SATURN VUE HYBRID 2007 Owners Manual

"(Unlock):Press this button on the remote
keyless entry transmitter to unlock the driver’s
door. This also disarms the content theft-deterrent
system. SeeContent Theft-Deterrent on page 109
for information on disarming the content
theft-deterrent system. Press the button again
within 5 seconds to unlock the rest of the doors.
Your vehicle can be programmed so that the
parking lamps or DRL will ash and/or the horn will
sound when you unlock the doors with the remote
keyless entry transmitter. See your retailer for more
information on programming this feature.
L(Panic Alarm):Press the button with the horn
symbol when the ignition is turned off. The horn
will sound and the parking lamps or DRL and
dome lamp will ash for up to two minutes.
To stop the panic alarm, press this button again.
Matching Transmitter(s) to Your Vehicle
Each remote keyless entry transmitter is coded to
prevent another transmitter from unlocking
your vehicle. If a transmitter is lost or stolen, a
replacement can be purchased through your
retailer. Remember to bring any remaining
transmitters with you when you go to your retailer.
When the retailer matches the replacementtransmitter to your vehicle, any remaining
transmitters must also be matched. Once your
retailer has coded the new transmitter, the
lost transmitter will not unlock your vehicle.
Each vehicle can have a maximum of four
transmitters matched to it.
Battery Replacement
Under normal use, the battery in your remote
keyless entry transmitter should last about
four years.
You can tell the battery is weak if the transmitter
will not work at the normal range in any location.
If you have to get close to your vehicle before
the transmitter works, it is probably time to change
the battery.
Notice:When replacing the battery, use care
not to touch any of the circuitry. Static
from your body transferred to these surfaces
may damage the transmitter.
1. Use a at thin object to pry open the
transmitter.
101
ProCarManuals.com

2. Once the transmitter is separated, use a
pencil or similar object to remove the old
battery. Do not use a metal object.
3. Insert the new battery as the instructions
under the cover indicate.
4. Snap the transmitter back together tightly to
be sure no moisture can enter.
5. Check the operation of the transmitter.
If the transmitter does not work, try synchronizing
your transmitter with your receiver. See
“Resynchronization” for more information.
Resynchronization
This is used to keep the transmitter of the vehicle
communicating with the receiver of the vehicle.
Resynchronization may be required due to
the security method used by this system.
Your vehicle has an automatic resynchronization
function built into the system. If your transmitter is
not working properly and you have to manually
resynchronize, press the lock and unlock buttons at
the same time for seven seconds while you are
near your vehicle. The doors will lock or unlock,
depending on their starting position. If they do not,
contact your retailer for service.
102
ProCarManuals.com

Doors and Locks
Door Locks
{CAUTION:
Unlocked doors can be dangerous.
Passengers, especially children, can
easily open the doors and fall out of a
moving vehicle. When a door is
locked, the handle will not open it.
You increase the chance of being
thrown out of the vehicle in a crash if
the doors are not locked. So, wear
safety belts properly and lock the
doors whenever you drive.
CAUTION: (Continued)
CAUTION: (Continued)

Young children who get into unlocked
vehicles may be unable to get out.
A child can be overcome by extreme
heat and can suffer permanent injuries
or even death from heat stroke.
Always lock your vehicle whenever
you leave it.
Outsiders can easily enter through an
unlocked door when you slow down
or stop your vehicle. Locking your
doors can help prevent this from
happening.
There are several ways to lock and unlock
your vehicle.
From the outside, turn the key in the driver’s door
lock counterclockwise to lock the door and
clockwise to unlock it or use the remote keyless
entry transmitter.
From the inside, move the manual lock control on
the door or use the power door lock switch.
103
ProCarManuals.com

Power Door Locks
The power door lock
switches are located on
the driver’s and front
passenger’s doors.
Press the bottom of the
switch to lock all doors.
Press the top of the
switch to unlock
all doors.
Delayed Locking
This feature will delay the actual locking of the
doors and arming of the theft-deterrent system for
ve seconds when the power door lock switch
or remote keyless entry transmitter is used to lock
the vehicle.If any door is open when locking the vehicle,
three chimes will sound signaling that the delayed
locking feature is active. Five seconds after the
last door is closed, all of the doors will lock.
To cancel the delay and lock the doors
immediately, press the lock button on the remote
keyless entry transmitter or the power door
lock switch a second time. The theft deterrent
system will arm after 30 seconds.
Programmable Automatic
Door Locks
Automatic Locking
Your vehicle has a locking feature that will
automatically lock all the doors and liftgate when
the ignition is in RUN and the shift lever is
moved out of PARK (P).
All doors must be closed. The automatic locking
feature cannot be disabled.
All doors will automatically lock again when the
brake pedal is applied, a door is opened and then
closed, and the brake pedal is released.
104
ProCarManuals.com

Programmable Automatic Unlocking
All the doors and liftgate will automatically unlock
when the shift lever is moved into PARK (P).
The unlocking feature can be programmed on or off
by turning the ignition to RUN, engine not running,
and pressing the unlock part of the power door lock
switch for eight seconds. The horn will chirp once
when this feature is on and twice when it is off.
Rear Door Security Locks
Your vehicle has rear door security locks that
prevent passengers from opening the rear doors
from the inside.
The rear door security
locks are located on the
inside edge of each
rear door.To set the rear door security locks, do the following:
1. Insert the key into the lock and turn it
counterclockwise (left) for the driver’s side and
clockwise (right) for the passenger’s side.
2. Close the door.
When you want to open a rear door when the
security lock is on, do the following:
1. Unlock the door using the remote keyless
entry transmitter, the power door lock
switch, or by lifting the rear door manual lock.
2. Open the door from the outside.
To cancel the rear door security lock, do the
following:
1. Unlock the door and open it from the outside.
2. Insert the key into the lock and turn it
clockwise (right) for the driver’s side
and counterclockwise (left) for the
passenger’s side.
105
ProCarManuals.com

