71 9-3 Convertible
4 Close the trunk lid fully as otherwise it
will obstruct the soft top cover.
5 Open the soft top cover, upward and
backward.
6 Tip forward the front seat backrests.7 Before raising the soft top, the two
catches in the leading edge of the soft
top must be opened. Stand in the rear
seat and pry off the cover with the screw-
driver. Using the tool, turn clockwise to
open the catches.
Stand in the rear seat and raise the soft
top. Pull it towards the windshield. This
operation requires 7.2 ft (2.2 m) of verti-
cal clearance.
WARNING
 Do not touch the hinges and struts of
the soft top during raising.
 Keep your hands clear of the front
windshield rail.
 Pinch hazard may cause personal
injury.
Soft top cover opened Manual closing started Soft top pulled towards windshield93U S M 06.book Page 71 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

72 9-3 Convertible8 Sit in one of the front seats and lock the
soft top to the windshield rail. Use the lug
wrench and the Allen key. Turn roughly
1/4 turn counterclockwise. Check that
the soft top is properly locked in place by
pressing up the front edge. The soft top
must not move upward.9 Lift up the rear window fully and hold it
there. Close the soft top cover. It is not
possible to lock the soft top cover after
manual raising.
10 Press down the rear edge of the soft top
as far as possible towards the soft top
cover.11 Now lock the rear window to the soft top
cover. Sit in the rear seat and insert the
tool (the same tool as used to lock the
soft top to the windshield rail) into the
hexagonal hole in the soft top mecha-
nism. Turn roughly 1/4 turn, counter-
clockwise on the right had side of the
soft top and clockwise on the left-hand
side. Look at the soft top cover when
locking the rear window. The rear
window must make a tight seal against
the soft top cover.
The soft top system must be checked and
rectified without delay. We recommend that
you contact a Saab dealer.
NOTICETo avoid damaging the paintwork on the
soft top cover and the trunk lid, take care
when closing the soft top cover.Closing the soft top cover
Rear window locked to soft top cover
Soft top locked to windshield rail93U S M 06.book Page 72 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

73 9-3 Convertible
Cause Suitable action
Soft top front not locked.
Try again.Failure of the soft top to lock automatically to
the windshield. Move the car so that it is standing level if on
a steep slope.
 Press the soft top button to fold the soft top
slightly. Fold the soft top again.
Soft top power pack
overheated.
Allow to cool.This message appears if the soft top is operated
continuously for more than 3 minutes.Wait 6 minutes to allow the hydraulic pump to
cool down.
Open trunk.
Move goods away from
top storage area.Move the object hindering soft top operation.
Soft top may be
damaged if operated
at low temperature.Displayed if the soft top is folded at temperatures
below 23°F (–5°C).
Only manual
operation possible.
Contact Saab dealer.
Soft top cover not locked.
Try again.
SID warnings and messagesThe following messages associated with the soft top system and can be displayed on the SID together with a chime:93U S M 06.book Page 73 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

74 9-3 Convertible
Battery low. The voltage of the car battery is too low to allow
soft top operation.
Soft top obstructed.
Clear obstacles and
try again.
Open/close soft top
completely to open trunk.Complete soft top operation.
Open/close soft top
completely before drivingComplete soft top operation.
Close trunk. Close the trunk lid.
Driver seat unlocked. The backrest is not locked. Raise the backrest fully to locked position, see
page 75.
Passenger front seat
unlocked.The backrest is not locked. Raise the backrest fully to locked position, see
page 75.
93U S M 06.book Page 74 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

75 9-3 Convertible
"Easy entry"To facilitate getting in and out of the rear
seat, the front seats can be slid forward.
Manually adjusted passenger seats3
1 Raise the handle by the head restraint
on the seat.
2 Tip the backrest and slide the seat
forward.
Repositioning:
1 Tip back the backrest.
2 Slide the seat back to the desired
position.
Make sure the backrest and seat are prop-
erly locked in position.Electrically adjustable front seats3
1 Raise the handle by the head restraint
on the seat.
2 Tip the backrest forward.
3 The seat now moves to its foremost
position.
Repositioning:
1 Tip the backrest back to its normal
position.
2 Raise and hold the handle until the seat
has returned to its previous position.
WARNING
Always check that the backrest locks
properly when returned to normal
position.
 Check that the fore-and-aft position of
the seat is properly locked. The back-
rest and the entire belt-in seat must be
locked in position; otherwise the occu-
pant of the seat is at risk of injury
during braking or in the event of a
crash, especially if a rear-facing child
seat is fitted behind the backrest.
"Easy entry" function. Illustration shows an electrically adjustable seat
3
93U S M 06.book Page 75 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

76 9-3 ConvertibleHead restraintsThe front seats are equipped with Saab
Active Head Restraints (SAHRs). These are
designed to reduce the risk of neck injury if
the car is hit from behind.
The SAHR is a mechanical system, actu-
ated by body weight. The mechanism is built
into the top of the backrest, where it is con-
nected to the head restraint.
In the event of a rear-end crash, the body is
forced back against the backrest. This, in
turn, causes the mechanism to press the
head restraint forward and upward, thus lim-
iting the backward movement of the head.The front and rear head restraints can be
raised and lowered to a number of positions.
 Raising: grasp the head restraint on both
sides and pull it straight up.
 Lowering: Press the head restraint
forward and downward.
The rear head restraints can be fully low-
ered to improve rearward vision when the
rear seats are unoccupied.
WARNING
 Adjust the head restraint so that the
head is optimally supported and the
center of the head restraint is at ear
height, thus reducing the likelihood of
neck injury in a crash.
 Raise the head restraints in the seats
that are occupied.
Rear head restraint Front head restraint
93U S M 06.book Page 76 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

