41 Security
Locking a car with dead batteryThe steering wheel lock requires sufficient
battery voltage to lock and unlock. If the bat-
tery voltage drops below a certain level
while the remote control is in the ignition
switch, you will not be able to remove the
remote control.
If you must leave the car, proceed as
follows:
1 Lock the car by pressing down the lock
buttons on the doors.
2 Lock the front left door from outside with
the traditional key (see page 40). The
car is now locked but the car alarm will
remain inactive.
Trunk lidOpening
The trunk lid is unlock and slightly opened
when the button on the remote control
or driver’s door is pressed once.
The hazard warning lights will flash three
times to confirm.
The movement sensor in the cabin will be
disarmed.
Closing
The trunk lid is locked when closed.
If the doors are locked when the trunk lid is
closed it is armed and the movement sensor
in the cabin will be armed.
Opening button on driver’s door
ProCarManuals.com
Page 42 of 256
42 SecuritySwitches on front doorsThe central locking can also be operated
from inside the car using the button by each
front door handle.
Locking the car with the remote control
renders these buttons inoperative.
If you are sitting in the car and press the
button on the driver’s door, this will unlock
the driver’s door and fuel filler door. Press
the button a second time to unlock the
remaining doors and the trunk lid. The
button on the passenger door works in the
same way except that this first unlocks the
passenger door and fuel filler flap. In this
mode, the other doors cannot be opened
from outside the car.
If the car is left with one or more doors open,
the interior lighting will be switched off auto-matically after 20 minutes. This is to prevent
the battery from running flat. Also, if the car
has electrically adjustable seats, these will
cease to operate.
Child safety locksThe rear doors are equipped with child
safety locks that are activated by means of
a catch next to the door latch.
Insert a screwdriver or the traditional key
(enclosed in the remote control) and turn it
45° in the direction shown on the label on
the door.
When the child safety lock is in the locked
position, the door can only be opened from
outside the car.
WARNING
If small children are carried in the rear
seat, the safety locks on the rear doors
should be activated to prevent uninten-
tional opening from the inside.
Child safety locks
Central locking switch
ProCarManuals.com
Page 43 of 256
43 Security
Trunk Release HandleThere is a glow-in-the-dark trunk release
handle located inside the trunk on the latch.
This handle will glow following exposure to
light. Pull the release handle down to open
the trunk from inside.
Reprogramming lock system
functionsCertain lock system functions can be
reprogrammed at a Saab dealer (see page
248).Checking the number of remote
controlsTo check the number of remote controls that
are programmed for the car:
1 Insert the remote control into the ignition
switch and turn it to ON.
2 Press the button on the remote
control.
3 The Saab Information Display (SID) will
now display the number of remote
controls that are programmed for your
car, and which of these (1–5) is in the
ignition switch.
Example of SID message:
NOTICEThe trunk release handle was not
designed to be used to tie down the trunk
lid or as an anchor point when securing
items in the trunk. Improper use of the
trunk release could damage it
X: standard key
Y: valet key
Key No: Z
Trunk Release Handle
ProCarManuals.com
Page 44 of 256
44 SecurityChanging the key battery
When the voltage of the remote control
battery drops below a certain level, the
Saab Information Display (SID) will display:
Change the battery as soon as possible to
avoid malfunctioning.
Battery type: Panasonic CR2032,
3V Lithium.
The battery should last for about 4 years of
normal use.
The battery type is marked on the inside of
the remote control. Avoid leaving finger-
prints on the faces of the battery.
1 Press the emblem on the reverse of the
remote control to remove the traditional
key.
2 Insert the tip of the key into the small slot
and turn the key to split the remote
control.
WARNING
Keep the battery and other small compo-
nents of the remote control out of reach of
children.NOTICEThe electronics of the remote control are
sensitive to electrostatic discharge. Incor-
rect handling when changing the battery
can damage the remote control. Avoid
touching electronic components of the
remote control with your hands.
Remote control battery low.
Replace battery.
