Low Tire Pressure Warning Light
This light will come on
briey when you turn
the ignition to RUN.
This light will also come on when one or more of
your tires are signicantly underinated.
A CHECK TIRE PRESS DIC message will
accompany the light, seeDIC Warnings and
Messages on page 182for more information.
Stop and check your tires as soon as it is safe to do
so. If underinated, inate to the proper pressure.
SeeTires on page 298for more information.
This light will ash for 60 seconds and then turn
on solid if a problem is detected with the Tire
Pressure Monitor system. SeeTire Pressure
Monitor System on page 305for more information.
Traction Control System (TCS)
Warning Light
If your vehicle has the
Traction Control System
(TCS), this light may
come on for the
following reasons:
If you turn the system off by pressing the TC
(traction control) button located on the center
console, the light will come on and stay on. To
turn the system back on, press the button again
and the warning light should go out.
If there is a brake system problem that is
specically related to traction control, the TCS
will turn off and the warning light will come on.
If the traction control system warning light comes
on and stays on for an extended period of
time when the system is turned on, your vehicle
needs service.
170

Electronic Stability Control Indicator
Light
Your vehicle may have
the Electronic Stability
Control (ESC) system.
You may feel or hear the system working, this is
normal. SeeElectronic Stability Control on
page 219for more information.
When the ESC indicator light is on and either the
SERVICE ESC or ESC OFF Driver Information
Center (DIC) message is displayed, the system will
not assist the driver to maintain directional
control of the vehicle. Adjust your driving
accordingly. SeeDIC Warnings and Messages on
page 182for more information.
Engine Coolant Temperature
Warning Light
This light indicates that
the engine coolant has
overheated or the
radiator cooling fan is
not working.
This light will come on briey when you turn on
the ignition as a check to show you it is working.
If the light comes on and the vehicle has been
operating under normal driving conditions, pull off
the road, stop the vehicle, and turn off the
engine as soon as possible.
SeeCooling System on page 278for more
information.
171

Fuel Economy Light
If enabled, this light will
come on briey when
the vehicle is started.
This light will also come on when the vehicle is
operating at a fuel efficient point.
This light can be disabled by using the Driver
Information Center (DIC) buttons. With the engine
off and the key turned to accessory, set the
DIC to the outside air temperature and odometer
mode. Press and hold the reset button for
several seconds. The light will come on solid and
then ash several times and turn off to indicate
it is disabled. Repeat the procedure to enable the
light. SeeDIC Warnings and Messages on
page 182for more information.
Driver Information Center (DIC)
Your vehicle has a Driver Information Center (DIC).
The DIC display gives you the status of many of
your vehicle’s systems. The DIC is also used to
display driver personalization menu modes and
warning/status messages. All messages will appear
in the DIC display, located at the bottom of the
instrument panel cluster.
The DIC buttons are located on the left side of the
steering wheel. Your vehicle will have one of
the buttons shown above.
q/INFO (Information):Press this button to
scroll through the vehicle information mode
displays.
179

AV (Average) SPEED
Press the information button until AV SPEED
displays. This mode shows the vehicle’s average
speed in miles per hour (mph) or kilometers
per hour (km/h).
To reset the average vehicle speed, press and
hold the reset button while AV SPEED is
displayed.
OIL LIFE
Press the information button until OIL LIFE
displays. The engine oil life system shows an
estimate of the oil’s remaining useful life. It shows
100% when the system is reset after an oil
change. It alerts you to change the oil on a
schedule consistent with your driving conditions.
In addition to the engine oil life system monitoring
the oil life, additional maintenance is
recommended in the Maintenance Schedule in this
manual. SeeEngine Oil on page 265and
Scheduled Maintenance on page 356.
Always reset the engine oil life system after an oil
change. See “How to Reset the Engine Oil Life
System” underEngine Oil Life System on
page 268.
COOLANT
Press the information button until COOLANT
displays. This mode shows the temperature of the
engine coolant in either degrees Fahrenheit (°F) or
degrees Celsius (°C).
DIC Warnings and Messages
These messages appear if there is a problem
detected in one of your vehicle’s systems.
A message clears when the vehicle’s condition is
no longer present. To acknowledge a message
and clear it from the display, press and hold any of
the DIC buttons. If the condition is still present,
the warning message comes back on the next time
the vehicle is turned off and back on. With most
messages, a warning chime sounds when
the message displays. Your vehicle may have
other warning messages.
AUTO (Automatic) LIGHTS OFF
This message displays if the automatic headlamp
system is disabled with the headlamp switch.
SeeAutomatic Headlamp System on page 150for
more information.
182

