SAAB 9-3 2004 Workshop Manual

51 Security
Overview of functionsLocking/arming Direction indicators flash once.
Unlocking/
disarmingDirection indicators flash twice.
Unlocking/
disarming trunk
lidDirection indicators flash three times.
Alarm triggered Direction indicators flash for 5 min.
The horn sounds for 30-second intervals with
10-second breaks (max. 10 cycles) or until you
press one of the remote control buttons or turn
the remote control ON in the ignition switch.
Remote control Normal range: 5–16 yds. (5–15 metres).
In favorable conditions the range can be signif-
icantly greater.
Remote control
batteryNormal life: approx. 4 years.
Change the battery when the SID displays:
Remote control battery low. See Changing the
key battery, page 46.
Some car alarm functions and indications can be reprogrammed.
Contact a Saab dealer for details of the possibilities and refer to
page 280.
ProCarManuals.com

52 SecurityQuick guide, LED and Saab Information Display (SID)
messagesActivity LED signal
Arming (delay period) Shines for 11 s.
Alarm armed Flashes once every 3 s.
Disarming Extinguishes.
Alarm not armed Off.
A door, the hood or the tailgate is
open or opened during the delay
period.Flashes for 11 s then flashes
once every 3 s.
Car immobilized but not locked. Off.
Change of status of immobilizer
system, valid remote control
inserted or removed from ignition
switch.Double-flashes for 3 s.
SID message Reason/action
Key not accepted.
Contact Saab dealer.Error when remote control
inserted into ignition switch.
Remote control battery low. Battery needs replacing.
See page 46.
2: standard key
Key No: 1Check of the number of remote
controls programmed for your
car. See page 45.
Alarm has been triggered
since being armed.The alarm has been tripped
since the car was last locked.
Immobilizer failure.
Try starting again.
Contact Saab dealer.Error when immobilizer code
checked.
ProCarManuals.com

53 9-3 Convertible
Advice on soft top
operation ___________ 54
Operating the soft top __ 55
Raising the soft top
manually ___________ 60
SID warnings and
messages __________ 63
"Easy entry" __________ 65
Head restraints _______ 66
Safety belts, rear seat,
Convertible _________ 67 Roll-over protection ____ 68
Electric windows _______ 69
Interior lighting ________ 70
Unlocking the trunk lid
manually ____________ 71
Placing two golf bags
in the trunk __________ 72
9-3 Convertible
ProCarManuals.com

54 9-3 ConvertibleAdvice on soft top
operation• Once you have raised the soft top and
before driving off, always check that the
soft top is properly engaged with the wind-
shield rail.
 Once you have folded the soft top and
before driving off, check that the soft top
cover is locked.
 Do not operate the soft top in tempera-
tures below 23°F (–5°C).
 Note that certain automatic car washes
can damage the soft top. This applies to
car washes that use mechanical feelers
bearing against the body. Saab advises
against washing the Convertible in an
automatic car wash.
 After rain or washing the car, allow the soft
top to dry completely before folding it.
Folding a wet or damp soft top can cause
water damage in the car and mildew to
form on the soft top. Roof racks and ski holders must not be
mounted on the soft top.
 On no account should anything be put into
the stowage space of the soft top (under
the soft top cover) since this could cause
an obstruction when the soft top is being
folded away.
 Do not place any objects on the covers
over the roll bars as this can hamper their
function.
 When operating the soft top, raise or fold
it fully until notified that operation is com-
plete by the SID. Do not leave the soft top
partially open/closed. If the soft top is left
in an intermediate position it will collapse
progressively after 20 seconds to prevent
overloading the drive system.
 Washing the soft top, see page 250.
WARNING
 Never touch the hinges and struts of
the soft top nor the upper rail of the
windshield while operating the soft
top.
 Do not operate the soft top while there
are bystanders close to the car.
ProCarManuals.com

