SATURN VUE 2004 Owners Manual

Usage Fluid/Lubricant
Rear Drive
Module and
Power Transfer
Unit (except
with
3.5L V6 engine)VERSATRAK
®Fluid
(GM Part No. U.S. 12378514,
in Canada 88901045).
Rear Drive
Module (with
3.5L V6 engine)VERSATRAK
®Fluid
(GM Part No. U.S. 12378514,
in Canada 88901045).
Transfer Case
(with 3.5L V6
engine)Synthetic Axle Lubricant
(GM Part No. U.S. 12378261,
in Canada 10953455).
Key Lock
CylindersMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241,
in Canada 10953474).
Hood Latch
Assembly,
Secondary
Latch, Pivots,
Spring Anchor
and Release
PawlLubriplate Lubricant Aerosol
(Saturn Part No. 21038869 or
GM Part No. U.S. 12346293,
in Canada 992723) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Usage Fluid/Lubricant
Hood, Liftgate
Door and rear
folding seat
HingesMulti-Purpose Lubricant, Superlube
(GM Part No. U.S. 12346241,
in Canada 10953474).
Sunroof TrackLubriplate Lubricant Aerosol
(Saturn Part No. 21038869 or
GM Part No. U.S. 12346293,
in Canada 992723) or lubricant
meeting requirements of NLGI #2,
Category LB or GC-LB.
Weatherstrip
ConditioningDielectric Silicone Grease
(GM Part No. U.S. 12345579,
in Canada 992887).
6-15
ProCarManuals.com

Normal Maintenance Replacement Parts
Replacement parts identied below by name, part number, or specication can be obtained from your retailer.
Part Saturn Part Number ACDelco®Part Number
Engine Air Cleaner/Filter 22676970 —
Engine Oil Filter
2.2L L4 L61
3.5L V6 L6612579143
12582255—
Passenger Compartment Air Filter Element 22665802 —
Spark Plugs
2.2L L4 L61
3.5L V6 L6612569190
12582002—
Windshield Wiper Blades
Driver’s Side Length — 23.6 inches (60.0 cm)
Passenger’s Side Length — 18.7 inches
(47.5 cm)22703502
—8–2241
8–2191
Rear Wiper Blade — 11.0 inches (28.0 cm) 22665009 —
6-16
ProCarManuals.com

Engine Drive Belt Routing
2.2L Four Cylinder (L61) Engine
3.5L V6 (L66) Engine
6-17
ProCarManuals.com

Maintenance Record
After the scheduled services are performed, record the date, odometer reading, who performed the service and the
type of services performed in the boxes provided. SeeMaintenance Requirements on page 6-2. Any additional
information fromOwner Checks and Services on page 6-10can be added on the following record pages.
You should retain all maintenance receipts.
Maintenance Record
DateOdometer
ReadingServiced ByMaintenanceIor
MaintenanceIIServices Performed
6-18
ProCarManuals.com

Maintenance Record (cont’d)
DateOdometer
ReadingServiced ByMaintenanceIor
MaintenanceIIServices Performed
6-19
ProCarManuals.com

Maintenance Record (cont’d)
DateOdometer
ReadingServiced ByMaintenanceIor
MaintenanceIIServices Performed
6-20
ProCarManuals.com

Customer Assistance and Information...............7-2
Customer Satisfaction Procedure......................7-2
Online Owner Center......................................7-4
Customer Assistance for Text Telephone
(TTY) Users...............................................7-4
GM Mobility Program for Persons with
Disabilities..................................................7-5
Roadside Assistance Program..........................7-6
Vehicle Data Collection and Event Data
Recorders..................................................7-7Reporting Safety Defects..................................7-8
Reporting Safety Defects to the United States
Government...............................................7-8
Reporting Safety Defects to the Canadian
Government...............................................7-9
Reporting Safety Defects to Saturn...................7-9
Service Publications Ordering
Information.................................................7-9
Section 7 Customer Assistance and Information
7-1
ProCarManuals.com