Press the emblem to remove
the traditional key
ProCarManuals.com
Page 45 of 256
45 Security
3 Change the battery. Fit the new battery
so that it is positioned in the same way
as the old battery.
4 Fit together the two halves of the remote
control and press them together until
you hear a click. Reinsert the traditional
key into the remote control.After changing the battery you must
synchronize the remote control with the
car’s receiver unit so that the car recognizes
it. Synchronization takes place when the
remote control is inserted into the ignition
switch for the first time after a battery
change.
If the battery has been changed outside the
car and the car is locked, proceed as fol-
lows:
1 Unlock the front left door with the tradi-
tional key. If the car has a car alarm, this
will be tripped.
2 Open the door and insert the remote
control into the ignition switch. If the car
has a car alarm, this will be silenced.
The remote control and receiver unit are
now synchronized.
ImmobilizerThe remote control contains an electronic
code that is unique to your car. When the
remote control is inserted into the ignition
switch, this code is checked and the LED
double-flashes for 3 seconds. If the code is
correct, the car can be started.
Each time you remove the remote control
from the ignition, the electronic starting
interlock is activated, the LED double-
flashes for 3 seconds and the car becomes
immobilized. If an incorrect remote control is
now inserted into the ignition switch (e.g.
the remote control of another car), the
immobilizer will remain operative (the LED
will not flash for 3 s) and it will not be possi-
ble to start the car.
If the immobilizer system malfunctions, the
Saab Information Display (SID) displays:
Immobilizer failure.
Try starting again.
Contact Saab dealer.
Change the battery and fit together
the two halves of the remote control
ProCarManuals.com
Page 46 of 256
46 SecurityIf, when inserted into the ignition switch,
there is a problem checking the electronic
code of the remote control, the following
message will appear on the SID:
Visit a Saab dealer to have the problem
checked and rectified.
Car alarmThe car alarm is armed when the car is
locked with the remote control.
The car alarm will not be armed if you
lock the car with the traditional key (see
page 40).
All the doors, the hood and the trunk lid are
monitored by the alarm. A movement
sensor triggers the alarm if movement is
detected in the cabin, such as if someone
sticks in their arm through a smashed
window.
All the windows should be shut when the
alarm is armed. Otherwise, the movement
sensor may interpret a passer-by as an
attempted break-in.The alarm is armed 11 seconds after the car
has been locked by remote control.
During the delay period, the LED shines
constantly. It will then start to flash once
every 3 seconds. The LED is located on the
fascia.
If a door or the trunk lid is open when the car
is locked with the remote control, the LED
will flash 3 times per second for
11 seconds. Check that the doors, hood
and trunk lid are closed.
If the signal persists, contact a Saab dealer
to have the problem checked and rectified.
If you unlock the trunk lid from outside the
car with the button on the remote con-
trol, you must lock the car with the
button to arm the car alarm. Key not accepted.
Contact Saab dealer.
WARNING
Leaving children or pets unattended in a
locked car is dangerous. It is also danger-
ous to leave children in a vehicle with the
ignition key. A child or others could be
badly injured or even killed.
ProCarManuals.com
Page 47 of 256
47 Security
To avoid any inconvenience, make sure that
anyone using the car is familiar with how the
car alarm and the locking system work.
If the alarm has been tripped since the car
was last locked, the Saab Information Dis-
play (SID) will display:
If a fault arises in the car alarm system, the
Saab Information Display (SID) will display:Arming the car alarmThe alarm is armed when all doors, the hood
and the trunk lid are closed and you lock the
car with the remote control.
What trips the alarm?The alarm will be tripped if:
a door, the hood or the trunk lid is opened
the movement sensor registers move-
ment in the cabin
somebody tries to hotwire the car
the car battery is disconnected.Signals when the alarm is trippedIf the alarm is triggered, the following alarm
signals will be set off:
all direction indicators flash for 5 minutes.
the horn sounds for 30-second intervals
with 10-second breaks (max. 10 cycles).
The signals can vary between markets
and due to legal and insurance require-
ments.Switching off the alarm if tripped
If the alarm has been triggered (direction
indicators flashing and horn sounding) it can
be turned off by pressing one of the buttons
on the remote control or, if you are sitting in
the car, by turning the ignition to ON (see
below).
