/
light sensor.
–Check that LC095 Automatic headlight function displays "With". If not, run
CF193 Automatic headlight function.
–Check that LC096 Automatic wiper function displays With. If not, run CF194
Automatic wiper function.
SPECIFICATIONSET114: ABSENT/LOW SPEED/HIGH SPEED
ET115: PRESENT/ABSENT
Conditions:
Check that the switch stalk (component code 209) is in the intermittent position so that automatic operation can
be activated.
Check that the vehicle has a rain/light sensor (component code 1415).
Check that the function is not deactivated, perform the following cycle twice to activate the automatic headlight
function: Switch stalk (component code 209) OFF → Σωιτχη σταλκ (χοµπονεντ χοδε 209) to side lights ON
position.
Check the condition and connection of the 3-track connector of the rain/light sensor (component 1415) (tabs
bent, broken or oxidised).
If the connector is faulty and there is a repair method (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
Check for + 12 V on connection BPT of component 1415.
Check for earth on connection MAM of component 1415.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
AFTER REPAIRRepeat the conformity check from the start.
Carry out fault finding on the system.
UCH_V44_ET114 / UCH_V44_ET115

87B -129
MR-413-X44-87B000$624.mif
V5
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Interpretation of statuses
UCH
Vdiag No.: 44
87B
ET114
ET115
CONTINUED
Check the continuity and insulation of the following connections:
●Connection code BPT between components 645 and 1415.
●Connection code MAM between component 1415 and earth.
●Connection code 14S between components 645 and 1415.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Check that the rain/light sensor (component code 1415) is correctly positioned and bonded (see MR411,
Mechanical systems, 85A Wiping - Washing, Rain and light sensor: Removal - Refitting).
If the fault is still present, replace the rain/light sensor (component code 1415). (See MR 411 Mechanical
85A, Wiping - Washing, Rain and light sensor: Removal - Refitting).
If the fault is still present, contact the Techline.
AFTER REPAIRRepeat the conformity check from the start.
Carry out fault finding on the system.

87B -145
MR-413-X44-87B000$720.mif
V5
87B
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Interpretation of parameters
PR002
EXTERNAL TEMPERATURE
NOTESOnly apply the checks if the parameter is inconsistent.
Special notes:
Check that LC002 "External temperature sensor" is "WITH". Otherwise perform
CF029 "External temperature sensor".
Check that LC067 "External temperature display" is "WITH". Otherwise perform
CF171 "External temperature display".
Note:
If the exterior temperature sensor (component code 245) is disconnected or the vehicle is not equipped with an
exterior temperature sensor, the temperature displayed is the default temperature of 215 ˚C.
Check the 12-track temperature sensor connector, (component code 245) (tabs bent, oxidised, broken, etc.).
Check the PE2 40-track connector of the UCH, component code 645 (tabs bent, oxidised, broken).
If the connector is faulty and there is a repair method (see Technical Note 6015A, Repairing electrical wiring,
Wiring: Precautions for repair), repair the wiring, otherwise replace the wiring.
Check the insulation, continuity and the absence of interference resistance on the following connections:
●Connection code 47D between components 240 (for left-hand drive vehicles) or 239 (for right-hand drive
vehicles) and 645.
●Connection code 47C between components 240 (for left-hand drive vehicles) or 239 (for right-hand drive
vehicles) and 645.
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
Measure the resistance of the connector sensor disconnected from connections 47C and 47D.
Temperature (˚C)
1
5
10
15
20
25
30
35Sensor resistance (Ω) ± 50 Ω
5980
5020
4280
3530
2900
2300
2010
1620
Replace the exterior temperature sensor (component code 245) if not correct. (See MR 411 mechanical
systems 62A, air conditioning, Exterior air temperature sensor: Removal - Refitting).
If the fault is still present, contact Techline.
UCH_V44_PR002
MR-413-X44-87B000$720.mif
UCH
Vdiag No.: 44

