131 Interior equipment, trunk
Child safety: rear windows
(ON/OFF) The window switches on the rear doors can
be rendered inoperative by the ON/OFF
switch in the panel on the center console.
When the switch is ON, the rear side win-
dows can be operated by the switch on each
rear door. The rear door switches have an
integrated indicator lamp that indicates
when the switches are operational.
When the switch is OFF, the rear side win-
dows can only be operated from the panel
on the center console. The indicator lamps
are extinguished when the switches are not
operational.
Steering-wheel
adjustmentThe steering wheel can be positioned
fore-and-aft by pulling the lever to the left.
Set the steering wheel to the desired posi-
tion and return the lever to the locked status.
Horn signalThe horn is operated by pressing at the
outer edges of the airbag module in the
center of the steering wheel.
WARNING
For safety reasons, you should adjust the
steering wheel only while the car is sta-
tionary.
IB811
IB1536
Lever for steering-wheel adjustment
ProCarManuals.com

132 Interior equipment, trunkSunroof
The sunroof is operated electrically using
the ROOF control on the center console.
The sunroof can be opened completely or
partially. As soon as you release the control
the sunroof stops.
1 If you wish to open the sunroof all the
way from the closed position, proceed
as follows:
 To open: slide the control rearward.
 To close: slide the control forward and
hold it forward until all movement of the
sunroof stops, indicating it is fully
closed.
2 You also have the option of opening the
rear edge of the sunroof from the closed
position for the purpose of ventilation.
 To open: slide the control forwards.
 To close: slide the control rearwards. But you must release the control after each
position so as to shift between the two
functions.
The sunroof also has an inner sun blind that
slides by hand.
Emergency operation of the sunroofThe sunroof can be operated manually with
a screwdriver, e.g. in the case of an electri-
cal fault. Slide back the cover on the roof
console. Insert a screwdriver into the slot in
the center of the motor shaft and turn
Turn clockwise to open the sunroof.
Turn counterclockwise if the sunroof is open
at the rear edge.
WARNING
 Bear in mind the pinch hazard when
operating the sunroof. Make sure that
all passengers keep their heads,
hands and fingers clear of the opening
before operating the sunroof. Serious
personal injury may otherwise be
caused.
Always remove the ignition key when
you leave the car to prevent personal
injury caused by the sunroof, for
example, due to children playing.
IB830
IB831
ProCarManuals.com

133 Interior equipment, trunk
Interior lightingThe interior lighting consists of one dome
light in the front and one in the back. The
switch for the interior lighting is on the over-
head panel next to the rearview mirror.
When the switch is in the mid-position
(door-activated), the interior lighting will
come on:
 When the car is unlocked from outside.
 When any door is opened with the ignition
off.
 When the ignition key is withdrawn from
the switch.The lighting goes out about 12 seconds
after the doors are closed or when the igni-
tion is turned on, provided that the switch is
in the mid-position.
If the doors are left open and the switch is in
position 2 or 3 with the ignition off, the inte-
rior lighting is turned off automatically after
20 minutes to preserve battery life.
The sun visors are equipped with vanity mir-
rors. On certain model variants, the sun
visors are fitted with vanity lighting, which
turns on when the cover is lifted.
9-3 Convertible: see page 58.
Trunk lightingThe trunk lighting is switched on and off
when you open and close the trunk, if the
switching button is set to ON. The lighting
can also be switched on and off using the
button on the light.
IB832
1 Interior lighting is off
2 Lighting comes on when a door is opened
3 Interior lighting on continuously
IB951
Rear-seat lighting 1 Reading lights
2 Dome light
ProCarManuals.com

134 Interior equipment, trunk
Cup holderThere are two cupholders, one in the fascia
under the SID unit and one in the cen-
ter-console compartment between the front
seats on certain models.
Next to the cup holder between the front
seats is a coin tray.
NOTEBe careful not to spill any drinks or liquid
onto the audio system when using the can
holders.
IB833
Cup holder in the center console
IB1329
Sun visor with vanity mirror
IB1177
Cup holder in fascia
ProCarManuals.com

135 Interior equipment, trunk
Ashtrays (accessory)The car can be equipped with two ashtrays.
One is positioned low down on the dash and
the other on the back of the center console.
Open the front ashtray by lightly pressing on
the front. Remove it by depressing the catch
on the underside. You do not need to open
it in order to take it out. To replace it, just
push it straight in. Open the rear ashtray by lightly pulling its
upper edge rearward. Remove it by
depressing the catch and opening it past the
catch point.
To put it back, align it with the two locating
pins on either side of the opening, then push
it closed.
The cigarette lighter socket can also be
used as a power supply for a mobile phone
or other electrical accessory.
Glove compartmentFor additional storage compartments see
next page.
WARNING
The maximum output that can be taken
from the cigarette lighter socket is 240 W
(20 A).
WARNING
The glove compartment must be closed
while travelling. An open glove compart-
ment door could cause leg injuries in the
event of a crash.
IB835
Glove compartment 1 To unlock
2To lock
IB836
Rear ashtray
IB834
Front ashtray
ProCarManuals.com

