SAAB 9-3 2006 Workshop Manual

51 Security
Remote control functions
*) parking lights, side direction indicators,
taillights and license plate lighting.
NOTICEThe remote control contains delicate
electronics.
 Do not expose it to water.
 Avoid rough handling.
 Do not place the remote control where
it may be subjected to high tempera-
tures, e.g. on the instrument panel.
 Warm the remote control in your
hands for a couple of minutes if it has
become very cold to prevent malfunc-
tion.
 For details on changing the battery,
refer to page 56.
Button Pressed once Pressed
twiceHold and
press the
button more
than 2 s
Locks all doors.
Unlocks driver´s
door.Sport Sedan:
The other
doors are
unlocked.
SportCombi:
The other
doors and tail-
gate are
unlocked.Comfort
opening, see
page 129.
Sport Sedan:
Unlocks and
slightly opens
the trunk lid.
SportCombi:
Unlocks the tail-
gate.
Checks number
of remote con-
trols, see
page 55.
Turns on exterior
and cabin light-
ing *) (for 30 s) or
turns off lighting
and deactivates
panic alarm.Panic alarm
(activates
alarm manu-
ally), see
page 60.
Remote control1 Locks car
2 Unlocks car and turns on cabin lighting
3 Unlocks and opens trunk lid.
4 Turns on exterior and cabin lighting.
Activates panic function93U S M 06.book Page 51 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

52 SecurityLocking/unlocking the carRemote locking and unlocking also control
the car alarm.
Remote locking
Press the button once:
Sport Sedan: all doors locked.
SportCombi: all doors and tailgate locked.
The hazard warning lights will flash once to
confirm.Remote unlocking
Pressing the button once: the driver´s
door is unlocked.
Pressin a second time:
Sport Sedan: the rest of the doors are
unlocked.
SportCombi: the rest of the doors and tail-
gate are unlocked.
The hazard warning lights will flash twice to
confirm.
Saab Information Display (SID), see
page 93.
Intermittent malfunctioning
Equipment in the vicinity of the car that uses
the same frequency as the remote control
may cause interference to the remote con-
trol signal. In this case, retry from another
angle and aim at the receiver located by the
steering wheel.If remote unlocking should fail to work
1 Remove the traditional key from the
remote control by pressing the emblem
on the reverse of the remote control.
(This key only fits the front left-hand
door.)
2 Unlock the door with the key.
The car alarm will be tripped. To silence the
alarm, insert the remote control into the igni-
tion switch.
WARNING
Leaving children or pets unattended in a
locked car is dangerous. It is also danger-
ous to leave children in a vehicle with the
ignition key. A child or others could be
badly injured or even killed.
Never lock anyone in the car.
Locking/unlocking the front left-hand door
with the traditional key1 Lock
2 Unlock
93U S M 06.book Page 52 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

53 Security
Locking a car with dead batteryThe steering wheel lock requires sufficient
battery voltage to lock and unlock. If the bat-
tery voltage drops below a certain level
while the remote control is in the ignition
switch, you will not be able to remove the
remote control.
If you must leave the car, proceed as
follows:
1 Lock the car by pressing down the lock
buttons on the doors.
2 Lock the front left door from outside with
the traditional key (see page 52). The
car is now locked but the car alarm will
remain inactive.
Trunk lid/TailgateOpening
Sport Sedan: The trunk lid is unlocked and
slightly opened when the button on the
remote control or on the inside of the driver’s
door is pressed once.
SportCombi: The tailgate is unlocked (not
opened) when the button on the remote
control or on the inside of the driver’s door
is pressed once.
The hazard warning lights will flash three
times to confirm.
Closing
Sport Sedan: The trunk lid is locked when
closed.
SportCombi: The tailgate is not locked
when closed. It is locked together with the
doors when button on the remote con-
trol is pressed once.
If the doors are locked when the trunk lid is
closed it is armed and the movement sensor
in the cabin will be armed.
Opening button on driver’s door
93U S M 06.book Page 53 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

