Seat Alhambra 2012 Owner's Manual

359
Technical specifications
Weights 5 seats 7 seats
Gross vehicle weight in kg 2340 2510
Weight in running order (with driver) in kg 1174 1822
Gross front axle weight in kg 1190/1240 1200/1250
Gross rear axle weight in kg 1100/1150 1260/1310
Permitted roof load in kg 100 100
Trailer weight
Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2200
Trailer with brakes, gradients up to 12% 2200
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0

Diesel engine 2.0 TDI CR 100 kW (136 PS) Automatic
Engine specifications Power output in kW (PS) rpm 100 (136)/ 4200
Maximum torque in Nm at rpm 320/1750-2500
No. of cylinders/capacity in cm3
4/1968
Fuel Min. 51 CN a)
a)
Cetane Number (cetane index) = Measure of the combustion power of the diesel
Performance Maximum speed in km/h 189
Acceleration from 0-80 km/h in sec. 7,8
Acceleration from 0-100 km/h in sec. 11,1 
Safety FirstOperating instructionsPractical tipsTechnical Specifications

360Technical specifications
Consumption (litres/100 km)/ CO 2 (g/km)
Urban cycle 6,9/182
Extra-urban cycle 5/132
Combined 5,7/149
Weights
5 seats 7 seats
Gross vehicle weight in kg 2370 2540
Weight in running order (with driver) in kg 1803 1851
Gross front axle weight in kg 1220/1270 1230/1280
Gross rear axle weight in kg 1100/1150 1260/1310
Permitted roof load in kg 100 100
Trailer weight
Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2200
Trailer with brakes, gradients up to 12% 2200
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0

Diesel engine 2.0 TDI CR 103 kW (140 PS)
Engine specifications Power output in kW (PS) rpm 103 (140)/ 4200
Maximum torque in Nm at rpm 320/1750-2500
No. of cylinders/capacity in cm3
4/1968
Fuel Min. 51 CN a)
a)
Cetane Number (cetane index) = Measure of the combustion power of the diesel 

361
Technical specifications
Performance Maximum speed in km/h 194
Acceleration from 0-80 km/h in sec. 7,7
Acceleration from 0-100 km/h in sec. 10,9
Consumption (litres/100 km)/ CO
2 (g/km)
5 seats 7 seats
Urban cycle 6,8/179 6,9/182
Extra-urban cycle 4,8/127 4,9/130
Combined 5,5/143 5,6/146
Weights
5 seats 7 seats
Gross vehicle weight in kg 2340 2510
Weight in running order (with driver) in kg 1174 1822
Gross front axle weight in kg 1190/1240 1200/1250
Gross rear axle weight in kg 1100/1150 1260/1310
Permitted roof load in kg 100 100
Trailer weight
Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2200
Trailer with brakes, gradients up to 12% 2200
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0

Safety FirstOperating instructionsPractical tipsTechnical Specifications

362Technical specifications
Diesel engine 2.0 TDI CR 103 kW (140 PS) Automatic
Engine specifications
Power output in kW (PS) rpm 103 (140)/ 4200
Maximum torque in Nm at rpm 320/1750-2500
No. of cylinders/capacity in cm3
4/1968
Fuel Min. 51 CN a)
a)
Cetane Number (cetane index) = Measure of the combustion power of the diesel
Performance Maximum speed in km/h 191
Acceleration from 0-80 km/h in sec. 7,7
Acceleration from 0-100 km/h in sec. 10,9
Consumption (litres/100 km)/ CO
2 (g/km)
Urban cycle 6,9/182
Extra-urban cycle 5/132
Combined 5,7/149
Weights
5 seats 7 seats
Gross vehicle weight in kg 2370 2540
Weight in running order (with driver) in kg 1803 1851
Gross front axle weight in kg 1220/1270 1230/1280
Gross rear axle weight in kg 1100/1150 1260/1310
Permitted roof load in kg 100 100

363
Technical specifications
Trailer weight Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2200
Trailer with brakes, gradients up to 12% 2200
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0

