SAAB 9-3 2001 Owners Manual

241 Maintenance and owner assistance
(c.) Check wheel alignment if irregular or premature tire wear is apparent.
(d.) Check and clean rear pads and rear calipers in areas with heavy road salt use.
Service Intervals **
Miles = U.S. Cars
Kilometers = Canadian Cars
30 day
10,000
(16,000 km)
20,000
(32,000 km)
30,000
(48,000 km)
40,000
(64,000 km)
50,000
(80,000 km)
60,000
(96,000 km)
70,000
(112,000 km)
80,000
(128,000 km)
90,000
(144,000 km)
100,000
(160,000 km)
Service #
1234567891011
Chassis
R Ball joint clearance, outer and inner steering joints and
rubber boots""""""""""
R Shock absorbers and bushes; tightness and condition"""
R Tire pressure, tread depth and wear, including spare (c.)"""""""""""
R Rotate tires, front to rear""""""""""
R Brake pads and discs; wear and condition (d.)""""""""""
R Brake lines and hoses""""""""""
R Brake fluid level & renewal (max. 2-year intervals)"""" ! """ ! ""
R Check parking brake function"""""""""""
R Power steering fluid level"""""""""""
ProCarManuals.com

242 Maintenance and owner assistance
Service Intervals **
Miles = U.S. Cars
Kilometers = Canadian Cars
30 day
10,000
(16,000 km)
20,000
(32,000 km)
30,000
(48,000 km)
40,000
(64,000 km)
50,000
(80,000 km)
60,000
(96,000 km)
70,000
(112,000 km)
80,000
(128,000 km)
90,000
(144,000 km)
100,000
(160,000 km)
Service #
1234567891011
Chassis (cont.)
RToe-in"""
R Cabin air filter!!!!!
R Door hinges, stops and locks"" # "" # "" # "
R Airbag system, SRS warning lamp, visual inspection"""""""""""
R Safety belts; operation and visual inspection of belt for
tears and fraying"""""""""""
R Wiper blades"""""""""""
R Washer system: check and top-up"""""""""""
R Reset service indicator""""""""""
Customer programming
R Carry out systems programming per customer request"
Road test
R Check performance of drive train, steering and brakes
and verify tire balance.
Check function of instruments and controls, including
horn, windshield wipers, cruise control and climate sys-
tem.
Note any noises or problems for correction."""""""""""
ProCarManuals.com

243 Technical data
Technical dataGeneral particulars .......... 244
Engine ............................... 247
Engine oil .......................... 247
Fuel.................................... 249
Engine variants ................ 249
Electrical system.............. 250
Drive belts......................... 250
Manual transmission ....... 250
Automatic transmission .. 250
Suspension....................... 251
Steering............................. 251
Brake system.................... 251
Rims and tires .................. 252
Plates and labels .............. 253
IB993
ProCarManuals.com

244 Technical dataGeneral particularsOverall length, with bumper(s):
Coupé/5-door/Convertible____________ 182.3" (4629 mm)
Viggen __________________________ 182.7” (4639 mm)
Overall width, including door mirrors _____ 76.2" (1936 mm)
Maximum height ____________________ 56.2" (1428 mm)
Maximum height when the soft top is being
operated (Convertible) ______________approx. 87"
approx. 2200 mm
Wheelbase ________________________ 102.6" (2605 mm)
Tr a c k :
front, Coupé/5-door/Convertible _______ 57.2" (1452 mm)
front, Viggen ______________________ 57.7” (1466 mm)
rear, Coupé/5-door/Convertible _______ 56.8" (1442 mm)
rear, Viggen ______________________ 57.3” (1456 mm)
Ground clearance at max. weight _______ approx. 3.9"
(100 mm)
Number of occupants, incl. driver:
Coupé and 5-door _________________ 5
Convertible _______________________ 4
Turning circle:
measured at vehicle extremities _______ 38.7 ft. (11.8 m)
curb to curb_______________________ 36.5 ft. (11.1 m)
Gross vehicle
weight (GVW)
Maximum train
weight
(GVW + max.
trailer weight)
Maximum axle
load, front
Maximum axle
load, rear Permissible load (in addition to the driver) = GVW minus curb weight.
The maximum permissible axle load, front or rear, must not be exceeded.
The precise curb weight of the vehicle (weight ready for driving + driver
á 154 lbs. (70 kg) and load capacity are specified in the vehicle registra-
tion documents.Chassis number plate in engine bay Length of the trunk:
rear seat raised, Coupé- and 5-door car 37.0" (940 mm)
rear seat lowered, Coupé- and 5-door car 67.2" (1705 mm)
Volume of trunk according to SAE:
with parcel shelf, Coupé- and 5-door car 15.9 cu.ft.
(451 dm
3)
whole rear seat tipped forward,
Coupé- and 5-door car _____________ 46.0 cu.ft.
(1303 dm3)
Convertible, soft top up _____________ 12.5 cu.ft.
(354 dm3)
Convertible, soft top down ___________ 10.1 cu.ft.
(285 dm3)
IB541
ProCarManuals.com