AUTO (Automatic) LIGHTS ON
This message displays if the automatic headlamp
system is enabled with the headlamp switch.
SeeAutomatic Headlamp System on page 150for
more information.
BRAKE FLUID
This message displays, while the ignition is on,
when the brake uid level is low. The brake system
warning light on the instrument panel cluster
also comes on. SeeBrake System Warning Light
on page 168for more information. Have the
brake system serviced by your retailer as soon as
possible.
CHANGE OIL SOON
This message displays when the life of the engine
oil has expired and it should be changed.
When this message is acknowledged and cleared
from the display, the engine oil life system
must still be reset separately. SeeEngine Oil Life
System on page 268andScheduled Maintenance
on page 356for more information.
CHECK GAS CAP
This message displays if the fuel cap has not
been fully tightened. Recheck the fuel cap to make
sure that it is on properly. A few driving trips
with the cap properly installed should turn
the message off.
CHECK TIRE PRESS (Pressure)
This message displays when the tire pressure in
one or more of the tires needs to be checked. If a
tire pressure message appears on the DIC, stop as
soon as you can. Have the tire pressures checked
and set to those shown on the Tire Loading
Information label. SeeTires on page 298,Loading
Your Vehicle on page 242, andInation - Tire
Pressure on page 304. If the tire pressure is low,
the low tire pressure warning light comes on. See
Low Tire Pressure Warning Light on page 170.
CRUISE ENGAGED
This message displays when the cruise control
system is active. SeeCruise Control on page 145
for more information.
183

SERVICE AIR BAG
This message displays when there is a problem
with the airbag system. Have your vehicle serviced
by your retailer immediately.
SERVICE ESC (ELECTRONIC STABILITY
CONTROL)
If your vehicle has Electronic Stability Control
(ESC), this message displays and a chime sounds
if there has been a problem detected with ESC.
The ESC light also appears on the instrument
panel cluster. This light stays on solid as long as
the detected problem remains present. When
this message displays, the system is not working.
Adjust your driving accordingly. SeeElectronic
Stability Control on page 219andElectronic
Stability Control Indicator Light on page 171for
more information.
If this message turns on while you are driving, pull
off the road as soon as possible and stop
carefully. Try resetting the system by turning the
ignition off and then back on. If this message
still stays on or turns back on again while you are
driving, your vehicle needs service. Have the
ESC inspected by your retailer as soon as
possible.
SERVICE HYBRID
This message displays if the hybrid components
need to be serviced. Have your vehicle serviced by
your retailer.
SERVICE TRACTION
If your vehicle has the Traction Control System
(TCS), this message displays and a chime sounds
when the system is not functioning properly.
The TCS light also appears on the instrument
panel cluster. This light stays on solid as long as
the detected problem remains present. When
this message displays, the system is not working.
Adjust your driving accordingly. SeeTraction
Control System (TCS) on page 217andTraction
Control System (TCS) Warning Light on page 170
for more information. Have the system serviced
by your retailer as soon as possible.
SRVC (Service) HILL START
This message displays if there is a problem with
the hill start assist function. Have your vehicle
serviced by your retailer.
186

TRACTION OFF
If your vehicle has the Traction Control System
(TCS), this message displays and the TCS light on
the instrument panel cluster comes on solid when
the system is turned off. Adjust your driving
accordingly. SeeTraction Control System (TCS) on
page 217andTraction Control System (TCS)
Warning Light on page 170for more information.
TRUNK AJAR
This message displays when the trunk is not
closed completely. Make sure that the trunk is
closed completely. SeeTrunk on page 97for more
information.
DIC Vehicle Personalization
Your vehicle has personalization capabilities that
allow you to program certain features to a
preferred setting. All of the features listed may not
be available on your vehicle. Only the features
available will be displayed on the DIC.
The default settings for the features were set
when your vehicle left the factory, but may have
been changed from their default state since
that time.To change feature settings, use the following
procedure:
Entering Personalization Menu
1. Turn the ignition on while the vehicle is
stopped.
To avoid excessive drain on the battery, it is
recommended that the headlamps are
turned off.
2. Press and hold the information and reset
buttons at the same time for one second, then
release to enter the personalization menu.
If the vehicle speed is greater than 2 mph
(3 km/h), only the UNITS menu will be
accessible.
3. Press the information button to scroll through
the available personalization menu modes.
Press the reset button to scroll through
the available settings for each mode.
If you do not make a selection within ten
seconds, the display will go back to the
previous information displayed.
187

