SUBARU FORESTER 2007 SG / 2.G Owners Manual

6
Interior equipment
Interior lights ...................................................... 6-2Dome light ............................................................... 6-2
Cargo area light ..................................................... 6-2
Map lights ........................................................... 6-3
Sun visors ........................................................... 6-3 Vanity mirror ........................................................... 6-3
Storage compartments ...................................... 6-4 Glove box ................................................................ 6-4
Center console ........................................................ 6-4
Overhead console .................................................. 6-6
Dashboard storage compartment ......................... 6-6
Convenience net ..................................................... 6-6
Pocket (if equipped) ............................................... 6-7
Cup holders ........................................................ 6-7 Front passenger’s cup holder ............................... 6-8
Rear passenger’s cup holder ................................ 6-8
Accessory power outlets ................................... 6-8 Use with a cigarette lighter (Canada only, if equipped) .................................. 6-10
Ashtray (Canada only, if equipped) .................. 6-11
Floor mat ............................................................. 6-12
Coat hook ............................................................ 6-12
Cargo area cover (if equipped) ......................... 6-13 Using the cover ....................................................... 6-13
To remove the cover housing ................................ 6-13
Stowage of the cover ............................................. 6-13
To install the cover housing .................................. 6-13
Shopping bag hook ............................................ 6-14 Cargo tie-down hooks ........................................ 6-14
Cargo area bars .................................................. 6-14
Under-floor storage compartment .................... 6-15

6-2 Interior equipment
Inte rior eq uip me ntInterior lights
When leaving your vehicle, make sure the
light goes out to avoid battery discharge. „Dome light
The dome light switch has three positions:
ON: The light stays on continuously.
DOOR (middle position): The dome light
comes on when any of the doors or the
rear gate is opened. The light remains on
for several seconds and gradually goes
out after all doors and the rear gate are
closed.
NOTE
If a door or the rear gate is left open,
the light flashes and a chime sounds about 30 minutes later and then the
light is turned off automatically.
The light also can be turned on by use of
the keyless entry transmitter. See the “Re-
mote keyless entry system” section in
chapter 2 for detailed information.
OFF:
The light stays off.
„ Cargo area light
The cargo area light switch has three po-
sitions:
ON: The light stays on continuously.
OFF: The light stays off.
DOOR: The light comes on only when the
rear gate is opened.
NOTE
If a door or the rear gate is left open,
the light flashes and a chime sounds
about 30 minutes later and then the
light is turned off automatically.
The light also can be turned on by use of
the keyless entry transmitter. See the “Re-
mote keyless entry system” section in
chapter 2 for detailed information.
ON
DOOR OFF
600078
ON
OFF
DOOR
600079

Interior equipment 6-3
Map lights
To turn on the map light, push the switch.
To turn it off, push the switch again.
When leaving the vehicle, make sure the
light is turned off to avoid battery dis-
charge.Sun visors
To block out glare, swing down the visors.
To use the sun visor at a side window,
swing it down and move it sideways.„
Vanity mirror
To use the vanity mirror, swing down the
sun visor and open the vanity mirror cov- er.
600080600081
600082

6-4 Interior equipment
Storage compartments
„Glove box
1) Lock
2) Unlock
To open the glove box, pull the handle. To close it, push the lid firmly upward.
To lock the glove box, insert the key and
turn it clockwise.
„ Center console
The center console box provides a stor-
age space. In addition, the top of the con-
sole can be used as an armrest and as a
rear passenger’s cup holder.
To use as armrest:
1. Tip the console top forward from its
vertical position. 2. Push the armrest part of the console
top forward to the desired position while
pulling up the knob at the front end of the
armrest and lock it in position by releasing
the knob. Adjust the position of the arm-
rest to suit your driving position. Make
sure the armrest is securely retained.
When you slide the armrest back to its
original position, pull the knob upward as
you do so.
To return the console top to the vertical
position, pull upward the knob at the front
end of the armrest while raising the con-
sole top until it emits a click.
y
Always keep the storage compart-
ment closed while driving to re-
duce the risk of injury in the event
of sudden stops or an accident.
y Do not store spray cans, contain-
ers with flammable or corrosive
liquids or any other dangerous
items in the storage compartment.
1 2
600471
600519
600473

Interior equipment 6-5
– CONTINUED –
To use as rear passenger’s cup holder:
With the console top tipped toward the
rear seat, it can be used as a cup holder.
To use as storage space:
Raise the console top to the vertical posi-
tion or tip it toward the rear seat. Then, pull
up the lock button of the console box and
open the lid.
When closed, the lid can be used as a tray
for placing small items in it.
Do not step or sit on the armrest,
and do not place heavy objects on it.
The armrest could break, and you
could get hurt.
600520y
To switch from using the console
top as an armrest to using it as a
rear passenger’s cup holder, raise
the console top to the vertical po-
sition before tipping it toward the
rear seat. Otherwise the console
top may break.
y Do not place any object weighing
more than 4.4 lbs (2 kg) on the ta- ble.
y Do not have hot drinks or other
objects on the table while driving.
During hard braking or negotia-
tion of a curve, they could fall
from the table and cause a burn or
other injury.
yBefore opening the lid of the con-
sole box, raise the console top
completely to the vertical position
or tip it toward the rear seat. Oth-
erwise, the lid may be damaged
and an injury may occur.
600475