Alarm has been triggered
since being armed.
Theft protection failure.
Contact Saab dealer.
Turns off lights and horn.
Unlocks car.
Turns off lights and horn.
Car remains locked.
Turns off lights and horn.
Unlocks trunk.
Turns off lights and horn.
Turns on exterior and cabin light-
ing. Car remains locked.
If sitting in the car: Turn the remote
control to ON in the ignition switch
ProCarManuals.com
Page 48 of 256
48 Security
Movement sensorThe movement sensor monitors the cabin.
The alarm will be triggered if a movement is
detected, such as if someone sticks in their
arm through a smashed window.
Note: Always contact your Saab dealer if
you intend to use a separate cabin heater as
this can interfere with the movement
sensor.Disabling the movement and tilt sensors
If, for example, you leave a dog in the car or
park on a ferry, you should disable the sen-
sors as described below:
1 Go to Profiler by pressing the CUSTOM-
IZE button (see also 64).
2 Turn the INFO dial until Theft Alarm is
selected.
3 Press in the INFO dial.
4 Select Door alarm only.
5 Confirm this selection by pressing the
INFO dial.
The movement and tilt sensors will be reac-
tivated automatically the next time you start
the car. You can activate the sensors man-
ually before the engine is started as
described above.
NOTICE It is possible to inadvertently deacti-
vate the car alarm and at the same
time unlock the car, if the button on the
key is pressed by mistake when the
car is still within its range. The car will
be locked automatically after
3 minutes.
When locking the car by remote
control in extremely cold weather, it is
advisable to check that the lock
system has operated properly. To do
so, check that the interior locking
buttons are all down.
If not, unlock and relock the car again.
Theft Alarm
Full theft alarmDoor alarm only
ProCarManuals.com
Page 49 of 256
49 Security
The functions of Full theft alarm and Door
alarm only modes are explained below.
Panic functionThe car alarm includes a panic function.
This function allows the alarm to be started
manually, for example, to attract attention.
The panic alarm can only be activated while
the car is stationary. The alarm is silenced if
the car is driven off.
When the alarm is tripped, the lights and
horn come on for 3 minutes or until you
press one of the remote control buttons.
To start the alarm manually proceed as
follows:
Press and hold the button on the
remote control for more than 2 seconds,
or if you are sitting in the car...
Press and hold the or button on
one of the front doors for more than
2 seconds.
To switch off the alarm:
Press one of the remote control buttons
or, if you are sitting in the car, the or
buttons on one of the front doors. Full theft alarm:
The alarm will be triggered if a window
is smashed and someone sticks in their
arm to take something from the car. All
windows and the sunroof should be
shut when the car is locked in Full theft
alarm mode.
Door alarm only:
In this mode, the movement and tilt
sensors are disabled. This can be use-
ful if you wish to leave a dog in the car
or are travelling by ferry, for example.
ProCarManuals.com
Page 50 of 256
50 SecurityOverview of functionsLocking/arming Direction indicators flash once.
Unlocking/
disarmingHazard warning lights flash twice.
Unlocking/
disarming trunk
lidHazard warning lights flash three times.
Alarm triggered Direction indicators flash for 5 min.
The horn sounds for 30-second intervals with
10-second breaks (max. 10 cycles) or until you
press one of the remote control buttons or turn
the remote control ON in the ignition switch.
Movement
sensorThe movement sensor trips the alarm if it regis-
ters a movement in the cabin.
Remote control Normal range: 5–16 yds. (5–15 metres).
In favorable conditions the range can be signif-
icantly greater.
Remote control
batteryNormal life: approx. 4 years.
Change the battery when the SID displays:
Remote control battery low. Replace battery.
See Changing the key battery, page 44.
Car battery The alarm will trip if the battery is disconnected
when the alarm is armed.
Some car alarm functions and indications can be reprogrammed.
Contact a Saab dealer for details of the possibilities and refer to
page 248.
ProCarManuals.com