54 SecuritySwitches on front doorsThe central locking can also be operated
from inside the car using the button by each
front door handle.
Locking the car with the remote control ren-
ders these buttons inoperative.
Sport Sedan: If you are sitting in the car and
pressing the button on the driver’s
door, the driver’s door will unlock. Pressing
the button a second time will unlock the
remaining doors.
SportWagon: If you are sitting in the car
and pressing the button on the driver’s
door, the driver’s door will unlock. Pressing
the button a second time will unlock the
remaining doors and the tailgate.
The button on the passenger door works in
the same way except that this first unlocks
the passenger door. During this operation
the rear doors remain locked.
If the car is left with one or more doors open,
the interior lighting will be switched off auto-
matically after 20 minutes. This is to prevent
the battery from running flat. Also, if the car
has electrically adjustable seats, these will
cease to operate.
Child safety locksThe rear doors are equipped with child
safety locks that are activated by means of
a catch next to the door latch.
Insert a screwdriver or the traditional key
(enclosed in the remote control) and turn it
45° in the direction shown on the label on
the door.
When the child safety lock is in the locked
position, the door can only be opened from
outside the car.
WARNING
If small children are carried in the rear
seat, the safety locks on the rear doors
should be activated to prevent uninten-
tional opening from the inside.
Child safety locks
Central locking switch
93U S M 06.book Page 54 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

55 Security
Trunk Release HandleThere is a glow-in-the-dark trunk release
handle located inside the trunk on the latch.
This handle will glow following exposure to
light. Pull the release handle down to open
the trunk from inside.
Reprogramming lock system
functionsCertain lock system functions can be
reprogrammed. We recommend that you
contact a Saab dealer (see page 309).Checking the number of remote
controlsTo check the number of remote controls that
are programmed for the car:
1 Insert the remote control into the ignition
switch and turn it to ON.
2 Press and hold the button for more
than 2 seconds within 30 seconds after
the ignition switch has been turned to
the ON position.
3 The Saab Information Display (SID) will
now display the number of remote
controls that are programmed for your
car, and which of these (1–5) is in the
ignition switch.
Example of SID message:
NOTICEThe trunk release handle was not
designed to be used to tie down the trunk
lid or as an anchor point when securing
items in the trunk. Improper use of the
trunk release could damage it
2: standard key
Key No: 1
Trunk Release Handle
93U S M 06.book Page 55 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

56 SecurityChanging the key batteryWhen the voltage of the remote control bat-
tery drops below a certain level, the Saab
Information Display (SID) will display:
Change the battery as soon as possible to
avoid malfunctioning.Battery type: For optimum performance in
all temperatures and good service life, Saab
recommends the use of a Sony or Pana-
sonic CR2032, 3V lithium battery.
The battery should last for about 4 years of
normal use.
The battery type is marked on the inside of
the remote control. Avoid leaving finger-
prints on the faces of the battery.
1 Press the emblem on the reverse of the
remote control to remove the traditional
key.
2 Insert the tip of the key into the small slot
and turn the key to split the remote
control.
WARNING
Keep the battery and other small compo-
nents of the remote control out of reach of
children.NOTICEThe electronics of the remote control are
sensitive to electrostatic discharge. Incor-
rect handling when changing the battery
can damage the remote control. Avoid
touching electronic components of the
remote control with your hands.
Remote control battery
low. Replace battery.
Press the emblem to remove
the traditional key
93U S M 06.book Page 56 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

57 Security
3 Change the battery. Fit the new battery
so that it is positioned in the same way
as the old battery, with the positive (+)
side facing down.
4 Fit the two halves of the remote control
together and press them together until
you hear several clicks. Avoid pressing
the buttons. Reinsert the traditional key
into the remote control.5 After changing the battery in the remote
control, it is only possible to use the
remote control a limited number of times
before synchronization with the car is
lost. Therefore, do not press the buttons
on the remote control repeatedly directly
after changing the battery.
Unlock the car and insert the remote
control into the ignition switch to
synchronize the remote control and car.
If the central locking system does not work
after changing the battery and the car is
locked, proceed as follows:
1 Unlock the front left door with the tradi-
tional key. If the car has a car alarm, this
will be tripped.
2 Open the door and insert the remote
control into the ignition switch. If the car
has a car alarm, this will be silenced.
The remote control and receiver unit are
now synchronized.
ImmobilizerThe remote control contains an electronic
code that is unique to your car. When the
remote control is inserted into the ignition
switch, this code is checked and the LED on
the dashboard double-flashes for
3 seconds. If the code is correct, the car can
be started.
Each time you remove the remote control
from the ignition, the electronic starting
interlock is activated, the LED double-
flashes for 3 seconds and the car becomes
immobilized. If an incorrect remote control is
now inserted into the ignition switch (e.g.
the remote control of another car), the
immobilizer will remain operative (the LED
will not flash for 3 s) and it will not be possi-
ble to start the car.
If the immobilizer system malfunctions, the
Saab Information Display (SID) displays:
Immobilizer failure.
Try starting again.
Contact Saab dealer.
Change the battery and fit together
the two halves of the remote control93U S M 06.book Page 57 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