87B -158
MR-413-X44-87B000$816.mif
V5
PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Interpretation of commands
UCH
Vdiag No.: 44
87B
AC056
AC057
AC058
LOW-SPEED WIPER
HIGH SPEED WIPER
INTERMITTENT WIPER REQUEST
NOTESNo faults should be present or stored.
Check that LC094 "Wiper intermittent speed ring" displays "With". If not, carry
out CF191 “Wiper intermittent speed ring”.
Check that LC096 “Automatic wiper function” displays “With”. If not, carry out
CF194 "Automatic wiper function".
Check that LC044 “Rain/light sensor” displays “Present”. If not, carry out CF035
"Rain/light sensor".
Check that LC095 "Automatic headlight function" displays "With". If not, carry
out CF193 "Automatic headlight function".
This fault may appear if the windscreen wiper motor is forced (e.g.: used on a dry screen, snow on the screen,
etc.).
Check that fuse F2 (15 A) is sound and correctly fitted to the passenger compartment fuse and relay box
(component code 1016).
Replace the fuse if necessary.
Check the condition and connection of the 3-track windscreen wiper motor connector (component code 212)
(broken, bent, oxidised tabs).
Check the condition and connection of the 40 track connectors PE1 and PE3 of the UCH (component code 645)
(tabs broken, bent or oxidised).
Check that the earth on connection MAS of the windscreen wiper motor connector (component code 212) is
correct.
Activate the low speed, check for + 12 V on connection 14B of the windscreen
wiper motor connector (component code 212). Activate the high speed, check for + 12 V on connection 14A of
the windscreen wiper motor connector (component code 212).
If the connection or connections are faulty and there is a repair procedure (see Technical Note 6015A, Electrical
wiring repair, Wiring: Precautions for repair), repair the wiring, otherwise replace it.
AFTER REPAIRCarry out another fault finding check on the system.
UCH_V44_AC056 / UCH_V44_AC057 / UCH_V44_AC058

87B -163
MR-413-X44-87B000$816.mif
V5
UCH
Vdiag No.: 44PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Interpretation of commands87B
AC110
TEMPERATURE DISPLAY
NOTESSpecial notes:
Check that the vehicle is equipped with an external temperature sensor.
IMPORTANT
This command lasts approximately 30 seconds.
It makes it possible to check the connection between the display (component code 653) and the UCH
(component code 645).
With the command running, the temperature display should change; if not apply the fault finding procedure below.
Read configuration LC002 External
temperature sensor.
Is the configuration “With”?
YES
Check that LC067 "External temperature display" is "WITH". Otherwise
perform CF171 "Temperature display".
Check the condition and connection of the PE2 40-track UCH connector,
(component code 645) (tabs bent, broken, etc.).
If the connector is faulty and there is a repair method (see Technical Note
6015A, Repairing electrical wiring, Wiring: Precautions for repair),
repair the wiring, otherwise replace the wiring.
Check the continuity of the following connection:
Connection code 47Z between components 645 and 653.
If the connection is faulty and there is a repair procedure (see Technical
Note 6015A, Electrical wiring repair, Wiring: Precautions for repair),
repair the wiring, otherwise replace it.
If the connection is correct, replace the display (component code 653)
(see MR 86A, Radio, Display: Removal - Refitting).
If the fault is still present, contact Techline.
NOIf the vehicle is fitted with an external
temperature sensor, check that the
configuration CF029 “External
temperature sensor” displays “With”.
If the vehicle is not fitted with an external
temperature sensor, it is normal that the
external temperature is not displayed.
AFTER REPAIRCarry out another fault finding check on the system.
UCH_V44_AC110

87B -176
MR-413-X44-87B000$912.mif
V5
UCH
Vdiag No.: 44PASSENGER COMPARTMENT CONNECTION UNIT
Fault finding - Fault Finding Chart87B
ALP 33 No external temperature display
NOTESOnly address this customer complaint after a complete check with the diagnostic
tool.
Check that the temperature display works, use AC110 Temperature display.
Read configuration LC002 External
temperature sensor.
Is the configuration YES?
YES
Check that LC067 Temperature display is With. Otherwise perform
CF171 Temperature display.
Check the condition and connection of the PE2 40-track connector in the
UCH (component code 645) (tabs bent, broken, etc.).
If the connector is faulty and there is a repair method (see Te chnical Note
6015A, Repairing electrical wiring, Wiring: Precautions for repair),
repair the wiring, otherwise replace the wiring.
Check the continuity of the following connection:
Connection code 47Z between components 645 and 653.
If the connection is faulty and there is a repair procedure (see Technical
Note 6015A, Electrical wiring repair, Wiring: Precautions for repair),
repair the wiring, otherwise replace it.
If the connection is correct, replace the display. (See MR 411 Mechanical,
86A, Radio, Display: Removal - Refitting).
If the fault is still present, contact the Techline.
NOThe vehicle is not equipped with the
External temperature sensor function.
It is normal for the external temperature
not to be displayed.
UCH_V44_ALP33