136 Interior equipment, trunk
IB1517
IB1518
IB1519
IB1520
IB1521
In the doors Front edge of front seats Front seat backrests
Center console between the seats Center console on passenger side
ProCarManuals.com

137 Interior equipment, trunk
Rearview mirrorsThe rear-view mirror has day/night positions
that can be selected by means of a knob
beneath the mirror. Adjust the mirror for best
vision in the day position and pull the tab on
the bottom of the mirror toward you for the
night position.
Door mirrorsThe door mirrors are electrically adjustable.
The controls are on the driver’s door.
1 Use the upper button to select a door
mirror.
2 Use the touch pad to set the mirror ver-
tically and horizontally. There are raised
points at the 12, 3, 6 and 9 o’clock posi-
tions to indicate adjustment points.
The mirror glass can also be adjusted man-
ually by gently pressing the glass in the
desired direction.
If subjected to a certain force, the whole
mirror will fold back to prevent injury. The mirror can also be retracted by hand,
which can be useful when parking in con-
fined spaces, e.g. on car ferries. Don’t forget
to fold the mirrors out again before driving
away.
The electric heating of the door mirrors is
switched on and off with the same button as
the heating of the rear window.
NOTEThe door mirrors should be retracted
before the car is put through an automatic
carwash.
IB813
Adjusting the door mirrors 1 Select mirror
2 Use touch pad to adjust mirror
IB814
Retracting a mirror
IB812
Rearview mirror1 Day position
2 Night position
ProCarManuals.com

138 Interior equipment, trunkTrunk, Coupé and 5-doorTrunk lid lockUnlock the trunk lid by pressing on the key, by pressing the
remote release button on the driver’s door or by using the key. The
alarm horn sounds three times and the lights flash when the trunk is
released with the remote control.
Programming features, see page 245.
Lowering the entire rear seatTo lower the rear seat, the front seats must be moved forward if they
are in the most rearward position. The seat back must be almost ver-
tical.
1 Flip up the seat bottom by pulling the loops located between the
backrest cushions and seat cushions.
2 Rest the seat cushions on edge just behind the front seats.
3 Release the entire backrest cushion, including the belt beam, by
pressing in the latch in the handle on the left (driver’s) side. After
this has been done, the fact that the belt beam has been
released is indicated by the red "warning tabs" popping up on the
right and left sides of the beam. For increased load capacity with
the backrest cushion down, remove the rear seat head restraints
(5).
WARNING
When the back seat has been put back in place, make certain that
the belt beam is locked firmly on both sides (the red warning tabs
must go down). This is vital since the upper anchorages for the
safety belts are located in the belt beam. The belts will not
restrain a rear seat occupant if the belt beam is not properly
latched.
When the entire rear seat has been lowered, you must remove the
rear window shelf. Otherwise it could come loose and cause per-
sonal injury during a crash.
IB850
ProCarManuals.com

139 Interior equipment, trunk
4 Lower the entire backrest cushion by pulling this same handle
(item 3) forward. At the same time, pivot the beam backwards.
IMPORTANT: When you replace the belt beam using the handle
(item 3), you must verify that it is properly locked and that the two
red "warning tabs" go down (thereby indicating that locking has
taken place properly).
5 To increase the volume, the rear head restraints can be removed
before the backrest cushion is lowered.
Lowering the right-hand part of the rear seat
WARNING
Never leave a child or animal unattended in the car. During sunny
weather the temperature in the cabin/luggage compartment can
climb to 160-180°F (70-80°C). Small children are very susceptible
to heat stroke.
The tail pipe of the exhaust system can become very hot during
driving. Bear this in mind when loading and unloading the car so
that children, for example, do not burn themselves.
WARNING
 If the head restraints have been removed, they must be stored
safely so that they cannot be thrown about and injure someone
while braking or in a crash.
 Do not ride in the rear seat without having remounted the head
restraints, and making sure they are properly locked in place.
 Whenever you handle any system containing moving parts,
such as the belt beam, always be careful not to get pinched.
 Never keep objects on the rear window shelf since they can be
thrown forward and cause personal injury during heavy brak-
ing or in the event of a crash.
 When the back seat has been put back in place, make certain
that the belt beam is locked firmly on both sides (the red warn-
ing tabs must go down). This is vital since the upper anchor-
ages for the safety belts are located in the belt beam.
The
belts will not restrain a rear seat occupant if the belt beam is
not properly latched
ProCarManuals.com

140 Interior equipment, trunkTo provide more flexibility, the rear seat is divided so that you can
lower the narrower (right) part separately.
1 Tilt the seat cushion forward by pulling the loop located between
the backrest and the seat cushion.
2 Stand the seat cushion on end behind the front seats.
3 Release the right backrest cushion by means of the latch on the
belt beam’s right side just behind the head restraint.
4 Lower the right backrest cushion.
IMPORTANT: When you replace the right backrest cushion, make
certain that it is properly locked.
IB1308IB852
Warning tabs
ProCarManuals.com
