clock SATURN ION 2004 User Guide

4. To access the headlamp bulb, turn the dust cap
counter-clockwise to remove it.5. Raise the lock tab and pull the connector from the
base of the bulb to remove the electrical connector
from the headlamp bulb.
5-49
ProCarManuals.com

6. To remove the bulb retaining nut, turn it
counter-clockwise.
7. Remove the bulb and replace it with the
appropriate bulb.
Headlamps (Coupe)
1. Turn the ignition and headlamp switch off.
2. After allowing the bulb to cool, open the hood.
SeeHood Release on page 5-10.
3. Pull up on the headlamp retaining pins to remove
them, gently pull the headlamp assembly away
from the vehicle and remove the electrical
connector.
5-50
ProCarManuals.com

4. To access the park/turn bulb, turn the dust cap
counter-clockwise to remove it.5. Remove the park/turn bulb socket and bulb by
rotating it counter-clockwise.
6. Gently remove the bulb and replace it with the
appropriate bulb.
5-52
ProCarManuals.com

Front Turn Signal and Parking
Lamps (Coupe)
1. Open the hood. SeeHood Release on page 5-10.
2. Reach behind the headlamp from inside the hood.
3. Rotate the bulb socket counter-clockwise to
remove it from the housing.
4. Gently pull the bulb from the socket and replace it
with the appropriate bulb.
Fog Lamps
1. Turn off the fog lamps and allow them to cool.
2. Reach under the front bumper to the rear of the
fog lamp to locate the bulb socket.
3. Then rotate the bulb socket counter-clockwise to
remove it.
4. Remove the bulb and replace it with the
appropriate bulb.
5-53
ProCarManuals.com

Sidemarker Lamps (Coupe)
1. Turn the ignition and headlamp switch off.
2. Open the hood. SeeHood Release on page 5-10.
3. Pull up on the headlamp retaining pins to remove
them, gently pull the headlamp assembly away
from the vehicle and remove the electrical
connector.4. Rotate the side marker bulb counter-clockwise to
disconnect it.
5. Gently remove the bulb and replace it with the
appropriate bulb.
5-54
ProCarManuals.com

4. Remove the bulb socket by rotating 1/8 of a turn
counter-clockwise.
5. Gently pull the bulb from the socket and replace it
with the appropriate bulb.
Replacement Bulbs
For any bulb not listed here contact your retailer.
Lamp TypeSaturn Part
Number
Headlamps
(All Models)9007 16524431
Front
Sidemarker
Lamps (Coupe)168 9425542
Front Turn
Signal/Parking
Lamps5702 10319394
Stop/Taillamps
(Top)3057 12450064
Back-Up Lamps 921L 22692679
CHMSL PC-175 9442441
Fog Lamps
(All Models)881L 12450176
5-56
ProCarManuals.com

2. Remove the nut that holds down the spare tire.
SeeCompact Spare Tire on page 5-86
3. Remove the spare tire by placing your hands at the
four and eight o’clock positions. Gently pull it up
and out of the trunk. For vehicles equipped with the
2.0L supercharged engine, complete Step 4 rst,
then Step 3.
4. Remove the wing nut that holds the jack and
remove the jack and wheel wrench.
The tools you’ll be using include the jack (A) and wheel
wrench (B).You will need to turn the plastic wheel nut
counterclockwise to loosen the wheel wrench
from the jack.
5-79
ProCarManuals.com

3. Position the jack lift head at the jack location nearest
the at tire. The front location is about 7 inches
(17.8 cm) rearward from the front wheel opening.
The rear location is about 2 inches (5.1 cm) forward
of the rear wheel opening.
Make sure the jack head is touching the metal
jacking ange under the body. Do not place the jack
under the plastic body panel.
Notice:Make sure that the jack lift head is in the
correct position or you may damage your vehicle.
The repairs would not be covered by your warranty.
{CAUTION:
Getting under a vehicle when it is jacked up is
dangerous. If the vehicle slips off the jack you
could be badly injured or killed. Never get under
a vehicle when it is supported only by a jack.
{CAUTION:
Raising your vehicle with the jack improperly
positioned can damage the vehicle and even
make the vehicle fall. To help avoid personal
injury and vehicle damage, be sure to t the
jack lift head into the proper location before
raising the vehicle.
4. Put the compact spare tire near you.
5. Raise the vehicle by turning the jack handle
clockwise. Raise the vehicle far enough off the
ground so there is enough room for the compact
spare tire to t under the vehicle.
5-81
ProCarManuals.com

6. Remove all of the wheel nuts.
7. Remove any rust or dirt
from the wheel bolts,
mounting surfaces
and spare wheel.
{CAUTION:
Rust or dirt on the wheel, or on the parts to
which it is fastened, can make the wheel nuts
become loose after a time. The wheel could
come off and cause an accident. When you
change a wheel, remove any rust or dirt from
the places where the wheel attaches to the
vehicle. In an emergency, you can use a cloth
or a paper towel to do this; but be sure to use
a scraper or wire brush later, if you need to,
to get all the rust or dirt off.
{CAUTION:
Never use oil or grease on studs or nuts. If you
do, the nuts might come loose. Your wheel
could fall off, causing a serious accident.
8. Place the compact spare tire on the wheel-mounting
surface.
9. Reinstall the wheel nuts with the rounded end of
the nuts toward the wheel. Tighten each nut by
hand until the wheel is held against the hub.
10. Lower the vehicle by turning the jack handle
counterclockwise. Lower the jack completely.
5-82