245 Technical data
Weight ready for driving (i.e. with full fuel
tank, washer- fluid reservoir, standard
tools and spare wheel)
Coupé ___________________________ 2980-3170 lbs.
(1350-1440 kg)
Viggen, Coupé ____________________ 3130-3160 lbs.
(1420-1435 kg)
5-door ___________________________ 3020-3220 lbs.
(1370-1460 kg)
Viggen, 5-door ____________________ 3170-3210 lbs.
(1440-1455 kg)
Convertible _______________________ 3110-3300 lbs.
(1410-1495 kg)
Viggen, Convertible ________________ 3250-3260 lbs.
(1475-1480 kg)Gross vehicle weight (GVW)
Coupé ___________________________ 3930-4060 lbs.
(1785-1840 kg)
Viggen, Coupé ____________________ 4060 lbs. (1840 kg)
5-door __________________________ 3980-4100 lbs.
(1805-1860 kg)
Viggen, 5-door ____________________ 4100 lbs. (1860 kg)
Convertible ______________________ 3940-4020 lbs.
(1785-1825 kg)
Viggen, Convertible ________________ 3990 lbs. (1810 kg)
Maximum axle load
front ____________________________ 2300 lbs. (1045 kg)
rear ____________________________ 1930 lbs. (875 kg)
Weight distribution:
Curb weight, front/rear ______________ approx. 62/38 %
GVW, front/rear ___________________ approx. 58/42%
ProCarManuals.com

246 Technical data Maximum permitted load in trunk
Coupé and 5-door at curb weight plus
4 passengers à 155 lbs. (70 kg) _______ 130 lbs. (60 kg)
For each passenger less in the rear seat the load may be
increased by 100 lbs. (45 kg)
Convertible at curb weight and
3 passengers à 155 lbs. (70 kg) _______ 120 lbs. (55 kg)
Coupé and 5-door at curb weight and
rear seat right down ________________ 475 lbs. (215 kg)
WARNING
 The GVW and maximum axle loads must not be exceeded.
Note that if some accessories (e.g. towbar, CD changer) are
fitted, the available load capacity is reduced by the weight of
these items.
 When goods are being transported their security is important,
especially if the car is being used with the rear seat down.
Max. permitted roof load ____________ 220 lbs. (100 kg)
Trailer weights:
Trailer with brakes _________________ Max. 3500 lbs.
(1588 kg)
Trailer without brakes _______________ Max. 1000 lbs.
(450 kg)
Recommended towbar-ball load ______ 110-165 lbs.
(50-75 kg)
Maximum towing speed, trailer with
brakes __________________________ 62 mph (100 km/h)
The above max. weights and speed limit are those which Saab
Automobile AB permits. Note that the national rules may set lim-
its to permitted weights and speed; see also page 179.
ProCarManuals.com

247 Technical data
Engine Engine oilType _____________________________ 4 cyl, 2 overhead
camshafts,
16 valves and 2 bal-
ancer shafts
Cylinder bores ______________________ 3.54" (90 mm)
Stroke:
2.0 Turbo _________________________ 3.071" (78 mm)
Viggen __________________________ 3.543” (90 mm)
Swept volume:
2.0 Turbo _________________________ 121 cu.in.
(1,985 dm
3)
Viggen __________________________ 140 cu.in.
(2.290 dm3)
Idling speed _______________________ 900 rpm
Antifreeze _________________________ Saab-approved
antifreeze
Coolant volume, cooling system ________ 8.7 qts. (8.5 l)
Oil grade: We recommend the use of oils that are available from your
Saab dealer, for the regular oil changes.
These oils fulfill the most stringent requirements set by API and
ACEA classifications.
Oil for gasoline engines is classified by the API standards
(American Petroleum Institute) into the grade classes SH (since
1993) and SJ (since 1996). The SJ class fulfils more stringent
requirements and has a lower phosphorous level.
These grade classes are most often combined with the corre-
sponding classes for diesel engines. The class designations for
diesel engines begin with the letter “C“ (Commercial). For ex-
ample a grade combination suitable for both types of engine
could be API SH/CD or SJ/CF.
Basic recommendations for Saab engines:
• SAE 5W-30 or 5W-40.
The oil should be semi or fully synthetic and fulfil the grade
requirements for ACEA A3/B3 or API SJ.
Oils which are less viscous, such as 0W/-40/50 are becoming
more common and may be used. However, the oil must be
fully-synthetic, of a well known brand, and fulfil ACEA grade re-
quirements A3/B3.
This viscosity makes starting in cold weather easier.
Oil capacity inc. filter (on changing) _____ 4.0 l
ProCarManuals.com

