76G-74E
Cleaning the Exterior
It is important that your vehicle be
kept clean and free from dirt. Failure
to keep your vehicle clean may result
in fading of the paint or corrosion to
various parts of the vehicle body.
Washing
Never attempt to wash and wax your
vehicle with the engine running.
When cleaning the underside of the
body and fender, where there may
be sharp-edged parts, you should
wear gloves and a longsleeved shirt
to protect your hands and arms
from being cut.
After washing your vehicle, carefully
test the brakes before driving to
make sure they have maintained
their normal effectiveness.When washing the vehicle, follow the
instructions below:
1) Flush the underside of body and wheel
housings with pressurized water to
remove mud and debris. Use plenty of
water.
When washing the vehicle, avoid
directing steam or hot water of more
than 80
0C (176
0F) on plastic parts.
2) Remove dirt and mud from the body
exterior with running water. You may use
a soft sponge or brush. Do not use hard
materials which can scratch the paint.
3) Wash the entire exterior with a mild
detergent or car wash soap using a
sponge or soft cloth. The sponge or
cloth should be frequently soaked in the
soap solution.
When using a commercial car wash
product, observe the cautions
specified by the manufacturer. Never
use strong household detergents or
soaps.
BODY WORK CARE11-3
w ww w
w WARNING
CAUTION
4) Once the dirt has been completely
removed, rinse off the detergent with
running water.
5) After rinsing, wipe off the vehicle body
with a wet chamois or cloth and allow
it to dry in the shade.
6) Check carefully for damage to painted
surfaces. If there is any damage,
“Touchup” the damage following the
procedure below:
a) Clean all damaged spots and allow
them to dry.
b) Stir the paint and “touchup” the
damaged spots lightly using a small
brush.
c) Allow the paint to dry completely.
Waxing
After washing the vehicle, waxing and
polishing are recommended to further
protect and beautify the paint.
Only use waxes and polishes of good
quality.
When using waxes and polishes,
observe the precautions specified by the
manufacturers.
CAUTION
CAUTION
Page 132 of 139
Downloaded from www.Manualslib.com manuals search engine 13376G-74E
GENERAL INFORMATION
12
GENERAL INFORMATION
Vehicle Identification.......................................................................................12-1
Page 133 of 139
Downloaded from www.Manualslib.com manuals search engine 134
76G-74E
GENERAL INFORMATION12-1
76G-12-001 76G-12-002
Chassis Serial Number
The chassis and/or engine serial numbers
are used to register the vehicle. They are
also used to assist your dealer when
ordering or referring to special service
information. Whenever you have occasion to
consult your MARUTI SUZUKI dealer,
remember to identify your vehicle with this
number. Should you find the number difficult
to read, you will also find it on the
identification plate in the engine
compartment.VEHICLE IDENTIFICATION
Engine Serial Number
The engine serial number is stamped on the
cylinder block as shown in the illustration
and also on the identification plate.
Page 134 of 139
Downloaded from www.Manualslib.com manuals search engine 13576G-74E
SPECIFICATIONS
13
SPECIFICATIONSNOTE:
Specifications are subject to change without notice.
ITEM: DIMENSIONS UNIT:mm
ALTO (STD / Lx / Lxi) ALTO K10 (Lxi / Vxi)
Overall length 3495 3620
Overall width 1475 1495/1475 (without side moulding)
Overall height 1460 1460
Wheelbase 2360 2360
Tread front 1295 1295
rear 1290 1290
Ground clearance 160 160
ITEM: MASS (WEIGHT) UNIT:Kg
ALTO (STD / Lx / Lxi) ALTO K10 (Lxi / Vxi)
Kerb mass (weight) 690-705 750-765
Gross vehicle mass (weight) rating 1140 1185
Seating Capacity 5 persons 5 persons
ITEM: ENGINE
ALTO (STD / Lx / Lxi) ALTO K10 (Lxi / Vxi)
Type F8D K10B
Number of cylinders 3 3
Bore 68.5 73
Stroke 72.0 79.5
Piston displacement 796 cc 998 cc
Compression ratio 9.2 ± 0.2 : 1 10.0 ± 0.4 : 1
13-1
Page 135 of 139
Downloaded from www.Manualslib.com manuals search engine 136
76G-74E
ITEM: ELECTRICAL
ALTO (STD / Lx / Lxi) ALTO K10 (Lxi / Vxi)
Standard spark plug NGK-DCPR7E, BOSCH-YR7DC NGK KR6A-10
Battery 34B20L (27AH/5HR) 38B20L (28AH/5HR)
Fuses See “INSPECTION AND MAINTENANCE” section
Headlight12V 55/60W
Turn signal light 12V 21W
Side turn signal light 12V 5W
Clearance light12V 5W
Tail/brake light 12V 21/5W
Registration plate light 12V 5W
Reversing light12V 21W
High Mount Stop Lamp 12V W16W
ITEM: WHEEL AND SUSPENSION
ALTO (STD / Lx / Lxi) ALTO K10 (Lxi / Vxi)
Tyre size, front and rear 145/80R12 155/65R13
Tyre pressures front/rear 2.1 kg/cm
2
2.2 kg/cm
2
Suspension type front Mac Pherson Strut
rear 3-link-rigid axle suspension
ITEM: STEERING
Toe-in front 0 ± 1 mm
ITEM: CAPACITIES
ALTO (STD / Lx / Lxi) ALTO K10 (Lxi / Vxi)
Coolant (Including reservoir tank) 3.5 Ltrs 4.3 Ltrs
Fuel tank 35.0 Ltrs 35.0 Ltrs
Engine oil (with oil filter) 2.7 Ltrs 2.9 Ltrs
Transmission oil 2.2 Ltrs 2.2 LtrsSPECIFICATIONS13-2