55 9-3 Convertible
Operating the soft top
Read the "Advice on soft top operation"
section on page 54 before operating the soft
top.
The soft top is operated with the switch on
the instrument panel. Hold the switch in the
desired position until the soft top is fully
folded or raised.
The completion of folding or raising the soft
top is indicated by a chime.
Error messages that can appear on the SID
are shown on page 63.
WARNING
 Do not touch the hinges or struts of the
soft top during opening due to the
pinch hazard.
 Keep children out of reach.
 Do not operate the soft top while there
are bystanders close to the car.
 Make sure that the soft top cover has
locked properly after folding the soft
top.
 Check that the soft top engages prop-
erly with the upper edge of the wind-
shield after raising.NOTICEIf you drive off while raising or folding the
soft top, operation is halted when
the speed of the car exceeds 20 mph
(30 km/h). This speed can be pro-
grammed (0–25 mph/0–40 km/h) at a
Saab dealer. The movement of the car
and force of the wind can seriously
damage the components of the soft top
system.
Switch for operating the soft topaRaising
b Folding
ProCarManuals.com

56 9-3 ConvertibleOpeningThe following conditions must be fulfilled for
the soft top to be folded:
 Vehicle speed must not exceed 20 mph
(30 km/h).
 Battery voltage must exceed 10 V.
 Outside temperature must exceed 23°F
(–5°C).
 The trunk lid must be locked.
 There must be sufficient space in the
trunk for the soft top.
1 Star t the engine and let it idle. Clearance
for soft top operation: height, min. 7.2 ft
(2.2 m); behind car, min. 2" (5 cm).
2 Press and hold the soft top button until
the soft top is fully folded and the soft top
cover raised. Completed folding is indi-
cated by a chime. If there is a malfunc-
tion a text message will be shown on the
SID. Refer to page 63.
If you continue to hold the button after the
chime, all the windows will open after a brief
delay.Remote opening (option)
You can fold the soft top when outside the
car by pressing and holding the
(unlock) button on the remote control. See
also page 117.
Folding
ProCarManuals.com

57 9-3 Convertible
3 Soft top folded. 4 The soft top cover is closed. 1 Rear window raised. Soft top storage in
luggage compartment lowered.
2 The soft top cover is opened.
a 7.2 ft (2.2 m)
b2" (5cm)
ProCarManuals.com

58 9-3 ConvertibleRaisingThe following conditions must be fulfilled for
raising the soft top:
 Vehicle speed must not exceed
20 mph (30 km/h).
 Battery voltage must exceed 10 V.
 The trunk lid must be locked.
1 Star t the engine and let it idle. Clearance
for soft top operation: height, min. 7.2 ft
(2.2 m); behind car, min. 2" (5 cm).
2 Press and hold the soft top button until
the soft top is fully raised and the soft top
cover closed. Completed raising is indi-
cated by a chime. If there is a malfunc-
tion a text message will be shown on the
SID. Refer to page 63.
All side windows are opened slightly to
protect the seals when the soft top is
raised.
Check that the hooks in the soft top hold
it securely to the upper edge of the wind-
shield.
If you hold the button pressed up after the
chime, all the windows will be closed after a
short delay.
Raising
ProCarManuals.com

59 9-3 Convertible
1 The soft top cover is opened. 2 The soft top is raised. 3 The soft top cover is closed.
4 The rear window is lowered.
a 7.2 ft (2.2 m)
b2" (5cm
ProCarManuals.com

60 9-3 ConvertibleRaising the soft top
manuallyIf the soft top has been folded mechanically
there will be a delay of 20 seconds before it
is possible to raise it manually (the pressure
must be released from the hydraulic sys-
tem).
If the car is without electrical power, the
trunk must be unlocked manually. Refer to
page 71.1 Find the lug wrench, Allen key and
screwdriver.
2 Remove the two covers from the side
trim in the trunk, one from either side.
If there are two of you, it is easiest if you
stand on either side of the car and perform
steps 3-6 and 9-10 together.
3 Unlock the soft top cover by pressing
forward the two wire catches, one on the
left and one on right-hand side.
WARNING
Only raise the soft top manually in an
emergency (e.g. due to an electrical
fault).
Do not touch the soft top button on the
instrument panel while closing the soft top
manually. This could cause personal
injury and damage the soft top mecha-
nism.
Do not fold the soft top having closed it
manually. This can damage the soft top
mechanism.
Tools under luggage compartment floor Wire catch for unlocking soft top cover
