SUZUKI ALTO 2014 User Guide

1159K,76G,844-74E
Annexure-A
List of parts covered under Emission Warranty
1. Fuel injection Assembly, Pressure Regulator, Throttle Body Assembly.
2. Electronic Control Module (ECM).
3. Intake Manifold.
4. EGR valve.
5. Distributor and internal parts.
6. Ignitions coil.
7. Canister Assembly.
8. Vapour Liquid Separator.
9. Fuel Tank and Filler Cap.
10. PCV (Positive Crankcase Ventilation) Valve.
11. Oil Filler Cap.
12. Catalytic Convertor.
13. Exhaust manifold.
14. All fuel injection System related SENSORS.
15. Maniverter
EMISSION WARRANTY2-5

1376G-74E
3
BEFORE DRIVING
BEFORE DRIVING
Fuel Recommendation........................................................................\
............... 3-1
Immobilizer System ........................................................................\
.................... 3-2
Door Locks ........................................................................\
.................................. 3-4
Windows ........................................................................\
....................................... 3-6
Mirrors ........................................................................\
........................................... 3-8
Front Seat Adjustment ........................................................................\
.............. 3-9
Adjusting Seat Position ........................................................................\
............ 3-9
Adjusting Seatbacks ........................................................................\
................ 3-10
Seat Belts ........................................................................\
.................................. 3-11
Lap Belt (if equipped) ........................................................................\
............. 3-15

14
76G-74E
3-1BEFORE DRIVING
FUEL RECOMMENDATIONYou must use unleaded petrol with an
octane number (RON) of 91 or higher.Use of leaded fuel in vehicle equipped
with catalytic converter is prohibited,
because lead deactivates the pollutant
reducing components of catalytic
converter and may result in permanent
damage to catalytic converter. Be careful not to spill fuel containing
alcohol while refuelling. If fuel is
spilled on the vehicle body, wipe it up
immediately. Fuels containing alcohol
can cause paint damage, which is not
covered under New Vehicle Limited
Warranty.
The fuel tank has an air space to
allow for fuel expansion in hot
weather. If you continue to add fuel
after the filler nozzle has automatically
shut off or an initial blowback occurs,
the air chamber will become full.
Exposure to heat when fully fuelled in
this manner will result in leakage due
to fuel expansion. To prevent such
fuel leakage, stop filling after the filler
nozzle has automatically shut off, or
when using an alternative non
automatic system, initial vent
blowback occurs.
Petrol/Ethanol Blends
Blends of unleaded petrol and ethanol (grain
alcohol), also known as gasohol, are
commercially available in some areas.
Blends of this type may be used in your
vehicle if they are no more than 5% ethanol.
Make sure this petrol-ethanol blend has
octane ratings no lower than those
recommended for petrol.
Petrol/Methanol Blends
Blends of unleaded petrol and methanol
(wood alcohol) are also commercially
available in some areas. DO NOT USE
fuels containing more than 5% methanol
under any circumstances. Fuel system
damage or vehicle performance problems
resulting from the use of such fuels are not
the responsibility of MARUTI SUZUKI and
may not be covered under Warranty.
Fuels containing 5% or less methanol may
be suitable for use in your vehicle if they
contain cosolvents and corrosion inhibitors.
NOTE:
If you are not satisfied with the driveabilityor fuel economy of your vehicle when youare using a petrol/alcohol blend, you should
switch back to unleaded petrol containing noalcohol.
CAUTION
CAUTIONCAUTION

1576G-74EYour vehicle comes with a pair of identical
keys. Keep the spare key in a safe place.
One key can open all of the locks on the
vehicle.
The key identification number is stamped on
a metal tag provided with the keys. Keep
the tag in a safe place. If you lose your
keys, you will need this number to have
new keys made. Write the number down
and keep it in a safe accessible place away
from the vehicle.
BEFORE DRIVING
3-2
ww ww
w WARNING
• Do not use locally made key.
Should you require a duplicate key,
place your order with a MARUTI
SUZUKI dealer only.Note:
Keep the spare key very carefully. When itis lost, consult your dealer by quoting keynumber.
Immobilizer System
This system is designed to help prevent
vehicle theft by electronically disabling the
engine starting system.
The engine can be started only with your
vehicle’s original immobilizer ignition key
which has an electronic identification code
programmed into it. The key communicates
the identification code to the vehicle when
the key is turned to the “ON” position. If
you need to make spare keys, contact your
MARUTI SUZUKI dealer. The vehicle must
be programmed with the correct identifica-
tion code for the spare keys. A key made
by an ordinary locksmith will not work.
Key Number :
IMMOBILIZER KEYS
76G-03-002

16
76G-74E
3-3
CAUTION
In case of attaching any metal objects
to the immobilizer key, it may not
start the engine.
The immobilizer key is a sensitive
electronic instrument. To avoid
damaging the immobilizer key:
Do not expose it to impacts,moisture or high temperature such
as by leaving it on the dashboard
under direct sunlight.
Keep the immobilizer key away from
magnetic objects.
If the Immobilizer system light (1) blinks
when the ignition switch is in the “ON”
position, there may be something wrong
with your key or with the immobilizer sys-
tem. Contact your MARUTI SUZUKI dealer
to inspect the system.
Ignition Key Reminder (if equipped)
A buzzer sounds intermittently to remind
you to remove the ignition key if it is in the
ignition switch when the driver's doors is
opened.
BEFORE DRIVING
NOTE: If you lose your Immobilizer ignition key,
contact your MARUTI SUZUKI dealer assoon as possible to have the lost onedeactivated, then have the new key
made by them.
If you own other vehicles with immobilizer keys, keep those keys awayfrom the ignition switch when using your
vehicle, or the engine may not bestarted because they may interfere withyour vehicle’s immobilizer system.
76G-03-003 76G-03-004