Control of a Vehicle
You have three systems that make your vehicle
go where you want it to go. They are the brakes,
the steering, and the accelerator. All three
systems have to do their work at the places where
the tires meet the road.
Sometimes, as when you are driving on snow or
ice, it is easy to ask more of those control systems
than the tires and road can provide. That means
you can lose control of your vehicle. SeeTraction
Control System (TCS) on page 217and
Electronic Stability Control on page 219.
Adding non-Saturn accessories can affect your
vehicle’s performance. SeeAccessories and
Modications on page 253.
Braking
SeeBrake System Warning Light on page 168.
Braking action involves perception time and
reaction time.
First, you have to decide to push on the brake
pedal. That is perception time. Then you have to
bring up your foot and do it. That is reaction time.
Average reaction time is about three-fourths of a
second. But that is only an average. It might be less
with one driver and as long as two or three seconds
or more with another. Age, physical condition,
alertness, coordination, and eyesight all play a part.
So do alcohol, drugs, and frustration. But even in
three-fourths of a second, a vehicle moving at
60 mph (100 km/h) travels 66 feet (20 m). That
could be a lot of distance in an emergency, so
keeping enough space between your vehicle and
others is important.
And, of course, actual stopping distances vary
greatly with the surface of the road, whether it is
pavement or gravel; the condition of the road,
whether it is wet, dry, or icy; tire tread; the
condition of the brakes; the weight of the vehicle;
and the amount of brake force applied.
214

Avoid needless heavy braking. Some people drive
in spurts — heavy acceleration followed by
heavy braking — rather than keeping pace with
traffic. This is a mistake. The brakes may not have
time to cool between hard stops. The brakes
will wear out much faster if you do a lot of heavy
braking. If you keep pace with the traffic and
allow realistic following distances, you will
eliminate a lot of unnecessary braking. That means
better braking and longer brake life.
If your vehicle’s engine ever stops while you are
driving, brake normally but do not pump the
brakes. If you do, the pedal may get harder to
push down. If the engine stops, you will still have
some power brake assist. But you will use it
when you brake. Once the power assist is used
up, it may take longer to stop and the brake pedal
will be harder to push.
Adding non-Saturn accessories can affect your
vehicle’s performance. SeeAccessories and
Modications on page 253.Antilock Brake System (ABS)
Your vehicle has the Antilock Brake System (ABS),
an advanced electronic braking system that will
help prevent a braking skid.
When you start the engine and begin to drive
away, ABS will check itself. You might hear
a momentary motor or clicking noise while this test
is going on, and you might even notice that the
brake pedal moves a little. This is normal.
If there is a problem
with ABS, this warning
light will stay on.
SeeAntilock Brake
System Warning Light
on page 169.
215

The TCS operates in all transmission shift lever
positions except PARK (P), NEUTRAL (N) or
REVERSE (R). But the system can upshift
the transmission only as high as the shift lever
position you’ve chosen, so you should use
the lower gears only when necessary. See
Automatic Transaxle Operation on page 116.
This light is located on
the instrument panel
cluster.
When the system is on, this warning light will
come on to let you know if there’s a problem, or if
the system has been turned off. When this light
is on, the system will not limit wheel spin.
Adjust your driving accordingly.
To limit wheel spin, especially in slippery road
conditions, you should always leave the TCS on.
But you can turn the system off if you prefer.To turn the system on or off, press the traction
control button (TC) located on the center console.
In order to effectively “rock” the vehicle, you
will need to turn off TCS.
If you press the TC button once, the TCS will turn
off, the TRACTION OFF message will display and
the TCS warning light will come on. The
StabiliTrak
®system will stay on. Press the TC
button again to turn the system back on. The TCS
warning light will go off. If you press and hold the
TC button, the StabiliTrak
®system and the traction
control system will turn off. Press the TC button
again to turn StabiliTrak
®and the traction control
system back on. For more information, see
Electronic Stability Control on page 219.
When you turn the system off, the TCS warning
light will come on and stay on. If the Traction
Control System is limiting wheel spin when you
press the button to turn the system off, the warning
light will come on – but the system won’t turn off
right away. It will wait until there’s no longer a
current need to limit wheel spin.
Adding non-dealer/non-retailer accessories can
affect your vehicle’s performance. SeeAccessories
and Modications on page 253for more
information.
218