6-6 Interior equipment
„Overhead console
To open the console, push on the console
lid lightly and the lid will automatically
open.
„ Dashboard storage compart-
ment
To open the dashboard compartment,
push the button on the lid and the lid will
automatically open. Be sure to close the
compartment fully before driving.„ Convenience net
A net for storing small articles is provided
at the front passenger’s foot-well.
y
Be careful not to trap your hands
between the console top and con-
sole box when raising and tipping
the console top.
y When there is an object on the
console box lid, do not tip the con-
sole top forward. Otherwise, the
console top or lid could be dam-
aged, and an injury could occur.
600085
When your vehicle is in the sun or
on a warm day, the inside of the
overhead console heats up. Avoid
storing plastic or other heat-vulner-
able or flammable articles such as a
lighter in the overhead console.
600086
When your vehicle is in the sun or
on a warm day, the inside of the
overhead console heats up. Avoid
storing plastic or other heat-vulner-
able or flammable articles such as a
lighter in the overhead console.
600087

Interior equipment 6-7
– CONTINUED –
„
Pocket (if equipped)
To use the pocket, push lightly on the lid
below the climate controls.
Cup holdersTIn front door trim
The door pockets can be used to hold
beverage bottles and other items.
Do not use the pocket as an ashtray
or leave a lighted cigarette in the
pocket. This could cause a fire.
600561
y When not in use, always keep the
cup holder stored while driving to
reduce the risk of injury in the
event of a sudden stop or an acci-
dent.
y Do not pick up a cup from the cup
holder or put a cup in the holder
while you are driving, as this may
distract you and lead to an acci-
dent.
y Take care to avoid spills. Beverag-
es, if hot, might burn you or your
passengers. Spilled beverages
may also damage upholstery or
carpets.
When placing a beverage in a door
pocket, make sure it is capped. Oth-
erwise, the beverage could spill
when opening/closing the door or
while driving and, if the beverage is
hot, it could scald you.
600608

6-8 Interior equipment
„Front passenger’s cup holder
A dual cup holder is built in the center con-
sole, beside the parking brake lever. „ Rear passenger’s cup holder
There are rear passenger’s cup holders at
the back of the center console as well as
on the reverse side of the console top.
To use the rear passenger’s cup holder lo-
cated at the back of the center console,
open the lid by pulling its upper edge. To use the rear passenger’s cup holder lo-
cated on the reverse side of the console
top, refer to “Center console” in the “Stor-
age compartments” part of this chapter for
details.Accessory power outlets
Power outlet beside front pocket
Power outlet in center console
600476
600092
600559
600477

Interior equipment 6-9
– CONTINUED –
Power outlet in cargo area
Accessory power outlets are provided be-
side the front pocket, in the center console
and in the cargo area. Electrical power
(12V DC) from the battery is available at
any of the outlets when the ignition switch
is in either the “ACC” or “ON” position.
You can use an in-car electrical appliance
by connecting it to an outlet.
The maximum power rating of an appli-
ance that can be connected varies among
outlets as shown in the following. Do not
use an appliance which exceeds the indi-
cated wattage for each outlet.
Outlet beside front pocket: 80W or less
Outlets in center console and cargo area:
120W or less
When using appliances connected to two or more outlets simultaneously, the total
power consumed by them must not ex-
ceed 120W.
600094
y
Do not attempt to use a cigarette
lighter in the center console and
cargo area power outlets.
y Do not place any foreign objects,
especially metal ones such as
coins or aluminum foil, into the
accessory power outlet. That
could cause a short circuit. Al-
ways put the cap on the accesso-
ry power outlet when it is not in
use.
y Use only electrical appliances
which are designed for 12V DC.
The maximum power rating of an
appliance that can be connected
varies among outlets as shown in
the following. Do not use an appli-
ance which exceeds the indicated
wattage for each outlet.
Outlet beside front pocket: 80W or
less
Outlets in center console and car-
go area: 120W or less
When using appliances connect-
ed to two or more outlets simulta-
neously, the total power con-
sumed by them must not exceed
120W. Overloading the accessory
power outlet can cause a short
circuit. Do not use double adapt-
ers or more than one electrical ap-
pliance.
y If the plug on your electric appli-
ance is either too loose or too
tight for the accessory power out-
let, this can result in a poor con-
tact or cause the plug to get stuck.
Only use plugs that fit properly.
y Use of an electric appliance in the
accessory power outlet for a long
period of time while the engine is
not running can cause battery dis-
charge.
y Before driving your vehicle, make
sure that the plug and the cord on
your electrical appliance will not
interfere with your shifting gears
and operating the accelerator and
brake pedals. If they do, do not
use the electrical appliance while
driving.

6-10 Interior equipment
NOTE
When the lid of the center console is
closed, an opening remains between
the center console and the lid to allow
the power outlet in the center console
to be used. Pass the electrical appli-
ance’s cord through this opening. „
Use with a cigarette lighter
(Canada only, if equipped)
To use the accessory power outlet beside
the front pocket as a cigarette lighter sock-
et, purchase the cigarette lighter plug,
which is an optional accessory.
A cigarette lighter plug is available from
your SUBARU dealer.
The cigarette lighter operates only when
the ignition switch is in the “ON” and
“ACC” positions.
To use the cigarette lighter, push in the
knob and wait a few moments. It will auto-
matically spring up when ready for use.
600478
600095
To avoid being burned, never grasp
the lighter by the end with the heat-
ing element. Doing so could result
in injury and could also damage the
heating element. y Do not hold the lighter pushed in,
because it will overheat.
y The electrical power socket locat-
ed on the lower part of the instru-
ment panel is originally designed
to use a genuine SUBARU ciga-
rette lighter plug. Do not use non-
genuine cigarette lighter plugs in
the socket. Doing so may cause a
short-circuit and overheating, re-
sulting in a fire.
