ForewordThis owner's manual and the corresponding supplements should be read carefully to familiarise yourself quickly
with your vehicle.
Also, the regular care and maintenance and correct handling of the vehicle will contribute to the conservation of
its value.
For safety reasons, note the information concerning accessories, modifications and parts exchange.
If se lling the vehicle, give all of the onboard documentation to the new owner be cause this belongs with the
vehicle.