1776G-74E
BEFORE DRIVING
3-4
Central door locking system (if equipped)
You can lock and unlock all doors simultan-
eously by using the key in the driver’s door
lock.
To lock all doors simultaneously, insert the
key in the driver’s door lock and turn the
top of the key toward the rear of the
vehicle.
To unlock all doors simultaneously, insert
the key in a driver’s door lock and turn the
top of the key toward the front of the
vehicle.
You can also lock or unlock all the side
doors by pushing down or pulling up the
driver's door lock knob.
76G-03-007
Side Door Locks
To lock the driver's door from outside the vehicle:
a) Insert the key fully and turn the top ofthe key toward the rear of the vehicle,
or
b) Push in the lock knob down and hold the door handle up as you close the door.
To unlock the driver's door from outside the
vehicle, insert the key fully and turn the top
of the key toward the front of the vehicle.
To lock a front passenger’s door from
outside the vehicle, turn the lock knob
forward, then pull and hold the door handle
as you close the door.
To lock a rear door from outside the
vehicle, push in the lock knob down and
close the door. To lock a door from inside the vehicle, push
the lock knob down. Pull the lock knob up
to unlock the door.
ww ww
w WARNING
DOOR LOCKS
76G-03-005 76G-03-006
Always lock all doors when driving.
Locking the door prevents occupants
from being thrown from the vehicle
in the event of an accident. It also
helps prevent unintentional opening
of the doors.

18
76G-74E
NOTE: Moving the lock knob on passenger's door locks or unlocks the passenger'sdoor only.
Be sure to hold the door handle up when you close a locked front door, orthe door will not remain locked.
ww ww
w WARNING
Child-Proof Locks (if equipped)
As illustrated, a child-proof lock is provided
for both rear doors. When the lock lever is
down, position 1 , the child proof lock is
activated, and when up, in position 2 the
child-proof lock is deactivated, when the
child-proof lock is activated, the rear door
cannot be opened from the inside even if
the inside door lock is unlocked but can be
opened from the outside.
Be sure to place the child-proof lock
in the locked position whenever
children are seated in the rear.
Rearend Door Lock
To unlock the door, insert the key into the
lock knob and turn it clockwise.
76G-03-008 76G-03-009
TYPE-1 (ALTO)
EXAMPLE
3-5BEFORE DRIVING

1976G-74E
BEFORE DRIVING
3-6
ww ww
w WARNING
76G-03-009A
Always make sure that the rearend
door is closed and latched securely.
Closing the door completely helps to
prevent exhaust gases from entering
the vehicle. Completely closing the
rearend door also helps prevent
occupants from being thrown from the
vehicle in the event of an accident.TYPE-2 (ALTO K10)
WINDOWSRaise or lower the door windows by turning
the handle located on the door panel.
76G-03-011
Electric window controls (if equipped)
The driver’s door has switches 1 & 2 to
operate the driver’s window and front
passenger’s window respectively.
The passenger’s door only has a switch 3
to operate the passenger’s window. The
electric windows can only be operated when
the ignition switch is in the “ON” position.
To open a window with the driver's door
switches, push the top part of the switch
and to close the window lift up the top part
of the switch.
76G-03-012

20
76G-74E
The driver’s window has an “auto-down”
feature for added convenience (at toll
booths or drive-through restaurants, for
example). This means you can open the
window without holding the window switch
in the “Down” position. Press the driver’s
window switch completely down and release
it. To stop the window before it reaches the
bottom, lift up the switch briefly.
To open or to close a window with the
passenger's door switch, push the top part
of the switch or lift up the top part of the
switch respectively.
76G-03-013
3-7BEFORE DRIVING
The driver’s door also has a lock switch for
the passenger’s window. When you push in
the lock switch, the passenger’s window
can not be raised or lowered by operating
either of the switches 2 or 3. To restore
normal operation, push the switch again.
76G-03-014
ww ww
w WARNING
You should always push in the lock
switch when there are children in the
vehicle. Children can be seriously
injured if they get part of their body
caught by the window during
operation.
Since the electric windows consumes
a large amount of electricity, the same
should not be used excessively with
engine in “OFF” condition.
CAUTION

2176G-74E
BEFORE DRIVING
3-8
MIRRORSInside Rearview Mirror
To adjust the inside rearview mirror, move
the mirror up, down, or sideways to obtain
the best view.
76G-03-015
Outside Rearview Mirrors
Adjust the outside rearview mirrors (with the
help of control lever, if equipped), so that
you can just see the side of your vehicle
in the mirrors.Be careful when judging the size or
distance of a vehicle or other object
seen in the side convex mirror (if
equipped). Be aware that objects look
smaller and appear farther away than
when seen in a flat mirror.
ww ww
w WARNING
76G-03-017
76G-03-017A
TYPE-1 (ALTO)
TYPE-2 (ALTO K10)