Customer Assistance and
Information
Customer Satisfaction Procedure
Your satisfaction and goodwill are important to
your retailer and to Saturn. Together we are committed
to providing our customers with unparalleled service,
before, during and after the purchase of a Saturn
vehicle, for total customer satisfaction. We call this the
Saturn Difference. Normally, any concerns with the
sales transaction or the operation of your vehicle will be
resolved by your retailer’s sales or service departments.
If, for any reason, your ownership experience falls
below your expectations, we suggest you take
the following action:
STEP ONE:Contact the Retail Customer Assistance
Liaison. Any member of the retail management team has
the authority and the desire to resolve your concerns.
Normally, concerns can be quickly resolved at this level.
STEP TWO:Should you need additional assistance,
contact the Saturn Customer Assistance Center by
calling 1-800-553-6000. In Canada, contact the Saturn
Customer Communication Centre at 1-800-263-1999.A Saturn Customer Assistance Center team member
will handle your call and assist in providing product and
warranty information, the nearest retailer location,
roadside assistance, brochures, literature and discuss
any concerns you may have.
We encourage you to call the toll-free number in order
to give your inquiry prompt attention. Please have
the following information available to give the Customer
Assistance Representative:
Vehicle Identication Number. This 17-digit number
can be found on the vehicle registration or title, on
the upper driver’s side corner of the dash, or on
your roadside assistance key card.
The name of your selling and servicing retail facility.
Vehicle delivery date and present mileage.
Your daytime and evening phone numbers.
If you wish to write to the Saturn Customer Assistance
Center, our address is:
Saturn Customer Assistance Center
100 Saturn Parkway
Mail Code 371-999-S24
Spring Hill, TN 37174-1500
7-2
ProCarManuals.com

In Canada, write to:
Saturn Customer Communication Centre
General Motors of Canada Ltd.
1908 Colonel Sam Drive
Oshawa, Ontario L1H 8P7
When contacting Saturn, please remember that your
concern will likely be resolved at a retailer’s facility.
That is why we suggest you follow Step One rst if
you have a concern.
STEP THREE:Both Saturn and its retailers are
committed to making sure you are completely satised
with your Saturn vehicle. However, if you continue to
remain unsatised after following the procedure outlined
in Steps One and Two, Saturn and its retailers offer the
additional assistance of a neutral party through our
voluntary participation in a mediation/arbitration program
called BBB Auto Line. Canadian owners refer to your
Warranty and Owner Assistance Information booklet,
located in the front cover pocket of your owner’s
handbook, for information on the Canadian Motor
Vehicle Arbitration Plan (CAMVAP).
The BBB Auto Line Program is an out-of-court program
administered by the Council of Better Business Bureaus
to settle automotive disputes regarding vehicle repairs or
the interpretation of the New Vehicle Limited Warranty.
This program is available at no cost to you, our customer.We ask that you not resort to BBB Auto Line until after
Saturn and its retailers have been given the opportunity
to satisfy your vehicle concerns. However, U.S. residents
may le a claim at any time by contacting your local
Better Business Bureau at 1-800-955-5100.
Although you may be required to resort to this informal
dispute resolution program prior to ling a court action,
use of the program is free of charge and your case will
generally be heard within 40 days. If you do not agree
with the decision given in your case, you may reject it and
proceed with any other venue for relief available to you.
You may contact the BBB Auto Line Program by using
the toll-free telephone number or by writing them at the
following address:
BBB Auto Line Program
Council of Better Business Bureaus, Inc.
4200 Wilson Boulevard
Suite 800
Arlington, VA 22203-1838
This program is available in all 50 states and the
District of Columbia. Eligibility is limited by vehicle
age, mileage and other factors. Saturn Corporation
reserves the right to change eligibility limitations and/or
discontinue its participation in this program.
7-3
ProCarManuals.com

Online Owner Center
The Owner Center is a resource for your GM ownership
needs. Specic vehicle information can be found in
one place.
The Online Owner Center allows you to:
Get e-mail service reminders.
Access information about your specic vehicle,
including tips and videos and an electronic
version of this owner’s manual (United States only).
Keep track of your vehicle’s service history and
maintenance schedule.
Find GM dealers for service nationwide.
Receive special promotions and privileges only
available to members (United States only).
Refer to the web for updated information.
To register your vehicle, visit www.MyGMLink.com
(United States) or My GM Canada within
www.gmcanada.com (Canada).
Customer Assistance for Text
Telephone (TTY) Users
To assist owners who have hearing difficulties, Saturn
has installed special TDD (Telecommunication Devices
for the Deaf) equipment in its Saturn Customer
Assistance Center.
Any hearing- or speech-impaired customer who
has access to a TDD or to a conventional Text
Telephone (TTY) can communicate with Saturn by
dialing 1-800-TDD-6000. TTY users in Canada may
dial 1-800-263-3830.
7-4