58 SecurityIf, when inserted into the ignition switch,
there is a problem checking the electronic
code of the remote control, the following
message will appear on the SID:
Visit a Saab dealer to have the problem
checked and rectified.
Car alarmThe car alarm is armed when the car is
locked with the remote control.
The car alarm will not be armed if you
lock the car with the traditional key (see
page 52).
All the doors, the hood and the trunk lid are
monitored by the alarm.The alarm is armed 11 seconds after the car
has been locked by remote control.
During the delay period, the LED shines
constantly. It will then start to flash once
every 3 seconds. The LED is located on the
dashboard.
If a door or the trunk lid is open when the car
is locked with the remote control, the LED
will flash 3 times per second for
11 seconds. Check that the doors, hood
and trunk lid are closed.
If the signal persists, contact a Saab dealer
to have the problem checked and rectified.
Locking the trunk lid:
Sport Sedan: If you open the trunk lid from
outside the car with the button on the
remote control, you must lock the car with
the button to arm the car alarm.
SportCombi: If you unlock and/or open the
trunk lid from outside the car with the
button on the remote control, you must lock
the car with the button to arm the car
alarm. Key not accepted.
Contact Saab dealer.
WARNING
Leaving children or pets unattended in a
locked car is dangerous. It is also danger-
ous to leave children in a vehicle with the
ignition key. A child or others could be
badly injured or even killed.
93U S M 06.book Page 58 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

59 Security
To avoid any inconvenience, make sure that
anyone using the car is familiar with how the
car alarm and the locking system work.
If the alarm has been tripped since the car
was last locked, the Saab Information Dis-
play (SID) will display:
If a fault arises in the car alarm system, the
Saab Information Display (SID) will display:
Arming the car alarmThe alarm is armed when all doors, the hood
and the trunk lid are closed and you lock the
car with the remote control.
What trips the alarm?The alarm will be tripped if:
 a door, the hood or the trunk lid is opened
 somebody tries to hotwire the carSignals when the alarm is trippedIf the alarm is triggered, the following alarm
signals will be set off:
 all direction indicators flash for 5 minutes.
 the horn sounds for 30-second intervals
with 10-second breaks (max. 10 cycles).
The signals can vary between markets
and due to legal and insurance require-
ments. Alarm has been triggered
since being armed.
Theft protection failure.
Contact Saab dealer.
93U S M 06.book Page 59 Friday, February 18, 2005 1:15 PM
ProCarManuals.com

60 SecuritySwitching off the alarm if tripped
If the alarm has been triggered (direction
indicators flashing and horn sounding) it can
be turned off by pressing one of the buttons
on the remote control or, if you are sitting in
the car, by turning the ignition to ON (see
below).
Panic functionThe car alarm includes a panic function.
This function allows the alarm to be started
manually, for example, to attract attention.
The panic alarm can only be activated while
the car is stationary. The alarm is silenced if
the car is driven off.
When the alarm is tripped, the lights and
horn come on for 3 minutes or until you
press one of the remote control buttons.
To start the alarm manually proceed as
follows:
 Press and hold the button on the
remote control for more than 2 seconds,
or if you are sitting in the car...
 Press and hold the or button on
one of the front doors for more than
2 seconds.
To switch off the alarm:
 Press one of the remote control buttons
or, if you are sitting in the car, the or
buttons on one of the front doors. Turns off lights and horn.
Unlocks car.
Turns off lights and horn.
Car remains locked.
Turns off lights and horn.
Unlocks trunk.
Turns off lights and horn.
Turns on exterior and cabin light-
ing. Car remains locked.
If sitting in the car: Turn the remote
control to ON in the ignition switch
NOTICE It is possible to inadvertently deacti-
vate the car alarm and at the same
time unlock the car, if the button on the
key is pressed by mistake when the
car is still within its range.
 When locking the car by remote
control in extremely cold weather, it is
advisable to check that the lock
system has operated properly. To do
so, check that the interior locking
buttons are all down.
If not, unlock and relock the car again.
93U S M 06.book Page 60 Friday, February 18, 2005 1:15 PM
ProCarManuals.com