77 9-3 Convertible
Safety belts, rear seat,
ConvertibleThe two rear seats have three-point safety
belts with inertia reels.
Fasten the belt by pulling the belt and insert-
ing the tongue in the buckle. Check that it is
securely fastened.
Position the lap part low across the hips.
Grasp the shoulder belt close to the buckle
and pull the belt towards the shoulder to
tighten the lap belt part.
The belt must be as far in on the shoulder as
possible.
Press the red button on the belt buckle to
release the belt.
Refer to page 276 for how to check the func-
tion of the safety belts, cleaning, etc.
For how to secure loads on the rear seat,
refer to page 17.
WARNING
 If cargo has to be placed on a seat, it
must be properly secured with the
safety belt. This reduces the risk of the
cargo being thrown about during hard
braking or a crash, which could cause
personal injury.
 Check that the belt is not twisted or
lying against sharp edges.
 Make sure you use the correct seat-
belt buckle.Safety belts, rear seat, Convertible
93U S M 06.book Page 77 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

78 9-3 ConvertibleRollover Pop-up BarsThe Rollover Pop Up Bars, which are
located behind each rear seat head
restraint, are designed to deploy in the
event of a crash or rollover.
WARNING
You can be severely injured or killed in a
crash if you are not wearing your safety
belt - even if you have airbags and Roll-
over Pop Up Bars. Wearing your safety
belt during a crash helps reduce your
chance of hitting things inside the vehicle
or being ejected from it.
 The Rollover Pop Up Bars have
powerful springs that rapidly extend
the bars in rollover crashes, as well as
in moderate to severe crashes in
which the airbags deploy. Rollover
Pop Up Bars are supplemental to the
safety belts. They are designed to
work with safety belts but do not
replace them.
 Rollover Pop Up Bars deploy with
great force, and you could be injured if
your arm or other body part, or if an
object is covering the bars when they
deploy. Don't put anything on the
cover of the Rollover Pop Up Bars.
The path of the Rollover Pop Up Bars
must be kept clear.
 The Rollover Pop Up Bars are
designed to deploy only once. If they
deploy, take your vehicle to a work-
shop immediately to have the Rollover
Pop Up Bars repaired so that they
operate properly in the event of a
crash or rollover. We recommend that
you contact a Saab dealer.NOTICETo avoid the risk of damage to the soft top
do not operated the soft top while the
bars are extended.
Rollover Pop-up Bars
93U S M 06.book Page 78 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

79 9-3 Convertible
Electric windows
To openSoft top raised – The windows open individ-
ually.
Soft top folded – The button for the front
window opens both side windows.
Automatic opening: Press the button all
the way down and release it. If the soft top
is folded, the rear side window is also low-
ered.
To closeSoft top raised – The windows are operated
individually.
Soft top folded – The button for the front
window closes both side windows.
Automatic closing of a front side
window: Raise the button all the way and
release it. The rear side window must be
fully closed. Pinch protection3 is available
for the front side windows.
For further information on the electric win-
dows, refer to page 129.Deactivating the passenger door
window buttonWith the button on the driver’s door,
you can deactivate the window button on
the passenger door.
The illuminated switch will change color
from green to amber (deactivated).
WARNING
Bear in mind the pinch hazard when clos-
ing the side windows. May cause serious
or fatal injuries!
Always remove the remote control
from the ignition switch when you
leave the car to prevent personal
injury caused by the activation of the
electric windows, for example, due to
children playing.
 The person operating the electric
window is responsible for ensuring
that no one, especially a child, has
their head, hands or fingers in the
window openings, before raising the
window.
 Do not stick any part of the body or the
head out through an open window
while the car is moving.
Window switches
93U S M 06.book Page 79 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

80 9-3 ConvertibleCalibrating front electric
windows with pinch protection3The window lifts should be calibrated if auto-
matic closing does not work or if the battery
has been disconnected. The pinch protec-
tion will not work if the windows are not
calibrated.
Perform calibration as follows:
1 Make sure the soft top is raised.
2 Make sure the doors are closed.
3 Let the engine idle.
4 Press and hold the soft top button up
until a chime sounds.
During calibration, the four windows will
be raised and lowered several times.
If calibration fails twice in a row, have the car
checked and rectified. We recommend that
you contact a Saab dealer.
Interior lightingThe interior lighting consists of a front roof
light, two front reading lights, footwell light-
ing and courtesy lighting in the doors. The
light switches are located in the roof con-
sole.
The cabin lighting comes on:
 When a door is opened and the ignition is
OFF.
 When the remote control is removed from
the ignition switch.
The lighting goes out:
 When the car is locked.
 When the ignition is turned on.
 Approx. 20 s after closing all doors.
The lights are dimmed out gradually.
If a door is left open with the ignition OFF,
the interior lighting goes out automatically
after 5 min so as not to drain the battery.
The interior lighting can be switched off
completely.
1 Open the driver’s door.
2 Turn off the cabin lighting with the center
button, see illustration.
This is canceled when the ignition switch is
turned to position ON or when the car is
locked with the remote control.
Front interior lighting - Convertible1 Left-hand reading light
2 Cabin light
3 Right-hand reading light
93U S M 06.book Page 80 Friday, February 18, 2005 1:15 PM
ProCarManuals.com