248 Technical dataUnder ACEA nomenclature, oils are divided into Class A for
gasoline engines and Class B for diesel-engined passenger
cars. There is a further class for heavy diesel engines. Each
class is divided into three grades: 1, 2 and 3, where grades 2
and 3 normally encompass semi and fully-synthetic oils. The
diesel class B also has a fourth grade, B4, which encompasses
tests and regulations aimed at improving the performance of
direct injection engines.
In the same way as in the API system, gasoline and diesel
engine specifications are combined for products that can be
used in both types of engine. For example, a grade designation
could be ACEA A2/B2 or ACEA A3/B3/B4.
To afford Saab engines the best protection, with regard to lubri-
cation, the ability to dissolve residues and the neutralization of
combustion products, we recommend the following oil grades:
 API SH/CD/CF or SJ/CD/CF.
 ACEA A3/B3/B4.
These oils contain the additives required for the engine to
function well. We advise against the use of further addi-
tives.
Viscosity: The viscosity of oil is classified according to the SAE standard.
Nowadays, multigrade oils are always used in cars. The proper-
ties of these oils facilitate starting the car in cold weather but
mean that the oil is also viscous enough to coat all moving parts
under high pressures and with high outside air temperatures.
Multigrade oils are graded with two viscosities, e.g. 10W-30,
where the 10W meets certain viscosity requirements at -4°F
(-20°C), while the 30 fulfills requirements at a temperature of
212°F (100°C).
ProCarManuals.com

249 Technical data
Fuel Engine variantsFuel-tank capacity __________________ 17 U.S. gal. (64 l)
For optimum performance, we recommend
the following:
2.0 Turbo 185 bhp__________________ 90 AON, unleaded
gasoline,
minimum 87 AON
2.0 Turbo 205 bhp and Viggen ________ 93 AON*), unleaded
gasoline,
minimum 87 AON
*) If the car is filled with 90 AON gasoline
and the outdoor temperature is above
77-86°F (25-30°C), a slight decrease in
engine performance may be noticeable.
2.0 Turbo 185 hp, manual transmissionRating, EEC at 5500 rpm ____________ 185 hp (136 kW)
Max. torque (man.), EEC at 2100 rpm _ 194.0 ft.lb (263 Nm)
Compression ratio _________________ 8.8:1 2.0 Turbo 185 hp, automatic transmissionRating, EEC at 5500 rpm ____________ 185 hp (136 kW)
Max. torque EEC at 1900 rpm ________ 184.4 ft.lb. (250 Nm)
Compression ratio _________________ 8.8:1 2.0 Turbo 205 hp, manual transmissionRating, EEC, at 5500 rpm ___________ 205 hp (151 kW)
Max. torque EEC at 2200 rpm ________ 206.5 ft.lb (280 Nm)
Compression ratio _________________ 8.8:12.0 Turbo 205 hp, automatic transmissionRating, EEC, at 5750 rpm ___________ 205 hp (151 kW)
Max. torque EEC at 1900 rpm ________ 184.4 ft.lb (250 Nm)
Compression ratio _________________ 8.8:12.3 Turbo 230 hp, manual transmissionRating, EEC, at 5500 rpm ___________ 230 hp (169 kW)
Max. torque EEC at 2500 rpm ________ 258.1 ft.lb (350 Nm)
Compression ratio _________________ 9.3:1
ProCarManuals.com

250 Technical dataElectrical system
Drive belts

Manual transmission
Automatic transmission
Voltage ___________________________ 12 V
Battery capacity ____________________ 60 Ah
Starter motor ______________________ 1.4 kW
Alternator rating ____________________ 130 A/14 V
Firing order ________________________ 1-3-4-2
Spark plugs:
2.0 Turbo 185 bhp__________________ NGK PFR 6H-10
2.0 Turbo 205 bhp __________________ NGK PFR 6H-10
Viggen __________________________ NGK PFR 6H-10
Electrode gap ______________________ 0.95 mm
(0.03740”)
Outside lengthCars with A/C compressor ____________ 2345 mm
Cars without A/C compressor __________ 1805 mmDrive belt
IB929
Type _____________________________ 5-speed, fully
synchronized with
final-drive gear and
differential
Oil type (for topping-up) ______________ Saab synthetic man-
ual gearbox oil
Oil capacity _______________________ 1.8 qts. (1.8 l)
Speed (mph/km/h) at 1000 rpm in 5th gear 26/42
Type _____________________________ Electronically con-
trolled 4-speed with
torque converter
and differential
Gear selector positions ______________ P R N D 3 2 1
Oil quantity, total ___________________ 7.4 qts. (7.2 litres)
Oil volume (on changing) _____________ 3.4 qts. (3.25 litres)
Oil type ___________________________ Texaco Texamatic
Dexron III, mineral
oil based
Clutch type ________________________ Hydraulically-oper-
ated plate clutches,
brake bands and
one-way clutches
Speed (mph/km/h) at 1000 rpm in 4th gear 25/40
ProCarManuals.com