Diesel engine 2.0 TDI CR 103 kW (140 PS) All-wheel drive
Engine specifications Power output in kW (PS) rpm 103 (140)/ 4200
Maximum torque in Nm at rpm 320/1750-2500
No. of cylinders/capacity in cm3
4,6/1984
Fuel Min. 51 CN a)
a)
Cetane Number (cetane index) = Measure of the combustion power of the diesel
Performance Maximum speed in km/h 191
Acceleration from 0-80 km/h in sec.
Acceleration from 0-100 km/h in sec. 11,4
Consumption (litres/100 km)/ CO
2 (g/km)
5 seats 7 seats
Urban cycle 7,4/195 7,5/197
Extra-urban cycle 5,2/137 5,4/143
Combined 6,0/158 6,2/162
Safety FirstOperating instructionsPractical tipsTechnical Specifications

364Technical specifications
Weights 5 seats 7 seats
Gross vehicle weight in kg 2530 2550
Weight in running order (with driver) in kg 1891 1945
Gross front axle weight in kg 1250/1300 1240/1290
Gross rear axle weight in kg 1230/1280 1290/1340
Permitted roof load in kg 100 100
Trailer weight
Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2400
Trailer with brakes, gradients up to 12% 2400
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0

Diesel engine 2.0 TDI CR 125 kW (170 PS)
Engine specifications Power output in kW (PS) rpm 125 (170)/ 4200
Maximum torque in Nm at rpm 350/1750-2500
No. of cylinders/capacity in cm3
4/1968
Fuel Min. 51 CN a)
a)
Cetane Number (cetane index) = Measure of the diesel combustion power.
Performance Maximum speed in km/h 210
Acceleration from 0-80 km/h in sec. 6,7
Acceleration from 0-100 km/h in sec. 9,5 

365
Technical specifications
Consumption (litres/100 km)/ CO 2 (g/km)
Urban cycle 7,3/192
Extra-urban cycle 5,0/132
Combined 5,8/152
Weights
5 seats 7 seats
Gross vehicle weight in kg 2360 2530
Weight in running order (with driver) in kg 1794 1842
Gross front axle weight in kg 1210/1260 1220/1270
Gross rear axle weight in kg 1100/1150 1260/1310
Permitted roof load in kg 100 100
Trailer weight
Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2200
Trailer with brakes, gradients up to 12% 2200
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0

Diesel engine 2.0 TDI CR 125 kW (170 PS) Automatic
Engine specifications Power output in kW (PS) rpm 125 (170)/ 4200
Maximum torque in Nm at rpm 350/1750-2500
No. of cylinders/capacity in cm3
4/1968
Fuel Min. 51 CN a)
a)
Cetane Number (cetane index) = Measure of the combustion power of the diesel 
Safety FirstOperating instructionsPractical tipsTechnical Specifications

366Technical specifications
Performance Maximum speed in km/h 204
Acceleration from 0-80 km/h in sec. 6,6
Acceleration from 0-100 km/h in sec. 9,8
Consumption (litres/100 km)/ CO
2 (g/km)
Urban cycle 6,7/177
Extra-urban cycle 5,4/143
Combined 5,9/154
Weights
5 seats 7 seats
Gross vehicle weight in kg 2370 2550
Weight in running order (with driver) in kg 1803 1851
Gross front axle weight in kg 1220/1270 1230/1280
Gross rear axle weight in kg 1100/1150 1260/1310
Permitted roof load in kg 100 100
Trailer weight
Trailer without brakes 750
Trailer with brakes, gradients up to 8% 2200
Trailer with brakes, gradients up to 12% 2200
Engine oil capacity
Approximate engine oil capacity with oil filter change 4,0


367
Technical specifications
Dimensions and capacities
DimensionsLength, width 4854 mm1904 mmHeight at kerb weight 1720 mmFront and rear projection Wheelbase 2919 mmTurning circle
Track width a)FrontRear1557 – 1569 mm1605 – 1617 mmCapacitiesFuel tank 70 litres. Reserve 8 litres.Windscreen washer fluid container with headlight washer 3.5 l/ 6 lTyre pressureSummer-grade tyres:The correct tyre pressure can be seen on the sticker on the inside of the tank flap.Winter tyres:The pressure of these tyres is the same as the summer tyre pressure plus 0.2 bar.a)
This data will change depending on the type of wheel rim.
CAUTION
● Special care should be taken when parking in areas with high kerbs or
fixed barriers. Objects protruding from the ground may damage the bumper
or other parts of the vehicle during manoeuvres.
● Special attention is required when driving through entrances, over
ramps, kerbs or other objects. The vehicle underbody, bumpers, mudguards
and running gear, and the engine and exhaust system could be damaged as
you drive over these objects. 