Lockout Protection
If you press the power door lock switch when the
key is in the ignition and any door is open, all
the doors will lock and then the driver’s door will
unlock. Be sure to remove the key from the ignition
when locking your vehicle.
If the remote keyless entry transmitter is used to
lock the doors while the key is in the ignition,
a chime will sound three times. All doors will
then lock.
Liftgate
{CAUTION:
It can be dangerous to drive with the
liftgate open because carbon monoxide
(CO) gas can come into your vehicle.
You cannot see or smell CO. It can cause
CAUTION: (Continued)
CAUTION: (Continued)
unconsciousness and even death. If you
must drive with the liftgate open or if
electrical wiring or other cable
connections must pass through the seal
between the body and the liftgate:
Make sure all other windows are shut.
Turn the fan on your heating or
cooling system to its highest speed
and select the control setting that will
force outside air into your vehicle. See
Climate Control System on page 156.
If you have air outlets on or under the
instrument panel, open them all the
way. SeeEngine Exhaust on page 125.
Use your remote keyless entry transmitter or
power door lock switches to unlock the liftgate.
To open the liftgate, lift the handle located in the
center of the liftgate.
106
ProCarManuals.com

Windows
{CAUTION:
Leaving children, helpless adults, or pets
in a vehicle with the windows closed is
dangerous. They can be overcome by the
extreme heat and suffer permanent
injuries or even death from heat stroke.
Never leave a child, a helpless adult, or a
pet alone in a vehicle, especially with the
windows closed in warm or hot weather.
107
ProCarManuals.com

Power Windows
The window switches
are located on each
side of the shift lever on
the center console.
To lower a window, press the switch down.
To raise a window, pull the switch up.
The power windows operate when the ignition is in
RUN or ACC.
A window switch is also located on each rear
door. Press the bottom of the switch to lower the
window. Press the top of the switch to raise
the window.
Express-Down Window
The driver’s window switch has an express-down
feature that is labeled AUTO. This allows the
driver’s window to open fully without having to
continuously press the switch. Press the switch to
the second position and the driver’s window will go
all the way down. To stop the window from
lowering, lift the switch all the way up and release it.
Window Lockout
The driver’s window switches also include a lockout
switch. Press the left side of the switch to prevent
rear passengers from using their window switches.
The driver can still control all the windows with the
lockout on. Press the right side of the window
lockout switch to return to normal window
operation.
Sun Visors
To block out glare swing the visors down or to the
side. The driver’s sun visor can be detached
from the center mount and slid along the rod to
block different areas of the front window.
Visor Vanity Mirrors
Your vehicle has covered visor vanity mirrors.
108
ProCarManuals.com

Theft-Deterrent Systems
Vehicle theft is big business, especially in some
cities. Although your vehicle has a number of
theft-deterrent features, we know that nothing we
put on it can make it impossible to steal.
Content Theft-Deterrent
The remote keyless entry transmitter is used to
arm/disarm the theft-deterrent system. Your
vehicle’s theft-deterrent system can be
programmed to three different modes.
Active Arming:The system will arm when the
lock button on the remote keyless entry transmitter
is pressed. The system will disarm when the
unlock button is pressed.
Passive Arming:The system will arm itself
one minute after the ignition is turned off and the
driver’s door has been opened and closed.
If the lock button on the transmitter is pressed
before the minute has passed, the system will arm
immediately. The system will disarm when the
unlock button is pressed.Security System Disable:The system will
not arm.
To change the mode that your vehicle is
programmed to, do the following:
1. Turn the ignition to RUN or ACC.
2. Press the panic alarm button on the
transmitter slowly four times within
ve seconds.
3. You must complete one of the following within
three seconds to change the mode.
To select the active arming mode, press the
lock button on the transmitter.
To select the passive arming mode, press
the lock button on the transmitter twice
within 3 seconds.
To select the security system disable mode,
press the unlock button on the transmitter.
A chime will sound once the mode has been
selected.
109
ProCarManuals.com

If you accidentally set off the alarm when
entering/exiting the vehicle, you can shut it off by
pressing any button on the remote keyless
entry transmitter other than the panic alarm button.
If you hear three horn chirps when you press
the unlock button on the transmitter, that means
the vehicle’s alarm was triggered while you
were away.
Passlock®
Your vehicle is equipped with the
Passlock®theft-deterrent system.
This light will come on
for the theft-deterent
system.Passlock
®is a passive theft-deterrent system.
Passlock®enables fuel if the ignition lock cylinder
is turned with a valid key. If a correct key is
not used or the ignition lock cylinder is tampered
with, fuel is disabled.
During normal operation, the security light will go
off approximately ve seconds after the key is
turned to RUN following an engine start.
If the engine stalls and the security light ashes,
wait until the light stops ashing before trying
to restart the engine. Remember to release the key
from START as soon as the engine starts.
If the engine is running and the security light
comes on, you will be able to restart the engine
if you turn the engine off. However, your
Passlock
®system is not working properly and
must be serviced by your retailer. Your vehicle is
not protected by Passlock
®at this time. You may
also want to check the fuses, seeFuses and
Circuit Breakers on page 380. See your retailer for
service. Also, seeRoadside Assistance Program
on page 413for more information.
110
ProCarManuals.com
